COMPONENTS AND ACCESSORIES FOR THE AIR DIFFUSION, DISTRIBUTION AND REGULATION

Dampers and operation kits Zone control system Supply air grilles Return air grilles Ceiling diffusers Adapters Y elbow Duct manifolds

Our dampers are manufactured from corrosion- resistant ABS plastic. Insulating properties of this material prevent condensation making it ideal for use with heating/cooling air conditioning systems (temperature range 0- 65°C / 30-140 °F). Dampers serve as airflow capacity regulators in the

• ducts. They control the air supply to the individual
• users. These dampers are of the butterfly type and

allow adjustment of 90° from fully open to closed

• position. 5 control methods are available:

Mechanical, electrical, thermostatic temperature

• control. The thermostatic method allows to control

the dampers proportionally regarding the difference between the actual air temperature and the desired temperature.

DAMPERS AND OPERATION KITS

MODULAR ROUND DAMPERS

Available from diameter 4” up to 14”, the dampers are designed for the direct connection to the flexible ducts or straight to the duct manifold of the A/C unit. The dampers of 14”, 12” (8” on request) feature an

• val shape. These dampers are uniquely designed

and the damper shell is split into two halves which are joined together on site. These stack able dampers ship compactly- saving storage space and shipping costs. Assembly is simple: slide the web into the slot, press the halves together until they click and the damper is ready for use. ABS modular damper diam. 100 mm (4”) DM1104 ABS modular damper diam. 150 mm (6”) DM1106 ABS modular damper diam. 200 mm (8”) DM1108 ABS modular damper diam. 200 mm

• val shape (8”)

ABS modular damper diam. 250 mm (10”) DM1110 ABS modular damper diam. 300 mm

• val shape (12”)

DM1112 ABS modular damper diam. 350 mm

• val shape (14”)

DM1114 Also available 127 mm (5”) DM1105

OPPOSED BLADE DAMPERS

Opposed blade dampers for supply air grilles.

#Code

150x300 mm 12861530 150x400 mm 12861540 150x500 mm 12861550 200x300 mm 12862030 200x400 mm 12862040 200x500 mm 12862050

OPERATION KIT TYPE MECHANICAL

Mechanical operation kit type Mechanical: the control box is connected with 2 m (6-8”) long brake cable to the damper. The cable operates the butterfly to desired setting (On/Off). Oper kit Mechanical (wall) 128907 Oper kit Mechanical (Box) 128908 Oper kit Mechanical component ( New) 1400131

4 OPPOSED BLADE DAMPERS

Opposed blade dampers for ceiling diffusers.

#Code

O.B.D 225*225 For Ceiling Diffuser 12862222 O..B.D 305*305 For Ceiling Diffuser 12863030 O.B.D 385*385 For Ceiling Diffuser 12863838 modu ula lar da damp mper diam 100 mm (4 4”) ”) D Box Wall

• Mac. Comp

Box W ll

OPERATION KIT TYPE EL-WM

The kit type EL-WM: is an electrical control toggle switch system which controls a motorized proportional damper. Main characteristics: Modern design

• Can be installed as an independent unit
• In any existing air conditioning system
• Ergonomic and easy to operate
• Easy adjusting of the airflow
• Several intermediate positions that can be
• Easily secured
• Quick and easy installation
• Dimmer for wall mount installation, motor unit for

damper, 6 m long RJ11 connection cable, installation and operation instructions. AC/DC 12V Transformator not included. Code# Operation kit Opal EL-WM 128913

UNIVERSAL REMOTE CONTROL

This nice and high tech remote control Specially disdain with transparent LCD . u can use with any kind / brands of air-conditioner ,By just pressing the SET button until the code of the A/C will flash on the LCD . The remote control is very thin and contain lithium battery . Code # UNIVERSAL REMOTE CONTROL 11890058

OPERATION KIT TYPE EL-BM

The kit type EL-MB: is an electrical control toggle switch System which controls a motorized proportional damper. Main characteristics:

• Modern design
• Can be installed as an independent unit in

any existing air conditioning system

• Ergonomic and easy to operate
• Easy adjusting of the airflow
• Several intermediate positions that can be

easily secured

• Quick and easy installation

Dimmer for box mount installation, motor unit for damper, 6 m long RJ11 connection cable, installation and operation instructions. AC/DC 12V Transformator not included. Code# Operation kit Opal EL-BM 128914

OPERATION KIT TYPE MOB 128DD

The kit type MOB 128DD is an electronic control unit for a proportional Motorized Opposed Blade Damper that maintains a required room temperature. It can be installed in any existing air conditioning system. The unit is based on a micro-controller that carries out the user’s instructions. The unit provides optimum control of the desired working temperature according to the selected operation mode. Main characteristics:

• Modern design
• Can be installed as an independent unit in any

existing air conditioning system

• Ergonomic and easy to use
• Cooling/Heating selector
• Manual, automatic selector
• Quick and easy installation

Package contents OPAL C128DD thermostat, motor unit for damper with frame adapter for the OBD, connection RJ11 cable lg. 6 m, installation and operation instructions

OPERATION KIT TYPE OPAL MOB RC-11

The OPAL MOB RC-11 is an electronic control system which controls a proportional Motorized Opposed Blade Damper. The system is based on a IR remote control unit that sends the operations commands to a wall mount IR receiver. The receiver is based on a strong micro-controller able to display the operating mode with 5 LEDs and to carry out the operation mode logic and algorithm. Main characteristics:

• Setting timer
• “I feel” temperature sensor on the remote control
• ID code
• On/Off, sleep mode
• Can be installed as an independent unit in any

existing air conditioning system

• Cooling/Heating selector
• Manual, automatic or turbo selector
• Modern design
• Quick and easy installation

Package contents Remote control type KFD, receiver type C612KFD, motor unit for damper with frame adapter for the OBD, 6 m long RJ11 connection cable, batteries for the remote control, installation and operation instructions

OPERATION KIT TYPE MOB 650DD

The kit type MOB 650DD is an electronic control unit for a proportional Motorized Opposed Blade Damper that maintains a required room temperature. It can be installed in any existing air conditioning system. The unit is based on a micro-controller that carries out the user’s instructions. The unit provides optimum control

• f the desired working temperature

according to the selected operation mode. Main characteristics:

• Modern design
• Display with back light
• Flash mount thermostat for standard electrical box
• Can be installed as an independent unit in any

existing air conditioning system

• Ergonomic and easy to use
• Cooling/Heating selector
• Manual, automatic selector
• Quick and easy installation

Package contents OPAL C650DD thermostat, motor unit for damper with frame adapter for the OBD, opposed blade damper dimensions 300x150 mm, 6 m long RJ11 connection cable, installation

and operation instructions.

ckage co cont nten ents k

CONNECTION CABLES RJ11

RJ11 connection cables for damper operation kits.

#Code

1005980400S0010 Length 4 m 140104 1005980450S0010 Length 6 m 140106 1005980500S0010 Length 10 m 140110 1005980550S0010 Length 15 m 140115 1005980550S0010 Length 20 m 140120

POWER SUPPLY TYPE C-315 FOR STAND ALONE CONFIGURATIONS

The power supply units type C-315 feature up to 4 12 V output channels for the electrical proportional dampers. Main characteristics:

• Input nominal voltage 230 Vac 50-60 Hz
• Non-flammable plastic ABS – V0
• Motor operation voltage 12 V
• Operation indication light
• UL/IEC certificates

#Code

Power supply output 1 channel 1400315 Power supply output 2 channels 14003152 Power supply output 4 channels 14003154

SPLITTER FOR RJ11 CABLES

RJ11 connection cables for damper operation kits To split 2 dampers with 1 operation kit.

#Code

RJ spliter (for white cabel) 140011 RJ spliter (for black cabel) 140012

CONNECTION EXAMPLES “STAND ALONE” CONFIGURATION

S p l i t e r- C o n n e c t i n g o n e thermostat or one Remote control and 2 dampers by using the RJ-11splitter. C-3154 Power Supply box 4 channels- connecting 4 Remote controls or 4 thermostats through the power supply box to 4 dampers C-3152 Power Supply box 2 channels- connecting 2 Remote controls or 2 thermostats through the power supply box to 2 dampers C-3151 Power Supply box 1 channel-connecting Remote control or thermostat through the power supply box to the damper

PROPORTIONAL MULTIZONE CONTROL SYSTEM

Why zone control- ZC-207DK

• Provides room by room comfort control
• Reduces equipment run time
• Eliminates hot/cold rooms
• Works with conventional air conditioning units, fan coils and heat pumps.
• Allows you to heat or cool only the areas you want, when you want
• Saves energy and reduces utility bills up to 40%
• Up to 7 modulation rooms (zones) + proportional electrical controlled BY-PASS
• Quick and easy installation

18º 19º 22º 21º 19º 21º 20º

UP TO 7 ZONES

+ PROPRTIONAL BYPASS

PROPORTIONAL DRY CONTACT MULTIZONE ZONE SYSTEM ZC-207DK PROPORTIONAL MULTI ZONE SYSTEM- ZC-207

The Proportional Dry Contact Multi zone System Type ZC-207DK has a dry contact controller. Designed to control up to 7 zones with round ABS dampers (diam. 4”, 6”, 8”, 10” 12” or 14” ), and By–Pass electrical proportional damper, 2 relays and communication port. The communication port allows connecting additional controller to the main one. This feature allows connecting up to 14 zones to one system. The ZC-207DK have indication panel that will display the status of system

• peration. It operates the air conditioning unit by two dry contacts relays and is not interfering with the air conditioning
• controller. The A/C will receive the command to operate or shut off according to the total system demand for cooling or
• heating. The controller receives operation commands from each zone and controls the air damper proportionally. The

system is equipped with quick connectors to ensure convenient and quick installation of the system elements. Package contents Power supply , Main board PCB, motor unit for by-pass damper, 8 black & red 6m long cables, installation and operation instructions. The Proportional Multi zone System ZC-207 is designed to control up to 7 zones with round ABS dampers (diam. 4”, 6”, 8”, 10” 12” or 14” ), By–Pass electrical proportional damper, 2 relays and communication port. The communication port allows connecting Additional controller to the main one. This feature allows connecting up to 14 zones to one system. The ZC-207 have indication panel that will display the status of system operation. It operates the air conditioning unit by two dry contact relays and is not interfering with the air conditioning controller. The A/C will receive the command to operate or shut off according to the total system demand for cooling or heating. The controller receives operation commands from each zone and controls the air damper proportionally. The system is equipped with quick connectors to ensure convenient and quick installation of the system elements. The controller C-207 automatically identifies the number of zones connected to it and the opening position of the dampers respectively, the controller will calculate the air conditioning load. According to the accumulation of the total openings of the dampers, the proportional electrical by-pass damper and air conditioner’s operation is adjusted to the required level of air

• conditioning. Consequently, with the decrease in heat or cool load, the evaporator fan speed will decrease, the compressor

will stop its operation and in parallel, the by-pass damper will fully open to drain surplus air volume in the system and make an easy start for the fan in the next operation cycle. The main board C-207 controls: the evaporator fan speeds,

• ne or two stage compressors, heat pump which operates

in the heating mode, condenser fan speeds and fan coil. Package contents Power supply, main board PCB, motor unit for by-pass damper, 7black&red 6m long cables, installation and operation instructions.2 sensors, c-130 panel control. k& d 6 l bl i t ll ti CODE# 1289207DK CODE# 1289207ZC

CODE# 128910KFD CODE# 1289650DD CODE# 128909

OPERATION KIT TYPE OPAL RC-11

The kit type OPAL RC-11 is an electronic control system which controls an electrical proportional damper. The system is based on a IR remote control unit that sends the operations commands to a wall mount IR receiver. The receiver is based on a strong micro-controller able to display the operating mode with 5 LEDs and to carry

• ut the algorithm operation mode logic.

Main characteristics:

• Setting timer
• Remote control with “I feel” function
• ID code
• On/Off, sleep mode
• Can be installed as an independent unit in any

existing air conditioning system

• Cooling/Heating selector
• Manual, automatic or turbo selector
• Modern design
• Quick and easy installation

Package contents Motor unit for damper, 6 m long RJ11 connection cable, batteries for the remote control, installation and

• peration instructions.

OPERATION KIT TYPE OPAL 650-DD

The kit type OPAL 650DD is an electronic control unit for an electrical proportional damper that maintains a required room temperature. It can be installed in any existing air conditioning system. The unit is based on a micro-controller that carries out the user’s

• instructions. The unit provides optimum control of the

desired working temperature according to the selected

• peration mode.

Main characteristics:

• Modern design
• Display with back light
• Flash mount thermostat for standard electrical box
• Can be installed as an independent unit in any

existing air conditioning system

• Ergonomic and easy to use
• Cooling/Heating selector
• Manual, automatic selector
• Quick and easy installation

Package contents Motor unit for damper, connection RJ11 cable lg. 6 m, installation and operation instructions

OPERATION KIT TYPE OPAL C-128DD

The kit type OPAL C-128 is an electronic control unit for an electrical proportional damper that maintains a required room temperature. It can be installed in any existing air conditioning system. The unit is based on a micro-controller that carries out the user’s

• instructions. The unit provides optimum control of the

desired working temperature according to the selected

• peration mode.

Main characteristics:

• Modern design
• Can be installed as an independent unit in any

existing air conditioning system

• Ergonomic and easy to use
• Cooling/Heating selector
• Manual, automatic selector
• Quick and easy installation

Package contents Motor unit for damper, 6 m long RJ11 connection cable, installation and operation instructions.

DRY CONTACT FOR INVRTER A/C

For inverter A/C These cable are intended to be used for the connection of the dry contact from the ZC- 207DK of the multizone PCB to the dry contact of the ducted units Cable for Daikin unit 140130DK Cable for Mitsubishi unit 140130MS Cable for Sanyo unit 140130SN Cable for LG unit 140130LG Cable for Fujitsu unit 140130FJ

MULTI ZONE Kit ZC207DK 7 rooms+ By pass Opal RC-11 Kit Code # 128910KFD Opal 650DD KIT Code #1289650 DD Opal 128DD KIT Thermostat Code # 128909 Dampers Code # (4”) 100mm DM1104 (6”)160mm DM1106 (8”)200mm DM1108 10”)250mm DM1110 (12”)315mm DM1112 (14”)355mm DM1114 ZC 207 DK +PS200 Code # 1289207 DK Remote control +I.R receiver flush Mount Thermostat Wall Mount Thermostat 8 motor Cables 1 Motor Damper for bypass 1 RJ-11 cable 1 Motor Damper 1 RJ-11 cable 1 Motor Damper 1 RJ-11 cable 1 Motor Damper

2 Z O N E S 1 Room + 1 salon 1 + 2 O R 2 O R 2 + 3 2 D a m p e r s + 1 B Y- PA S S D a m p e r 3 Z O N E S 2 Room + 1 sal o n 1 + 3 O R 3 O R 3 + 4 3 D a m p e r s + 1 B Y- PA S S D a m p e r 4 Z O N E S 3 Room + 1 salon 1 + 4 O R 4 O R 4 + 5 4 D a m p e r s + 1 B Y- PA S S D a m p e r 5 Z O N E S 4 Room + 1 salon 1 + 5 O R 5 O R 5 + 6 5 D a m p e r s + 1 B Y- PA S S D a m p e r 6 Z O N E S 5 Room + 1 salon 1 + 6 O R 6 O R 6 + 7 6 D a m p e r s + 1 B Y- PA S S D a m p e r

ALL THE REASONS TO USE

™

L O N G L I F E P L A S T I C A I R C O N D I T I O N I N G A C C E S S O R I E S

BY

™

Complete range of top quality & modular plastic grilles, diffusers, Y elbow, return air grilles, adapters, duct manifold, Opposed Blade dampers, manual and electric proportional dampers, controls and thermostats for A/C and Zone control system, all under one roof. For the air conditioning and ventilation industry. Long life products even under harsh environmental conditions. Corrosion-resistant, no condensation. Reduce cost and time in installation. Light weight. Fine engineering and control for even air distribution to all zones. Manufactured by injection moulding, strong and scratch-resistant. Over 500 standard products. The standard color is white but other colors can be supplied for large quantities.
