Platzhalter fr Bild, Bild auf Titelfolie hinter das Logo einsetzen Communication Architecture, Challenges and Paradigms for Robotic Firefighters Sebastian Schildt, Stephan Rottmann and Lars Wolf Extremecom 2013, Iceland The RFF Project
SLIDE 2
SLIDE 3
Sebastian Schildt | RFF Communication Architecture | Page 3 / 19
Situations
- S&R in case of Fire
- Indoor fire
- Outdoor (forest fire, bush fire)
- Earthquakes
- Terrorist Attacks
- Operation in Radioactive Environments
SLIDE 4
Sebastian Schildt | RFF Communication Architecture | Page 4 / 19
RFF Vision
SLIDE 5
Sebastian Schildt | RFF Communication Architecture | Page 5 / 19
RFF Goals
Build IT concepts and framework for robot teams in disaster management scenarios Combining fields of
- Robot Research: Actuators & Sensors (“the hardware”)
- Multi-Agent Research (autonomy, cooperation, coordination)
- Communication (holding it all together in light of harsh and
unpredictable conditions) This is not an exercise in algorithms: Prototypes and Demonstrators right from the start!
SLIDE 6
Sebastian Schildt | RFF Communication Architecture | Page 6 / 19
Distributed Common Information Model
SLIDE 7
Sebastian Schildt | RFF Communication Architecture | Page 7 / 19
dCIM Datatypes
- Time and Position
- Gridmaps
- No topology maps (except a-priori knowledge to seed grid map)
- Distributed Object/Incident database
- Reporting Unit
- Coordinates
- Timestamps
- States, Goals, Plans
SLIDE 8
Sebastian Schildt | RFF Communication Architecture | Page 8 / 19
Dropbox Concept
Improve Information Proliferation Mobile RFF units transport droppable communication boxes WSN Dropbox
- Battery Powered
- INGA Node
- IEEE 802.15.4 & muDTN
SLIDE 9
Sebastian Schildt | RFF Communication Architecture | Page 9 / 19
WSN Dropbox
SLIDE 10
Sebastian Schildt | RFF Communication Architecture | Page 10 / 19
WSN Dropbox Scenario
SLIDE 11
Sebastian Schildt | RFF Communication Architecture | Page 11 / 19
DCIM Dropbox
Aggregate and distribute DCIM data
- Battery Powered
- Wi-Fi & IBR-DTN Bundle Protocol Implementation
- Storage
- Raspberry Pi-based
- Sealed custom case
- Inductive Charging
SLIDE 12
Sebastian Schildt | RFF Communication Architecture | Page 12 / 19
DCIM Dropbox Prototype
Charge Controller / Voltage Regulator Power-On Circuit LiPo Cells RaspberryPi SBC Reed Contact WiFi Module
SLIDE 13
Sebastian Schildt | RFF Communication Architecture | Page 13 / 19
Droppbox Scenario 2
A B C
Can be dropped based on a-priori knowledge Can be dropped, in case of low connectivity, or as markers
Trajectories Blocked Path Dropbox Target Robot Destination
SLIDE 14
Sebastian Schildt | RFF Communication Architecture | Page 14 / 19
Current DCIM Dropbox Prototype (WIP)
SLIDE 15
Sebastian Schildt | RFF Communication Architecture | Page 15 / 19
From Concepts to Prototypes
For rapid transition from concepts to working prototypes, RFF uses VREP +ROS for development
Physics Simulation Robot Kinematics Environment Collisions, etc. Components and Middleware for Developing Robot Applications
SLIDE 16
Sebastian Schildt | RFF Communication Architecture | Page 16 / 19
VREP
SLIDE 17
Sebastian Schildt | RFF Communication Architecture | Page 17 / 19
Experimental Platform
6-wheeled Dagu “Wild Thumper” Platform WSN Dropbox Dropping Mechanism Beaglebone SBC as Controller Custom Interface Board raspINGA IEEE 802.15.4 radio Motor Drivers
SLIDE 18
Sebastian Schildt | RFF Communication Architecture | Page 18 / 19
Experimental Platform
GPS Receiver Camera Ultrasonic Distance Sensor Dropping Mechanism Electronics German Oak
(for size Comparison)
