CUSTOMER PRESENTATION 1 HISTORY ASAP was Founded in February, 2006 - PowerPoint PPT Presentation

CUSTOMER PRESENTATION 1 HISTORY ASAP was Founded in February, 2006 Corporate Offices and Manufacturing Facility Located in a 10,000 Sq Ft Building in Midvale, Ohio Began Production in June, 2006 Sales to Date Over 250 Units


  1. CUSTOMER PRESENTATION 1

  2. HISTORY • ASAP was Founded in February, 2006 • Corporate Offices and Manufacturing Facility Located in a 10,000 Sq Ft Building in Midvale, Ohio • Began Production in June, 2006 • Sales to Date – Over 250 Units • Current Production Capacity – 5 to 10 Units per Month with One Work Shift – 15 to 20 Units per Month with Two Shifts 2

  3. POLARIS & ASAP AGREEMENT • ASAP has a Contract with Polaris Industries that Allows ASAP to Modify the Chassis and Polaris Still Maintains the Chassis Warranty 3

  4. ASAP CHASSIS • Polaris Ranger 6x6 Chassis • Modified with Extended Wheel Base – Chassis Extended approx. 20” in Center and 20” in Rear • More Usable Space to Mount Equipment • Increased Carrying Capacity • Better, More Stable Ride with Added Weight • Improved Steering, Reduces Push Steer with Added Weight 4

  5. STANDARD CHASSIS 5

  6. EXTENDED CHASSIS 6

  7. ASAP PRODUCTS WILDFIRE MEDSTAT FIRE FIGHTING & RESCUE AMBULANCE LIFEGUARD SELECT SERIES 7 BEACH & TRAIL RESCUE MULTI-USE

  8. 8

  9. MEDSTAT FEATURES & ADVANTAGES • Off – Road Rescue/EMS Vehicle • Tested by the Transportation Research Center • Low Center of Gravity – Tilt Table Test Over 24° • Fully Enclosed Compartment for Patient Protection & Privacy • Carries Full Size Cot or Stokes Basket • Attendant Bench Seat with Storage and Exterior Access Door • Seating for Driver and Two Attendants • Backboard Mounting System to Carry Second Patient • Numerous Options - Deep Cycle Battery, A/C & Generator, Scene & Emergency Lights, Siren & Speaker, Run Flat Tires, Mattracks Track System 9

  10. 10

  11. 11

  12. MEDSTAT MODELS • MS 100 • MS 250 • MS 500 • ALL HAVE NUMEROUS OPTIONS AVAILABLE 12

  13. MEDSTAT MS 100 • Modified Chassis • Power Steering • Tread Plate Roof & ROPS Roll Bar • Aluminum Rear Compartment • Cot Mount System • ABS Skirting w/ Tail Lights • Rear Canvas Door & Tread Plate Step 13

  14. MEDSTAT MS 250 • Steel Cab Mounted to ROPS Rollbar – w/ Windshield & Composite Doors • Deep Cycle Battery w/ on Board Charger • Aluminum Rear Roll Up Door • Aluminum Skirting w/ Step Bumper • Turn Signals • Rear Scene Light • LED Emergency Lights 14

  15. MEDSTAT MS 500 • A/C & Generator • Siren & Speaker • Underbody Storage Compartments • Upper and Lower ALS Cabinets • LED Light Bar • All Trail Tires • Aluminum Rims 15

  16. MEDSTAT APPLICATIONS EMERGENCY – EVENT – RECREATIONAL – INDUSTRIAL - MILITARY 16

  17. 17

  18. 18

  19. 19

  20. WILDFIRE FEATURES & ADVANTAGES • Off-Road Fire Fighting/Rescue Vehicle • Tested by the Transportation Research Center • 160 gallon water, 16 gallons foam • Low Profile Poly Tank Mounted Directly to Frame • Low center of gravity - Tilt Table Tests over 30° • Suction Hose Storage Integrated in Tank – 21’ • 13 HP Honda Pump, Electric Start • Carries a full size stokes basket • Deep Cycle Battery • Numerous Options – Cab, Winch, Generator, Scene & Emergency Lights, Run Flat Tires, Mattracks Track System 20

  21. 21

  22. 22

  23. 23 150 GAL. POLY TANK w/ BAFFLES & HOSE STORAGE

  24. WILDFIRE APPLICATIONS 24 EMERGENCY – EVENT – INDUSTRIAL - MILITARY

  25. 25

  26. 26

  27. LIFEGUARD FEATURES & ADVANTAGES • Off-Road Beach & Trail Patrol/Rescue Vehicle • Roll Bar & Tread Plate Roof • Mirrors & ABS Skirting • Aluminum Bed with Canvas Top • 80” Bench Seat with Seat Back Pad • Carries Full Size Cot or Stokes Basket • Sand Tires • Numerous Options - Deep Cycle Battery System, Generator, Scene & Emergency Lights, Run Flat Tires, Mattracks Track System 27

  28. 28

  29. LIFEGUARD APPLICATIONS WATER & REMOTE RESCUE – PATROL BEACHES & TRAILS & PARKS 29

  30. 30

  31. 31

  32. SELECT SERIES FEATURES & ADVANTAGES • Multi-use Vehicle Allows Flexibility with Easy to Change Modification Kits • Extreme Off-Road Capabilities • Allows Access to Narrow, Hard to Maneuver Locations. • Numerous Options - Deep Cycle Battery System, Generator, Scene & Emergency Lights, Run Flat Tires, Mattracks Track System 32

  33. Select Series- Mod Kits Flat Bed- Base Unit Transporter 33

  34. Select Series- Mod Kits Heavy Hauler Roughneck with or without Dump System 34

  35. Select Series Trail Rescue Trail Rescue with Cot Mount System with Tool Box w/ Stokes Mount 35

  36. Select Series Applications Oil, Gas, Mining – Recreational – Industrial – Military – Emergency – Event – Beach/Trail 36

  37. VEHICLE TESTING Testing – ASAP Models Tested at Transportation Research Center (TRC) – Tilt Table – Slope Climbing – Braking – Tractive Effort (MedStat only) 37

  38. SLOPE CLIMBING BRAKING TILT TABLE TRACTIVE EFFORT 38

  39. 39 DOMETIC’S ENVIRONMENTAL TEST CHAMBER

  40. MEDSTAT TESTING RESULTS • All Testing Done in Fully Loaded Conditions – Driver, Patient, Two Attendants • Tilt Table - – Right 27° – Left 24° • Slope Climbing – – Climbed TRC’s Maximum Slope of 60% or 31 ° – Forward and in Reverse – At top, Stop, Set E-Brake, Shut Down Engine, Restart, Descend • Braking – Asphalt 10 Mph=4.4’, 17 MPH=14.8’ – Gravel 10 Mph=5.8’, 17 MPH=16.3’ • Tractive Effort – Pulled Pickup Truck Through 324’ Soft Sand Pit • A/C Testing – Temperature in Degrees F in Environmental Test Chamber TIME CAB PATIENT COMP. TEST CHAMBER BEGIN 111.78 111.58 109.76 1 HR 83.52 82.60 111.38 2 HR 80.46 79.90 110.66 3 HR 79.02 79.36 110.12 4 HR 78.84 78.64 109.94 5 HR 78.30 78.28 109.94 6 HR 78.30 78.46 109.94 40

  41. BRAKING SLOPE CLIMBING 41 TILT TABLE SLOPE DESCENDING

  42. WILDFIRE TESTING RESULTS • All Testing Done in Fully Loaded Conditions – Driver and Full Water Tank(150 gals) • Tilt Table - – Right 34° – Left 30° • Slope Climbing – – Climbed TRC’s Maximum Slope of 60% or 31 ° – Forward and in Reverse – At top, Stop, Set E-Brake, Shut Down Engine, Restart, Descend • Braking – Asphalt 20 Mph=25’, 30 MPH=47’ – Gravel 20 Mph=23’, 30 MPH=58’ 42

  43. SPECIAL MILITARY DESIGNS SCBA SEATS – ASAP Designed, Built and Installed Special Seat Backs for the Ranger to Accommodate Driver and Passenger in Level A Suits with SCBA Bottles on their Back. This was Done for the USAF CBRN Teams. 43

  44. SPECIAL MILITARY DESIGNS 120 MM MORTAR CARRIER – Based on the Initial Concept and Prototype of Mike Cooney, ASAP Reverse Engineered, Made CAD Drawings, Designed and Added Features to an all Aluminum 120 MM Mortar Carrier to be Mounted on the Polaris MVRS 4X4. 44

  45. SPECIAL MILITARY DESIGNS FRONT RACK 45

  46. SPECIAL MILITARY DESIGNS Replaces the standard molded bed Bed is 54”x38” Powder-coated Four (4) D-ring steel bed has with sides up style tie down and 10” side rail and 77”x 55” litter mount system and tailgate folded down that fold down 46

  47. MASS CAUSALTY OPTION – Camp Lejeune Requested We Design a MedStat Unit That Could Carry Multiple Patients Out of the “Hot Zone”. 47

  48. SPECIAL DESIGNS PARKING GARAGE UNIT – Designed to Go Inside 6’8” High Parking Garage with low rear compartment and small golf cart style tires. 48

  49. MANUFACTURING PROCESS 49 Frame Extension

  50. MANUFACTURING PROCESS 50 Pick Carts for Stall Build

  51. MANUFACTURING PROCESS 51 Extended Frame with Generator

  52. MANUFACTURING PROCESS 52 Extended Frame with Cab & A/C Unit

  53. MANUFACTURING PROCESS 3” Radius Corner Extrusion w/ 1/8” Wall Thickness Raw Aluminum Apparatus Body Tread Plate Floor & Bench Seat 53

  54. MANUFACTURING PROCESS Ceiling w/ 1”x1 ½” Sq Tubing Supports, IV Holder Brackets & ½” x 5” Center Mount Brackets Tread Plate Floor with 3”x2” Square Tubing Grid Support Structure 54

  55. MANUFACTURING PROCESS 55 Painted Body Ready for Mounting

  56. MANUFACTURING PROCESS 56 Stall Building at Various Stages

  57. MAJOR CUSTOMERS • Miami-Dade, FL • Baltimore, MD • Glendale, AZ • Jacksonville, FL • US Air Force • TEEKS • US Marine Corps. – Camp Lejeune • Kanawha County, WV • Oklahoma City • US Army - Fort Bliss • University of Medical & Dentistry of New Jersey 57

  58. Baltimore Miami - Dade 58 Glendale Jacksonville

  59. US Air Force US Marine Corps. 59 TEEKS Kanawha Co. WV
