Coherent radio pulses from high energy showers: A blooming field

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

1

Enrique Zas

Instituto Galego de Fisica de Altas Enerxias & Universidad de Santiago de Compostela

In the memory of a brilliantly original mind

slide-2
SLIDE 2

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

2

Particles radiate (or induce radiation Cerenkov)

  • Radiation adds coherently for low enough frequencies
  • Power of coherent radiation scales with (shower particles)2
  • Showers have lots of particles => Interesting for UHE!

Interference effects give rich diffraction patterns

  • Shower could be fully visualized if sufficiently well sampled !!

(amplitude & phases in every direction)

Signal: contributions from many (all) shower stages

  • Reduced fluctuations => good observable

Antennas: cheap Radio detection: high duty cycle Main difficulty: dealing with noise

slide-3
SLIDE 3

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

3

58 J. Jelley 58 extend Cherenkov to radio 61 G. Askary’an excess Q=∆q 65 In air: high ν 65 J. Jelley 8 “mechanisms” (ICRC65)

  • Enhanced Cherenkov(Askary’an)
  • Dipole Cherenkov
  • Synchrotron radiation
  • Transition radiation
  • Coulomb field bremsstrahlung
  • Induction (by nearby charges)
  • Molecular transitions
  • Reflections of continuous waves (Doppler shifted)

67-70 Air: e+e- separation in BGeo dominant (Th & exp) 75 decline of field, steep ldf, storm interference … 90 ν detection: full calculations in ice (ZHS)

New initiatives radio telescopes, air showers, ice, salt …

00 Lab measurements Air showers 1st generation LOPES, CODALEMA, ANITA (GHz) 10 Full simulations (ZHS algorithm + MC) 2nd generation LOFAR, AERA, Tunka-Rex (E,Xmax) 20 Ambitious plans: GRAND, AugerRadio, phased arrays …

Complex some are limiting cases

  • f given situations

but it is all in Maxwell’s laws!

slide-4
SLIDE 4

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

4

Calculations are key: Based on simple solution

Maxwell’s Equations in transverse gauge The transverse current is the divergenceless component (the transverse projection at large distances) Well known solution, Vector potential A gives us the radiated field

Delta of Retarded time with

nc = με

slide-5
SLIDE 5

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

5

Solve for simple case (constant speed)

t1 t2 v v=0

position

δt=t2-t1

slide-6
SLIDE 6

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

6

Organize t and t’ and massage

vδt

θ Fraunhofer approximation

i.e.

slide-7
SLIDE 7

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

7

Substitute into solution for A

Divergence at Cherenkov angle? NO!! We formally get derivative of Theta funciton Limit Note A proportional to TRACKLENGTH CHERENKOV Radiation

slide-8
SLIDE 8

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

8

Vector potential E-field

Time

Field single track: Time domain

“Decceleration” “Acceleration”

[J. Alvarez Muniz, A. Romero-Wolf, E.Z., PRD 81, 123009 (2010)]

NOTE: “Acceleration” with a grain of salt Limit of large δt gives Cerenkov radiation (by medium) Terms of adjacent sub-tracks give large cancellations

slide-9
SLIDE 9

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

9

) ( 1 1 ) (

) ( ) (

v k i e v e R i E

t v k i phase

  • verall

i

  

 

⋅ − − =

⋅ − ⊥ −

ω ω ω

δ ω

[ ]

t n t n t v ω θ β ω θ β δ ) cos 1 ( ) cos 1 ( sin − −

⊥

trackl klength

if ω=0

  • r θ=θc
  • r δt=0

t v δ

⊥

(Fraunhofer limit)

Fourier transform => ZHS

State -o f-the -art: simulatio ns AI RE S / CORSI K A + Zas-Halze n-Stane v alg o rithm (c lassic al e le c tro mag ne tism)

[E.Z., F. Halzen, T. Stanev PRD45 (1992) 386]

slide-10
SLIDE 10

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

10

Askary’an effect: excess charge

G.A. Askaryan

slide-11
SLIDE 11

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

11

  • J. A-M, A. RW, E

. Z, PRD 81, 123009 (2010)

J(z,t) = v Q(z) δ(z - vt) A(to bs, θ) ≈ v Q(ζ) / R

Vector potential

E(to bs, θ) = d A(to bs, θ)/ d to bs

Electric field ζ → Retardation + time-compression:

F ro m z to time to bs (θ –d e pe nd e nt)

to b s = z(1 - nc o sθ)/ c + t0 to b s = t0 @ θc

Unidimensional current

slide-12
SLIDE 12

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

12

Interesting for neutrino detection e showers & hadronic debris separate (LPM) Flavor tagging : νe Measure y (energy transfer to hadrons)

slide-13
SLIDE 13

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

13

νe + N → e + jet

E(νe) = 10 EeV E(hadron jet) = 2 EeV E(electron) = 8 EeV

slide-14
SLIDE 14

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

14

slide-15
SLIDE 15

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

15

Pulseahead of time!

Path difference

θ > θc

Emission out of phase L path difference =λ => diffraction minimum like in a single slit L ~ slit width

slide-16
SLIDE 16

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

16

The slit diffraction analogy

If current is “thin”:

∫

∝

ikz

e z dzQ R i E ) ( ) ( ω ω 

c n k ω θ) cos 1 ( − =

FT with

θc

Great scaling properties: reduced fluctuations

integrated emission (“calorimetric”)

slide-17
SLIDE 17

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

17

Esh (TeV)

slide-18
SLIDE 18

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

18

Esh (TeV)

slide-19
SLIDE 19

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

19

Esh (TeV)

slide-20
SLIDE 20

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

20

Path difference = d sinθc

θc

Blow up of shower front In Cherenkov direction: d sinθ= λ Interference minimum at lower λ(higher frequency)

d

slide-21
SLIDE 21

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

21

slide-22
SLIDE 22

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

22

Why is the atmosphere so different?

Opposite charges cancel!!

The Cherenkov angle is small ~ 10

J┴ = Q v┴ ~ 0.2Nec sin θ ~ 0.003 Nec (Askary’an) B → transverse current ~ v┴drift ~ qB┴/ρ ~ 0.04c J┴ = Q v┴drift ~ 0.04 Nec (geomagnetic) often dominant

Depends on sin(α) [angle between shower axis and B field]

  • O. Scholten et al. ApP29(2008)94
slide-23
SLIDE 23

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

23

Jgeo

B

Sho we raxis

v

Ge o mag ne tic Askaryan

Polarization of two components is different

However new complex issues: Loss of symmetry (mixed patterns) There is a varying refractive index There is curvature of the atmosphere …

F ro m e xc e ss c harg e

slide-24
SLIDE 24

Lessons from experiments

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

24

slide-25
SLIDE 25

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

25

Many activities pursued

>89 On Moon from Earth: GLUE, ATCA, LUNASKA, LOFAR … >96 In Ice: Rice, ARA, ARIANNA … >00 On “lab”: SLAC (Silica Sand, Salt, Ice, Air+B), Utah (ARAcalTA) … >03 In air: LOPES, CODALEMA, AERA, LOFAR, Tunka-Rex… >03 In ice from air: ANITA … >10 in air microwave: MIDAS, CROME, EASIER, MAYBE ...

R.D. Dagkesamanskii, I.M. Zheleznykh, Sov. Phys. JETP Lett. 50(1989)259 …

  • P. Gorham, D. Saltzberg et al. PRL86(2001)2802 …
  • P. Gorham, et al. PRL96(20006)171101

D.Ardouin; H. Falcke …

  • G. Frichter; D.Besson; D. Seckel; …
  • P. Privitera; A. Lettessier-Selvon; R. Smida; V. Verzi, …
slide-26
SLIDE 26

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

26

Xmax reliably measured!

Buitnik, S. et al. Nature 531 (2016) 70

slide-27
SLIDE 27

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

27

Energy in radio is an excellent energy estimator!

The Pierre AugerCollaboration, PRL 116, 241101 (2016); PRD 93 122005 (2016)

slide-28
SLIDE 28

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

28

36 km high

ν

14 events CR detected! Why GHz radiation?

  • P. Gorham, et al. PRL105(2010)151101
slide-29
SLIDE 29

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

29

Path difference = d sinθc

θc

Blow up of shower front At θc coherence up to the GHz in spite of scale factor!!

d

Diameter 1000 times larger BUT θc VERY small

slide-30
SLIDE 30

Insight from time delays

Antarctica proton 1019 eV

Observer at position such that shower center (0,0) is viewed viewed at Cherenkov angle

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

30

Alvarez-Muñiz, et al. PRD 86 (2012) 12300

slide-31
SLIDE 31

Blow up of central region

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

31

slide-32
SLIDE 32

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

32

Different spectra as we get away from Cher angle

Inner cone ψ=0.70 ψ=0.620 ψ=0.550 ψ=0.480 ψ=0.40 ψ=0.330 ψ=0.250 ψ=0.180 ψ=0.110

slide-33
SLIDE 33

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

33

Inner cone ψ=0.70 ψ=0.620 ψ=0.550 ψ=0.480 ψ=0.40 ψ=0.330 ψ=0.250 ψ=0.180 ψ=0.110

slide-34
SLIDE 34

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

34

Inner cone ψ=0.70 ψ=0.620 ψ=0.550 ψ=0.480 ψ=0.40 ψ=0.330 ψ=0.250 ψ=0.180 ψ=0.110

slide-35
SLIDE 35

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

35

Excellent scaling with energy

Inner cone ψ=0.70 ψ=0.620 ψ=0.550 ψ=0.480 ψ=0.40 ψ=0.330 ψ=0.250 ψ=0.180 ψ=0.110

slide-36
SLIDE 36

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

36

  • H. Schoorlemmeret al. Astropart.Phys. 77 (2016) 32-43
slide-37
SLIDE 37

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

37

Gorham et al. PRL117(16)071101 Gorham et al. PRL121(18)161102

slide-38
SLIDE 38

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

38

slide-39
SLIDE 39

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

39

A Romero-Wolf et al. ArXiv:1811.07261

slide-40
SLIDE 40

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

40

The future is Big and Bright

URGENT need to explore the PeV to EeV neutrino region

In Ice experiments -> Phased Array, NGR

(Next Generation Radio Array)

In Air from Ice experiments -> EVA, GRAND In Air: Auger, SKA, GRAND (neurinos & CR)

slide-41
SLIDE 41

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

41

A.G. Vieregg, K. Bechtol, A. Romero-Wolf; JCAP 1602 (2016) no.02, 005

slide-42
SLIDE 42

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

42

G ra nd35 (2.4 km 2) 2018 G ra nd300 (135 km 2) 2020 1016.5- 1018eV G ra nd10K (104 km 2) 2025 G ra nd200K (2 105 km 2) 2035?

  • J. Alvarez-Muñiz et al ArXiv:1810.09994
slide-43
SLIDE 43

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

43

J.HörandelUHECR, Paris 2018

slide-44
SLIDE 44

Thank You

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

44

There has been much progress in radio Manyinitiatives are being pursued explored Ambitiousplanstargetingphysicsare quite advanced Surely new ones are bound to crop up The future is wide open

slide-45
SLIDE 45

What have we been looking for?

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

45

slide-46
SLIDE 46

Energy in radio correlated with shower energy

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

46

slide-47
SLIDE 47

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

47

slide-48
SLIDE 48

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

48

(SquareKilometerArray)

MID Frequency ApertureArray LOW Frequency ApertureArray

  • world’s largest radio telescope
  • 1 km2 of total collecting area
  • thousands of antennas
  • to be built in Australia &

South Africa

  • broad scientific goals:

astronomical& cosmological obs.

  • “phased array": can observe

multiple regions of sky simultaneously!!

  • Moon proposed to be observed at

differentfrequency bands:

  • SKA-LOW (100 – 750 MHz)
  • SKA-MID (350 – 1760 MHz)
  • can also detect UHECRs
slide-49
SLIDE 49

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

49

slide-50
SLIDE 50

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

50

slide-51
SLIDE 51

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

51

slide-52
SLIDE 52

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

52

slide-53
SLIDE 53

Why is the atmosphere so different?

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

53

slide-54
SLIDE 54

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

54

Path difference = w cos θc

θc

Further blow up of front

w

Interference from late and early particles within shower front Often 2ndorder

Shower front thickness and curvature play the limiting role

slide-55
SLIDE 55

proton shower of energy 1019 eV in Antarctica at Cherenkov angle

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

55

slide-56
SLIDE 56

Is the picture Complete?

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

56

slide-57
SLIDE 57

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

57

Reflection

  • Earth’s curvature
  • Roughness

Refractive Index

  • Ray’s curvature
  • Variability
slide-58
SLIDE 58

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

58

slide-59
SLIDE 59

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

59

Events can be reconstructed from single location!!

slide-60
SLIDE 60

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

60

slide-61
SLIDE 61

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

61

slide-62
SLIDE 62

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

62

slide-63
SLIDE 63

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

63

slide-64
SLIDE 64

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

64

slide-65
SLIDE 65

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

65

slide-66
SLIDE 66

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

66

slide-67
SLIDE 67

The future is wide open

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

67

slide-68
SLIDE 68

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

68

toroidal reflector feed array @ focus

  • Concept: Turn an entire super pressure

balloon into the antenna !!

Similar sensitivity to full, 3 y

  • f ground-based arrays

G o rha m e t a l. APP 35, 242 (2011)

slide-69
SLIDE 69

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

69

slide-70
SLIDE 70

Coherent radio detection: ν- experiments

Natural transparent media

 ICE:

 Antarctica

 RICE (array buried)  ANITA (balloon)

 Greenland

 FORTE (satellite)  SALT:  Domes explored  SALSA  MOON REGOLITH:

 Radiotelescopes

 GLUE

 Radiotelecope array

 LUNASKA (ska)  ATMOSPHERE:

 Antenna array

 LOFAR

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

70

slide-71
SLIDE 71

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

71

Askary’an effect confirmed: SLAC

P.Gorham, D.Saltzberg et al. PRL (2000)

slide-72
SLIDE 72

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

72

slide-73
SLIDE 73

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

73

Coherence! |E| α Esh |E(ω)| spectral agreement

slide-74
SLIDE 74
  • Radio Technique has an enormous potential

 To detect highest energy events  To get detail about showers  To cover large surfaces

  • It is my opinion (and others) that radio could

provide the next step in the search for UHE radiation

  • There are many projects under consideration
  • It is worth investing on them (lot work to do)

EZ Heidelberg 2018 Coherent radio pulses from high energy showers

74

Summary and conclusion:
