Cirrus Logic Mixed-Signal Leadership

Mixed-Signal Technologies Explained

• Analog-to-Digital Converter (ADC)
• Used for Microphone or other analog

inputs in audio systems

…0001101001…

ADC

• CODEC (ADC + DAC)
• Used in surround sound systems
• Mainly multi-channel DAC + single

ADC

DAC

…0001101001…

CODEC

…0001101001…

• Digital to Analog Converter (DAC)
• Used for converting digital back to

analog so they can be sent to amp/ speaker

Interface

• Digital Interface (S/PDIF)
• Digital In/Out
• Connects digital devices like DVD

player and AVR

…0001101001… …01001…

Cirrus Mixed-Signal Markets

• Cirrus Offering:
• ADC,DAC,CODEC, Interfaces

and Class D Amplifier

Consumer I ndustrial

Home Audio Portable Audio Video Automotive

• Cirrus Offering:
• ADC,DAC, OpAMP

High Precision Measurement Pow er Meter

Industrial Technology Leverage

Analog & Mxd Signal Technology Driver

I ndustrial Consumer

• Analog & Mixed-Signal Expertise
• Superior ADC & DAC Technologies
• Delta Sigma Innovation Legacy
• Audio-Video-Connectivity
• Home Entertainment Upgrade
• Analog & Mixed-Signal Critical

Showcase Industrial Technology Innovation

Ultra-Low Noise, Low Drift OpAMP

• Industry First low noise &

drift Amplifier

• Low Offset: 10 mV
• Low Drift: 50 nV/°C
• High Open-Loop Gain: 200 dB

min

• Low Noise 6 nV/rt.Hz@0.5 Hz
• Industrial Temp (-40ºC to +85ºC)
• Proprietary Multipath

TM

Amplifier Technology

• 10x better system noise
• 4x better system drift, than

closest competitor

Source: published product sheets and CRUS

Mixed Signal Leadership in Digital Consumer

• Leadership Technology

Portfolio

• Video DAC
• Audio ADC, DAC, CODECs
• S/DIF Receivers
• Digital Power Amplification
• Over 900 patents and patent

applications, 125 focused on mixed- signal

• Innovation Leadership
• Long list of industry firsts
• Highest integration
• Highest performance
• Strong pipeline of new

products Mixed Signal Technology

Portable Audio

Entertainment Processor

Home Audio

Entertainment Processor

DVD Player

Entertainment Processor

Video Recording

Entertainment Processor

Cirrus Total-E Technology Platform

Large Portfolio of Analog Audio Converters

= CODEC = ADC = DAC

CS5361

114dB, 192kHz

CS5394

117dB, 48kHz

CS5396

120dB, 96kHz

CS5333

98dB, 96kHz

CS5351

108dB, 192kHz

CS4226

98dB, 48kHz

CS4227

98dB, 48kHz 3:6

CS4228A

102dB, 96kHz 2:6

Performance System Cost

CS4396

120dB, 192kHz

CS4397

120dB, 192kHz

CS43122

122dB, 192kHz

CS4334

96dB, 96kHz

CS4340/1

102dB, 96kHz

CS4340A

102dB, 192kHz

CS4391

108dB, 192kHz

CS4392

114dB, 192kHz

CS4360

103dB, 192kHz 6 channels

CS4362

114dB, 192kHz 6 channels

CS4382

114dB, 192kHz 8 channels

CS5331A

94dB, 48kHz

CS5360

105dB, 48kHz

CS42528

114dB, 192kHz 6-8 channel

Cirrus’ Mixed-Signal Innovations

• 1st stereo DAC in an 8-pin SOIC package (98db, 96kHz)
• 1st 96kHz digital audio transmitter and receiver
• 1st 120db 96kHz audio A/D converter
• 1st PCM/DSD DAC (DVD-Audio and SACD capable)
• High performance multi-channel DAC
• High performance stereo DAC
• High performance PCM/DSD DAC
• Most integrated portable DAC
• Most integrated portable CODEC
• Shipped 200 millionth audio DAC since 1998

The Future of Music

• Resolution: 24-bit
• Sample Rates: 192kHz

(2-ch), 96kHz (6-ch)

• Channels: 2/6
• Resolution: 1-bit
• Sample Rates: 2.88224MHz
• Channels: 2/6
• Cirrus actively supports both standards
• High performance D/A converters available for 2 & 6 channel

applications

• Most complete DVD-Audio, SACD product offering

New CS425xx Family DVD-Audio-Ready CODECs Integrate 6 chips Into 1

• Enables 2 chip Solution

for AVR and Car AV

• All non-DSP functionality on
• ne chip!
• Perfect match for Cirrus Audio

DSP products

• Highly integrated, cost-

effective scalable solution

• 192kHz S/PDIF Receiver
• 192kHz Stereo A/D converter
• 6 or 8 192kHz D/A converter

Cirrus Leveraging Mixed-Signal Expertise to Deliver a 2-chip High-Performance 8-Channel Audio Solution

CS49400

Audio Decoder w/Sub DSP

Programmable Multi-Standard 90 MIPs 24-bit DSP Plus 32-bit Cobra DSP @ 90MIPs AC-3 + DTS + Surround in ROM AC-3 Virtual in ROM SRS Circle or MP-3 in ROM SDRAM Controller + 6 Ch PWM 16-Channel In, 16-Channel Out 144 Pin TQFP

CS425XX

8 S/PDIF inputs 1 S/PDIF output 2 analog inputs 6 or 8 DAC outputs MCLK management

RLRCK RSCLK RSDATA SDATA1 SDATA2 SDATA3 SDATA4 LRCK SCLK SDATA RMCLK or OMCLK

Cirrus’ New CS5361/51 Drives High Performance Audio at Low Cost

• 192kHz Sample Rates
• Advanced multi-bit Delta Sigma

architecture

• DVD-Audio “ready” products
• High-Performance Audio

Conversion

• Dynamic range - 114/108dB,

CS5361/51

• THD+N - 105/100dB, CS5361/51
• 24-bit conversion
• Pin-Compatible Product

Family

• Easy upgrade path
• Reduces time-to-market
• Flexible performance & pricing

CS5361 CS5351

New 192kHz Digital Audio Receiver and Transmitter for DVD-Audio

Product: CS8416 & CS8406

CS8416 CS8406

• DVD-Audio capable
• Technology advantage
• Interface to logic levels from 3.3V to 5V
• Extremely low jitter spec – 200ps max.
• Selectable signal routing to 3 GPO pins
• On-chip channel status and user bit

buffer memories

• 28-pin TSSOP or SOIC
• DVD recorders
• AV Receivers and DVD Receivers
• Digital mixing consoles
• Digital multi-track recording

systems

• Automotive audio systems
• PVRs

Target Markets Key Specifications

New Value-Line DVD-Audio Stereo DACs

CS4340A CS4341A

• Complete 2 channel D/A converter
• Sample rate up to 192kHz - DVD

Audio capable

• 3V to 5V power supply
• Filtered line level outputs
• Automatic sample rate detection
• Low jitter sensitivity
• DVD-Audio players
• Line powered
• Portable
• Automotive
• DVD Receivers
• Digital A/V receivers
• Digital STB/TV

Product: CS4340A/41A Target Markets Key Specifications

New 6/8 Channel DAC – DVD-Audio and SACD

• Complete 6/8 channel DAC
• DVD-Audio and SACD capable
• 114dB dynamic range
• 100dB THD+N
• Digital volume control
• Simultaneous support for 2

synchronous sample rates for DVD-Audio

CS4382 CS4362

• Mid range DVD players
• Mid range A/V receivers
• SACD players
• Professional mixing consoles
• Professional outboard

converters/recorders

• Professional effects processors

Products: CS4362/82 Target Markets Key Specifications
