CIS 6930 - Cellular and Mobile Network Security:

Classical Telephony Security

Professor Patrick Traynor 10/30/18

Florida Institute for Cybersecurity (FICS) Research

Ah, the Classics...

2

Florida Institute for Cybersecurity (FICS) Research

Well Placed Nostalga?

• The general feeling is that the Internet and its openness brought about

significant insecurity.


• If only, some lamented, we could go back to a more closed and controlled

environment like telecommunications networks, security would no longer be such an issue.


• Is such an assertion well founded?

• How secure are telecommunications


networks in reality?

3

Florida Institute for Cybersecurity (FICS) Research

Setting Expectations

• This lecture is designed to kick off the final portion of the semester and give us

context to our security discussions.

• Just how good were the “good old days”?

• We will introduce classes of vulnerabilities today.
• We will spend the rest of the semester studying many of them in great detail.

• Many of the lectures moving ahead rely on


the understanding of the architecture of the
 networks you have spent so much time
 learning.

4

Florida Institute for Cybersecurity (FICS) Research

Weak Cryptography

• The algorithms underlying these operations are also insecure.
• Rumor has it that was is partially intentional.
• COMP-128 (used as A3) can expose Ki.
• 219 queries to the SIM card allow attacker to recover Ki.
• A5/1 and A5/2 (used as A5) are also weak.
• Golic (1997) and Biryukov (2000) created known-plaintext attacks

possible in 240 operations or with 300 GB of space.

• Multiple recent efforts use rainbow tables and GPUs to rapidly crack

keys.

5

Florida Institute for Cybersecurity (FICS) Research

Vulnerabilities in the Network Core

• In-band Signaling
• “Captain Crunch” attacks

• Unauthenticated signaling in the SS7 core.
• MAPSec standard created, never used in reality outside of one unfortunate and

informative instance.

• How “walled” are these gardens in reality?

• ASN.1 compiler/parser buffer overflows
• Nearly every core node vulnerable.

6

Florida Institute for Cybersecurity (FICS) Research

Eavesdropping

• AMPS had no encryption.
• Device cloning attacks by capturing the ESN.

• Networks can specify A5/0 mode during Cipher Mode “negotiation”.
• A5/0 is mandated in France to allow easy over-the-air lawful

interception.


• Crypto ends at the BS.
• Microwave backhauls to the network make interception easy.

7

Florida Institute for Cybersecurity (FICS) Research

Jamming

• A number of companies sell “personal jamming” devices.
• You can buy them in street markets in many major cities.
• Many public places (e.g., theaters, churches, etc) have considered purchasing

slightly higher-grade products.

• This is HIGHLY illegal in the US, but not so in other countries.

• AMPS and GSM are relatively easy to jam directly.

• CDMA should make this much hard.
• Why do you think jamming is still possible?

8

Florida Institute for Cybersecurity (FICS) Research

Tracking, Privacy and CALEA

• Lawful intercept of personal communications has a deep legal history in this

country.

• In general, your calls can not be listened in upon without the approval of a

judge.

• Significant infrastructure exists to support lawful interception.
• Recent history provides examples of “less-lawful” interception.
• Location of specific individuals, email sent over cellular networks and text

messages are very much in a grey area.

• US DoJ is arguing against the need for warrants

• here. Implications?

9

Florida Institute for Cybersecurity (FICS) Research

Overload and DoS

• Networks are designed and provisioned based on certain assumptions

about traffic load.

• Voice traffic is much easier to predict than data.
• Connecting telephony to the much less regulated, less predictable Internet

creates opportunities to violate the above assumptions.

• Understanding the architecture can make these attacks targeted and

efficient.

• Brute-force DoS is largely uninteresting...

10

Florida Institute for Cybersecurity (FICS) Research

Malware and Mobile Phones

• Up to this point, most malware in this space has been fairly basic and

uninteresting from an analysis perspective.

• The vast majority rely on social engineering.
• Mobile AV products exist, but how many people do you know that

actually run them?

• New exploits are becoming increasingly sophisticated.
• PDF vulnerabilities, Heap spraying
• What are applications secretly leaking about you?
• What can be done in this space given the constraints?

11
