Operations Center Communication Console Brief Bob Dick Presenter: Bob Dick CRITICAL COMMUNICATIONS HOW DO YOU COMMUNICATE TODAY? IN AN EMERGENCY OR CRISIS SITUATION DO YOU HAVE THE TECHNOLOGY PLATFORM TO COMMUNICATE EFFECCTIVELY? ABOUT ACG

slide-1
SLIDE 1

Bob Dick Operations Center Communication Console Brief

Presenter: Bob Dick

slide-2
SLIDE 2

CRITICAL COMMUNICATIONS

HOW DO YOU COMMUNICATE TODAY? IN AN EMERGENCY OR CRISIS SITUATION DO YOU HAVE THE TECHNOLOGY PLATFORM TO COMMUNICATE EFFECCTIVELY?

slide-3
SLIDE 3

ABOUT ACG SYSTEMS

COMMAND AND CONTROL CENTER GROUND RADIO COMMS AIR to GROUND COMMUNICATIONS PTP MICROWAVE INTER OP & REMOTE RADIO ACCESS RECORDING ACG Systems is a communication solution provider capable of delivering complex integrated systems to aviation and federal customers. MARKET LEADER IN AVIATION COMMUNICATIONS

slide-4
SLIDE 4

ABOUT ACG SYSTEMS

MARKET LEADER IN AVIATION COMMUNICATIONS

  • AM Ground/Air Radio:

Park Air, Technisonic, ICOM

  • FM Ground Radio:

Motorola, ICOM, Kenwood

  • Command & Control Consoles:

AVTEC / WAVE / Zetron / Orion / Telex ACG IS A VENDOR NEUTRAL PROVIDER COMMITTED TO CUSTOMER NEEDS

slide-5
SLIDE 5

ACG SERVICES

  • PEOPLE. PROCESS. PRODUCTS

DESIGN AND ENGINEERING CONFIGURATION LOGISTICS PROGRAM MANAGEMENT INTEGRATION TESTING INSTALLATION ACCEPTANCE TESTING HELP DESK SUPPORT TRAINING

slide-6
SLIDE 6

CUSTOMERS

COMMERCIAL AVIATION

slide-7
SLIDE 7

CUSTOMERS

AVIATION RELATED

slide-8
SLIDE 8

What is Communication Console Technology?

Technology that allows you to integrate different communication systems such as radio, telephone into one platform.

slide-9
SLIDE 9

Console System Architecture

Ground Radio Phone switch VPGate™ Console A/G Base Radio LAN/WAN

  • Simple scalable expansion to add positions or

radio/telephone

slide-10
SLIDE 10

CONSOLE POSITIONS INCLUDE:

A. 1 Touchscreen Monitor B. 2 Speakers C. 1 Headset

C

slide-11
SLIDE 11

SAMPLE OPERATOR POSITION

slide-12
SLIDE 12

Sample Airport Operator Position

Intuitive & Logical Design

slide-13
SLIDE 13

Auto & Speed Dial Feature

Lack of immediate access to telephone numbers slows down an operation!

slide-14
SLIDE 14

Sample Airport Autodial Page

Speed dial data bases for immediate access to thousands of numbers

slide-15
SLIDE 15

MOBILE DISPATCH SCOUT

.

SCOUT MOBILE DISPATCH Scout or Ranger installed on a Windows laptop or tablet communicating via secure VPN connection: CONNECTION OPTIONS LTE – Greatest regional mobility to stay connected while on the move Wi-Fi – Site connectivity to increase situational awareness during operational meetings

slide-16
SLIDE 16

Airport Operations Center Ramp Tower Airport Security Police & Fire Communication Console: Value Proposition

How can it improve your the

  • peration?
slide-17
SLIDE 17

VALUE PROPOSITION:

Expand Communications

  • Expand telephone functionality
  • Add access to radio resources: ramp frequencies, TSA, FAA, state & local
slide-18
SLIDE 18

VALUE PROPOSITION:

Expand Communications

  • Increased communications = more informed operational decisions by all

Ground Radio Phone Console A/G Base

Before After

Radio Phone

slide-19
SLIDE 19

VALUE PROPOSITION: Improve Communications

Via intuitive operator GUI & digital/IP voice technology

  • Ease of operation

= increased use of communication tools

  • More expedient comms

= Access to assets allows more time for better, safer decisions

  • Clarity of comms

= Fewer mistakes & misunderstandings

slide-20
SLIDE 20

VALUE PROPOSITION: Improve Communications

Via intuitive design, clarity & timing

slide-21
SLIDE 21

VALUE PROPOSITION: Connect Communications

  • Simultaneous Broadcasting over

Radio & Telephone = Expedites info flow

  • Patching disparate groups reduces

delay of critical information = Timely decision making

  • Enhanced telephone capabilities:

Conferencing, Transferring, Unattended/Attended Call Forwarding

slide-22
SLIDE 22

VALUE PROPOSITION:

Employee production & professional

  • Increase employee production
  • Allows piping of audio for training during downtime
  • Impress potential business partners
slide-23
SLIDE 23

VALUE PROPOSITION:

Enable Mobile Communications

  • Flexible Emergency backup sites w/lower costs
  • Or pick up and go
  • Offsite access for management & critical personnel
  • Future: remote office
slide-24
SLIDE 24

VALUE PROPOSITION:

Recording

ACCESS to playback of communications

  • Instant Recording: Real Time Retrieval, Playback,

Forwarding

  • Long Term: Recording and Archiving
  • Use for QC, Training, Law Enforcement
slide-25
SLIDE 25

VALUE PROPOSITION SUMMARY

EXPAND your ability to communicate with various departments, agencies, airlines IMPROVE the clarity and timing of comms via intuitive GUI design & technology CONNECT radio & telephone comms between those who could not previously talk INCREASE productivity & professional of airport personnel & operation center ENABLE mobility of comms thus increasing flexibility of operation ACCESS immediate and long term recordings

slide-26
SLIDE 26

Bob Dick Thank you! Come and Talk to us at Booth 1000

Presenter: Bob Dick
