CS 5460: Operating Systems

CS5460: Operating Systems

Lecture 13: Memory Management

(Chapter 8)

Where are we?

 Basic OS structure, HW/SW interface, interrupts,

scheduling

 Concurrency  Memory management  Storage management  Other topics

CS 5460: Operating Systems

CS 5460: Operating Systems

Example Virtual Address Space

 Typical address space has 4 parts – Code: binary image of program – Data: static variables (globals) – Heap : explicitly allocated data (malloc) – Stack: implicitly allocated data  Kernel mapped into all processes  MMU hardware: – Remaps virtual addresses to physical – Supports read-only, supervisor-only – Detects accesses to unmapped regions  How can we load two processes

into memory at same time?

– Assume each has similar layout

Kernel code segment Kernel data segment

Kernel heap

User code segment User data segment User heap User stack segment

Kernel User

0x00000000 0x80000000 0xFFFFFFFF

PC HP SP

CS 5460: Operating Systems

Mapping Addresses

 How can process (virtual) addresses be mapped to

physical addresses?

– Compile time: Compiler generates physical addresses directly

» Advantages: No MMU hardware, no runtime translation overhead » Disadvantages: Inflexible, hard to multiprogram, inefficient use of DRAM

– Load time: OS loader “fixes” addresses when it loads program

» Advantages: Can support static multiprogramming » Disadvantages: MMU hardware, inflexible, hard to share data, …

– Dynamic: Compiler generates address, but OS/HW reinterpret

» Advantages: Very flexible, can use memory efficiently » Disadvantages: MMU hardware req’d, runtime translation overhead

 For “real” OSes, processes only use virtual

addresses

– Small-sized embedded systems use physical addresses

CS 5460: Operating Systems

Uniprogramming (e.g., DOS)

 One process at a time  User code compiled to sit in

fixed range (e.g., [0,640 KB])

– No hardware virtualization of addresses

 OS in separate addresses

– E.g., above 640KB

 Goals:

– Safety: None (good and bad) – Efficiency: Poor (I/O and compute not overlapped, response time)

Code (Text segment) Static data (Data segment) Uninitialized data (BSS segment)

0x00000000 0xFFFFFFFF

Heap (Dynamically allocated) Stack

SP HP PC 0xA0000

Reserved for DOS kernel

CS 5460: Operating Systems

Multiprogramming: Static Relocation

 OS loader relocates programs – OS stored in reserved “high” region – Compiler maps process starting at 0 – When process started, OS loader:

» Allocates contiguous physical memory » Uses relocation info in binary to fix up addresses to relocated region

– TSRs in DOS based on this technique  Problems: – Finding/creating contiguous holes – Dealing with processes that grow/shrink  Goals: – Safety: None! à à process can destroy

• ther processes

– Efficiency: Poor à à only one segment per process; slow load times; no sharing

Code Data

0x00000000 0xFFFFFFFF

Heap Stack

SP1 HP0 PC0

Reserved for OS kernel Code Data Heap Stack

SP0 HP1 PC1

CS 5460: Operating Systems

Dynamic Relocation

 Idea:

– Programs all laid out the same – Relocate addresses when used – “Requires” hardware support

 Two views of memory:

– Virtual: Process’s view – Physical: Machine’s view

 Many variants

– Base and bounds – Segmentation – Paging – Segmented paging

0x00000000 0xFFFFFFFF

SP1

OS kernel

Code Data Heap Stack

OS kernel

Code Data Heap Stack

OS kernel

Heap Data Code Stack Stack Heap Data Code

0x00000000 0xFFFFFFFF

SP0 HP0 PC0 HP1 PC1

Physical Addresses Virtual Addresses

CS 5460: Operating Systems

Base and Bounds

 Each process mapped to

contiguous physical region

 Two hardware registers

– Base: Starting physical address – Bounds: Size in bytes

 On each reference:

– Check against bounds – Add base to get physical address

 Evaluation:

– Good points: … – Bad points: …

 OS handled specially  Example: Cray-1

Base register Bounds register Virtual address

>?

Physical address Trap

+

0x00000000 0xFFFFFFFF

Code Data Heap Stack OS kernel Code Data Heap Stack Base0 Bounds1 Base1 Bounds0

0x00000 0x00000 0x00000 0x7ffff 0x7ffff

P1 VAs P0 VAs Physical Virtual

CS 5460: Operating Systems

Base and Bounds

 Each process has private address space – No relocation done at load time  Operating system handled specially – Runs with relocation turned off (i.e., ignores Base and Bounds) – Only OS can modify Base and Bounds registers  Good points: – Very simple hardware  Bad points: – Only one contiguous segment per process à à inhibits sharing – External fragmentation à à need to find or make holes – Hard to grow segments

CS 5460: Operating Systems

Segmentation

 Idea: Create N separate segments – Each segment has separate base and bounds register – Segment number is fixed portion of virtual address

Seg# Offset Base Bounds Base Bounds Base Bounds Base Bounds Base Bounds

…

>?

Error! (Trap)

+

Physical address

CS 5460: Operating Systems

Segmentation Example

 Virtual address space is 2000

bytes in size

 4 segments up to 500 bytes

each

– Starting at 0, 500, 1000, 1500

 What if processor accesses…

– VA 0 – VA 1040 – VA 1900 – VA 920 – VA 1898

 What if we allocate:

– 100-byte segment – 200-byte segment

Base Bounds 1000 400 500 600 300 1500 400

• 1
• 2
• 3

Seg3 Seg0 Seg2 Seg1 2000 1000 Seg3 Seg0 Seg2 Seg1 Virtual Address Physical Address Segment Table

CS 5460: Operating Systems

Segmentation Discussion

 Good features: – More flexible than base and bounds à à enables sharing (How?) – Reduces severity of fragmentation (How?) – Small hardware table (e.g., 8 segments) à à can fit all in processor  Problems: – Still have fragmentation à à How? What kind? – Hard to grow segments à à Why? – Non-contiguous virtual address space à à Real problem?  Possible solutions: – Fragmentation: Copy and compact – Growing segments: Copy and compact – Paging

CS 5460: Operating Systems

Paging

 Problem w/ segmentation à

à variable-sized segments

 Solution à

à Paging!

– Insist that all “chunks” be the same size (typically 512-8K bytes) – Call them “pages” rather than “segments” – Allocation is done in terms of full page-aligned pages à à no bounds – MMU maps virtual page numbers to physical page numbers

Physical Page# Other Physical address Virtual Page# Offset Physical Page# Other Physical Page# Other Physical Page# Other Physical Page# Offset Wired concatenate What other info?

CS 5460: Operating Systems

Paging Discussion

 How does this help? – No external fragmentation! – No forced holes in virtual address space – Easy translation à à everything aligned on power-of-2 addresses – Easy for OS to manage/allocate free memory pool  What problems are introduced? – What if you do not need entire page? Internal fragmentation – Page table may be large

» Where should we put it?

– How can we do fast translation if not stored in processor? – How big should you make your pages?

» Large: Smaller table, demand paging more efficient » Small: Less fragmentation, finer grained sharing, larger page table

CS 5460: Operating Systems

Paging Examples

 Assume 1000-byte pages  What if processor accesses:

– VA 0 – VA 1040 – VA 2900 – VA 920 – VA 4998

• 1
• 2
• 3

VP3 VP0 VP2 VP1 Virtual Address Physical Address PPN Valid R/O Super 3 Y N Y 8 N N N 5 Y Y N 7 Y N N 1 N Y Y

• 4

VP4 VP0 VP1 VP2 VP3 VP4 Free List Page Table

x86 Paging

 x86 typically uses 4 KB pages  Virtual addresses are 32 bits  How big is the offset field of a virtual address?  How big is the virtual page number field?  How many pages are in a virtual address space?  How big is a flat page table? – Assume PTE (page table entry) is 32 bits

CS 5460: Operating Systems

Key Idea From Today

 Address space virtualization – Programs see virtual addresses – Kernel can see both virtual and physical addresses – Virtual and physical address spaces need not be the same size – You must understand this to understand modern operating systems  Kernel + HW supports the virtual to physical

mapping

– Has to be fast – There are different ways to do it – Modern OSes use paging
