Data Exploration and Visualisation with R Yanchang Zhao http://www.RDataMining.com R and Data Mining Course Beijing University of Posts and Telecommunications, Beijing, China July 2019 Chapter 3: Data Exploration, in R and Data Mining:

slide-1
SLIDE 1

Data Exploration and Visualisation with R ∗

Yanchang Zhao

http://www.RDataMining.com

R and Data Mining Course Beijing University of Posts and Telecommunications, Beijing, China

July 2019

∗Chapter 3: Data Exploration, in R and Data Mining: Examples and Case Studies.

http://www.rdatamining.com/docs/RDataMining-book.pdf

1 / 45

slide-2
SLIDE 2

Contents

Introduction Have a Look at Data Explore Individual Variables Explore Multiple Variables More Explorations Save Charts to Files Further Readings and Online Resources

2 / 45

slide-3
SLIDE 3

Data Exploration and Visualisation with R

Data Exploration and Visualisation ◮ Summary and stats ◮ Various charts like pie charts and histograms ◮ Exploration of multiple variables ◮ Level plot, contour plot and 3D plot ◮ Saving charts into files

3 / 45

slide-4
SLIDE 4

Quiz: What’s the Name of This Flower?

Oleg Yunakov [CC BY-SA 3.0 (https://creativecommons.org/licenses/by-sa/3.0)], from Wikimedia Commons. 4 / 45

slide-5
SLIDE 5

The Iris Dataset

The iris dataset [Frank and Asuncion, 2010] consists of 50 samples from each of three classes of iris flowers. There are five attributes in the dataset: ◮ sepal length in cm, ◮ sepal width in cm, ◮ petal length in cm, ◮ petal width in cm, and ◮ class: Iris Setosa, Iris Versicolour, and Iris Virginica. Detailed desription of the dataset can be found at the UCI Machine Learning Repository †.

†https://archive.ics.uci.edu/ml/datasets/Iris 5 / 45

slide-6
SLIDE 6

Contents

Introduction Have a Look at Data Explore Individual Variables Explore Multiple Variables More Explorations Save Charts to Files Further Readings and Online Resources

6 / 45

slide-7
SLIDE 7

Size and Variables Names of Data

# number of rows nrow(iris) ## [1] 150 # number of columns ncol(iris) ## [1] 5 # dimensionality dim(iris) ## [1] 150 5 # column names names(iris) ## [1] "Sepal.Length" "Sepal.Width" "Petal.Length" "Petal.Wid... ## [5] "Species"

7 / 45

slide-8
SLIDE 8

Structure of Data

Below we have a look at the structure of the dataset with str().

str(iris) ## 'data.frame': 150 obs. of 5 variables: ## $ Sepal.Length: num 5.1 4.9 4.7 4.6 5 5.4 4.6 5 4.4 4.9 ... ## $ Sepal.Width : num 3.5 3 3.2 3.1 3.6 3.9 3.4 3.4 2.9 3.1... ## $ Petal.Length: num 1.4 1.4 1.3 1.5 1.4 1.7 1.4 1.5 1.4 1... ## $ Petal.Width : num 0.2 0.2 0.2 0.2 0.2 0.4 0.3 0.2 0.2 0... ## $ Species : Factor w/ 3 levels "setosa","versicolor",....

◮ 150 observations (records, or rows) and 5 variables (or columns) ◮ The first four variables are numeric. ◮ The last one, Species, is categoric (called “factor” in R) and has three levels of values.

8 / 45

slide-9
SLIDE 9

Attributes of Data

attributes(iris) ## $names ## [1] "Sepal.Length" "Sepal.Width" "Petal.Length" "Petal.Wid... ## [5] "Species" ## ## $class ## [1] "data.frame" ## ## $row.names ## [1] 1 2 3 4 5 6 7 8 9 10 11 12 13 ... ## [16] 16 17 18 19 20 21 22 23 24 25 26 27 28 ... ## [31] 31 32 33 34 35 36 37 38 39 40 41 42 43 ... ## [46] 46 47 48 49 50 51 52 53 54 55 56 57 58 ... ## [61] 61 62 63 64 65 66 67 68 69 70 71 72 73 ... ## [76] 76 77 78 79 80 81 82 83 84 85 86 87 88 ... ## [91] 91 92 93 94 95 96 97 98 99 100 101 102 103 1... ## [106] 106 107 108 109 110 111 112 113 114 115 116 117 118 1... ## [121] 121 122 123 124 125 126 127 128 129 130 131 132 133 1... ## [136] 136 137 138 139 140 141 142 143 144 145 146 147 148 1...

9 / 45

slide-10
SLIDE 10

First/Last Rows of Data

iris[1:3, ] ## Sepal.Length Sepal.Width Petal.Length Petal.Width Species ## 1 5.1 3.5 1.4 0.2 setosa ## 2 4.9 3.0 1.4 0.2 setosa ## 3 4.7 3.2 1.3 0.2 setosa head(iris, 3) ## Sepal.Length Sepal.Width Petal.Length Petal.Width Species ## 1 5.1 3.5 1.4 0.2 setosa ## 2 4.9 3.0 1.4 0.2 setosa ## 3 4.7 3.2 1.3 0.2 setosa tail(iris, 3) ## Sepal.Length Sepal.Width Petal.Length Petal.Width Spe... ## 148 6.5 3.0 5.2 2.0 virgi... ## 149 6.2 3.4 5.4 2.3 virgi... ## 150 5.9 3.0 5.1 1.8 virgi...

10 / 45

slide-11
SLIDE 11

A Single Column

The first 10 values of Sepal.Length

iris[1:10, "Sepal.Length"] ## [1] 5.1 4.9 4.7 4.6 5.0 5.4 4.6 5.0 4.4 4.9 iris$Sepal.Length[1:10] ## [1] 5.1 4.9 4.7 4.6 5.0 5.4 4.6 5.0 4.4 4.9

11 / 45

slide-12
SLIDE 12

Contents

Introduction Have a Look at Data Explore Individual Variables Explore Multiple Variables More Explorations Save Charts to Files Further Readings and Online Resources

12 / 45

slide-13
SLIDE 13

Summary of Data

Function summary() ◮ numeric variables: minimum, maximum, mean, median, and the first (25%) and third (75%) quartiles ◮ categorical variables (i.e., factors): frequency of every level

summary(iris) ## Sepal.Length Sepal.Width Petal.Length Petal.Wid... ## Min. :4.300 Min. :2.000 Min. :1.000 Min. :0.... ## 1st Qu.:5.100 1st Qu.:2.800 1st Qu.:1.600 1st Qu.:0.... ## Median :5.800 Median :3.000 Median :4.350 Median :1.... ## Mean :5.843 Mean :3.057 Mean :3.758 Mean :1.... ## 3rd Qu.:6.400 3rd Qu.:3.300 3rd Qu.:5.100 3rd Qu.:1.... ## Max. :7.900 Max. :4.400 Max. :6.900 Max. :2.... ## Species ## setosa :50 ## versicolor:50 ## virginica :50 ## ## ##

13 / 45

slide-14
SLIDE 14

library(Hmisc) # describe(iris) # check all columns describe(iris[, c(1, 5)]) # check columns 1 and 5 ## iris[, c(1, 5)] ## ## 2 Variables 150 Observations ## -----------------------------------------------------------... ## Sepal.Length ## n missing distinct Info Mean Gmd ... ## 150 35 0.998 5.843 0.9462 4.... ## .10 .25 .50 .75 .90 .95 ## 4.800 5.100 5.800 6.400 6.900 7.255 ## ## lowest : 4.3 4.4 4.5 4.6 4.7, highest: 7.3 7.4 7.6 7.7 7.9 ## -----------------------------------------------------------... ## Species ## n missing distinct ## 150 3 ## ## Value setosa versicolor virginica ## Frequency 50 50 50 ## Proportion 0.333 0.333 0.333 ## -----------------------------------------------------------...

14 / 45

slide-15
SLIDE 15

Mean, Median, Range and Quartiles

◮ Mean, median and range: mean(), median(), range() ◮ Quartiles and percentiles: quantile()

range(iris$Sepal.Length) ## [1] 4.3 7.9 quantile(iris$Sepal.Length) ## 0% 25% 50% 75% 100% ## 4.3 5.1 5.8 6.4 7.9 quantile(iris$Sepal.Length, c(0.1, 0.3, 0.65)) ## 10% 30% 65% ## 4.80 5.27 6.20

15 / 45

slide-16
SLIDE 16

Variance and Histogram

var(iris$Sepal.Length) ## [1] 0.6856935 hist(iris$Sepal.Length)

Histogram of iris$Sepal.Length

iris$Sepal.Length Frequency 4 5 6 7 8 5 10 15 20 25 30

16 / 45

slide-17
SLIDE 17

Density

library(magrittr) ## for pipe operations iris$Sepal.Length %>% density() %>% plot(main='Density of Sepal.Length')

4 5 6 7 8 0.0 0.1 0.2 0.3 0.4

Density of Sepal.Length

N = 150 Bandwidth = 0.2736 Density

17 / 45

slide-18
SLIDE 18

Pie Chart

Frequency of factors: table()

library(dplyr) iris2 <- iris %>% sample_n(50) iris2$Species %>% table() %>% pie() # add percentages tab <- iris2$Species %>% table() precentages <- tab %>% prop.table() %>% round(3) * 100 txt <- paste0(names(tab), '\n', precentages, '%') pie(tab, labels=txt)

setosa versicolor virginica setosa 38% versicolor 36% virginica 26%

18 / 45

slide-19
SLIDE 19

Bar Chart

iris2$Species %>% table() %>% barplot() # add colors and percentages bb <- iris2$Species %>% table() %>% barplot(axisnames=F, main='Species', ylab='Frequency', col=c('pink', 'lightblue', 'lightgreen')) text(bb, tab/2, labels=txt, cex=1.5)

setosa versicolor virginica 5 10 15

Species

Frequency 5 10 15

setosa 38% versicolor 36% virginica 26%

19 / 45

slide-20
SLIDE 20

Contents

Introduction Have a Look at Data Explore Individual Variables Explore Multiple Variables More Explorations Save Charts to Files Further Readings and Online Resources

20 / 45

slide-21
SLIDE 21

Correlation

Covariance and correlation: cov() and cor()

cov(iris$Sepal.Length, iris$Petal.Length) ## [1] 1.274315 cor(iris$Sepal.Length, iris$Petal.Length) ## [1] 0.8717538 cov(iris[, 1:4]) ## Sepal.Length Sepal.Width Petal.Length Petal.Width ## Sepal.Length 0.6856935

  • 0.0424340

1.2743154 0.5162707 ## Sepal.Width

  • 0.0424340

0.1899794

  • 0.3296564
  • 0.1216394

## Petal.Length 1.2743154

  • 0.3296564

3.1162779 1.2956094 ## Petal.Width 0.5162707

  • 0.1216394

1.2956094 0.5810063 # cor(iris[,1:4])

21 / 45

slide-22
SLIDE 22

Aggreation

Stats of Sepal.Length for every Species with aggregate()

aggregate(Sepal.Length ~ Species, summary, data = iris) ## Species Sepal.Length.Min. Sepal.Length.1st Qu. ## 1 setosa 4.300 4.800 ## 2 versicolor 4.900 5.600 ## 3 virginica 4.900 6.225 ## Sepal.Length.Median Sepal.Length.Mean Sepal.Length.3rd Qu. ## 1 5.000 5.006 5.200 ## 2 5.900 5.936 6.300 ## 3 6.500 6.588 6.900 ## Sepal.Length.Max. ## 1 5.800 ## 2 7.000 ## 3 7.900

22 / 45

slide-23
SLIDE 23

Boxplot

◮ The bar in the middle is median. ◮ The box shows the interquartile range (IQR), i.e., range between the 75% and 25% observation.

boxplot(Sepal.Length ~ Species, data = iris)

setosa versicolor virginica 4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0

23 / 45

slide-24
SLIDE 24

Scatter Plot

with(iris, plot(Sepal.Length, Sepal.Width, col = Species, pch = as.numeric(Species)))

4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0 2.0 2.5 3.0 3.5 4.0 Sepal.Length Sepal.Width

24 / 45

slide-25
SLIDE 25

Scatter Plot with Jitter

Function jitter(): add a small amount of noise to the data

with(iris, plot(jitter(Sepal.Length), jitter(Sepal.Width), col=Species,pch=as.numeric(Species)))

4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0 2.0 2.5 3.0 3.5 4.0 jitter(Sepal.Length) jitter(Sepal.Width)

25 / 45

slide-26
SLIDE 26

A Matrix of Scatter Plots

pairs(iris)

Sepal.Length

2.0 3.0 4.0 0.5 1.5 2.5 4.5 5.5 6.5 7.5 2.0 3.0 4.0

Sepal.Width Petal.Length

1 2 3 4 5 6 7 0.5 1.5 2.5

Petal.Width

4.5 5.5 6.5 7.5 1 2 3 4 5 6 7 1.0 2.0 3.0 1.0 2.0 3.0

Species

26 / 45

slide-27
SLIDE 27

Contents

Introduction Have a Look at Data Explore Individual Variables Explore Multiple Variables More Explorations Save Charts to Files Further Readings and Online Resources

27 / 45

slide-28
SLIDE 28

3D Scatter plot

library(scatterplot3d) scatterplot3d(iris$Petal.Width, iris$Sepal.Length, iris$Sepal.Width)

0.0 0.5 1.0 1.5 2.0 2.5 2.0 2.5 3.0 3.5 4.0 4.5 4 5 6 7 8

iris$Petal.Width iris$Sepal.Length iris$Sepal.Width

28 / 45

slide-29
SLIDE 29

Interactive 3D Scatter Plot

Package rgl supports interactive 3D scatter plot with plot3d().

library(rgl) plot3d(iris$Petal.Width, iris$Sepal.Length, iris$Sepal.Width)

29 / 45

slide-30
SLIDE 30

Heat Map

Calculate the similarity between different flowers in the iris data with dist() and then plot it with a heat map

dist.matrix <- as.matrix(dist(iris[, 1:4])) heatmap(dist.matrix)

42 23 14 9 43 39 4 13 2 46 36 7 48 3 16 34 15 45 6 19 21 32 24 25 27 44 17 33 37 49 11 22 47 20 26 31 30 35 10 38 5 41 12 50 28 40 8 29 18 1 119 106 123 132 118 131 108 110 136 130 103 126 101 144 121 145 61 99 94 58 65 80 81 82 63 83 93 68 60 70 90 54 107 85 56 67 62 72 91 89 97 96 100 95 52 76 66 57 55 59 88 69 98 75 86 79 74 92 64 109 137 105 125 141 146 142 140 113 104 138 117 116 149 129 133 115 135 112 111 148 78 53 51 87 77 84 150 147 124 134 127 128 139 71 73 120 122 114 102 143 42 23 14 9 43 39 4 13 2 46 36 7 48 3 16 34 15 45 6 19 21 32 24 25 27 44 17 33 37 49 11 22 47 20 26 31 30 35 10 38 5 41 12 50 28 40 8 29 18 1 119 106 123 132 118 131 108 110 136 130 103 126 101 144 121 145 61 99 94 58 65 80 81 82 63 83 93 68 60 70 90 54 107 85 56 67 62 72 91 89 97 96 100 95 52 76 66 57 55 59 88 69 98 75 86 79 74 92 64 109 137 105 125 141 146 142 140 113 104 138 117 116 149 129 133 115 135 112 111 148 78 53 51 87 77 84 150 147 124 134 127 128 139 71 73 120 122 114 102 143

30 / 45

slide-31
SLIDE 31

Level Plot

Function rainbow() creates a vector of contiguous colors. rev() reverses a vector.

library(lattice) levelplot(Petal.Width ~ Sepal.Length * Sepal.Width, data=iris, cuts=8)

Sepal.Length Sepal.Width

2.0 2.5 3.0 3.5 4.0 5 6 7 0.0 0.5 1.0 1.5 2.0 2.5

31 / 45

slide-32
SLIDE 32

Contour

contour() and filled.contour() in package graphics contourplot() in package lattice

filled.contour(volcano, color=terrain.colors, asp=1, plot.axes=contour(volcano, add=T))

100 120 140 160 180

1 100 100 110 110 110 1 1 1 2 130 140 1 5 160 1 6 1 7 170 180 180 190

32 / 45

slide-33
SLIDE 33

3D Surface

persp(volcano, theta = 25, phi = 30, expand = 0.5, col = "lightblue")

v

  • l

c a n

  • Y

Z

33 / 45

slide-34
SLIDE 34

Parallel Coordinates

Visualising multiple dimensions

library(MASS) parcoord(iris[1:4], col = iris$Species)

Sepal.Length Sepal.Width Petal.Length Petal.Width 34 / 45

slide-35
SLIDE 35

Parallel Coordinates with Package lattice

library(lattice) parallelplot(~iris[1:4] | Species, data = iris)

Sepal.Length Sepal.Width Petal.Length Petal.Width Min Max

setosa versicolor

Sepal.Length Sepal.Width Petal.Length Petal.Width

virginica

35 / 45

slide-36
SLIDE 36

Visualisation with Package ggplot2

library(ggplot2) qplot(Sepal.Length, Sepal.Width, data = iris, facets = Species ~ .)

setosa versicolor virginica 5 6 7 8 2.0 2.5 3.0 3.5 4.0 4.5 2.0 2.5 3.0 3.5 4.0 4.5 2.0 2.5 3.0 3.5 4.0 4.5

Sepal.Length Sepal.Width

36 / 45

slide-37
SLIDE 37

Contents

Introduction Have a Look at Data Explore Individual Variables Explore Multiple Variables More Explorations Save Charts to Files Further Readings and Online Resources

37 / 45

slide-38
SLIDE 38

Save Charts to Files

◮ Save charts to PDF and PS files: pdf() and postscript() ◮ BMP, JPEG, PNG and TIFF files: bmp(), jpeg(), png() and tiff() ◮ Close files (or graphics devices) with graphics.off() or dev.off() after plotting

# save as a PDF file pdf("myPlot.pdf") x <- 1:50 plot(x, log(x)) graphics.off() # Save as a postscript file postscript("myPlot2.ps") x <- -20:20 plot(x, x^2) graphics.off()

38 / 45

slide-39
SLIDE 39

Save ggplot Charts to Files

ggsave(): by defult, saving the last plot that you displayed. It also guesses the type of graphics device from the extension.

ggsave("myPlot3.png") ggsave("myPlot4.pdf") ggsave("myPlot5.jpg") ggsave("myPlot6.bmp") ggsave("myPlot7.ps") ggsave("myPlot8.eps")

39 / 45

slide-40
SLIDE 40

Contents

Introduction Have a Look at Data Explore Individual Variables Explore Multiple Variables More Explorations Save Charts to Files Further Readings and Online Resources

40 / 45

slide-41
SLIDE 41

Further Readings

◮ Examples of ggplot2 plotting:

https://ggplot2.tidyverse.org/ ◮ Package iplots: interactive scatter plot, histogram, bar plot, and parallel coordinates plot (iplots) http://rosuda.org/software/iPlots/ ◮ Package googleVis: interactive charts with the Google Visualisation API http://cran.r-project.org/web/packages/googleVis/vignettes/ googleVis_examples.html ◮ Package ggvis: interactive grammar of graphics http://ggvis.rstudio.com/ ◮ Package rCharts: interactive javascript visualisations from R https://ramnathv.github.io/rCharts/

41 / 45

slide-42
SLIDE 42

Online Resources

◮ Book titled R and Data Mining: Examples and Case Studies

http://www.rdatamining.com/docs/RDataMining-book.pdf

◮ R Reference Card for Data Mining

http://www.rdatamining.com/docs/RDataMining-reference-card.pdf

◮ Free online courses and documents

http://www.rdatamining.com/resources/

◮ RDataMining Group on LinkedIn (27,000+ members)

http://group.rdatamining.com

◮ Twitter (3,300+ followers)

@RDataMining

42 / 45

slide-43
SLIDE 43

The End

Thanks! Email: yanchang(at)RDataMining.com Twitter: @RDataMining

43 / 45

slide-44
SLIDE 44

How to Cite This Work

◮ Citation

Yanchang Zhao. R and Data Mining: Examples and Case Studies. ISBN 978-0-12-396963-7, December 2012. Academic Press, Elsevier. 256

  • pages. URL: http://www.rdatamining.com/docs/RDataMining-book.pdf.

◮ BibTex @BOOK{Zhao2012R, title = {R and Data Mining: Examples and Case Studies}, publisher = {Academic Press, Elsevier}, year = {2012}, author = {Yanchang Zhao}, pages = {256}, month = {December}, isbn = {978-0-123-96963-7}, keywords = {R, data mining}, url = {http://www.rdatamining.com/docs/RDataMining-book.pdf} }

44 / 45

slide-45
SLIDE 45

References I

Frank, A. and Asuncion, A. (2010). UCI machine learning repository. university of california, irvine, school of information and computer sciences. http://archive.ics.uci.edu/ml. 45 / 45
