TOGETHER FOR BETTER

CF 68 FOLDING DOOR

2

CF 68 Folding door

• Subject of the launch
• Context
• Concept
• Business
• Technical information
• Launch material

Subject of the launch

• CF 68
• Adjustable side profile
• CF 68-AP
• CF 68-HI

Content

3

CF 68 Folding door

Insight ‘Your garden is your living room - extend your living room with the garden’ Architectural trend: indoor and outdoor are integrated. Boundaries disappear. Promise Open up your living room in just a few seconds with excellent performing folding doors at an attractive price point

Context

4

CF 68 Folding door

User

Comfort, speed and ease

• Comfort in installation and logistics thanks to the adjustable side profile
• Less time consuming and easy to assemble
• In- and outward opening with the same profiles and accessories
• Minimum number of profiles – maximum number of configurations

Performing concept at an attractive price point

• Open up your living room in just a few seconds – ultimate flexibility
• Highly insulating: fulfilling the most recent and near future market demands
• Different performance and access solutions to cover different needs and wishes
• RC2 anti-burglar solution available

Architects Fabricators

Concept

Benefits

Architectural flexibility and design

• Different opening configurations and bottom solutions
• Open up the wall up to 7 meters and up to 7 vents
• Vent sizes (W: 1000 mm, H: 2426 mm) allowing transparent constructions
• Design flexibility – different design handle options available

5

CF 68 Folding door

Concept

Innovation Comfort in installation and logistics thanks to the adjustable side profile: Due to tolerances it’s often recommended to measure and fabricate the last vent after the others are installed. This is history: from now easy adjustment on site is possible, facilitating the installation of the complete folding wall in 1 site visit.

Adjustable side profile covers up tolerances on vent dimensions

6

CF 68 Folding door

Business

Market (drivers)

• Main driver: Product positioning:
• Price point:
• Basic CF 68 25-30% below CF 77
• Upscaling possible: HI, AP, design handles
• Main target market: Retail/Domestic sector and small local builders
• Focus markets (geographic)
• UK
• NL
• Ireland
• SE Asia
• Balkan/Turkey
• Spain
• Sales channels: typical folding door market
• Retail Showrooms
• Online Sales
• trade fabricators supplying the domestic/retail trade

7

CF 68 Folding door

Business

System positioning Price positioning Reynaers assortment CF 68 price 25-30% lower than CF 77

CF 68 CF 77

CF 68-AP CF 68-HI CF 68 with Purity CF 68 with adjustable profile

8

1200

CF 68 Folding door

Business

Product positioning Fit in assortment CF 68 vs. CF 77

2500 3000 1000 90 kg 120 kg Frame max 7000 8 vents Frame max 7000 7 vents

9

CF 68 Folding door

Technical information

• Innovative
• Configurations
• AWW
• Insulation
• Technical specifications
• Integration in Reynaers product range
• Window gear
• Door gear
• Door gear AP
• Principles
• Overview developments

10

Innovative

• Symmetrical design of vent profile
• 2 outer grooves for rolling accessories,

hinges and gaskets

• In- and outward opening with same profiles

& accessories = Logistic advantage

CF 68 Folding door

Technical information

11

Configurations

One design: Functional and slim

• Visible width vent-vent 131 mm
• Visible width frame-vent 99.5mm
• CS 38-SL Glazing beads

CF 68 Folding door

Technical information

12

Also available with door locking gear

CF 68 Folding door

Technical information

Configurations

• 38 Opening types
• All configurations: inward and & outward opening available
• Window locking principle available for all configurations
• Door locking principle available for entrance door

(for single and double leaf types)

13

• Bottom solutions
• 4 bottom solutions = 5 AWW level solutions in total

 Optimal Accessibility  Aesthetical bottom solution  Economic solution  Low threshold  Elementary AWW rating  Weather seal  Double weather seal  Suitable for renovation  High performance  Double weather seal  2 Different performance levels in one profile Air None Testing phase Class 4 Class 4 Wind None Testing phase Class C2 Class C2 Water None Testing phase Class 7A (300 Pa) Class 9A (600Pa) Class 7A (300 Pa)

7A 9A

CF 68 Folding door

Technical information

14

Insulation

• Meeting actual and near future market
• Regulatory requirements for business and domestic buildings
• Reaching Uw values down to 1.1 W/m²K, for an element of BxH

4000x2500 with an Ug of 0.6 W/m²K

• Insulation levels for a standard element and glazing:

Type Style AWW Perf. Pex- foam Ug Uf

up to …

Ψ Uw

4-3-1 Funct Low No 1.1 2.6 0.07 1.7 “ (HI var.) Low Yes 1.1 1.8 0.07 1.5

CF 68 Folding door

Technical information

15

Maximal dimensions

• Bottom rolling:
• Vent weights up to 90 kg for all configurations
• ptimal for refurbishment
• Integrated rolling accessories
• Vent dimensions:
• Width up to 1000 mm
• Height up to 2426 mm
• Large variety in configurations from 1 to 7 vents
• Glass thickness between
• 12 mm and 55 mm
• Suitable for triple glazing

MIN MAX

CF 68 Folding door

Technical information

16

Integration in Reynaers product range

• Build-in depth of 68 mm
• compatible with the existing CS product range
• Dedicated profiles

Partial re-use of standard CS gaskets and accessories:

• Glazing gaskets
• Design handles
• Standard Access
• ...
• Re-use of standard CS details & glazing beads
• CS 38 glazing beads

CF 68 Folding door

Technical information

17

CF 68 folding door

Horizon: All RAL Purity: 3 + 5 colours Pull Handle: All RAL

Technical information

Different designs handles

18

Window Gear

• Window locking principle:
• 1 One set
• Gearbox operated
• 2 Threaded rods and locking pins
• Easy assembling
• AP receiver, anti lift block
• Additional “Two in One” set
• Top receivers for AP
• With anti-lift functionality
• AP handles
• Cup handle
• Lockable handle

CF 68 Folding door

Technical information

19

Door Gear

• Optional door locking principle > first leaf as an entrance door:
• 5 point lock with the following specifications:
• Stainless steel front plate
• 4 Stainless mushroom cams, adjustable.
• Latch and deadbolt
• Handle operated with possibility to lock with PZ cylinder
• Integrated double casement locking mechanism for the

second vent in the case of a double opening leaf.

CF 68 Folding door

Technical information

20

Door Gear AP

• Anti-burgular Proof door locking principle > first leaf as an

entrance door:

• 3 point lock with the following specifications:
• Stainless steel front plate
• 2 Stainless hooks.
• Latch and deadbolt
• Handle operated with possibility to lock with PZ cylinder
• Integrated double casement locking mechanism for the

second vent in the case of a double opening leaf.

CF 68 Folding door

Technical information

21

Principles

• First leaf

On first leaf: Option for door or window locking principle 9mm Adjustible Frame profiles CS 38-SL glazing beads Same vent profile all around Vents can be crimped , screwed or nailed Same carriar for all opening types Suits Shield, Horizon, Sobinox, Purity handles

CF 68 Folding door

Technical information

22

Principles

• Folding leaves

Frame profile screwable

• n workfloor or onsite

Flat handle for primary and secondary leaves Same accessories for in and outward opening types Same gasket all around

CF 68 Folding door

Technical information

23

Principles

• Vertical sections

CF 68 Folding door

Technical information

Identical frame & vent profiles

Inward

• pening

Outward

• pening

24

Overview developments

• Adjustable frame
• 9mm adjustable in and width
• Distance piece 069.8567.--

Horizontal adjustability: 9 mm (+6mm and -3 mm)

CF 68 Folding door

Technical information

25

Overview developments

• Profiles

Bottom profiles

CF 68 Folding door

Technical information

26

Overview developments

• Profiles

Frame profiles

CF 68 Folding door

Technical information

27

Overview developments

• Profiles

Vent profile Supporting profiles T-profile

CF 68 Folding door

Technical information

28

Overview developments

• Folding accessories
• Clampable and adjustable in height
• Available in 3 colours: black, grey, white

060.6744.XX 060.6742.XX 060.6741.XX 060.6740.XX 060.6739.XX

CF 68 Folding door

Technical information

29

Overview developments

• EPDM piece for hinge and wheel set
• Slim part
• Low assembly time
• High performance

069.8654.04

CF 68 Folding door

Technical information

30

locks 061.7600.zc 061.7610.zc 061.7619.zc 061.7620.zc

Overview developments

• Door locking gear: Standard and AP

Receivers 061.7601.-- 061.7614.-- 061.7602.-- 061.7615.-- 061.7603.-- 061.7622.-- 061.7604.-- 061.7623.-- 061.7605.-- 061.7624.-- 061.7606.-- 061.7625.-- 061.7607.-- 061.7628.-- 061.7608.-- 061.7629.-- 061.7609.-- 061.7630.-- 061.7611.-- 061.7631.-- 061.7612.-- 061.7613.--

AP locks and receivers

CF 68 Folding door

Technical information

31

Overview developments

• Accessories: Locking Gear

CF 68 Folding door

Technical information

32

Overview developments

• Accessories: Locking Gear

CF 68 Folding door

Technical information

33

Overview developments

• Accessories:

CF 68 Folding door

Technical information

34

Overview developments

• Accessories:

CF 68 Folding door

Technical information

35

Overview developments

• Tooling:

CF 68 Folding door

Technical information
