Vulcano Workshop 2010 - May, 23-29, 2010 UHE Cosmic Rays in the Auger Era UHE Cosmic Rays in the Auger Era Sergio Petrera, L'Aquila University email: sergio.petrera@aquila.infn.it Vulcano Workshop 2010 - May, 23-29, 2010 UHE Cosmic Rays in the

slide-1
SLIDE 1

Vulcano Workshop 2010 - May, 23-29, 2010

UHE Cosmic Rays in the Auger Era UHE Cosmic Rays in the Auger Era

Sergio Petrera, L'Aquila University email: sergio.petrera@aquila.infn.it

slide-2
SLIDE 2

Vulcano Workshop 2010 - May, 23-29, 2010

UHE Cosmic Rays in the Auger Era UHE Cosmic Rays in the Auger Era

Sergio Petrera, L'Aquila University email: sergio.petrera@aquila.infn.it

Motivations Present status of the Pierre Auger Observatory The physics items: energy spectrum CR composition arrival directions Summary and outlook

slide-3
SLIDE 3

The interest for UHECRs in three points

transition galactic/extragalactic origin GZK effect pointing to the sources (particle astronomy !?) E > 1018 eV

slide-4
SLIDE 4

The interest for UHECRs in three points

transition galactic/extragalactic origin GZK effect pointing to the sources (particle astronomy !?) E > 1018 eV

The interest for UHECRs in three points

slide-5
SLIDE 5

The interest for UHECRs in three points

transition galactic/extragalactic origin GZK effect pointing to the sources (particle astronomy !?) E > 1018 eV

slide-6
SLIDE 6

The interest for UHECRs in three points

transition galactic/extragalactic origin GZK effect pointing to the sources (particle astronomy !?) E > 1018 eV

slide-7
SLIDE 7

The interest for UHECRs in three points

transition galactic/extragalactic origin GZK effect pointing to the sources (particle astronomy !?) E > 1018 eV

+ GZK  reduces the horizon

slide-8
SLIDE 8

AGASA: stopped Jan. 2004 HiRes: stopped Apr 2006 Auger: operating Telescope Array: starting

UHE UHE ankle GZK few/km sq per century

the all-particle spectrum

slide-9
SLIDE 9

AGASA: stopped Jan. 2004 HiRes: stopped Apr 2006 Auger: operating Telescope Array: starting

Exposures Exposures

slide-10
SLIDE 10

The Pierre Auger Observatory

slide-11
SLIDE 11

Auger South: the plan Auger South: the plan

slide-12
SLIDE 12

3000 km 3000 km2

2 area

area

Vulcano Workshop

slide-13
SLIDE 13

Nitrogen fluorescence detected as shower develops Particles detected as they reach ground

Fluorescence

Fluorescence (50 W light bulb @ c) (50 W light bulb @ c)

 nearly calorimetric  direct view of shower evolution  10% duty cycle  Acceptance depends on energy +

atmosphere

 Surface

Surface (10 (1012

12 particles over 20 km

particles over 20 km2

2)

)

 100% duty cycle  Flat acceptance above threshold  Indirect measurements of primary

energy and mass (relies on simulation)

Hybrid = surface + fluorescence Hybrid = surface + fluorescence

Auger detection techniques

slide-14
SLIDE 14

Observables at Auger

slide-15
SLIDE 15

Observables at Auger

slide-16
SLIDE 16

Observables at Auger

slide-17
SLIDE 17

SD energy calibration based on FD profiles “golden hybrid” events (independently detected) energy systematic error ~22 % mostly from systematics

  • f the FD detector

(fluorescence yield, atmospheric transparency...)

Energy Calibration

slide-18
SLIDE 18

Water Cherenkov tank

Rotomolded polyethylene tank 10 m2 x 1.2 m of ultrapure water in a light diffusing Tyvek liner, 3 PMTs Photonis (9’’ diameter); Autonomous unit: solar panel+battery, GPS timing, communication antenna, electronics Max 10 W power consumption

the Surface Detector

slide-19
SLIDE 19

Camera with 440 PMTs

(Photonis XP 3062)

Schmidt Telescope using 11 m2 mirrors UV optical filter (also: provide protection from outside dust)

the Fluorescence Detector

slide-20
SLIDE 20

Camera with 440 PMTs

(Photonis XP 3062)

UV optical filter (also: provide protection from outside dust) Schmidt Telescope using 11 m2 mirrors

the Fluorescence Detector

slide-21
SLIDE 21

Construction ended Apr. 2008 Enhancements for Detection @ Low Energies: HEAT (High Elevation Auger Telescopes) AMIGA (Auger Muon and Infill Array) + AERA array of radio detectors

Auger 2010

slide-22
SLIDE 22

Construction ended Apr. 2008 Enhancements for Detection @ Low Energies: HEAT (High Elevation Auger Telescopes) AMIGA (Auger Muon and Infill Array) + AERA array of radio detectors New R&D: MW fluorescence detection [after Gorham et al., PR D 78 (2008) 032007] Towards an FD with 100% duty cycle?

Auger 2010

slide-23
SLIDE 23

ENERGY SPECTRUM ENERGY SPECTRUM

slide-24
SLIDE 24

PLB 685 (2010) 239

the Energy Spectrum

Cutoff at ~1019.6 eV significant with > 30

slide-25
SLIDE 25

PLB 685 (2010) 239

the Energy Spectrum

Cutoff at ~1019.6 eV significant with > 30

slide-26
SLIDE 26

the Energy Spectrum

Within the energy scale systematics

slide-27
SLIDE 27

Comparison to Source Models

slide-28
SLIDE 28

MASS COMPOSITION MASS COMPOSITION

slide-29
SLIDE 29

photons protons Fe Energy Xmax

Mass Composition: the principle

slide-30
SLIDE 30

photons protons Fe Data Energy Xmax Xmax

Mass Composition: the principle

slide-31
SLIDE 31

Elongation Rate Measurement

Auger and HiRes Xmax measurements are compatible within systematic uncertainties

slide-32
SLIDE 32

Comparison with Hadronic Models

⇒ Mass composition getting heavier HiRes PRL 2010 “proton dominance above 1.6 EeV” but... difficult to compare with HiRes due to different definitions

  • f observables.

PRL 104 (2010) 091101

slide-33
SLIDE 33

Comparison with Hadronic Models

PRL 104 (2010) 091101

More about Mass Composition by Analisa Mariazzi

slide-34
SLIDE 34

Photons: upper limits

Top down models strongly constrained

slide-35
SLIDE 35

Neutrinos: Earth skimming ντ

slide-36
SLIDE 36

ARRIVAL DIRECTIONS ARRIVAL DIRECTIONS

slide-37
SLIDE 37

Typical accuracy of reconstruction <1°

No significant emission from Galactic Centre No broadband signals – e.g. Dipole – at any energy above 1 EeV e.g 1 < E < 3 EeV, Amplitude < 0.7% No clustering of the type claimed by AGASA No signal from BL Lacs as possibly seen by HiRes Summary: Previous reports have not been confirmed Summary: Previous reports have not been confirmed ICRC 2007

Initial Anisotropy Searches

slide-38
SLIDE 38

Correlation with AGN's (2007)

Based on a Prescribed Anisotropy Test: Correlation with Veron-Cetty-Veron AGN Catalog

20 out of 27 events E>57 EeV correlating within 3.1 degrees with z<0.017 AGN's Isotropy rejected with >99% C.L.

slide-39
SLIDE 39

Update of the Prescribed Anisotropy Test (correlation with VCV catalog of AGNs) 38% (21/55) correlate (post exploration) vs. 21% expected from isotropy correlation decreased but still incompatible with isotropy at 99% C.L.

Correlation with AGN's (2010)

slide-40
SLIDE 40

More results on Correlations

New paper in preparation: new catalogs, autocorrelation, CenA preliminary

slide-41
SLIDE 41

Summary...

High quality results on all the observables of UHECR's A comprehensive interpretation of the whole data still missing

slide-42
SLIDE 42

Summary...

High quality results on all the observables of UHECR's A comprehensive interpretation of the whole data still missing

slide-43
SLIDE 43

Summary...

High quality results on all the observables of UHECR's A comprehensive interpretation of the whole data still missing

slide-44
SLIDE 44

Summary...

High quality results on all the observables of UHECR's A comprehensive interpretation of the whole data still missing Much work to do... many more data....

slide-45
SLIDE 45

… and Outlook

What's coming next?What's coming next?

A new observatory: TA (Telescope Array) Auger South: low energy extension HEAT (3 high elevation telescopes) AMIGA (SD infill + muon detectors) +... Auger North: at Lamar (CO) undergoing evaluation Go to space!

slide-46
SLIDE 46

… and Outlook

What's coming next?What's coming next?

A new observatory: TA (Telescope Array) TA (Telescope Array) Auger South: low energy extension HEAT (3 high elevation telescopes) AMIGA (SD infill + muon detectors) +... Auger North: at Lamar (CO) undergoing evaluation Go to space!

30 km

576 scintillator detectors 1.2 km interval

3 FD stations (atmospheric fluorescence telescopes) 3 (+2) Communication Towers ~2.5 hours from SLC

slide-47
SLIDE 47

… and Outlook

What's coming next?What's coming next?

A new observatory: TA (Telescope Array) TA (Telescope Array) Auger South Auger South: low energy extension HEAT (3 high elevation telescopes) AMIGA (SD infill + muon detectors) +... Auger North: at Lamar (CO) undergoing evaluation Go to space!

slide-48
SLIDE 48

… and Outlook

What's coming next?What's coming next?

A new observatory: TA (Telescope Array) TA (Telescope Array) Auger South Auger South: low energy extension HEAT (3 high elevation telescopes) AMIGA (SD infill + muon detectors) +... Auger North Auger North: at Lamar (CO) undergoing evaluation Go to space!

slide-49
SLIDE 49

Auger North

slide-50
SLIDE 50

Auger North: comparison with other expts

slide-51
SLIDE 51

Auger North: correlations above 60 EeV

slide-52
SLIDE 52

Photon search

slide-53
SLIDE 53

Auger North: Photon search

slide-54
SLIDE 54

… and Outlook

What's coming next?What's coming next?

A new observatory: TA (Telescope Array) TA (Telescope Array) Auger South Auger South: low energy extension HEAT (3 high elevation telescopes) AMIGA (SD infill + muon detectors) +... Auger North Auger North: at Lamar (CO) undergoing evaluation Go to space! Go to space!

slide-55
SLIDE 55

… and Outlook

What's coming next?What's coming next?

A new observatory: TA (Telescope Array) TA (Telescope Array) Auger South Auger South: low energy extension HEAT (3 high elevation telescopes) AMIGA (SD infill + muon detectors) +... Auger North Auger North: at Lamar (CO) undergoing evaluation Go to space! Go to space!

Thanks
