SPaT Challenge Webinar Series

Webinar #1: Initial SPaT Challenge Activities

2:00 – 3:30 PM (Eastern) | March 6, 2018

2

Webinar Logistics

• All lines are muted
• Webinar will be recorded
• Submit questions and comments in chat or

Q&A section of webinar window

• Questions will be answered at webinar

conclusion

3

Agenda

• Introduction to the SPaT Webinar Series
• Blaine Leonard, Utah DOT
• Systems Engineering Approach to the SPaT

Challenge

• Ray Starr, Minnesota DOT
• Dean Deeter, Athey Creek Consultants
• Costs, Procurement, and Corridor Selection
• Blaine Leonard, Utah DOT
• Q&A

Introduction to the SPaT Webinar Series

Blaine Leonard, Utah DOT

5

Update on V2I Deployment Coalition (V2I DC) Phase 2

• V2I DC activities have resumed
• https://transportationops.org/V2I/V2I-overview
• SPaT Challenge activities will continue under the

Strategic Initiatives Technical Working Group

Strategic Initiatives TWG

SPaT Challenge Resource Team SPaT Challenge Tactical Working Group

6

Update on V2I DC Phase 2

• Strategic Initiatives Working Group (Phase 1 TWG 1)
• Chaired by Greg Larson, Caltrans
• Meets 4th Thursday of every month at 2pm ET
• Next meeting: March 22 at 2pm ET
• Technical Resources Working Group (Phase 1 TWG 4)
• Chaired by Faisal Saleem, MCDOT
• Meets 2nd Wednesday of every month at 11am ET
• Peer Exchange & Outreach Working Group
• Chaired by Ed Seymour, TTI
• To be added to or removed from one or more groups,

visit: https://www.surveymonkey.com/r/V2IDC_TWGs

7

SPaT Challenge

What is the Challenge? To challenge state and local public sector transportation IOOs to cooperate together to achieve deployment of DSRC infrastructure with SPaT broadcasts in at least one corridor or network (approximately 20 signalized intersections) in each state by January 2020

8

SPaT Challenge

What is SPaT? A Signal Phase and Timing (SPaT) message defines the current intersection signal light phases Current state of all lanes at intersection are provided, as well as any active pre-emption or priority. SPaT message defined by SAE J2735 (a subject of a subsequent webinar)

9

SPaT Challenge

Why do this Challenge? To provide IOOs with an entry into DSRC-based V2I deployment and gain valuable procurement, licensing, installation, and operation experience, which in turn will:

• Lay ground work for more advanced V2I deployments
• Show a commitment to OEMs and applications developers
• Analogous to early fiber deployments – most benefits came later

10

SPaT Challenge

What are the benefits?

• Be more prepared for DSRC-equipped

vehicles and on-board V2I applications

• Useful as testing site for future applications
• Supports deployment of V2I applications that

build on SPaT at intersections:

• Smart Transit Signal Priority
• Red Light Violation Warning
• Intelligent Signal Systems
• Eco-Driver

11

SPaT Challenge

What is the long-term goal?

• Widespread deployment of V2I applications at

intersections will lead to:

• Improved safety for drivers and pedestrians
• Improved mobility for traveling public, transit, freight,

snow plows, and other fleet vehicles

• High penetration rates in vehicles
• Agency vehicles and OEM-produced vehicles able to

utilize and benefit from SPaT broadcasts

• We have to start small . . . And scale up!

12

SPaT Challenge Website

One-stop shop for SPaT-related information

• Overview
• Current map

with SPaT deployment details and contacts

• Resources

https://transportationops.org/spatchallenge

13

SPaT Challenge Website

+ New ConOps Document + Webinar Schedule and Recordings

14

Upcoming SPaT Challenge Webinars

• Design Considerations, Part 1
• March 20, 2018 2:00-3:30pm ET
• Signal controller interface and creation of SPaT messages
• Examples of designs for assembling SPaT messages
• DSRC licensing
• Design Considerations, Part 2
• April 17, 2018 2:00-3:30pm ET
• MAP messages and vehicle position correction
• MAP Creator Tool Demonstration
• April 24, 2018 1:00-2:30pm ET
• Live technical demonstration and step-by-step training on using the MAP creator tool
• Design Considerations, Part 3
• May 15, 2018 2:00-3:30pm ET
• Backhaul infrastructure, intersection, and roadside equipment specification, design and

installation

• Deployment & Validation
• June 12, 2018 2:00-3:30pm ET
• Procurement, validation, verification, and security of SPaT deployments

Systems Engineering Approach to the SPaT Challenge

Ray Starr, Minnesota DOT

16

Why a Systems Engineering Approach?

• Federal funding requires it
• System that meets user needs
• Needs are not missed
• Common understanding of intent
• Basis for testing
• Stakeholder roles
• Especially valuable for implementing non-

routine systems

17

Systems Engineering “Vee” Diagram

Source: FHWA https://www.fhwa.dot.gov/cadiv/segb/

18

Concept of Operations (ConOps)

Source: FHWA https://www.fhwa.dot.gov/cadiv/segb/

19

• Scope/Background
• System overview (Context Diagram)
• Operational needs
• Concept(s) (apps & functions)
• User oriented operational descriptions
• Operational scenarios

Concept of Operations (ConOps)

20

System Requirements

Source: FHWA https://www.fhwa.dot.gov/cadiv/segb/

21

• Itemized requirements
• Verification method
• Demonstration, test, analysis, inspection
• References for requirement
• Traceability to needs

System Requirements

22

Minnesota’s SPaT Deployment

Planning Phase Scope of Work

• ConOps
• System requirements
• Data governance plan & tech support
• System security plan
• Project deployment plan
• Design support
• Construction inspection support

23

Minnesota’s ConOps (First Draft)

24

Minnesota’s ConOps (First Draft)

Challenge Need ID Need Roadway User Needs General Equipped Vehicle Operator/Self‐Equipped Driver Needs In‐Vehicle equipment running applications need intersection data to support those applications UN‐CC‐1.01‐ v01 Signal Phase and Timing. A General Equipped Vehicle Operator Driver/Self‐Equipped Driver needs advance notice

• f signal phase and timing changes to safely approach an

intersection Drivers may be unaware that they are approaching a short term mobile work zone or snow plow actively engaging in

• perations

UN‐CC‐1.02‐ v01 Dynamic Roadway Maintenance Activity Awareness. A General Equipped Vehicle Operator Driver/Self‐Equipped Driver needs to be aware of dynamic maintenance activities (e.g. snow plowing, pothole filling) in/along the path of travel General Vehicle Operator is not aware of pedestrian in crosswalk due to a‐pillar

• cclusion

UN‐CC‐1.03‐ v01 Pedestrian in Crosswalk Awareness. A General Equipped Vehicle Operator Driver/Self‐Equipped Driver needs increased awareness of a pedestrian in a crosswalk when making a movement at a signalized intersection due to

• cclusion by the vehicle a‐pillar to reduce the likelihood of a

pedestrian crash

25

Minnesota’s ConOps (First Draft)

User Class Use Cases SPaT Vehicle‐ Pedestrian Intersection Conflict Warning Snow Plow Signal Priority CV Data Mgmt Third‐Party Traffic Signal Data Sharing Mobile Work Zone Warning System General Equipped Vehicle Operator X X X Self‐Equipped Driver X* X* X* X Unequipped Driver X Snow Plow Operator X X Pedestrian X Traveler Information Provider X Work Zone Worker X Traffic Manager X X X X

26

Scenario Diagram Key Actions and Flow of Events

Source Step Key Action Comments General 1 Traffic Signal turns green (permitted) for the vehicle and for

• pposing traffic

Solid green bulb (no left turn arrow) indicates a permitted left turn Pedestria n 2 Simultaneously receives a walk signal and begins to cross the crosswalk to the left of the vehicle Crosswalk is in the intended path

• f the vehicle

CC System 3 Issues notification to general equipped vehicle operator that there is a pedestrian in the crosswalk. As the system properly detects a potential conflict between the vehicle and the pedestrian General Equipped Vehicle Operator 4 Advances into the intersection and stops, waiting for opposing traffic to clear General 5 Opposing traffic clears the intersection Pedestria n 6 Continues to cross and remains in the crosswalk CC System 7 Continues to issue notification to general vehicle operator that there is a pedestrian in the crosswalk. See Step 3 comment

Minnesota’s ConOps (First Draft)

Use Case Vehicle‐Pedestrian Intersection Conflict Warning Scenari

• ID and

Title UC2‐S1: Normal Operating Conditions – Pedestrian in Signalized Crosswalk Scenari

• Objectiv

e  Improve awareness of pedestrians to general equipped vehicle operators  Notify and warn general equipped vehicle

• perators when their path of travel is across a

crosswalk with a pedestrian in it Operati

• nal

Event(s)  The system properly determines there is a pedestrian in the vehicle’s path  The system properly notifies the General Equipped Vehicle Operator of a pedestrian in the path of the vehicle User(s) User Role Pedestrian Safely traverse the crosswalk at the intersection General Equipped Vehicle Operator Safely navigate through the intersection Initial Conditio ns  A vehicle is waiting to make a permitted (not protected) left turn at a red light  Opposing traffic is queued at the same signalized intersection  A pedestrian is waiting to cross the opposing crosswalk, but is traveling against the flow of

• pposing traffic

 The pedestrian has performed all required actions (e.g. pressing the pedestrian crossing push button) to receive a walk signal during the next cycle  Note: This scenario is generally applicable to any pedestrian movement and general equipped vehicle movement such that the path of the vehicle crosses the path of the pedestrian when the pedestrian has the right‐of‐way. Post‐ Conditi

• ns

 The pedestrian safely crosses the intersection in the crosswalk  The general equipped vehicle operator completes the left turn without compromising the safety of the pedestrian Traceab ility UN‐CC‐1.03‐v01 Pedestrian in Crosswalk Awareness UN‐CC‐4.01‐v01 Pedestrian in Crosswalk Safety CC System Inputs  Detection (of Pedestrian)  Map Input (from Traffic Manager)  Position Correction Data (from NTRIP Caster)  Raw Traffic Signal Data (from Traffic Signal Controller)  General Equipped Vehicle Location/Motion (from GNSS) CC System Outputs  Pedestrian in Crosswalk Notification (to General Equipped Vehicle Operator)  Pedestrian in Crosswalk Warning (to General Equipped Vehicle Operator)

27

Systems Engineering “Vee” Diagram

Source: FHWA https://www.fhwa.dot.gov/cadiv/segb/

SPaT Challenge Model ConOps & Requirements

Dean Deeter, Athey Creek Consultants

29

SPaT Challenge Model ConOps & Requirements Overview

Four Things I’d Like to Accomplish Today

• 1. Introduce the Model ConOps &

Requirements Documents

• 2. Define the term “SPaT Infrastructure

System”

• 3. Describe the Approach to the Documents
• 4. Share a Few Examples of Details

30

Introduction to the Model Documents

• SPaT Challenge Model Concept of Operations and

Functional Requirements

• Two stand-alone but related documents
• Available online:

https://transportationops.org/spatchallenge/resources

• Developed to help agencies plan a SPaT

infrastructure deployment

• Written for transportation agencies to adapt to

various local site conditions, individual practices, and to address specific needs

• Represents initial “model” concepts
• These are “working drafts” to serve as resources to
• you. Not prescriptive in any way

31

Driver

Pedestrians

Defining “SPaT Infrastructure System”

Users who will Benefit From SPaT Data Traffic Signal Systems Sources of SPaT Data

32

Driver

Pedestrians

SPaT Enabled V2I Connected Vehicle Systems

Users who will Benefit From SPaT Data Traffic Signal Systems Sources of SPaT Data

SPaT Enabled Connected Vehicle Systems

33

SPAT Infrastructure System

(the Focus of the ConOps Document) Driver

Pedestrians

Defining “SPaT Infrastructure System”

Users who will Benefit From SPaT Data New infrastructure to securely communicate SPaT, MAP, and supporing data to Vehicles and Pedestrian devices. May also receive data from vehicles and pedestrian devices. Traffic Signal Systems Sources of SPaT Data

34

SPAT Infrastructure System

(the Focus of the ConOps Document) SPAT Vehicle System Driver

Pedestrians

Defining “SPaT Infrastructure System”

Users who will Benefit From SPaT Data New infrastructure to securely communicate SPaT, MAP, and supporing data to Vehicles and Pedestrian devices. May also receive data from vehicles and pedestrian devices.

Applications that will be installed on passenger or fleet vehicles to communicate with SPaT Infrastructure Systems to receive data, and use the data to support the drivers’ safety, mobility, and efficiency.

Personal Information Devices (a User of the SPaT Infrastructure System)

Handheld devices that receive communications from the infrastructure and support pedestrians as they cross intersections

Traffic Signal Systems Sources of SPaT Data Direct Users of the SpaT Infrastructure System

35

SPaT Challenge Model ConOps

• Focused on SPaT Infrastructure System
• Needs and Operational Concepts written for –
• Indirect stakeholders:

Pedestrians and drivers

• Direct stakeholders:

SPaT Vehicle System equipped with applications Pedestrian Personal Information Devices (PIDs) Traffic Signal System including system controlling the traffic signals at the intersection Traffic Data System including traffic conditions databases, central signal control systems (CSCS), and Advanced Traffic Management Systems (ATMS) Security Back End including the Security Credentials Management System Traffic Engineering Staff Maintenance Staff

36

SPaT Challenge Model ConOps

• V2I applications based on SPaT that are

considered in the Model ConOps

37

Section 2 – Current Situation and Needs

• Current System Overview
• Stakeholders
• Indirect Users
• Users
• Other Stakeholders
• Stakeholders Use of the SPaT Infrastructure System
• Stakeholders Needs

Challenge Need ID Need Indirect User Stakeholder Needs Driver Needs Vehicles running red lights and entering signalized intersections is a safety concern, with an average of 700 fatalities each year, 90,000 injuries related to an average of 100,000 red light running related crashes. 1.1

Drivers need a red light violation warning (RLVW) to help them avoid unintended red light violations.

38

Section 3 – Operational Concept for the SPaT Infrastructure System

• How each user will interact with the SPaT

Infrastructure System

• Users include humans and systems
• Written as numbered lines for traceability by

the Requirements

3.3 SPaT Vehicle Systems’ Perspective

3.3.1 SPaT Vehicle Systems will receive current signal phase and timing (SPaT Data) from the SPaT Infrastructure System for the approaching intersection. (Need 3.1) 3.3.1.1 For intersections equipped with SPaT Infrastructure Systems, SPaT Vehicle Systems will receive the SPaT Data upstream of the intersection, beginning at a distance that enables the SPaT Vehicle System to perform needed calculations and information display to

• drivers. (Need 8.3)

39

Section 4 – Operational Concept for SPaT, MAP, and Traffic Data

• Presents details about the use of J2735

SPaT and MAP Message, as well as details about Traffic Controller Data

• Our attempt to get as much of the

information describing this data exchange into one document

40

Section 5 – Operational Scenario

• Initial Conditions
• Sequence of Events
• Chronological description of the interactions of

the SPaT Infrastructure System with the users

5.2 Sequence of events

Map Message:

• 1. The SPaT Vehicle System receives the MAP message and validates the security credentials.
• 2. The SPaT Vehicle System checks the message revision number and determines it has never received

this revision of the MAP message (alternate ‐ the SPaT Vehicle System determines it has already received this revision of the MAP message and skips step 3.)

• 3. The SPaT Vehicle System decodes the MAP message and determines
• a. Intersection location.
• b. Ingress and egress lane geometry and location.
• c. Connections from ingress lanes to egress lanes via specific maneuvers.
• a. The signal group IDs related to the connections.

41

SPaT Challenge Model Requirements

• Contain industry input
• Include relevant specifications and

standards

• Define the minimal requirements to

maintain compatibility between broadcast SPaT messages and vehicle on-board units planned by automobile industry

• Requirements organization on next slide

42

Group 11: Manage Security Back End Interface Group 9: Manage Traffic Data System Interface Group 3: Manage User Interface Group 6: Manage SPaT Vehicle System Interface Group 1: Manage Interface to SPaT Sources Interface with the Traffic Signal Controller Broadcast 5.9 GHz DSRC Messages Exchange data with the Traffic Data System Configure data exchanges Include an interface for users to manage the SPaT infrastructure System and its data Assemble the content needed for Standard SPaT Messages Monitor Preemption & Priority Requests Manage Conflicting Signal Request Messages (SRMs) Request Preemption & Priority Obtain Preemption & Priority Status Assemble Standard Signal Status Messages (SSM) Monitor Basic Safety Messages (BSM), Probe Vehicle Data (PVD) & Personal Safety Messages (PSM) Convert BSM & PSM to Detector Calls Aggregate BSM & PVD Data Assemble Traffic Data Messages Manage a Map database Manage Map Dynamic Features Assemble the content needed for MAP Message Obtain Position Correction Data Assemble SAE J2735 compliant position correction messages Manage Reports Manage Alerts Provide Diagnostics Reset the System Configure System Manage Logs Obtain valid Security Credentials Verify Received Message Credentials Apply Security Credentials to broadcasts Manage access to the system network

Traffic Signal Controller Traffic Data System Security Back End Traffic Engineer Personal Information Device SPaT Vehicle System

Group 7: Manage Preemption / Priority Group 8: Manage Vehicle & PID Data Group 10: Manage Security Group 2: Manage SPaT Group 4: Manage Maps Group 5: Manage Position Correction Group 12: Provide Support

Maintenance Tech

Notes: Bold text and boxes represents minimum SPaT Functions to support Vehicle based applications

Interface with the Central Signal Control System

Central Signal Control System

Receive and process 5.9 GHz DSRC Messages Publish Data over alternate communications Mediums Configure Messages Manage MAP Data Manage GPS Corrections Manage Detection Zones Assemble MAP messages that conform to the SAE J2735 standard message format Assemble other standard MAP messages Assemble SPaT messages that comply with other standardized message formats. Assemble SPaT messages that conform to the SAE J2735 standard message format. Include security to limit user access Display information to users Assemble other standard correction messages Configure the security back end system Obtain data for Position Correction messages Receive Data over alternate communications Mediums

43

Group 11: Manage Security Back End Interface Group 9: Manage Traffic Data System Interface Group 3: Manage User Interface Group 6: Manage SPaT Vehicle System Interface Group 1: Manage Interface to SPaT Sources Interface with the Traffic Signal Controller Broadcast 5.9 GHz DSRC Messages Exchange data with the Traffic Data System Configure data exchanges Include an interface for users to manage the SPaT infrastructure System and its data Assemble the content needed for Standard SPaT Messages Monitor Preemption & Priority Requests Manage Conflicting Signal Request Messages (SRMs) Request Preemption & Priority Obtain Preemption & Priority Status Assemble Standard Signal Status Messages (SSM) Monitor Basic Safety Messages (BSM), Probe Vehicle Data (PVD) & Personal Safety Messages (PSM) Convert BSM & PSM to Detector Calls Aggregate BSM & PVD Data Assemble Traffic Data Messages Manage a Map database Manage Map Dynamic Features Assemble the content needed for MAP Message Obtain Position Correction Data Assemble SAE J2735 compliant position correction messages Manage Reports Manage Alerts Provide Diagnostics Reset the System Configure System Manage Logs Obtain valid Security Credentials Verify Received Message Credentials Apply Security Credentials to broadcasts Manage access to the system network

Traffic Signal Controller Traffic Data System Security Back End Traffic Engineer Personal Information Device SPaT Vehicle System

Group 7: Manage Preemption / Priority Group 8: Manage Vehicle & PID Data Group 10: Manage Security Group 2: Manage SPaT Group 4: Manage Maps Group 5: Manage Position Correction Group 12: Provide Support

Maintenance Tech

Notes: Bold text and boxes represents minimum SPaT Functions to support Vehicle based applications

Interface with the Central Signal Control System

Central Signal Control System

Receive and process 5.9 GHz DSRC Messages Publish Data over alternate communications Mediums Configure Messages Manage MAP Data Manage GPS Corrections Manage Detection Zones Assemble MAP messages that conform to the SAE J2735 standard message format Assemble other standard MAP messages Assemble SPaT messages that comply with other standardized message formats. Assemble SPaT messages that conform to the SAE J2735 standard message format. Include security to limit user access Display information to users Assemble other standard correction messages Configure the security back end system Obtain data for Position Correction messages Receive Data over alternate communications Mediums

44

Group 11: Manage Security Back End Interface Group 9: Manage Traffic Data System Interface Group 3: Manage User Interface Group 6: Manage SPaT Vehicle System Interface Group 1: Manage Interface to SPaT Sources Interface with the Traffic Signal Controller Broadcast 5.9 GHz DSRC Messages Exchange data with the Traffic Data System Configure data exchanges Include an interface for users to manage the SPaT infrastructure System and its data Assemble the content needed for Standard SPaT Messages Monitor Preemption & Priority Requests Manage Conflicting Signal Request Messages (SRMs) Request Preemption & Priority Obtain Preemption & Priority Status Assemble Standard Signal Status Messages (SSM) Monitor Basic Safety Messages (BSM), Probe Vehicle Data (PVD) & Personal Safety Messages (PSM) Convert BSM & PSM to Detector Calls Aggregate BSM & PVD Data Assemble Traffic Data Messages Manage a Map database Manage Map Dynamic Features Assemble the content needed for MAP Message Obtain Position Correction Data Assemble SAE J2735 compliant position correction messages Manage Reports Manage Alerts Provide Diagnostics Reset the System Configure System Manage Logs Obtain valid Security Credentials Verify Received Message Credentials Apply Security Credentials to broadcasts Manage access to the system network

Traffic Signal Controller Traffic Data System Security Back End Traffic Engineer Personal Information Device SPaT Vehicle System

Group 7: Manage Preemption / Priority Group 8: Manage Vehicle & PID Data Group 10: Manage Security Group 2: Manage SPaT Group 4: Manage Maps Group 5: Manage Position Correction Group 12: Provide Support

Maintenance Tech

Notes: Bold text and boxes represents minimum SPaT Functions to support Vehicle based applications

Interface with the Central Signal Control System

Central Signal Control System

Receive and process 5.9 GHz DSRC Messages Publish Data over alternate communications Mediums Configure Messages Manage MAP Data Manage GPS Corrections Manage Detection Zones Assemble MAP messages that conform to the SAE J2735 standard message format Assemble other standard MAP messages Assemble SPaT messages that comply with other standardized message formats. Assemble SPaT messages that conform to the SAE J2735 standard message format. Include security to limit user access Display information to users Assemble other standard correction messages Configure the security back end system Obtain data for Position Correction messages Receive Data over alternate communications Mediums

45

Group 11: Manage Security Back End Interface Group 9: Manage Traffic Data System Interface Group 3: Manage User Interface Group 6: Manage SPaT Vehicle System Interface Group 1: Manage Interface to SPaT Sources Interface with the Traffic Signal Controller Broadcast 5.9 GHz DSRC Messages Exchange data with the Traffic Data System Configure data exchanges Include an interface for users to manage the SPaT infrastructure System and its data Assemble the content needed for Standard SPaT Messages Monitor Preemption & Priority Requests Manage Conflicting Signal Request Messages (SRMs) Request Preemption & Priority Obtain Preemption & Priority Status Assemble Standard Signal Status Messages (SSM) Monitor Basic Safety Messages (BSM), Probe Vehicle Data (PVD) & Personal Safety Messages (PSM) Convert BSM & PSM to Detector Calls Aggregate BSM & PVD Data Assemble Traffic Data Messages Manage a Map database Manage Map Dynamic Features Assemble the content needed for MAP Message Obtain Position Correction Data Assemble SAE J2735 compliant position correction messages Manage Reports Manage Alerts Provide Diagnostics Reset the System Configure System Manage Logs Obtain valid Security Credentials Verify Received Message Credentials Apply Security Credentials to broadcasts Manage access to the system network

Traffic Signal Controller Traffic Data System Security Back End Traffic Engineer Personal Information Device SPaT Vehicle System

Group 7: Manage Preemption / Priority Group 8: Manage Vehicle & PID Data Group 10: Manage Security Group 2: Manage SPaT Group 4: Manage Maps Group 5: Manage Position Correction Group 12: Provide Support

Maintenance Tech

Notes: Bold text and boxes represents minimum SPaT Functions to support Vehicle based applications

Interface with the Central Signal Control System

Central Signal Control System

Receive and process 5.9 GHz DSRC Messages Publish Data over alternate communications Mediums Configure Messages Manage MAP Data Manage GPS Corrections Manage Detection Zones Assemble MAP messages that conform to the SAE J2735 standard message format Assemble other standard MAP messages Assemble SPaT messages that comply with other standardized message formats. Assemble SPaT messages that conform to the SAE J2735 standard message format. Include security to limit user access Display information to users Assemble other standard correction messages Configure the security back end system Obtain data for Position Correction messages Receive Data over alternate communications Mediums

46

Group 11: Manage Security Back End Interface Group 9: Manage Traffic Data System Interface Group 3: Manage User Interface Group 6: Manage SPaT Vehicle System Interface Group 1: Manage Interface to SPaT Sources Interface with the Traffic Signal Controller Broadcast 5.9 GHz DSRC Messages Exchange data with the Traffic Data System Configure data exchanges Include an interface for users to manage the SPaT infrastructure System and its data Assemble the content needed for Standard SPaT Messages Monitor Preemption & Priority Requests Manage Conflicting Signal Request Messages (SRMs) Request Preemption & Priority Obtain Preemption & Priority Status Assemble Standard Signal Status Messages (SSM) Monitor Basic Safety Messages (BSM), Probe Vehicle Data (PVD) & Personal Safety Messages (PSM) Convert BSM & PSM to Detector Calls Aggregate BSM & PVD Data Assemble Traffic Data Messages Manage a Map database Manage Map Dynamic Features Assemble the content needed for MAP Message Obtain Position Correction Data Assemble SAE J2735 compliant position correction messages Manage Reports Manage Alerts Provide Diagnostics Reset the System Configure System Manage Logs Obtain valid Security Credentials Verify Received Message Credentials Apply Security Credentials to broadcasts Manage access to the system network

Traffic Signal Controller Traffic Data System Security Back End Traffic Engineer Personal Information Device SPaT Vehicle System

Group 7: Manage Preemption / Priority Group 8: Manage Vehicle & PID Data Group 10: Manage Security Group 2: Manage SPaT Group 4: Manage Maps Group 5: Manage Position Correction Group 12: Provide Support

Maintenance Tech

Notes: Bold text and boxes represents minimum SPaT Functions to support Vehicle based applications

Interface with the Central Signal Control System

Central Signal Control System

Receive and process 5.9 GHz DSRC Messages Publish Data over alternate communications Mediums Configure Messages Manage MAP Data Manage GPS Corrections Manage Detection Zones Assemble MAP messages that conform to the SAE J2735 standard message format Assemble other standard MAP messages Assemble SPaT messages that comply with other standardized message formats. Assemble SPaT messages that conform to the SAE J2735 standard message format. Include security to limit user access Display information to users Assemble other standard correction messages Configure the security back end system Obtain data for Position Correction messages Receive Data over alternate communications Mediums

47

Model Requirements Document

• Example of a Requirement, and mapping

to the Numbered Operational Concept

Group 2: Manage SPaT Requirements describing the functions of the SPaT Infrastructure to assemble the SPaT data into standard SPaT messages for broadcast. 2.1 The SPaT Infrastructure System shall assemble the content needed for standard SPaT messages. 2.1.1 The SPaT Infrastructure System shall process the message containing SPaT data obtained from the Traffic Signal System and generate a SPaT message. Minimum; RLVW 3.3.1.3

48

SPaT Challenge Model Requirements

Requirements classified as:

• Minimum: necessary to achieve minimum SPaT broadcast

functionality to support Red Light Violation Warning (RLVW)

• Optional: alternate approach to achieve minimum SPaT

functionality

• e.g. a different message format or communication mechanism
• Optional – minimum for application: necessary if additional

functionality is desired; not needed for minimum functionality

• e.g. priority/preemption and data collection from vehicles
• Optional – recommended: improves system manageability,

but not needed for minimum functionality

• e.g. reporting, log, and user management tools

49

Verifying and Validating SPaT Deployments

SPaT Challenge Verification Document:

• https://transportationops.org/content/spat-challenge-

verification-document

• Developed by the Crash Avoidance Metrics

Partnership (CAMP)

• Intent is to ensure:
• Deployments are compatible and meet minimum

requirements for on-board applications released by automobile manufacturers

• Compatibility with future Red Light Violation

Warning (RLVW) applications

• More on this topic during Webinar #5

Costs, Procurement, and Corridor Selection

Blaine Leonard, Utah DOT

51

Corridor Selection

• Select a Corridor / Area
• Infrastructure Compatibility

Signal Controllers Backhaul and Central Control of Intersections Number of signals

• Concept of Operations

Consider local conditions and needs Identify partners and partners Future V2I Applications (Long-term Strategy)

• Get on the NOCOE SPaT Challenge Map

52

Corridor Selection / Procurement

• Define Operations / Requirements
• System Requirements

Messages Being Sent – SPaT and MAP Messages Being Received – BSM Other Messages (Application Dependent)

• SRM, SSM, TIM, etc

Performance Requirements Security (SCMS)

53

Procurement

• Procurement Approaches
• Government Procurement

Testing / Small Quantity Full Procurement

• Partner / University
• Consultant

Faster Ownership / Maintenance

54

Procurement

• Define Hardware Requirements
• RSU 4.1 Specification
• Outside Certification (pending)
• Specific Requirements

Messages Performance Security

• Software Development Kit (SDK)

Needed for software development / modification

• OBUs (optional)

Number of radios (one vs two)

55

Procurement

• Other Hardware
• Cabling
• Mounting
• Processor (optional)

56

Costs

• Disclaimer . . .
• Every deployment is different – lots of variables

Learning Curve – Experience of Team Consultant vs In-house Efforts (or Combination) Testing Applications Beyond SPaT Procurement Variations Installation Parameters

• We would love your input on cost experience!

57

Costs

• Hardware
• RSU

$1500 to $3200

• Mounting Brackets, Cables, Power Supply

$200 to $600

• OBU

$900 to $1500

58

Costs

• Engineering
• Design / Testing

$1000 to $8500

• Installation / Integration

$2000 to $11,000 Location of DSRC Installation Lane Closures / Night Work

• Create MAP Data (future webinar)

$400 to $1500 Use of Tool Local Mapping

Webinar Wrap-Up and Q&A

60

Next SPaT Challenge Webinar

• Design Considerations, Part 1
• March 20, 2018 2:00pm ET
• Minimum content for SPaT broadcasts to be

verified/validated

• Signal controller interface and creation of SPaT

messages

• Examples of designs for assembling SPaT messages
• DSRC licensing
• Registration: https://transportationops.org/event/webinar-2-

spat-challenge-design-considerations-part-1

Q&A

Submit questions and comments in chat or Q&A section of webinar window

Upcoming SPaT Challenge Webinars

Design Considerations, Part 1 March 20, 2018 2:00-3:30pm ET Design Considerations, Part 2 April 17, 2018 2:00-3:30pm ET MAP Creator Tool Demonstration April 24, 2018 1:00-2:30pm ET Design Considerations, Part 3 May 15, 2018 2:00-3:30pm ET Deployment & Validation June 12, 2018 2:00-3:30pm ET
