Coffee Bean Sorter Orange Team Outline 2. Customer 3. Product 4. Distribution 4. Distribution Motivation Gourmet size requirement Limited processing technology ~17/64 Customer As Green as it Gets Works with a farming cooperative

slide-1
SLIDE 1

Coffee Bean Sorter

Orange Team

slide-2
SLIDE 2

Outline

  • 2. Customer
  • 3. Product
  • 4. Distribution
  • 4. Distribution
slide-3
SLIDE 3

Motivation

  • Gourmet size

requirement

  • Limited processing

technology

~17/64”

slide-4
SLIDE 4

Customer

As Green as it Gets Works with a farming cooperative in Guatemala Maya Pedal Builds human-powered agricultural tools

slide-5
SLIDE 5

Global Market

20-25 million small-scale coffee farmers worldwide

slide-6
SLIDE 6

Screen Sorting Drum Sorting

Sorting Methods

slide-7
SLIDE 7

Our Solution

slide-8
SLIDE 8

Hopper Design

Challenge:

– Accommodate the average farmer – Small or large batch loading

slide-9
SLIDE 9

Hopper Design

Challenge:

– Accommodate the average farmer – Small or large batch loading

slide-10
SLIDE 10

Bean Paths in Drum

Undersized Optimal Size Oversized

slide-11
SLIDE 11

Drums

Challenge: Accuracy

– 15 undersized beans per pound – Dependent on:

  • Feed rate: 230 lb/hour
  • Turning rate : ¼ turn per sec
  • Drum Length: 48 in
  • Drum angle: 1 degree
slide-12
SLIDE 12

Collection Bags

Challenge:

– Quick loading and unloading – Visible throughput

slide-13
SLIDE 13

Frame

Challenge:

– Easily manufactured – No sharp corners

slide-14
SLIDE 14

Frame

slide-15
SLIDE 15

Benefit Analysis

  • 10 times faster
  • Annual revenue increase of 10%
  • Net Present Value of $800
slide-16
SLIDE 16

Cost Analysis

  • $205 material costs
  • Fabrication costs

– Estimated 20 hours of labor – $36 in labor

  • Payoff in 2 months of use
slide-17
SLIDE 17

Distribution Scheme

  • Building plans
  • Field test prototype
  • Worldwide dissemination
slide-18
SLIDE 18

Questions?

slide-19
SLIDE 19

Bean Dynamics and Diameter

Better for sorting Worse for sorting Beans mix rather than bounce Beans bounce and fly Tumbling helps beans mix between layers But with too much tumbling, the beans do not contact the drum surface enough to sort

slide-20
SLIDE 20

Drum diameter Drum angle Drum length Rotation rate Hopper feed rate Improving Accuracy Improving Rate Design parameter

Results of Testing

slide-21
SLIDE 21

Optimization of Drum Dimensions and Rotation Rate

Drum angle Rotation rate rot/sec Diameter Length Total rate lbs/hr Defect occurrence rate beans/lb 2 0.5 big short 225 327 2 0.33 big short 260 130 2 0.33 big short 235 96 2 0.25 big short 230 66 2 0.25 small short 240 47 2 0.25 small long 230 20

slide-22
SLIDE 22

Black Pergamino Genetically Deformed Rocks or Twigs Cherry

Eye Eye

Sorting Each Bean Type

Size Size Size

slide-23
SLIDE 23

Cost Analysis

Material Cost

25 meters Angle Iron

$25

(2) 4’ x 8’ Sheet Metal

$70

(1) 4’ x 8’ Screens

$35

18 tabular feet of 3/4” plywood

$45

Fasteners

$30

Total

$205

slide-24
SLIDE 24

Customer

As Green As It Gets

  • Works with a farming

cooperative in Guatemala

MayaPedal

  • Builds human powered

agricultural tools

slide-25
SLIDE 25
  • Builds human powered

agricultural tools

Customer

As Green As It Gets MayaPedal

  • Works with a farming

cooperative in Guatemala

slide-26
SLIDE 26

Customer

  • As Green As It Gets

– Works with a farming cooperative in Guatemala

  • MayaPedal

– Builds human powered agricultural tools

slide-27
SLIDE 27

Hopper Design

  • Challenge:

– Accommodate the average farmer – Small or large batch loading
