GSM SPEECH PROCESSING

ECE 2526 – MOBILE COMMUNICATION Wednesday, 18 March 2020

1

BASIC SPEECH PROCESSING FUNDAMENTALS (1)

2

Basic GSM Band 890 + n*0.2 Basic GSM Band 890 + n*0.2 +45

• 1. A GSM frame is

4.61msec long.

• 2. Each time slot is

therefore 4.61/8 = 577µsec

3

GSM SPEECH PROCESSING FUNDAMENTALS -REVISITED

SPEECH PROCESSING IN GSM

4

Adaptive Filter Data Burst at 12 Kbps Removes redundant Parts in each data stream sample

QPSK MODULATION USED IN GSM

1. Each byte of data is split into four pairs of bits.

• 2. Each pair of bits is assigned a

particular phase for I(t) and Q(t).

• 3. The modulated signal is the sum
• f the two sinusoidal waves, with

a phase shift depending on the logic symbol.

5

WHY COMPRESSION IS NECESSARY IN GSM CODEC?

• 1. If speech were digitised in a linear fashion it would require

a high data rate that would occupy a very wide bandwidth.

• 2. It is necessary to compress the data to send it through the

available channel.

• 3. Speech is captured at a high enough sample rate and

resolution to allow clear reproduction of the original sound. 4. It must then be compressed in such a way as to maintain the fidelity of the audio over a limited bit rate, error-prone wireless transmission channel.

• 5. At the receiver, the compressed data is expanded to

regenerate the audio.

6

GSM CODEC RATES

7

Codec name Bit rate (kbps)

• 1. Full rate

13

• 2. Enhanced Full Rate (EFR)

12.2

• 3. Half rate

5.6

• 4. Adaptive Multirate (AMR )

12.2 - 4.75

• 5. Adaptive Multirate

Wideband (AMR-WB) – baseband is enhanced to the range 50 – 7,000 Hz. 23.85 - 6.60

SALIENT FEATURES OF ADAPTIVE MULTIRATE (AMR)

• 1. AMR uses 20ms frames.
• 2. Discontinuous transmission is employed so that when there is no

speech activity the transmission is cut.

• 3. Voice Activity Detection (VAD) is used to indicate when there is
• nly background noise and no speech.
• 4. Comfort Noise Generator (CNG) is added at the receiver to provide

some background noise, even when no speech data is being

• transmitted. This provides the feedback for the user that the

connection is still present.

8

WHAT IS TRANSMITTED FOR VOICE IN GSM?

9

Best coefficients are selected get the best approximation of the 20mS sample Low order coefficients are coded as 6-bit while Higher order are coded as 3-bit 20ms of 104 Kbps stream = 2080 bits
