Green and Sustainable Remediation CLICK TO EDIT MASTER TITLE STYLE Presented by: Amanda Ludlow, Principal Scientist ROUX ASSOCIATES, INC. Environmental Consulting Roux Associates, Inc. & Management June 7, 2017 Green and Sustainable

SLIDE 1

ROUX ASSOCIATES, INC.

Environmental Consulting & Management

CLICK TO EDIT MASTER TITLE STYLE

June 7, 2017

Green and Sustainable Remediation

Presented by:

Amanda Ludlow, Principal Scientist Roux Associates, Inc.

SLIDE 2

Green and Sustainable Remediation

 Definitions  U.S. Environmental Protection Agency  “The practice of considering all environmental

effects of remedy implementation and incorporating

ptions to maximize net environmental benefit of

cleanup actions.”

 Interstate Technology Regulatory Council (ITRC)  “The site-specific employment of products, processes,

technologies, and procedures that mitigate contaminant risk to receptors while making decisions that are cognizant of balancing community goals, economic impacts, and net environmental effects.

 New York State  “The practice of considering all environmental

effects of remedy implementation and incorporating

ptions to minimize the environmental footprint of

cleanup actions.”

SLIDE 3

Why GSR?

 Improved stakeholder engagement

 Community benefits  Educational opportunities  Collaboration

 Simplified, reproducible results

 Quantify desired metrics

 Reduced impacts

 Emissions / greenhouse gases  Energy/Water/Waste  Ecosystems

SLIDE 4

Sustainable Remediation

SLIDE 5

Brief History

 2006 – Sustainable Remediation Forum (SURF) formed; SURF formally

integrates sustainable principles, practices, and metrics into remediation projects and works to foster GSR on a national and international basis

 2007 – Association of State and Territorial Solid Waste Management

Officials (ASTSWMO) creates Green Cleanups Task Force which advocates for what are referred to as “greener cleanups”

 2008 – EPA develops The Green Remediation Technical Primer and forms the

EPA/State Greener Cleanup Working Groups

 2010 – NYSDEC issues DER-31 which establishes a preference for

remediating sites in the most sustainable manner while still meeting all legal, regulatory and program requirements

 2011 – Interstate Technology Regulatory Council (ITRC) publishes Green and

Sustainable Remediation Technology Overview (GSR-1) and GSR Technical/Regulatory Guidance (GSR-2)

 2013 – American Society of Testing and Materials (ASTM) publishes two

standard guides: Greener Cleanups (E2893), Integrating Sustainable Objectives into Cleanup (E2876), Best Management Table in Excel format

SLIDE 6

GSR

Environmental Social Economic

Sustainability

SLIDE 7

Core Elements

Energy Air Water Land & Ecosystems Material & Waste

Minimize energy use Increase renewable energy Minimize emissions Minimize water use Preserve water quality Conserve material resources Minimize waste Protect land and ecosystem services

SLIDE 8

GSR Planning

Investigation Remedy Selection Remedial Design Construction O&M Closure

Level 3 BMPs + Advanced Evaluation Level 2 BMPs + Simple Evaluation Level 1 Best Management Practices

Increasing Tool Complexity and Data Needs

SLIDE 9

EPA

Green Remediation

BMP Fact Sheets (13)

Sustainability Concepts

in Decision-Making

ASTM

Standard Guide for

Integrating Sustainable Objectives into Cleanup

Standard Guide for

Greener Cleanups

ITRC

Green and

Sustainable Remediation: A Practical Framework

SuRF

Framework for

Integrating Sustainability into Remediation Projects

BMPs

Best Management Practices (BMPs)

 Project Planning  Sampling & Analysis  Site Preparation & Restoration  Water Quality  Residual Management  Materials  Vehicles and Equipment  Power and Fuel  Buildings

SLIDE 10

GSR Tools – Level 1

 EPA fact sheets

 Introduction to BMPs  Site investigation  Excavation  Pump and treat  Bioremediation  SVE & Air Sparging  Clean fuel and emission

technologies

 Renewable energy

SLIDE 11

BMP Examples

Minimize impacts to natural resources Engage stakeholders Identify recycling/ reuse options Maximize renewable energy use Use local labor and resources Reuse unimpacted soil

SLIDE 12

GSR Tools – Level 2

 California Department of Toxic Substances Control

Green Remediation Evaluation Matrix (GREM)

Metrics Option 1 - SVE Option 2 - MNA Relative Importance Yes/No Score* Yes/No Score* Air emissions Yes 2 Yes 1 1 Solid waste Yes 2 Yes 1 1 Wastewater Yes 1 Yes 1 1 Noise/odor/vibration Yes 3 Yes 1 1 Land stagnation Yes 1 Yes 3 2 TOTAL 9 7 WEIGHTED TOTAL 10 10 http://www.dtsc.ca.gov/omf/grn_remediation.cfm

*Scale of 1 to 3 where 1 is favorable (more green or sustainable) in this example

SLIDE 13

GSR Tools – Level 3

 Carbon footprint calculators  Remedy footprint tools

 Air Force Sustainable Remediation

Tool (SRTTM)

 Navy and Army Corps of Engineers SiteWiseTM  Other tools

 Net environmental benefits analysis tools  Life-cycle assessment (LCA) tools

SLIDE 14

SiteWiseTM

Emissions Water Consumption Energy Used

Model

Material Production Transportation Equipment Use Residual Handling Resource Consumption

SLIDE 15

SiteWiseTM

Input Sheets

 Materials Production

 Well Construction  Treatment Chemical  Treatment Media  Construction Materials  Well Decommissioning  Silt Curtains  Bulk Materials

MATERIAL PRODUCTION WELL MATERIALS

Well Type 1 Input number of wells Input depth of wells (ft) Choose specific casing material schedule from drop down menu Sch 40 PVC Choose well diameter (in) from drop down menu 1/8 Input total quantity of Sand (kg) Input total quantity of Gravel (kg) Input total quantity of Bentonite (kg) Input total quantity of Typical Cement (kg) Input total quantity of General Concrete (kg) Input total quantity of Steel (kg)

TREATMENT CHEMICALS & MATERIALS

Treatment 1 Input number of injection points Choose material type from drop down menu Hydrogen Peroxide Input amount of material injected at each point (pounds dry mass) Input number of injections per injection point

TREATMENT MEDIA

Treatment 1 Input weight of media used (lbs) Choose media type from drop down menu Virgin GAC

CONSTRUCTION MATERIALS

Material 1 Choose material type from drop down menu HDPE Liner Input area of material (ft2) Input depth of material (ft)

WELL DECOMMISSIONING

Well Type 1 Input number of wells Input depth of wells (ft) Input well diameter (in) Choose material from drop down menu Soil

SILT CURTAIN MATERIALS

Curtain 1 Input length or perimeter of silt curtain (ft) Input depth of silt curtain (ft)

BULK MATERIAL QUANTITIES

Material 1 Choose material from drop down menu Acetic Acid Choose units of material quantity from drop down menu pounds Input material quantity

www.navfac.navy.mil/navfac_worldwide/sp ecialty_centers/exwc/products_and_services /ev/erb/gsr.html

SLIDE 16

Interpretation – Overall Results

0.01 0.10 1.00 10.00 100.00 1,000.00 10,000.00 100,000.00 1,000,000.00 10,000,000.00

MMBTU MWH gallons metric ton metric ton metric ton metric ton metric ton metric ton metric ton Total Energy Used Electricity Usage Water Consumption GHG Emissions Onsite NOx Emissions Onsite SOx Emissions Onsite PM10 Emissions Total NOx Emissions Total SOx Emissions Total PM10 Emissions

Excavation Hot Spot Excavation & Capping

SLIDE 17

Interpretation – Details

Phase Activities Total Energy Used Electricity Usage Water Consumpt ion GHG Emissions Onsite NOx Emissions Onsite SOx Emissions Onsite PM10 Emissions Total NOx Emissions Total SOx Emissions Total PM10 Emissions MMBTU MWH gallons metric ton metric ton metric ton metric ton metric ton metric ton metric ton Excavation Consumables 121,878.74 NA NA 5,364.03 NA NA NA 18.90 26.69 8.27 NA NA Transportation-Personnel 239.66 NA NA 19.03 NA NA NA 0.01 0.00 0.00 0.00 0.06 Transportation-Equipment 5.45 NA NA 0.42 NA NA NA 0.00 0.00 0.00 0.00 0.00 Equipment Use and Misc 2,572.60 1.23 4,500,826 166.97 0.45 0.11 0.03 0.96 0.48 0.08 0.00 1.21 Residual Handling 51,475.74 NA NA 3,037.97 0.00 0.00 0.00 10.73 5.56 29.59 0.00 0.34 176,172.19 1.23 4,500,826 8,588.41 0.45 0.11 0.03 30.60 32.73 37.94 0.01 1.60 Consumables 0.00 NA NA 0.00 NA NA NA 0.000 0.000 0.000 0.00 0.00 Transportation-Personnel 0.00 NA NA 0.00 NA NA NA 0.000 0.000 0.000 0.00 0.00 Transportation-Equipment 0.00 NA NA 0.00 NA NA NA 0.000 0.000 0.000 0.00 0.00 Equipment Use and Misc 0.00 0.000 0.000 0.00 0.000 0.000 0.000 0.000 0.000 0.000 0.00 0.00 Residual Handling 0.00 NA NA 0.00 0.000 0.000 0.000 0.000 0.000 0.000 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00 176,172.19 1.23 4,500,826 8,588.41 0.45 0.11 0.03 30.60 32.73 37.94 0.01 1.60 Hot Spot Excavation & Capping Consumables 2,814.36 NA NA 122.21 NA NA NA 0.26 0.49 0.11 0.00 0.00 Transportation-Personnel 15.33 NA NA 1.20 NA NA NA 0.00 0.00 0.00 0.00 0.00 Transportation-Equipment 5.44 NA NA 0.42 NA NA NA 0.00 0.00 0.00 0.00 0.00 Equipment Use and Misc 703.62 0.09 81,641.64 52.26 0.13 0.02 0.01 0.31 0.16 0.03 0.00 0.48 Residual Handling 746.25 NA NA 45.24 0.00 0.00 0.00 0.15 0.08 0.41 0.00 0.01 4,285.00 0.09 81,641.64 221.33 0.13 0.02 0.01 0.73 0.73 0.55 0.00 0.49 Consumables 6,818.19 NA NA 413.45 NA NA NA 0.96 1.70 0.40 NA NA Transportation-Personnel 13.42 NA NA 1.06 NA NA NA 0.00 0.00 0.00 0.00 0.00 Transportation-Equipment 0.00 NA NA 0.00 NA NA NA 0.00 0.00 0.00 0.00 0.00 Equipment Use and Misc 864.89 0.00 0.00 64.24 0.16 0.03 0.01 0.39 0.20 0.03 0.00 0.02 Residual Handling 850.49 NA NA 57.80 0.00 0.00 0.00 0.10 0.05 0.26 0.00 0.01 8,546.99 0.00 0.00 536.55 0.16 0.03 0.01 1.46 1.95 0.69 0.00 0.04 12,832.00 0.09 81,641.64 757.88 0.30 0.06 0.02 2.18 2.67 1.24 0.00 0.52 Long Term Total Construc tion Short Term Total O&M O&M Total Long Term Total Accident Risk Fatality Accident Risk Injury Construc tion Short Term Total O&M O&M Total

SLIDE 18

Evaluate BMPs to further reduce footprint



Power and Fuel

 Use biodiesel produced from waste or

cellulose-based products to power equipment

 Use on‐site generated renewable

energy to fully or partially provide power



Vehicle and Equipment

 Implement an idle reduction plan  Use biodegradable hydraulic fluids on

hydraulic equipment

 Use electric, hybrid, ethanol, or

compressed natural gas vehicles instead of conventional vehicles



Site Preparation and Land Restoration

 Reuse on-site or local clean materials

(e.g., crushed concrete)

 Use reclaimed asphalt pavement as a

granular base for new roads



Project Planning and Team Management

 Choose equipment and product

vendors with production and distribution centers near the site to minimize fuel consumption associated with delivery

 Select local waste disposal and

recycling facilities to minimize transportation impacts

 Use a local laboratory to minimize

transportation impacts

 Use local staff (including

subcontractors) when possible to minimize transportation impacts



Residual Solid and Liquid Waste

 Reuse or recycle recovered product

(such as resale of captured petroleum products, precipitated metals) and materials (for example, cardboard, plastics, asphalt, concrete)

SLIDE 19

Wrap Up

Investigation Remedy Selection Remedial Design Construction O&M Closure

Level 3 BMPs + Advanced Evaluation Level 2 BMPs + Simple Evaluation Level 1 Best Management Practices

Increasing Tool Complexity and Data Needs
