SLIDE 1

Cosmic Rays: AMS Experiment

Javier Berdugo (CIEMAT, Madrid)

Frontiers of Astroparticle Physics. La Palma October 11th 2018

slide-2
SLIDE 2
  • P. Mertsch arXiv: 1012.4239 [astro-ph.HE]

Cosmic rays are a sample of solar, galactic and extragalactic matter which includes all known nuclei and their isotopes, as well as electrons, positrons and antiprotons

Cosmic rays

2

  • Sci. Amer. 276 (1997) 44
slide-3
SLIDE 3

p, He + ISM antiparticles + …  +   antiparticles + …

EARTH

        

p, He

antiparticles

ISM

The collision of cosmic rays with interstellar medium (ISM) produces antiparticles (e+, p, D, …) The collision of dark matter particles will produce additional antiparticles Antiparticles in Cosmic Rays and Dark Matter

3

slide-4
SLIDE 4

Positrons in Cosmic Rays

m=800 GeV

  • I. Cholis et al., arXiv:0810.5344

m=400 GeV e± energy [GeV]

e+ /(e+ + e-)

4

  • M. S. Turner and F. Wilczek, Phys. Rev. D42 (1990) 1001;
  • J. Ellis, 26th ICRC Salt Lake City (1999) astro-ph/9911440;
  • H. Cheng, J. Feng and K. Matchev, Phys. Rev. Lett. 89 (2002) 211301;
  • S. Profumo and P. Ullio, J. Cosmology Astroparticle Phys. JCAP07 (2004) 006;
  • D. Hooper and J. Silk, Phys. Rev. D 71 (2005) 083503;
  • E. Ponton and L. Randall, JHEP 0904 (2009) 080;
  • G. Kane, R. Lu and S. Watson, Phys. Lett. B681 (2009) 151;
  • D. Hooper, P. Blasi and P. D. Serpico, JCAP 0901 025 (2009) 0810.1527; B2

Y–Z. Fan et al., Int. J. Mod. Phys. D19 (2010) 2011;

  • M. Pato, M. Lattanzi and G. Bertone, JCAP 1012 (2010) 020.
slide-5
SLIDE 5

Precision measurements of antiparticles requires long exposure time with detectors with large acceptance and percent level precision.

Flux of antiparticles in cosmic rays

5

Experiments operating outside the atmosphere and capable to measure simultaneously the spectra of the different cosmic ray components.

slide-6
SLIDE 6
  • O. Adriani et al. Nature 458 (2009)
  • M. Ackerman et al. Phys. Rev. Lett. 108 (2012) 011103

PAMELA: Launched on June 15th 2006

Image: http://wizard.roma2.infn.it/pamela/html/resurs.html

Baikonur Cosmodrome (Kazakhstan) FERMI Launched on June 11, 2008

Image credit: NASA/Jerry Cannon, Robert Murray

Space based cosmic ray experiments

6

slide-7
SLIDE 7

7

CALET, started August 2015 ISS CREAM, started August 2017 AMS, started May 2011 DAMPE, started December 2015

Space-born Cosmic Ray Experiments in operation

7

slide-8
SLIDE 8

5m x 4m x 3m 7.5 tons

TRD TOF 1, 2 TOF 3, 4 RICH ECAL Magnet and Veto Counters

Silicon layer 1 Silicon layers 2 - 8 Silicon layer 9

Acceptance: 0.5 m2 sr

08/07/2014 8

slide-9
SLIDE 9

USA MEXICO

UNAM

  • UNIV. OF TURKU

ASI IROE FLORENCE INFN & UNIV. OF BOLOGNA INFN & UNIV. OF MILANO-BICOCCA INFN & UNIV. OF PERUGIA INFN & UNIV. OF PISA INFN & UNIV. OF ROMA INFN & UNIV. OF TRENTO

NETHERLANDS

ESA-ESTEC NIKHEF

RUSSIA

ITEP KURCHATOV INST.

SPAIN

CIEMAT - MADRID I.A.C. CANARIAS. ETH-ZURICH

  • UNIV. OF GENEVA

CALT (Beijing) IEE (Beijing) IHEP (Beijing) NLAA (Beijing) BUAA(Beijing) SJTU (Shanghai) SEU (Nanjing) SYSU (Guangzhou) SDU (Jinan) EWHA KYUNGPOOK NAT.UNIV.

PORTUGAL

  • LAB. OF INSTRUM. LISBON
  • ACAD. SINICA (Taipei)

CSIST (Taipei) NCU (Chung Li) NCKU (Tainan)

TAIWAN TURKEY

METU, ANKARA

CER N= JSC DOE- NASA

LUPM MONTPELLIER LAPP ANNECY LPSC GRENOBLE

FRANCE 9 BRAZIL

IFSC – SÃO CARLOS INSTITUTE OF PHYSICS RWTH-I. Aachen KIT-KARLSRUHE

SWITZERLAND MIT KOREA GERMANY FINLAND ITALY CHINA

AMS is an international collaboration based at CERN

9

It took 650 physicists and engineers 17 years to construct AMS

slide-10
SLIDE 10

Ground Tests and Calibrations

Space Qualification (EMI and TV at ESTEC)

1,762 positions and angles with p, e+, e−, pion beams from 10 to 400 GeV/c

TVT Chamber: P < 10-9 bar Ambient temperature:

  • 90oC to 40oC

10

Test Beam at CERN (Calibration)

10

slide-11
SLIDE 11

11

237<|R|<290 GV

Positron measurement with AMS

Signal identification from 2D template fit in (∧TRD - ∧CC ) plane

slide-12
SLIDE 12

12

Positron fraction in cosmic rays with AMS

slide-13
SLIDE 13

1 10 100 1000 Energy [GeV]

50 100 150 200 250 ]

2

GeV

  • 1

sr

  • 1

s

  • 2

[m

3

E

  • e

F 5 10 15 20 25 ]

2

GeV

  • 1

sr

  • 1

s

  • 2

[m

3

E

+

e

F

Latest AMS results on positron and electron fluxes 28.1 million electrons 1.9 million positrons

Energy range from 0.5 GeV to 1 TeV

13

slide-14
SLIDE 14

Astrophysical point sources like pulsars will imprint a higher anisotropy on the arrival directions of energetic positrons than a smooth dark matter halo.

positrons Isotropic Map

C1 is the dipole moment The anisotropy in galactic coordinates

Amplitude of the dipole anisotropy on positrons for 16 < E < 350 GeV δ < 0.019 (95% C.I.)

AMS Positron cosmic ray anisotropy

14

slide-15
SLIDE 15

Models based on very different assumptions describe observed trends of a single measurement.

Positron flux modeling

Many models proposed to explain the physics origin of the observed behavior

1) Particle origin: Dark Matter 2) Astrophysics origin: Pulsars, SNRs 3) Propagation of cosmic rays

Simultaneous description of several precision measurements is difficult in the framework of a single model

15

slide-16
SLIDE 16

16

⦁ 1.9 million positrons

1.2 TeV Dark Matter + Collision of Cosmic Rays The positron flux appears to be in agreement with predictions from a 1.2 TeV Dark Matter model (J. Kopp, Phys. Rev. D 88, 076013 (2013))

slide-17
SLIDE 17

(e+ + e–) AMS data: comparison with other detectors

Measuring (e++e–) is much less sensitive to detect the source term due to the large e– background

17

slide-18
SLIDE 18

18

(e+ + e–) AMS data: comparison with other detectors

slide-19
SLIDE 19

The Antiproton Flux is ~10-4 of the Proton Flux. A percentage precision experiment requires background rejection close to 1 in a million

Kinetic energy [GeV] Antiproton / proton ratio

Donato et al., PRL 102, 071301 (2009)

Dark matter

10-4 10-5 10-6 10-7 10-3 10-2 1 10 100 1000 Dark matter +

Collision of cosmic rays with ISM

Antiprotons in Cosmic rays

19

slide-20
SLIDE 20

p

e p 175<|R|<211 GV

χ2/d.f. = 138/154

20

Antiproton measurement with AMS

Signal identification from 2D template fit in (∧TRD - ∧CC ) plane

slide-21
SLIDE 21

p 3.49105 events

  • AMS-02
  • PAMELA

21

Antiproton-to-Proton Flux Ratio

  • M. Aguilar et al. Phys. Rev. Lett. 117 (2016) 091103

Show no rigidity dependence above 60 GV

slide-22
SLIDE 22

G.Giesen, et. al., JCAP 09 (2015) 023 C.Evoli et. al., JCAP 12 (2015) 039 R.Kappl, et. al., JACP 10(2015) 034

Collision of cosmic rays with interstellar medium:

22

slide-23
SLIDE 23

Primary and secondary cosmic ray

08/07/2014 23 PDG, Phys. Rev. D86, 010001 (2012)

  • A. Obermeier et al. Astrophys. J. 742 (2011) 14

Understanding the origin, acceleration and propagation of CR require the knowledge of the chemical composition over a wide energy range

slide-24
SLIDE 24

24

Primary and secondary Cosmic Rays

Comparison with earlier measurements

  • M. Aguilar et al. Phys. Rev. Lett. 120 (2018) 021101
  • M. Aguilar et al. Phys. Rev. Lett. 119 (2017) 251101

24

slide-25
SLIDE 25

25

Primary and secondary Cosmic Rays with AMS

slide-26
SLIDE 26

Secondary/Primary Flux Ratios = KRΔ

Combining the six ratios, the secondary over primary flux ratio (B/C, …), deviates from single power law above 200 GV by 0.13±0.03

Δ[200-3300GV] – Δ[60-200GV] = 0.13±0.03

200 GV 200 GV

26

slide-27
SLIDE 27

[GV] R ~ Rigidity

3 4 5 10 20

2

10

2

10 ´ 2

3

10

3

10 ´ 2 ]

1.7

GV

  • 1

sr

  • 1

s

  • 2

[ m

2.7

R ´

N

F 5 10 15 20 25 a)

AMS

S N

F +

P N

F =

N

F

B

F ´ = 0.62

S N

F ;

O

F ´ = 0.09

P N

F

Primary Component Secondary Component

Nitrogen Cosmic Rays

27

AMS

ΦN = ΦNP+ΦNS

ΦN = ΦNP+ΦNS = (0.090±0.002)×ΦO+(0.62±0.02)×ΦB

  • M. Aguilar et al. Phys. Rev. Lett. 121 (2018) 051103

27

slide-28
SLIDE 28

3He/4He abundancies

Preliminary data, refer to upcoming AMS PRL publication

28

slide-29
SLIDE 29

29

AMS continous measurement of the e+ and e- flux in the energy range 1 -50 GeV

  • ver 6 years with a time resolution of 27 days.
  • M. Aguilar et al. Phys. Rev. Lett. 121 (2018) 051102
slide-30
SLIDE 30

Anti Deuterons have been proposed as an almost background free channel for Dark Matter indirect detection

30

Anti Deuterons in Cosmic rays

The Anti Deuterons Flux is < 10-4 of the Antiproton Flux. Additional background rejection

1 4 10 40 100 10-6 10-8 10-10

Rigidity [GV]

Flux [(m2 sr s GV)-1]

D from collisions of

  • rdinary cosmic rays

D from annihilation

  • f Dark Matter

 Dark Matter model:

  • F. Donato et al., Phys. Rev. D, 62 (2000) 043003

 Collisions of CR model

  • K. Blum et al., Phys. Rev. D 96 (2017) 103021)
slide-31
SLIDE 31

31

Anti-deuterons have never been observed in space

BESS results (COSPAR 2018)

31

slide-32
SLIDE 32

32

Anti-Deuteron Search with AMS

slide-33
SLIDE 33

33

Anti-Deuteron Search prospects

slide-34
SLIDE 34

34

Y Z X

First anti-Helium event in the cosmos:

Momentum = 33.1 ± 1.6 GeV/c Charge = -1.97 ± 0.05 Mass = 2.93 ± 0.36 GeV/c2 Mass (3He) = 2.83 GeV/c 2

Date: 2011-269:11:19:32

Anti-Helium Search with AMS

slide-35
SLIDE 35

35

3He flux models from collisions of cosmic rays

There are large uncertainties in models to ascertain the origin of 3He The rate of anti-helium is ~1 in 100 million helium. We have also observed two 4He candidates. More events are necessary to ensure that there are no backgrounds.

Kinetic Energy/nucleon

model variations factor of ~300

  • K. Blum et al., Phys. Rev. D 96, 103021 (2017)
slide-36
SLIDE 36

36

High precision measurements of cosmic rays open new windows to observe unexpected phenomena There are several large scale detectors in space to study high energy charged cosmic rays: AMS, CALET, DAMPE, ISS-CREAM exploring a new and exciting frontier in physics research

36
