CITY OF CORPUS CHRISTI VIRTUAL MEETING LOGISTICS Please do your best to monitor your mute buttons during the meeting when you are not speaking. During the presentation, feel free to submit written questions via the Chat button.

slide-1
SLIDE 1

CITY OF CORPUS CHRISTI

slide-2
SLIDE 2
  • Please do your best to monitor your mute buttons during the meeting when

you are not speaking.

  • During the presentation, feel free to submit written questions via the “Chat”

button.

  • At specific times during the presentation, we will take the opportunity to

answer questions.

  • At the end of the presentation, as time allows, we will open the forum for

additional questions from attendees.

VIRTUAL MEETING LOGISTICS

slide-3
SLIDE 3

PRESENTERS

Dave Buzan Jason Cocklin Esteban Ramos Leah Olivarri

slide-4
SLIDE 4

PROJECT TEAM MEMBERS

Nikolay Voutchkov Mike Morrison Tom Dixon Katie Leatherwood Jeremy Rice Neil Callahan

  • Dr. Ernest To

Jorge Arroyo

slide-5
SLIDE 5

PRESENTATION OUTLINE

  • Coastal Bend Water Supply Development
  • Introduction to Seawater Desalination &

Project Status Updates

  • Intake & Discharge Considerations
  • Corpus Christi Bay Dynamics
  • Project Costs and Financing
slide-6
SLIDE 6

Coastal Bend Water Supply Development

slide-7
SLIDE 7

Innovative approaches ... practical results ... outstanding service

SURFACE WATER SUPPLIES

slide-8
SLIDE 8

Innovative approaches ... practical results ... outstanding service

Pre-2017 Safe Yield (125k) = 219k AFY 20 MGD SWD Plant Supply Model, Survey, LNRA Recall 75% of Firm Yield Firm Yield

slide-9
SLIDE 9

Introduction to Seawater Desalination & Project Status Updates

slide-10
SLIDE 10

Innovative approaches ... practical results ... outstanding service

Seawater Desalination

Illustrative Process Diagram

slide-11
SLIDE 11

PROJECT STATUS UPDATES

Phase 1 2014 – 2017 Technical & Economic Feasibility Project Prototype HRI Siting Report Phase 2 2017 - 2020 Confirm/Define Project Project Siting Permitting Outreach Phase 3 2020 - 2025 Procurement Financial Closing Design, Construction, Commissioning

slide-12
SLIDE 12

Innovative approaches ... practical results ... outstanding service

Average Production Capacities in MGD

Production Phase Average Daily Production Inner Harbor Ship Channel Plant Initial Capacity 20 MGD Expandable / Ultimate Capacity 30 MGD La Quinta Channel Plant Initial Capacity 20 MGD Expandable Capacity 30 MGD Ultimate Capacity 40 MGD

PROJECTS DEFINED

slide-13
SLIDE 13

Permitting Phase

2 Preferred Sites

Screening Parameters

  • Social & Environmental
  • Tract Characteristics
  • Water Quality
  • Intake
  • Discharge
  • Product Water Delivery
  • Power

Evaluation Parameters

  • Environment
  • Cost
  • Preliminary Diffusion Modeling
  • Water Quality
  • Surveys
  • Permitting Considerations

PLANT SITING

Detailed Evaluation 4

Candidate Sites

Qualitative Screening 19 Potential Sites

slide-14
SLIDE 14

Short Break for Written Questions

slide-15
SLIDE 15

Intake and Discharge Considerations

Reminder: Type your questions in the Q&A box by clicking the Q&A button at the bottom of your screen.

slide-16
SLIDE 16

CONSIDERATIONS FOR A SEAWATER DESALINATION INTAKE

Mapping Sensitive Species & Ecosystems

  • Ecosystems and Species mapping during the siting phase
  • No oyster reefs, no critical habitat for federally listed species within 2,500ft for

intake or discharge zones.

  • Hardened shorelines can be habitats, too.
slide-17
SLIDE 17

CONSIDERATIONS FOR A SEAWATER DESALINATION INTAKE

Mitigating Impingement and Entrainment

  • Wedge-wire screen narrow
  • penings (2mm to 3mm wide)
  • Low inlet velocities (<0.5fps)
slide-18
SLIDE 18

CONSIDERATIONS FOR A SEAWATER DESALINATION INTAKE

Targeting Sustainability

  • Specifically targeting stable water

quality with optimal characteristics

  • Sufficient depth to reduce impacts

from any spills in the water body

  • Sufficient depth to mitigate

impacts to seagrasses

Desalination Plant Intake – Beckton, U.K.

slide-19
SLIDE 19

CONSIDERATIONS FOR A SEAWATER DESALINATION DISCHARGE

  • Permitting Requirements
  • Jet Diffusion
  • ADCPs & Dispersion

Modeling – Near Field and Far Field

  • Temperature < 1.5oF above

Ambient

slide-20
SLIDE 20

SALINITY TOLERANCES

Optimum Maximum

slide-21
SLIDE 21

Corpus Christi Bay Dynamics

Reminder: Type your questions in the Q&A box by clicking the Q&A button at the bottom of your screen.

slide-22
SLIDE 22

CONCENTRATE MIXING AND DISPERSION – NEAR FIELD

Source: Sustainable Management of Desalination Plant Concentrate; Voutchkov N., International Desalination Association World Congress, 2019.

shore

50 ft 200 ft 400 ft

slide-23
SLIDE 23

CORPUS CHRISTI BAY VOLUME 282,000,000,000 Gallons (865,513 ac-ft)

  • Inflows
  • Rain & Runoff
  • River water
  • Tidal water
  • Municipal/Industrial Discharges
  • Outflows
  • Evaporation
  • Outflow to
  • cean
  • Tidal water
slide-24
SLIDE 24

NATURAL SALINITY VARIATIONS CORPUS CHRISTI BAY

TCEQ SWQMS 13407

slide-25
SLIDE 25

CORPUS CHRISTI BAY DYNAMICS

Evaporation

Discharges River Inflow Bay Outflow Tidal flow ~ 552 MGD ~ 3,312 MGD

slide-26
SLIDE 26

Evaporation

Discharges ~ 552 MGD ~ 3,312 MGD River Inflow Bay Outflow Tidal Exchange Public Water System Desal Plant Bay Water Concentrate Potable Water

slide-27
SLIDE 27

IMPACT ON BAY SALINITY – FAR FIELD

NATURAL RANGE OF SALINITY CORPUS CHRISTI BAY

25 TO 42 ppt

20 40 60 80 100 120 140 160 180 0.3 0.6

Desal Production (MGD)

Increase in Bay Salinity (ppt) No Return Flows With Return Flows

slide-28
SLIDE 28

Short Break for Written Questions

slide-29
SLIDE 29

Project Costs and Financing

Reminder: Type your questions in the Q&A box by clicking the Q&A button at the bottom of your screen.

slide-30
SLIDE 30

PROJECT COSTS

First SWIFT Loan

  • $2.75M with no impact on general water rates
  • Principal and interest payments deferred up to 8-years

Second SWIFT Loan – Development of Inner Harbor Plant 20 MGD Expandable to 30 MGD Capital Cost ($222M) Operations & Maintenance Costs Construction = $164M $16M annually (includes treatment to potable) Non-Construction = $26M Contingencies = $32M Objective – No RATE SHOCK, i.e. minimal or no impact to general water rates

slide-31
SLIDE 31

PROJECT FINANCING

Water Supply Development Funds - $0.05/kgal ($1.6M/year) Large Volume Users’ Additional Contributions - $0.25/kgal ($3M/year) TWDB State Water Implementation Fund for Texas (SWIFT)

  • Subsidized Loan – Interest approx. 2% or less
  • 30 Year Term
slide-32
SLIDE 32

COST OF TREATED WATER

$3.50 to $4.50 per thousand gallons

  • Includes substantial contingency estimates
  • Work continues to refine the cost estimates and will continue

through establishment of a contract for design and construction with a private contractor.

  • This is a supplemental supply, so only a portion of the regional

water supply will be developed at this rate.

  • The cheapest water supply is always the one you already have.
slide-33
SLIDE 33

Short Break for Written Questions

slide-34
SLIDE 34

Open Q&A

slide-35
SLIDE 35

CITY OF CORPUS CHRISTI
