Current status of works on the barrel EMC at IHEP Andrey Ryazantsev on behalf of the IHEP-Protvino group A. Ryazantsev, IHEP - Protvino, Russia PANDA Collaboration Meeting at GSI, June 2016 Major milestones for the EMC Barrel Mechanics

slide-1
SLIDE 1
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Current status of works on the barrel EMC at IHEP

Andrey Ryazantsev

  • n behalf of the IHEP-Protvino group
slide-2
SLIDE 2
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Major milestones for the EMC Barrel Mechanics

Mile- stone Work Description Prerequisites to start work / procurement Validation Criteria Date Pre-Series Slice 1.1 M6 Finalise technical specifications Technical specifica- tions Nov 2013 1.2 Design and delivery of 3D model and design of main support structures (sup- port beam, support feet, module plate) 0.0, 1.1 Delivered 3D model and design drawings Apr 2014 1.3 M7 Develop design documentation for Pre- Series Slice 0.0, 0.1, 1.1 Final Design Review for Pre-Series Slice Sep 2014 1.4 Production and delivery of batch 1 of Pre-Series Slice (PSS-B1) 1.2 SAT Aa for PSS-B1 Mar 2015 1.5 Production and delivery of all remaining components (batch 2) for Pre-Series Slice (PSS-B2) 1.3 SAT Aa for PSS-B2 Sep 2015 1.6 M8 Testing of Pre-Series Slice 1.5 SAT Ab for mechan- ics of Pre-Series Slice Mar 2016

slide-3
SLIDE 3
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Super-module structure

Module plate

slide-4
SLIDE 4
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Crystals modular support structure

Support beam (Aluminum) Support feet, 40 pcs. (G10 ) Module plates, 7 pcs. (Aluminum)

slide-5
SLIDE 5
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Support beam at production facility

slide-6
SLIDE 6
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Support beam deliveredat IHEP

slide-7
SLIDE 7
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Module plates with mounted support feet

slide-8
SLIDE 8
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Front inserts production at IHEP

slide-9
SLIDE 9
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Design of front inserts and optical fibers coupling

slide-10
SLIDE 10
  • A. Ryazantsev, IHEP - Protvino, Russia

PANDA Collaboration Meeting at GSI, June 2016

Summary

  • Manufacturing of single carbon alveoli units of 18 different types for the whole barrel was
  • completed. Spare units of each type were produced in amount of about 10%.
  • Special mold is ready for the mass production of front inserts at IHEP. Production rate is

about 100 pcs./day.

  • Module plates and support feet as well as the support beam were produced and delivered to

IHEP; pre-assembling test is in progress .

  • Addendum 3 and Addendum 4 to the Collaboration Contract which are necessary to solve

custom formalities and perform delivery of Batch #2 of the components and devices for the pre-series slice assembling were written and sent to FAIR for the final approval and signing.

  • We plan to finish all the tests during couple of weeks and hope to get signed Addenda

a.s.a.p.
