SLIDE 1
2
Commercial Disclosures
- Jerome C. Ramos-Esteban, MD (none)
- Ronald R. Krueger, MD (IntraLase)
- Maria Regina Chalita, MD, PhD (none)
- Daniel Pierre, MSIV (none)
Corneal Changes Following LASIK and Enhancement with Microkeratome - - PowerPoint PPT Presentation
Corneal Changes Following LASIK and Enhancement with Microkeratome - - PowerPoint PPT Presentation
Corneal Changes Following LASIK and Enhancement with Microkeratome and Femtosecond Laser Flaps Jerome C. Ramos-Esteban, MD Cole Eye Institute Cleveland Clinic Commercial Disclosures Jerome C. Ramos-Esteban, MD (none) Ronald R.
SLIDE 2
SLIDE 3
3
Purpose
SLIDE 4
4
Purpose
- To determine the thickness of both LASIK flaps and
residual stromal bed at the time of primary LASIK and LASIK enhancement
- To compare differences in these two parameters
according to ablation type
- To determine longitudinal changes in these two
parameters between Microkeratome and femtosecond laser procedures
SLIDE 5
5
Methods
SLIDE 6
6
98 patients n=196 eyes Microkeratome n=79 eyes Femtosecond N=117 eyes Primary LASIK treatment Myopia n=91 Hyperopia=26 Myopia n=59 Hyperopia=20
SLIDE 7
7
Methods
Primary procedures:
- Microkeratome (Moria M2, 110 um head)
- Femtosecond (IntraLase 15 and 30 kHz, 110 um flap)
Laser Platform:
- Alcon LadarWave 4000
- Preoperative and intraoperative Ultrasound Pachymetry
50 HZ (Sonogage) probe
SLIDE 8
8
Measurements
SLIDE 9
9
Measurements
Primary Procedures
- Central Corneal Thickness
- Pre-ablation Stromal Thickness
- Post-ablation Stromal Thickness
SLIDE 10
10
Measurements
Enhancement Procedures
- Central Corneal Thickness
- Pre-enhancement Stromal Thickness
- Post-ablation Stromal Thickness
SLIDE 11
11
Calculations
SLIDE 12
12
Primary Procedures
SLIDE 13
13
Central Corneal Thickness (CCT)
(CCT)
SLIDE 14
14
Primary Flap Thickness (PFT)
PFT = CCT - PAST
Preablation Stromal Thickness (PAST)
SLIDE 15
15
Calculated Primary Post-Ablation Depth (CPPAD)
CPPAD = PAST - TLAD
Theoretical Laser Ablation Depth (TLAD)
SLIDE 16
16
Measured Ablation Depth (MAD)
MAD = PAST - POST
Post-Ablation Stromal Thickness (POST)
SLIDE 17
17
LASIK Enhancements
SLIDE 18
18
Enhancement Central Corneal Thickness (ECCT)
(ECCT)
SLIDE 19
19
Enhancement Flap Thickness (EFT)
EFT = ECCT - PEST
Pre-enhancement Stromal Thickness (PEST)
SLIDE 20
20
Calculated Enhancement Post-Ablation Depth (CEPAD)
CEPAD = PEST - TLAD
Theoretical Laser Ablation Depth (TLAD)
SLIDE 21
21
Measured Enhancement Ablation Depth (MEAD)
MEAD = PEST - POST
Post-Ablation Stromal Thickness (POST)
SLIDE 22
22
Statistical Analysis
- Paired t-test was used to assess differences in
thickness between:
- Primary & Enhancement flaps
- Calculated & pre-enhacement stromal thickness
- Calculated & Measured ablation depth
- A p value < 0.05 was considered statistically significant
SLIDE 23
23
Results
SLIDE 24
24
Microkeratome
SLIDE 25
25
Microkeratome Flap Thickness
0.94 119.8 120 Hyperopia <0.0001 141.8 114.9 Myopia p value EFP PFT Mean
SLIDE 26
26
Microkeratome
Residual Stromal Bed Thickness
<0.0001 411.5 366 Hyperopia <0.0001 346.6 364.1 Myopia p value PEST CPPAD Mean
SLIDE 27
27
Femtosecond
SLIDE 28
28
Femtosecond: Flap Thickness
0.07 118.6 126 Hyperopia 0.003 141 134.9 Myopia p value EFT PFT Mean
SLIDE 29
29
Femtosecond:
Residual Stromal Bed Thickness
<0.0001 421.2 376.32 Hyperopia <0.0001 331.8 351.2 Myopia p value PEST CPPAD Mean
SLIDE 30
30
Femtosecond Primary Treatment Difference in Ablation Depth
<0.001 19 54 Hyperopia <0.001 102 85 Myopia p value MAD TLAD Mean
SLIDE 31
31
Femtosecond Enhancement Difference in Ablation Depth
<0.001 7 21 Hyperopia <0.001 10 15 Myopia p value MEAD ETLAD Mean
SLIDE 32
32
Primary LASIK vs. Enhancements
SLIDE 33
33
Flap Thickness Difference Primary LASIK vs. Enhancement
0.07
- 7.42
0.94
- 0.25
Hyperopia
0.003 + 6.1 <0.001 + 26.3 Myopia
p value Femtosecond p value Microkeratome
FT = EFT - PFT
SLIDE 34
34
Stromal Thickness Difference Primary LASIK vs. Enhancement
<0.001 + 44.8 <0.001 + 45.6 Hyperopia <0.001
- 19.4
<0.001
- 17.97
Myopia
p value Femtosecond p value Microkeratome
ST = PEST - CPPAD
SLIDE 35
35
Conclusions
SLIDE 36
36
Microkeratome vs. Femtosecond
Myopic Ablations
- PFT thinner due to underestimation of pre-ablation stromal bed
- Calculated post ablation depth > pre-enhancement stromal bed
- Substraction methods are very sensitive to tissue hydration
SLIDE 37
37
Microkeratome vs. Femtosecond
Myopic Ablations
- PFT femtosecond flaps > microkeratome flaps
- Possible fluid displacement during flap creation
- Difference Femtosecond & microkeratome EFT not significant
SLIDE 38
38
Microkeratome vs. Femtosecond
Hyperopic Ablations
- No statistically significant differences between PFT and EFT
- Pre-enhancement stromal bed > calculated post ablation depth
- Lamellar tension reduction from more peripheral ablation
may lead to increased baseline tissue hydration
SLIDE 39
