CIS 4930/6930: Principles of Cyber-Physical Systems Chapter 5: Composition of State Machines Hao Zheng Department of Computer Science and Engineering University of South Florida H. Zheng (CSE USF) CIS 4930/6930: Principles of CPS 1 / 28

SLIDE 1

CIS 4930/6930: Principles of Cyber-Physical Systems

Chapter 5: Composition of State Machines Hao Zheng

Department of Computer Science and Engineering University of South Florida

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 1 / 28

SLIDE 2

Introduction

State machines are useful for modeling system behaviors.
How to represent a system for systematic analysis?
Complete systems though often have a very large state space.
Can represent complicated system as composition of simpler

systems.

Modular approaches are always needed to handle large complex

problems.

Care must be taken though as the same syntax (model notation)
ften has different semantics (meaning).
H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 2 / 28

SLIDE 3

Actor Model and Extended SM Notation

i1 in

... ...

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 3 / 28

SLIDE 4

Overview

Side-by-side synchronous composition (simultaneous reactions).
Side-by-side asynchronous composition (independent reactions).
Communication through shared variables.
Cascade (serial) composition.
General composition that combines side-by-side and cascade.
Hierarchical state machines.
H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 4 / 28

SLIDE 5

Side-by-side Composition

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 5 / 28

SLIDE 6

Side-by-side Composition Example

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 6 / 28

SLIDE 7

Synchronous Side-by-side Composition

A

= (StatesA,InputsA,OutputsA,updateA,initialStateA)

B

= (StatesB,InputsB,OutputsB,updateB,initialStateB)

The synchronous side-by-side composition C is given by: StatesC

=

StatesA × StatesB InputsC

=

InputsA × InputsB OutputsC

=

OutputsA × OutputsB initialStateC

= (initialStateA,initialStateB)

updateC((sA,sB),(iA,iB))

= ((s′

A,s′ B),(oA,oB))

where

(s′

A,oA)

=

updateA(sA,iA)

(s′

B,oB)

=

updateB(sB,iB) for all sA ∈ StatesA, sB ∈ StatesB , iA ∈ InputsA , and iB ∈ InputsB.

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 7 / 28

SLIDE 8

Synchronous Side-by-side Composition

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 8 / 28

SLIDE 9

Asynchronous Side-by-side Composition

Semantics 1: a reaction of C is a reaction of one of A or B, where

the choice is nondeterministic (interleaving semantics). updateC((sA,sB),(iA,iB))

= ((s′

A,s′ B),(o′ A,o′ B))

where either

(s′

A,o′ A) = updateA(sA,iA) and s′ B = sB and o′ B = absent

(s′

B,o′ B) = updateB(sB,iB) and s′ A = sA and o′ A = absent

for all sA ∈ StatesA, sB ∈ StatesB, iA ∈ InputsA, and iB ∈ InputsB.

Semantics 2: a reaction of C is a reaction of A, B, or both A and

B, where the choice is nondeterministic.

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 9 / 28

SLIDE 10

Asynchronous Side-by-side Composition

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 10 / 28

SLIDE 11

Shared Variables

Extended state machines have variables that are read/written by

transitions.

These can be shared when composing state machines.
Useful when modeling interrupts and threads.
Ensuring correct semantics though can be challenging.
H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 11 / 28

SLIDE 12

Shared Task Queue Example

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 12 / 28

SLIDE 13

Semantic Subtleties

Interleaving semantics makes accesses to the shared variable

atomic.

Tricky to satisfy in practice.
What if both machines react or machines use synchronous

semantics?

Leads to non-deterministic outputs.
H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 13 / 28

SLIDE 14

Cascade Composition

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 14 / 28

SLIDE 15

Cascade Composition Example

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 15 / 28

SLIDE 16

Synchronous Cascade Composition Example

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 16 / 28

SLIDE 17

A Model of a Pedestrian Crossing Light

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 17 / 28

SLIDE 18

Traffic Light Model

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 18 / 28

SLIDE 19

Synchronous Cascade Composition

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 19 / 28

SLIDE 20

Arbitrary Interconnections of State Machines

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 20 / 28

SLIDE 21

Hierarchical FSM

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 21 / 28

SLIDE 22

Semantics of a Hierarchical FSM

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 22 / 28

SLIDE 23

Preemptive Transition Example

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 23 / 28

SLIDE 24

Semantics of a Preemptive Transition

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 24 / 28

SLIDE 25

History Transition Example

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 25 / 28

SLIDE 26

Semantics of a History Transition

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 26 / 28

SLIDE 27

Concluding Remarks

Any well-engineered system is a composition of simpler

components.

Considered concurrent composition and hierarchical composition.
For concurrent composition, introduced both synchronous and

asynchronous composition.

Several possible semantics for asynchronous composition.
Hierarchical models similar to Statecharts introduced by Harel

(1987).

H. Zheng (CSE USF)

CIS 4930/6930: Principles of CPS 27 / 28
