e ectrace Countries Afgected by Landmines Countries afgected by Landmines Image adapted from Handicap International Afgected Countries Non Afgected Countries 2 Conceptual Design Wifj enabled device reads Electrace current and sends data to

slide-1
SLIDE 1

e ectrace

slide-2
SLIDE 2

2

Countries Afgected by Landmines

Countries afgected by Landmines Image adapted from Handicap International Afgected Countries Non Afgected Countries

slide-3
SLIDE 3

3

Conceptual Design

μtrace contains E. coli (Landmine) biosensor

e

Read-out from Electrace Wifj enabled device reads Electrace current and sends data to web app.

slide-4
SLIDE 4

4

Biosensor

  • Landmines

Outside the Lab

  • Microfmuidic Platform

Electrical Signal

  • Conductive Curli
  • Electron Transport

INPUT OUTPUT μTRACE

slide-5
SLIDE 5

5

Biosensor

  • Landmines

Outside the Lab

  • Microfmuidic Platform

Electrical Signal

  • Conductive Curli
  • Electron Transport

INPUT OUTPUT μTRACE

slide-6
SLIDE 6

6

Improving the Response

BioBrick (BBa_K1316008)

Literature: Yagur-Kroll et al., 2014

Time (hr)

100mg/L DNT 50mg/L DNT 0mg/L DNT 100mg/L DNT +N 50mg/L DNT +N 0mg/L DNT +N

ybiJ Promoter

5 5 10 15 5 10 15 20 25

slide-7
SLIDE 7

7

Biosensor

  • Landmines

Outside the Lab

  • Microfmuidic Platform

Electrical Signal

  • Conductive Curli
  • Electron Transport

INPUT OUTPUT μTRACE

slide-8
SLIDE 8

8

Biosensor

  • Landmines

Outside the Lab

  • Microfmuidic Platform

Electrical Signal

  • Conductive Curli
  • Electron Transport

INPUT OUTPUT μTRACE

slide-9
SLIDE 9

9

Curli in Biofjlm

BioBrick (BBa_K1316014)

csgB csgA Constitutive Inducible B A A A B A A A B A A A A A A A A

Induction

Cell Membrane

Barnhart and Chapman, 2006

slide-10
SLIDE 10

10

Conductive Curli

Cell with Curli Cell without Curli Gold nanoparticle Medium Gold Electrode Substrate

Induction

Chen et al., 2014

slide-11
SLIDE 11

11

Stochastic Curli Modeling

Gene Level

nm scale

Cell Level

μm scale

Colony Level

mm scale

slide-12
SLIDE 12

12

Stochastic Curli Modeling

Deterministic

ODEs

Stochastic

Worm Like Chains Percolation Theory & Graph Theory

Stochastic

slide-13
SLIDE 13

13

Percolation

slide-14
SLIDE 14

14

Percolation

slide-15
SLIDE 15

15

Conclusions from Modeling

Induction of conductive Curli results in an electrical signal. This is a qualitative response.

slide-16
SLIDE 16

16

e- Biosensor

  • Landmines

Outside the Lab

  • Microfmuidic Platform

Electrical Signal

  • Conductive Curli
  • Electron Transport

INPUT OUTPUT μTRACE

slide-17
SLIDE 17

17

Shewanella oneidensis MR-1

Adapted From Goldbeck et al., 2013

Extracellular Space Cytosol Lactate Dehydrogenase Q QH2 MtrB MtrC MtrA CymA Electron Donor Electron Donor Oxidized Metal Oxides

slide-18
SLIDE 18

18

Escherichia coli C43

The fjrst functioning MtrCAB Cluster (BBa_K1316012)

Electrode Extracellular Space Cytosol Lactate Dehydrogenase Q QH2 Electron Donor Electron Donor Oxidized MtrB MtrC MtrA NapC

Cytochrome C Maturation System (BBa_K1316011)

Adapted From Goldbeck et al., 2013
slide-19
SLIDE 19

19

Flux Balance Analysis

Electrode Extracellular Space Cytosol Lactate Dehydrogenase Q QH2 Lactate Pyruvate MtrB MtrC MtrA NapC Anoxic

Determination of Optimal Electron Donor Using COBRA Toolbox

Adapted From Goldbeck et al., 2013
slide-20
SLIDE 20

20

Electron Flow

A

Donor Oxidized Donor e- e- e- e- e- Working Electrode Counter Electrode Reference Electrode MtrCAB

+

Potentiostat

  • e-
slide-21
SLIDE 21

21

Custom-designed Bioreactor

Magnetic stirrer-bar Heating mantle Carbon cloth working electrode Nitrogen inlet Sampling tube Gas outlet Silver/Silver Chloride reference electrode Counter Electrode

slide-22
SLIDE 22

22

Custom-designed Bioreactor

Software Development in LabVIEW

Experimental Setup Potentiostat Circuit and Software

slide-23
SLIDE 23

23

Measurement of Current

  • E. coli C43 +

MtrCAB & Ccm

  • E. coli C43

Normalized Currnet [mA] 10 9 8 7 6 5 4 3 2 1 Time [hr] 4 3 2 1

A e- e- e- e- e-

+

  • MtrCAB & Ccm BioBrick (BBa_K1316012 & BBa_K1316011)
slide-24
SLIDE 24

24

Biosensor

  • Landmines

Outside the Lab

  • Microfmuidic Platform

Electrical Signal

  • Conductive Curli
  • Electron Transport

INPUT OUTPUT μTRACE

slide-25
SLIDE 25

25

Microbial Biosensors

Now: Numerous but Impractical

slide-26
SLIDE 26

26

Microbial Biosensors

Now: Numerous but Impractical Our System: Cheap, Easy to handle for non- biologists in the fjeld, plug-&-play, quantifjable

slide-27
SLIDE 27

27

Microbial Biosensors

“Alternative read-outs are very interesting. For a device like yours, which is able to be applied in the fjeld, this is a really nice trick.” - Dr Van Der Burg (BioDetection Systems) Now: Numerous but Impractical Our System: Cheap, Easy to handle for non- biologists in the fjeld, plug-&-play, quantifjable

slide-28
SLIDE 28

28

B t By ofgering a synbio solution to solve an every day problem, we prove to the broader public that they need synthetic biology in their life.

slide-29
SLIDE 29

29

“If your system is capable of detecting land mines, I wouldn’t mind if it uses synthetic biology.” - Suzanne Oosterwijk, PAX By ofgering a synbio solution to solve an every day problem, we prove to the proader public that they need synthetic biology in their life.

slide-30
SLIDE 30

30

μtrace - a Custom-designed Device

Fluid Channel Commercial Electrode Glass Slide Electrical Contacts PDMS 33 μL of Analyte

Inexpensive Prototyping

~$3

slide-31
SLIDE 31

31

μtrace - a Custom-designed Device

Inexpensive Prototyping

slide-32
SLIDE 32

32

Potentiostat μtrace Infmow Outfmow Working Electrode Counter Electrode Reference Electrode

A

Syringe Pump

Experimental Setup

slide-33
SLIDE 33

33

μtrace test results - Ascorbic Acid Voltammetry

0.4 0.6 0.8 1.0 1.2 1.4 1.6 0.2 1.8 Ascorbic Acid 0.2V Ascorbic Acid 0.4V Water 0.4V Water 0.2V

Time (s) 50 100 150 200

ybiJ Promoter

250 Current (mA) 300

slide-34
SLIDE 34

34

μtrace with MtrCAB & Ccm

0.005 0.01 0.015 0.02 0.025 0.03 0.035 0.04 0.045

Current (μA)

  • E. coli C43 + MtrCAB & Ccm
  • E. coli C43

Water

Time (s) 50 100 150 200 250 300

slide-35
SLIDE 35

35

Achievements

Improved responsiveness of modifjed E. coli to detect landmines Stochastic modeling of Curli shows a qualitative response Improved the formerly registered MtrCAB BioBrick Modifjed E. coli to produce an electrical output Designed μtrace - a microfmuidic device for measurement

  • f electrical output
slide-36
SLIDE 36

36

e ectrace

A plug-&-play platform for biosensors, that produces a quantitative electrical output that can be used for the detection of landmines.

slide-37
SLIDE 37

37

Partner:

TU Delft Department

  • f Biotechnology

TU Delft Faculty of Applied Sciences

Sponsors:

slide-38
SLIDE 38

38

e ectrace

A plug-&-play platform for biosensors, that produces a quantitative electrical output that can be used for the detection of landmines.
