International Business Center

EasyIP Series

Contents

EasyIP Overview

01

EasyIP Family

02

EasyIP 4.0 Solution

03

01.

EasyIP Overview

2018 EasyIP 4.0

• AcuSense &ColorVu
• 4MP/2MP
• 120dB WDR
• Powered by DarkFighter
• H.265+ codec
• 5/6 VCA

2012 EasyIP 1.0

• 2 MP
• H.264 codec

2014 EasyIP 2.0

• 4 MP/2 MP
• 120dB WDR
• H.264+ codec
• Hik-connect service

2017 EasyIP 2.0+

EasyIP Timeline

2017 EasyIP 3.0

• 4K
• Powered by DarkFighter
• H.265+ codec
• 5/6 VCA

2018 EasyIP 1.0+

EasyIP Upgrade

EasyIP 1.0+

DS-2CD2XX1 Series

• 2 MP
• 120dB True WDR
• Powered by DarkFighter (box only)
• H.265+/H.265/H.264+/H.264
• EXIR
• 2 VCA

2018

DS-2CD2XX0 Series 2 MP H.264 DWDR IR

EasyIP 1.0

2012

DS-2CD2XX2 Series 4 MP/2 MP 120dB True WDR H.264+ Hik-connect service

EasyIP 2.0

2014

EasyIP 2.0+

DS-2CD2XX3 Series

• 4K
• 120dB True WDR
• Powered by DarkFighter
• H.265+
• 3 VCA

2017

02.

EasyIP Family

EasyIP Family

IPC DS-2CD2xx3 EasyIP 2.0+ IPC DS-2CD2xx1 EasyIP 1.0+ EasyIP 3.0 IPC DS-2CD2xx5 NVR PTZ DS-2DExxxx EasyIP 4.0 AcuSense IPC DS-2CD2xx6 ColorVu IPC DS-2CD2xx7 AcuSense NVR DS-7xxxNXI

EasyIP 1.0+ & 2.0+ Features

EasyIP 1.0+ Network Camera

120 dB True WDR H.265+ 2 MP 2 VCA

2

EasyIP 2.0+ Network Camera

120 dB True WDR H.265+ Up to 4K 3VCA Powered by DarkFighter

EasyIP 3.0 Features

Powered by DarkFighter

EasyIP 3.0 Network Camera EasyIP 3.0 Network PTZ

Auto Tracking

(DE4A, DE7 and DE5 none IR series only)

120 dB True WDR H.265+ Up to 4K 5 → 6 VCA

(from V5.5.51)

4

Powered by DarkFighter 120 dB True WDR H.265+ 4 MP 7 VCA

4K

More details in ultimate clarity

4K

2MP 4MP 6MP 8MP

More Details

4K

More details in ultimate clarity

4K

2 MP Camera

4K Ultra HD Camera

Greater Coverage

Powered by DarkFighter

4 MP conventional 4 MP Powered by DarkFighter 8 MP conventional 8 MP Powered by DarkFighter

Powered by DarkFighter

Better color images in low light environment

True WDR

True WDR

Clearer presentation with strong backlight WDR off, photo by EasyIP 2.0+/3.0 2MP Camera WDR on, photo by EasyIP 2.0+/3.0 2MP Camera

H.265+

H.265+

More savings

• n bandwidth

and storage

17.9 9.5 3.3 4.8 2.3 0.56

5 10 15 20 25 H.264 H.265 H.265+ 24-hour Recording File Size (GB) by H.264, H.265 and H.265+ Daytime Nighttime Up to 83% gap!! Up to 67% gap!!

• Long

ng-te term rm Bit Bitrate ate Contr ntrol

• l
• Noise

ise Sup uppre pression ion

• Predi

edicti ctive Enc ncoding

• ding

H.265+

H.264 H.265 H.265+

5 cameras 10 cameras 20 cameras

 2MP Camera

20Mb broadband network

H.264

0.5 month 1 month 2 months

H.265 H.265+

5TB HDDS

8 pcs 2MP cameras

VCA

EasyIP 1.0+ Network Camera EasyIP 2.0+ Network Camera EasyIP 3.0/4.0 Network Camera EasyIP 3.0 Network PTZ

Line crossing detection Intrusion detection Region Entrance Region Exiting Face detection Unattended baggage detection Object removal detection Scene change detection (from V5.5.51)

VCA

More VCA functions, a smarter system

03.

EasyIP 4.0 Solution

AcuSense IPC & NVR ColorVu IPC

EasyIP 4.0

Accurate Sense, the intelligent

analysis technology based on deep learning algorithm improves efficiency of monitoring and searching.

Colorful view, the 24/7

chromatic imaging technology improves video surveillance quality.

EasyIP 4.0 Features

EasyIP 4.0 Solution

AcuSense IPC & NVR

Why?

Massive data Resources are wasted Frequent false alarms Other objects

···

Security surveillance scenarios People and vehicle

Targets Classification

Others Human Vehicle One Stand-alone Module Hikvision Deep Learning Algorithm

AcuSense Technology

Conventional IP Device

VCA rules are triggered by targets Targets classification by AcuSense devices

False Alarm Filter

✘

✔

1

• False Alarm Filter

Human & vehicle targets detected efficiently. The interference caused by other objects (animal, leaf, light, rain, etc.) can be eliminated efficiently.

Main Functions

AcuSense Camera & NVR

Targets classification False Alarm Filtered by AcuSense Devices

Demonstration – False Alarm Filter

Cost-saving Time-saving

Compared with conventional CCTV system, AcuSense system can filter out nearly 80%- 90% false alarm events.

Quick Target Search

• Quick Target Search

Human Target Search & Vehicle Target Search (Supported by Hikvision AcuSense NVRs integrated with AcuSense technology)

Main Functions Targets classification Human Target Search & Vehicle Target Search Human File Search Vehicle File Search

Demonstration – Quick Target Search

False Alarm Filter Human & Vehicle Accurate Locating Highly-efficient Search

Line Crossing Intrusion

✔

Strobe light & Audio Alarm

Select AcuSense cameras support Strobe light & audio alarm Bait Light for a unconscious Glance

Facial Information as evidence

Demonstration – Strobe light & Audio Alarm

EasyIP 4.0 Solution

ColorVu Camera

Why?

Crimes often happen at night. Too dark to see anything...... Up to now, EasyIP 3.0 has supported powered by DarkFighter technology. Better Effect image in the evening! But still need IR LED, represent black and white image at the dark night. No details. No Colors.

If we want to acquire 24/7 colorful image?!

ColorVu IP Camera

More light, brighter images.

• 1. Large aperture

F2.0

Conventional Camera

F1.6

Powered by DarkFighter Camera

F1.0

ColorVu Camera

4X amount of light of conventional camera, 2.56X amount of light of powered by DarkFighter camera.

• 2. Advanced Sensor

Higher utilization of light, more light enter sensor (4 MP 1/1.8” Sensor)

ColorVu Camera (warm-light switch

• n)
• 3. Warm-light

Not dazzling

Demonstration

Test Environment: Outdoor Test Time: 20:00

4MP Conventional Camera (Supplement Light Switch-off) 4MP ColorVu Camera (Supplement Light Switch-off)

Demonstration

Test Environment: Outdoor Test Time: 20:00

4MP Conventional Camera (Supplement Light Switch-on) 4MP ColorVu Camera (Supplement Light Switch-on)

Demonstration

Test Environment: Darkroom

Powered by DarkFighter Camera (IR LED switch on) Conventional Camera (IR LED switch on) ColorVu Camera (warm-light switch on)

Brighter and colorful image, more details, but no overexposure

23 series turret (Support strobe-light and audio alarm)

DS-2CD2346G1-I/SL DS-2CD2326G1-I/SL

2T series bullet (Support strobe-light and audio alarm)

DS-2CD2T46G1-4I/SL DS-2CD2T26G1-4I/SL

Product Showcase

AcuSense Camera (4/2 MP) AcuSense Camera with Strobe-light & Audio Alarm (4/2 MP)

DS-2CD2346G1-I DS-2CD2326G1-I

23 series turret

DS-2CD2T46G1-2I/4I DS-2CD2T26G1-2I/4I

2T series bullet

DS-2CD2646G1-IZ(S) DS-2CD2626G1-IZ(S)

26 series VF bullet

DS-2CD2146G1- I(S) DS-2CD2126G1- I(S)

21 series dome

DS-2CD2746G1- IZ(S) DS-2CD2726G1- IZ(S)

27 series VF dome

Product Showcase

DS-7716NXI-I4(/16P)/4S DS-7732NXI-I4(/16P)/4S DS-7608NXI-I2(/8P)/4S DS-7616NXI-I2(/16P)/4S DS-7632NXI-I2(/16P)/4S

ColorVu Camera (4/2 MP) AcuSense NVR 23 series turret

DS-2CD2347G1-L(U) DS-2CD2327G1-L(U)

2T series bullet

DS-2CD2T47G1-L DS-2CD2T27G1-L

False alarm filter Quick target search

(All channels) AcuSense NVR AcuSense Camera AcuSense NVR ColorVu Camera

False alarm filter Quick target search

(Key positions) AcuSense NVR Conventional Camera Conventional NVR AcuSense Camera

False alarm filter

(Key positions)

ColorVu False alarm filter Quick target search

Recommended System

International Business Center
