SLIDE 1
Presenting today
Patrick King
Associate Director & Head of BIM Technologies
Agenda
- Introduction
- Implementing BIM for Councils
- BIM Pilot Project
- Conclusion
Building Information Modelling (BIM) BIM Use in Social Housing with - - PowerPoint PPT Presentation
Building Information Modelling (BIM) BIM Use in Social Housing with - - PowerPoint PPT Presentation
Building Information Modelling (BIM) BIM Use in Social Housing with Westminster Council Presenting today Patrick King Associate Director & Head of BIM Technologies Agenda Introduction Implementing BIM for Councils
SLIDE 2
SLIDE 3
Introduction
SLIDE 4
4 Public Participation Consultation & Research Project Management, Cost Consultancy, Building Surveying and Principal Designer Services Architecture Masterplanning Urban Design Energy & Sustainability Consultancy
Group Overview
SLIDE 5
5
Award Winning Designs
SLIDE 6
6
SLIDE 7
7
Office in London & Glasgow
SLIDE 8
8
Our Team
SLIDE 9
9
Three Year Process:
All projects delivered using BIM processes & modelling techniques. 1. Training & Support from the Top Down
- ALL Directors have completed the BRE BIM
Level 2 Essentials Course 2. Upskilling ALL staff
- Over 90% are Revit Certified Professionals
- All Staff receive 4 hours per month of BIM &
Revit training
- All Senior Staff to complete BIM Essentials
- ECD YouTube & Vimeo channel for Staff
training 3. Modelling Tools
- Revit • Navisworks • Cato • Dynamo • AutoCAD
4. ECD Standards & Validation Procedures
- Development of ECD Standards, Methods &
Procedures Documents & Modelling Templates
- Validation of Models using DynamoBIM for
Office/BS Standards and BIM LOD/LOI compliance
- Validation of Models using Navisworks for
Coordination
SLIDE 10
Implementing BIM for Councils
SLIDE 11
Three new priorities for Westminster City Council.
BUILDING HOMES AND CELEBRATING NEIGHBOURHOODS. GREENER CITY SMART COUNCIL
SLIDE 12
BIM Implementation on Pilot Projects
STAGE 3 Work stream
- Pilot Project Review
- User Group Workshop
- Client Training
- Document Development
- KPI Assessment
1 2 3 4 5
STAGE 1 Work stream
- Implementation plan
- Capability Assessment
- User Group setup
- Workshops
- Document creation
- Procurement & Legal Documents
STAGE 2 Work stream
- Procurement of Pilot Project
- Team Capability Assessment
- Project Set Up & Workshops
- Client Document review & feedback
- KPI Assessment
STAGE 4 Work stream
- Pilot Project Review (Design Team)
- User Group Workshops
- Smart City Review & Strategy
- Document creation
- Procurement & Legal Review
- KPI Assessment
STAGE 5
- Pilot Project Deliver Review
- User Group Workshop Review
- Capability Assessment of WCC
- Workshops
- Document Review & Signoff
- Procurement & Legal Review
- Business case of BIM Review
SMP Document Creation Westminster City Council BIM Business Case Lessons Learned Smart City Approach
SLIDE 13
BIM Assessment
SLIDE 14
BIM Workshop Group
Procurement BIM Finance Asset Management Project Managers Policy Legal
SLIDE 15
SLIDE 16
SLIDE 17
(OIR) EIR) (AIR)
SLIDE 18
(OIR) EIR) (AIR)
BIM Business Case
SLIDE 19
WCC Project Implementation Documents
SLIDE 20
BIM Pilot Project
SLIDE 21
Ashbridge Street
Proposed development on this site to deliver 26 new affordable homes.
Design principles
- Create a gateway to the neighbourhood and kick-off the
masterplan's aim to make a greener neighbourhood
- Public realm enhancements to Ashmill Street and
courtyard behind existing building
- Building height of new development should have
appropriate relationship with neighbouring buildings
- Hybrid green/blue or brown roofs
Existing situation
BT repeater station
Homes
- 26 new homes
- 4-5 storey building
SLIDE 22
Client Suppliers Submission
SLIDE 23
RIBA Stage 1&2 BIM Pilot Project
SLIDE 24
(OIR)
RIBA Stage 1 BIM Kick-off Meeting
SLIDE 25
SLIDE 26
RIBA Stage 1&2
Design Model QS Cost Model Client
SLIDE 27
RIBA Stage 3&4 BIM Pilot Project
SLIDE 28
(OIR)
RIBA Stage 3&4 BIM Kick-off Meeting
SLIDE 29
SLIDE 30
(OIR)
TIDP Programme
SLIDE 31
Information Exchange Process
Design Team Models
SLIDE 32
S1.P1
File Naming Convention 1564_ECD_00_XX_M3_A_PROPOSED_S1.P1
Suitability
Shared S1 Issued for co-ordination S2 Issued for information S3 Issued for internal review and comment S4 Issued for construction approval S5 Issued for manufacture S6 Issued for PIM authorization (Information Exchanges 1-3) S7 Issued for AIM authorization (Information Exchange 6) D1 Issued for costing D2 Issued for tender D3 Issued for contractor design D4 Issued for manufacture/procurement
SLIDE 33
Validation Process
Design Model QS Cost Model Client Information Checks for Costing (LOI) Checker for Asset Information (AIR)
SLIDE 34
Design Coordination & Clash Validation
Client Model Review Coordination Meeting
SLIDE 35
BIM Pilot Project Delivery
Gateway/Approval 2D Information Delivery BIM Model Delivery
SLIDE 36
Conclusion
SLIDE 37
BIM Pilot Project Lesson Learned
(OIR)
The building is Data- Based Information model
01 02 03 04 05
BIM
Change in design team workflow Strong understanding of what is required (PAS1192,EIR & BEP) Stakeholder engagement in using the model Sharing knowledge and training the team Faster and better quality of information delivered
SLIDE 38
Thank you
ECD Architects Ltd Studio 3, Blue Lion Place, 237 Long Lane, London SE1 4PU T: 020 7939 7500 www.ecda.co.uk
