CIS 6930 - Cellular and Mobile Network Security: GSM Overload Professor Patrick Traynor 11/1/18 Florida Institute for Cybersecurity (FICS) Research Reminders You need to start working on your project! Some of you have not yet built

slide-1
SLIDE 1

Florida Institute for Cybersecurity (FICS) Research

CIS 6930 - Cellular and Mobile Network Security: GSM Overload

Professor Patrick Traynor 11/1/18

slide-2
SLIDE 2

Florida Institute for Cybersecurity (FICS) Research

Reminders

  • You need to start working on your project!
  • Some of you have not yet built anything. This will be a problem soon!
  • Remember, you must turn in all of your code, plus a makefile and

instructions on how to run it!

  • Remember to keep doing your reading!
  • Not just for the final, but also so that you can participate in the class!

2

slide-3
SLIDE 3

Florida Institute for Cybersecurity (FICS) Research

Unintended Consequences

  • The law of unintended consequences states that


most human actions have at least


  • ne unintended consequence.

3

slide-4
SLIDE 4

Florida Institute for Cybersecurity (FICS) Research

Low Rate DoS Attacks

  • While recent attacks on cellular networks seem unrelated, there is a common factor that catalyzes

them all.


  • Comparing multiple attacks uncovers causality:
  • SMS Attack


(JCS’09, CCS’05)

  • Network Characterization and


Partial Mitigations (TON’10, MobiCom’06)

  • Data

Teardown/Setup Attacks


(USENIX Security’07)


  • The architecture of cellular networks inherently makes them susceptible to denial of service attacks.

Clash of Design
 Philosophies

4

slide-5
SLIDE 5

Florida Institute for Cybersecurity (FICS) Research

SMS Delivery (simplified)

Network Internet PSTN

MSC

VLR VLR

MSC

ESME

HLR

SMSC

CCH

5

slide-6
SLIDE 6

Florida Institute for Cybersecurity (FICS) Research

Control Channels

  • Control channels are used for a handful of infrequently used functions.
  • Call setup, SMS delivery, mobility management, etc...

  • The SDCCH allows the network to perform most of these functions.

  • The number of SDCCHs typically depends on the expected use in an area.
  • 4/8/12...

PCH AGCH RACH SDCCH

6

slide-7
SLIDE 7

Florida Institute for Cybersecurity (FICS) Research

Recognition

  • Once you fill the SDCCH channels with SMS traffic, call setup is blocked
  • The goal of an adversary is therefore to fill SDCCHs with SMS traffic.
  • Not as simple as you might think...

SMS Voice SMS SMS SMS SMS SMS SMS SMS X

7

slide-8
SLIDE 8

Florida Institute for Cybersecurity (FICS) Research

Reconnaissance

  • Can such an attack be launched by targeting a single phone?
  • Low end phones: 30-50 msgs
  • High end phones: 500+ msgs (battery dies)

  • How do you get messages into the network?
  • Email, IM, provider websites, bulk senders, etc...

  • Don’t the networks have protections?
  • IP Address blocking, Spam filtering

8

slide-9
SLIDE 9

Florida Institute for Cybersecurity (FICS) Research

Finding Phones

  • North American Numbering Plan (NANP)












  • Mappings between providers and exchanges publicly documented

and available on the web

  • Implication: An adversary can identify the prefixes used in a target

area.

NPA-NXX-XXXX

Numbering Plan Area (Area code) Numbering Plan Exchange

9

slide-10
SLIDE 10

Florida Institute for Cybersecurity (FICS) Research

Web-Scraping

  • Googling for phone numbers


gives us better results:

 7,300 in NYC
 6,184 in D.C.

 in 5 seconds...

10

slide-11
SLIDE 11

Florida Institute for Cybersecurity (FICS) Research

Provider Interfaces

  • Almost all provider interfaces indicate whether or not a number is good.
  • Some sites even tell you a target phone’s availability.

  • This interface is an “oracle” for available phones.

11

slide-12
SLIDE 12

Florida Institute for Cybersecurity (FICS) Research

Exploit (Metro)

  • 165 msgs/sec * 1500 bytes = 1933.6 kb/sec
  • 193.36 kb/sec on multi-send interface...
  • Comparison: Cable modem ~= 768 kb/sec

Sectors in Manhattan SDCCHs per sector Messages per SDCCH per hour

C

  • (55 sectors)

„12 SDCCH 1 sector « „900 msg/hr 1 SDCCH «

  • 594, 000 msg/hr
  • 165 msg/sec

12

slide-13
SLIDE 13

Florida Institute for Cybersecurity (FICS) Research

Attack Profile

  • Applied simulation and analysis to better characterize the attacks.
  • Examined call blocking under multiple arrival patterns with exponentially distributed

service times.

  • Using 495 msgs/sec, a blocking probability of 71% is possible with the bandwidth of a

cable modem.

0.2 0.4 0.6 0.8 1 1.2 500 1000 1500 2000 2500 3000 3500 4000 Utilization Time (seconds) SDCCH Utilization TCH Utilization

SDCCH Utilization TCH Utilization

13

slide-14
SLIDE 14

Florida Institute for Cybersecurity (FICS) Research

Security Goals

  • Goal: To preserve the fidelity of both voice services and legitimate text messages

during targeted SMS attacks.


  • Security Model:
  • We must trust equipment in the network core.
  • We can not trust Internet users or customer devices.


14

slide-15
SLIDE 15

Florida Institute for Cybersecurity (FICS) Research

Placing Mitigations

Network Internet PSTN

MSC

VLR VLR

MSC

ESME

HLR

SMSC

15

slide-16
SLIDE 16

Florida Institute for Cybersecurity (FICS) Research

Solution Classifications

  • Scheduling/Shaping/Regulation
  • WFQ, Leaky Bucket, Priority Queues
  • AQM (WRED, REM, AVQ)

  • Resource Provisioning
  • SRP
  • DRP
  • DCA
0.2 0.4 0.6 0.8 1 500 1000 1500 2000 2500 3000 3500 4000 Percent of Attempts Blocked Time (seconds) Service Queue (SMS) Service Queue (Voice) TCH (Voice) 0.2 0.4 0.6 0.8 1 500 1000 1500 2000 2500 3000 3500 4000 Percent of Attempts Blocked Time (seconds) SDCCH (SMS) SDCCH (Voice) TCH (Voice) 0.2 0.4 0.6 0.8 1 500 1000 1500 2000 2500 3000 3500 4000 Percent of Attempts Blocked Time (seconds) SDCCH (SMS) SDCCH (Voice) TCH (Voice) 0.2 0.4 0.6 0.8 1 500 1000 1500 2000 2500 3000 3500 4000 Utilization Time (seconds) SDCCH TCH Service Queue

16

slide-17
SLIDE 17

Florida Institute for Cybersecurity (FICS) Research

WRED - Overview

Low Med High

tlow,min tmed,min tmed,max

tlow,max

17

slide-18
SLIDE 18

Florida Institute for Cybersecurity (FICS) Research

WRED - Overview

Low Med High

ρtarget = ρactual(1 − Pdrop)

Pdrop = Pdrop,high · λhigh + Pdrop,med · λmed + Pdrop,low · λlow λSMS

Pdrop = Pdrop,max · (Qavg − tmin) (tmax − tmin)

tlow,min tmed,min tmed,max

tlow,max

NQ = PQ ρ 1 − ρ

18

slide-19
SLIDE 19

Florida Institute for Cybersecurity (FICS) Research

WRED - Results

  • Messages of high and medium-priority experience no blocking, but increased delay.
  • An average of 77% of low-priority messages are blocked.
  • This is a nice solution, assuming meaningful partitioning of flows.

0.2 0.4 0.6 0.8 1 500 1000 1500 2000 2500 3000 3500 4000 Percent of Attempts Blocked Time (seconds) Service Queue (SMS - Priority 1) Service Queue (SMS - Priority 2) Service Queue (SMS - Priority 3)

Low Priority SMS Blocking

0.2 0.4 0.6 0.8 1 500 1000 1500 2000 2500 3000 3500 4000 Utilization Time (seconds) SDCCH TCH Service Queue

Average Queue
 Occupancy

19

slide-20
SLIDE 20

Florida Institute for Cybersecurity (FICS) Research

...and yet...

  • Performance improvements come from one of two changes: speedup or

parallelization.


  • As diverse as our solutions appear, they all attempt to maximize performance

through the latter.

  • In many senses, we are not solving the problem - we are pushing food

around on our plate.


  • Adding bandwidth should logically


address this problem.

20

slide-21
SLIDE 21

Florida Institute for Cybersecurity (FICS) Research

Cellular Data Networks

  • GPRS/EDGE provide much higher bandwidth service.

  • Packet-switched data services are attractive to providers and users for a number of

reasons.


  • User devices operate in one of three


states: IDLE, STANDBY and READY.

  • IDLE: The device is unavailable.
  • STANDBY: Available, but not


exchanging packets.

  • READY: Actively listening for packets.

STANDBY READY IDLE GPRS Attach READY Timer Expires Paging Request STANDBY Timer Expires GPRS Detach

21

slide-22
SLIDE 22

Florida Institute for Cybersecurity (FICS) Research

Internet

IP Address SGSN 192.168.100.1 192.168.1.2 192.168.100.2 192.168.1.2

HLR GGSN SGSN

Data Architecture

22

slide-23
SLIDE 23

Florida Institute for Cybersecurity (FICS) Research

Real Network Configs

  • To make these simulations represent reality, we use a Samsung Blackjack in

Field Test Mode to discover settings of an operational network.


  • Field Test Mode tells us that control channels for voice and data are shared in

real networks.

  • Voice and data traffic may be


able to interfere with each


  • ther.

23

slide-24
SLIDE 24

Florida Institute for Cybersecurity (FICS) Research

Reducing Overhead

  • Because paging is so expensive, we don’t want to do it for every packet.

  • Establishing a connection takes 5 seconds:
  • Waiting: Paging, Wakeup, Processing, Acquiring timeslots
  • Transmission

  • GPRS differentiates packets at the MAC layer by Temporary Block Flows

(TBFs).

  • Each TBF is assigned a Temporary Flow ID (TFI).

24

slide-25
SLIDE 25

Florida Institute for Cybersecurity (FICS) Research

Teardown Attack: Overview

  • TFIs are implemented as 5-bit fields, yielding a maximum of 32 concurrent

flows.


  • If you send a message to a phone once every 5 seconds, the targeted device

maintains its TFI.

  • An adversary can therefore cause legitimate flows to block due to TBF/TFI

exhaustion.


Capacity ≈ 55 sectors × 32 msgs 1 sector × 41 bytes 1 msg × 1 5 sec ≈ 110 Kbps

Capacity ≈ 55 sectors × 4 → 16 msgs 1 sector × 41 bytes 1 msg × 1 5 sec ≈ 14.1 → 56.4 Kbps

25

slide-26
SLIDE 26

Florida Institute for Cybersecurity (FICS) Research

Teardown Attack: Results

  • If an attacker can send 160Kbps of data traffic,


97% of legitimate traffic will be blocked.

  • Note that data service is blocked with less than 30% of the attack traffic

previously used to attack SMS.

0.2 0.4 0.6 0.8 1 200 180 160 140 120 100 Average Percent Blocking During Attack Attack Traffic (kbps)

RACH (Data) RACH (Voice) PDTCH (Data) TCH (Voice)

26

slide-27
SLIDE 27

Florida Institute for Cybersecurity (FICS) Research

Setup Attack

  • To prevent this attack, we reclaim TFIs when the base station sends the “last” packet in a flow.
  • If an attacker can send 4950Kbps of attack traffic, over 85% of all legitimate traffic will be

blocked.

  • Voice and SMS will be blocked at the same rate!

0.2 0.4 0.6 0.8 1 2200 2750 3300 3850 4400 4950 Average Percent Blocking During Attack Attack Traffic (kbps)

RACH (Data) RACH (Voice)

27

slide-28
SLIDE 28

Florida Institute for Cybersecurity (FICS) Research

Broken Solutions

  • Add more TFIs.
  • This is an artificial boundary. Why does it exist?

  • Add more bandwidth.
  • Session establishment requires a few


seconds, so adding bandwidth should speed
 this up and alleviate the problem.

lim

BW →∞ Throughput =

# Requests Setup(Paging, Waiting, Processing)

Throughput = #Requests Setup(Paging, Waiting, Processing) + Transmission

28

slide-29
SLIDE 29

Florida Institute for Cybersecurity (FICS) Research

The Failure of Bandwidth

  • Decreasing the cost of connection establishment requires reducing connection setup latency.

0.25 0.5 0.75 1 1.25 1.5 0.01 0.1 1 10 100 1000 10000 100000 Control Channel Throughput (requests/sec) Bandwidth (packets/sec) 5 sec 4 sec 3 sec 2 sec 1 sec

Bandwidth (packets/sec)

Today Increased Rate

Decreasing the cost of connection
 establishment requires reducing
 connection setup latency.

Setup Latency = (packets/sec)

29

slide-30
SLIDE 30

Florida Institute for Cybersecurity (FICS) Research

Connecting the Dots...

  • The concept of connection establishment is considerably different in cellular

and data networks.

  • Cellular networks page, wake and negotiate with hosts.
  • Data networks simply forward packets.

  • These networks were specialized to deliver voice, but data service has been

shoehorned in...

  • The setup for data connections simply can not be


amortized like voice calls...

30

slide-31
SLIDE 31

Florida Institute for Cybersecurity (FICS) Research

Clash of Design Philosophies

  • The Internet uses the End-to-End Principle as its guiding philosophy.
  • Cellular data networks are still fundamentally circuit-switched systems.

  • Because specialized networks implement more functionality than absolutely

necessary for all flows, they exhibit rigidity.

  • Such systems are unable to adapt to meet changing requirements and

conditions.


31

slide-32
SLIDE 32

Florida Institute for Cybersecurity (FICS) Research

A Cautionary Tale...

  • Cellular networks are among the most specialized systems ever constructed.

  • Adding services that violate the assumptions upon which the network is
  • ptimized allows an attacker to force such systems to fail at very low rates...
  • The unintended consequence of attempts to save battery life allow attackers to

shut down the network.


  • Many more vulnerabilities exist in this network...

32
