Connectivity Will Make Motorcycling Safer

• Hennes Fischer, YAMAHA MOTOR EUROPE, The Netherlands
• Tomohiro Matsuda, KAWASAKI MOTORS EUROPE, The Netherlands
• Arne Purschwitz, BMW MOTORRAD, Germany
• Oliver Kohlinger, HONDA R&D EUROPE, Germany

ITS European Congress Strasbourg, France 21 June 2017

Connectivity Will Make Motorcycling Safer

• Hennes Fischer, YAMAHA MOTOR EUROPE, The Netherlands
• Tomohiro Matsuda, KAWASAKI MOTORS EUROPE, The Netherlands

Benefit: Valuable Contribution to Future Mobility

• 21. June 2017

Page 3

• MCs have a great potential
• Ideal urban mobility
• Minimal space requirements
• Smart combination of leisure and

commuting

• Favourable ecological footprint

Accident data

• 21. June 2017

Page 4

Motorcycle Riders are Vulnerable Road Users

Challenge: Motorcycle Safety

Page 5

USA Europe Japan Development of car and motorcycle fatalities

Source: IfZ

• 21. June 2017

Reasons: Perception Failures

Page 6

Majority of accidents:

Caused by other vehicle driver

Majority of collision partner:

Car

Majority of collision type:

Crossing and turning

Source Data based on country specific studies (USA, Europe, Japan)

50 - 70 %

OV driver causes accident

60 – 90 %

Collision partner is a car

15 – 30 %

Collisions at intersections

• 21. June 2017

Causation and Solution

Page 7

Human Error Digital conspicuity

70 - 90%

perception failure by car driver

I never r saw him.

MAI (Motorcycle Approach Indicator) MAW (Motorcycle Approach Warning)

• 21. June 2017

Technical Solutions

• 21. June 2017

Page 8

Digital Conspicuity Triggering Conditions

Motorcycle Approach Indication (MAI)

• 21. June 2017

Page 9

Day 1.5 – Information with Basic Function & Simple requirements

Information Function

• Basic Beaconing
• Pre-Information for driver

!

Motorcycle Approach Warning (MAW)

• 21. June 2017

Page 10

Day 2 – Warning in critical situations & Higher requirements

Information Function

• Basic Beaconing
• Pre-Information for driver

Sophisticated safety Function

• Higher requirements
• Warnings only in critical situation

Real safety impact as Day 2 function

• 21. June 2017

Page 11

Intersection Violation Warning Left Turn Assistant MAW – Day 2 Requirements for PTW to be recognized Cooperation with car industry standards for car industry

• MAW is a real safety function with only warning in critical situation
• MAW huge impact on motorcycle safety as a DAY 2 function

Car Solutions will not work on Motorcycles

• 21. June 2017

Page 12

Taylor made ITS technology needed

Content

• Limited space
• High vibrations
• Limitation on sensing parameters

Design

• Antenna positioning
• Exposed to elements (rain, humidity, etc.)

No cabin

• Leaning in corners
• Steering by inertia
• High influence of rider

Dynamics

• Width of PTW is under 1 meter
• Vehicle movement
• Higher positioning accuracy needed

Localisation

Triggering Conditions based on cars BUT....

Page 13

• 21. June 2017

Use case: Stationary Vehicle Warning

Hazard light on

✓

(✓)

Parking break

✓

X

Door open

✓

X

Trunk open

✓

X

Drivers seat not occupied

✓

X

Proposal: side stand

X

✓

Motorcycles behave different than cars

• 21. June 2017

Page 14

Use case: Traffic Jam Requirement: …indicate a velocity less than or equal to 30 km/h of at least five

• ther vehicles in at most 100 m distance and the same driving

direction…

Triggering Conditions based on cars BUT....

Page 15

• 21. June 2017

Use case: Traffic Jam

PTW can ride through traffic jam Sends „wrong“ trigger conditions – cancel traffic jam

Motorcycle Industry Initiative

• 21. June 2017

Page 16

Make Motorcycles Part of Connected World

v

Mission: Integration of Motorcycles in Connected Environment

Page 17

• 21. June 2017

Milestone: ACEM Memorandum of Understanding

Page 18

MoU Statement:

“…The ACEM manufacturing members agree to initiate deployment of safety-relevant cooperative ITS on PTWs* in Europe and agree to have at least one of their models available for sale with a cooperative ITS, either as standard equipment or as optional equipment, by 2020.”

Connectivity technology like C-ITS will become a major part of future mobility

Published on 29 September 2014

Signed by all ACEM manufacturing members:

*Powered Two Wheeler

• 21. June 2017

WG leader

CMC Vision & Objectives

Page 19

UNIFICATION & INTEROPERABILITY FEASIBILITY & PROTOTYPING PROMOTING & EXTERNAL RELATIONS

Enhance Riding safety by jointly promoting, researching and developing C-ITS for Motorcycles

• Integrating Motorcycles as an accepted and recognized partner into global future ITS strategies
• Joining our forces to create a common approach on ITS for motorcycles
• Achieving a successful implementation and deployment of motorcycle ITS functions

VISION OBJECTIVES

WG-Leader WG-Leader WG-Leader

• 21. June 2017

Page 20

Thank you for your attention

www.cmc-info.net contact@cmc-info.net
