SLIDE 1
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
CFX TRAFFIC OPERATIONS AND ITS
ITS
Video Travel Times DMS Traffic counts Software WWD Fiber
- ptics
Bryan Homayouni, P .E. Manager of Traffic Operations Brent Poole ITS S ystems Analyst
CENTRAL FLORIDA EXPRESSWAY AUTHORITY CFX Traffic Operations and - - PowerPoint PPT Presentation
CENTRAL FLORIDA EXPRESSWAY AUTHORITY CFX Traffic Operations and - - PowerPoint PPT Presentation
CENTRAL FLORIDA EXPRESSWAY AUTHORITY CFX Traffic Operations and Intelligent Transportation Systems (ITS) CFX TRAFFIC OPERATIONS AND ITS Bryan Homayouni, P .E. Brent Poole Manager of Traffic Operations ITS S ystems Analyst Video Fiber
SLIDE 2
SLIDE 3
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
CFX VIDEO SYSTEM
- S
ystemwide video coverage for traffic safety
- Monitored from FDOT
traffic management center
- Available to media
partners
– Local news – TrafficLand.com
HD CCTV IMAGE
SLIDE 4
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
TRAFFIC MONITORING STATIONS
- Real-time traffic volume
data system wide
- No traffic tubes = improved
safety
- Data for annual proj ections
and specific studies
10 20 30 40 50 60 70 80 200 400 600 800 1000 1200 1400 1600 1800 2000
Speed (MPH) Volume (vehicles)
Speed
Traffic volume
SLIDE 5
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
CFX TRAVEL TIME SYSTEM
- CFX hosts our own
travel time system
- Real-time information
updated once per minute
- S
hared with customers via DMS and FL511
SLIDE 6
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
DYNAMIC MESSAGE SIGNS (DMS)
41 Dynamic Message S igns
- Full Matrix, LED technology
- Walk-in housing
S R 417 Nort h of S R 408 Color DMS on S R 414
SLIDE 7
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
CFX INNOVATION:
TRAVEL TIME ALERTS Flashing alerts are automatically posted for abnormally high travel times
SLIDE 8
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
- Full color DMS
automatically posts congestion message
- Radar-based traffic sensors detect traffic speed
- Two sites: S
R 408 and S R 429
CFX INNOVATION:
AUTOMATED CONGESTION DMS
SLIDE 9
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
- Detects WWD acts at
equipped ramps
- Flashes beacons to
alert driver
- S
ends alarm to traffic management center
CFX INNOVATION:
WRONG WAY DRIVING (WWD)
SLIDE 10
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
CFX FIBER OPTIC NETWORK
- First deployed in 1999
- Upgraded to keep pace with
industry
- Comprehensive network
supporting:
– Tolls – ITS
data / video
– Telephone
SLIDE 11
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
SUNGUIDE™ TRAFFIC MANAGEMENT SOFTWARE
- S
unGuide™ is Florida’s statewide traffic management
- Controls cameras, DMS
, and
- ther ITS
devices
- CFX partners with FDOT for
S unGuide updates and improvements
SLIDE 12
CENTRAL FLORIDA EXPRESSWAY AUTHORITY
FLORIDA HIGHWAY PATROL (FHP)
- Dedicated squad
patrols
– Improved safety – Reduced response
time
- Dedicated service
