BROADVIEW PLANNING STUDY Community Consultation Meeting 2 February 2015 2 Agenda 7:00 pm Introductions, Agenda Review and Welcome 7:10 pm Presentation What Weve Heard and Information Assembled to Date 7:35 pm Questions of

slide-1
SLIDE 1

BROADVIEW PLANNING STUDY

Community Consultation Meeting 2

February 2015

slide-2
SLIDE 2

Agenda

7:00 pm Introductions, Agenda Review and Welcome 7:10 pm Presentation – What We’ve Heard and Information Assembled to Date 7:35 pm Questions of Clarification 7:50 pm Small Table Discussions – Our Goals and Vision for the Study Area

  • Exercise 1 – Character Zones and Study Area Boundary
  • Exercise 2 – Our Goals
  • Exercise 3 – Our Vision

8:30 pm Small Table Report Back and Plenary Discussion 8:55 pm Wrap-up and Next Steps 9:00 pm Adjourn 2

slide-3
SLIDE 3

Background

slide-4
SLIDE 4
  • Increasing pressure for redevelopment on

Broadview and community concerns regarding:

  • insufficient on-street parking
  • vehicular and pedestrian conflicts
  • a desire to maintain the character of the

street/area

  • November 2013, City Council direction to

initiate the study

Background

4

slide-5
SLIDE 5

City Council request the Director of Community Planning, Toronto and East York District to commence a planning study in 2014, on the portion

  • f Broadview Avenue which is identified as an Avenue, that will address

how new development will complement the existing built form, identify

  • pportunities for public realm improvements, and plan for the

transportation impacts of new development

Council Direction

5

slide-6
SLIDE 6

Meeting Purpose

1.

Provide update on study process and timeline

2.

Discuss analysis of existing conditions

3.

Define a vision for the future of Broadview

6

slide-7
SLIDE 7

June 2014 Kick off Meeting Winter 2015 Community Meeting 2 Spring 2015 Community Meeting 3 Fall 2015 Community Meeting 4 Report to TEYCC/Council

Winter 2014 SAC 1 Spring 2015 SAC 2 Fall 2015 SAC 3

We are Here

Study Process and Timeline

Assets and Opportunities Vision for the Future Options and Priorities Draft Design Guidelines

7

slide-8
SLIDE 8

What We Have Heard… So Far

Low-rise

(4 storeys)

Mid-rise

(6-8 storeys)

High-rise

(> 8 storeys)

Diverse Mixed-use Buildings Small businesses Walkable Cyclist-safe Accessible Community Feel Artistic Parking Mix of building heights Safe Connected to Nature Stable Green Unique Views Open Feel Old Charm Hodge Podge Community Involvement Complete Streets 8

slide-9
SLIDE 9

Examples

slide-10
SLIDE 10

Urban Design Guidelines: Queen Street East

10

slide-11
SLIDE 11

Urban Design Guidelines: Leslieville

11

slide-12
SLIDE 12

Study Area

Properties with frontage on Broadview between Danforth and Bater Avenue 12

slide-13
SLIDE 13

Existing Planning Framework

slide-14
SLIDE 14

Mixed-Use Areas:

  • Commercial-Residential uses are

permitted

  • Mid-rise development
  • Transition in built form to adjacent

neighbourhoods

Planning Framework

Avenues:

  • The Official Plan directs growth to the

Downtown area, Centres, and Avenues

  • Avenues are important corridors along

major streets where reurbanizaton is anticipated and encouraged because of existing infrastructure; including transit, retail, and community services 14

slide-15
SLIDE 15

Zoning By-law

Former Borough of East York 6752

  • Residential (low density - high density)
  • Commercial (residential /commercial)

Former City of Toronto 438-86

  • Commercial-Residential uses
  • 14 m (4 storeys) height limit
  • Total density of 2.5 times the lot area

City-wide Zoning By-law 569-2013

  • Under appeal at OMB
  • Same permissions as ZBL 6752 & 438-86

15

slide-16
SLIDE 16

Mid-rise Development

  • Study adopted by City

Council in 2010

  • Building height relates to

width of City Right-Of-Way (ROW)

  • Allows for 5 hrs of sunlight
  • n the opposite sidewalk
  • Stepback of upper storeys
  • Rear setback and angular

plane requirements

What is a Mid-Rise building? Mid-rise buildings are 'in between' scale of buildings, they are bigger than houses but smaller than towers (5-11 storeys subject to other criteria).

16

slide-17
SLIDE 17

Existing and As-of-right Heights

Zoned Heights:

10.5m (approx. 3 storeys) 14m (approx. 4 storeys) 16m (approx. 5 storeys) EAST

Erindale Ave. Pretoria Ave. Browning Ave. Fulton Ave. Nealon Ave.

Danforth Ave.

Westwood Ave. Bater Ave.

30m 70m 10m

Mortimer Ave.

17

Avenues and Mid-rise Study 27m 20m

varies (17m-25m)

Pretoria Ave.

Danforth Ave.

Chester Hill Rd.

Pottery Rd.

Hillside Dr.

WEST

10m 30m 70m

Avenues and Mid-rise Study 27m 20m

varies (17m-25m)

slide-18
SLIDE 18

Heritage Properties Listed in City’s Inventory

18

1 2 3 4 1 2 3 4

slide-19
SLIDE 19

PLANNING ANALYSIS

Complementing Existing Built Form

slide-20
SLIDE 20

Lot Configuration

20

slide-21
SLIDE 21

Building Footprints

21

slide-22
SLIDE 22

Massing Model

22

slide-23
SLIDE 23

Existing Uses

Institutional Mixed-Use Commercial Public Transit Residential

23

slide-24
SLIDE 24

Built Form Samples

24

slide-25
SLIDE 25

Streetwall

Varying streetwall height (base building height)

5 storeys 2 storeys 4 storeys 5 commercial storeys 3.5 storeys 3 storeys 3.5 storeys

West of Broadview: Danforth Ave. to Pretoria Ave. East of Broadview: Pretoria Ave. to Browning Ave.

25

slide-26
SLIDE 26

PLANNING ANALYSIS

Improving the Public Realm

slide-27
SLIDE 27

Streetscape

Boulevard width (distance from the property line to the street edge/curb, including sidewalk)

4.8m – 5.5m 3.8m – 4.8m < 3.8m > 5.5m

27

slide-28
SLIDE 28

Streetscape

Varying Boulevard widths and Building setbacks

28

3.5m 3.9m 1.9m 1.5m

Zero building setback Expansive front yard setback Front yard setback with landscaping in planter boxes

slide-29
SLIDE 29

Streetscape

Recessed entrances Seating Areas 29

slide-30
SLIDE 30

WEST SIDE OF BROADVIEW EAST SIDE OF BROADVIEW

  • 500

1,000 1,500 2,000 2,500 3,000 782 784 786 788 790 792 794 796 798 824 826 828 838 864 866 868 870 880 894 908 910 936 938-940 1040 CIBC 791 793 795 797 Albany Clinic 811-813 815B 815C 817 827 Medical Centre 871-873 889 891-893 895 897 905 959 985 Whistlers 1003 1005 1007 Sobey's

Retail Size

Average = 222 m2 Median = 119 m2

30 a b c a b c Ground Floor Area

slide-31
SLIDE 31

WEST SIDE OF BROADVIEW EAST SIDE OF BROADVIEW

  • 10

20 30 40 50 60 782 784 786 788 790 792 794 796 798 824 826 828 838 864 866 868 870 880 894 908 910 936 938-940 1040 CIBC 791 793 795 797 Albany Clinic 811-813 815B 815C 817 827 Medical Centre 871-873 889 891-893 895 897 905 959 985 Whistlers 1003 1005 1007 Sobey's

Retail Size

31

Average = 9m Median = 6 m

a b c a b c Storefront Width

slide-32
SLIDE 32

Existing Parks and Open Spaces

V

Viewpoints

32

V V V

slide-33
SLIDE 33

Character Zones for Discussion

A C B

Mix of lot sizes and land uses, backyard to backyard condition Small and diagonal lots, mainly residential, backyard to sideyard condition Wider and deeper lots, backyard to

  • pen space condition. Generally

expansive front landscaping

33

D

Wider and deeper lots, backyard to backyard or sideyard condition.

slide-34
SLIDE 34

PLANNING ANALYSIS

Planning for Transportation Impacts

slide-35
SLIDE 35

35

Parking Inventory and Usage

0.2 0.4 0.6 0.8 1 1.2 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24

Occupancy (%) Time/ Hour of the Day Busy Weekdays Fridays Saturdays

Street Side Between Hours

  • Max. Period Permitted

Broadview Ave. West & East Erindale Ave. & north of Chester Hill Rd. / Browning Ave. 9 am to 4 pm 1 hour Broadview Ave. West & East Chester Hill Rd./Browning Ave. & Bater Ave. Off-Peak Parking (3 hours) Erindale Ave. South Broadview Ave. & Ellerbeck St. 8 am to 6 pm 1 hour Pretoria Ave. North Broadview Ave. & Ellerbeck St. 8 am to 6 pm 1 hour

On-Street Parking: Off-Street Green P Parking: 35 Erindale Ave. (93 spaces – Surface Parking Lot)

Heavily Occupied Times

July 2014 Data

slide-36
SLIDE 36

Vehicle Traffic Growth Rate

400 800 1200 1998 2005 2012

Traffic Volume at Petoria: AM PEAK

500 1000 1500 2002 2008 2014

Traffic Volume Pottery/Mortimer: AM PEAK

Historical Data:

  • Vehicle volumes counts over a 10

year period (AM and PM peak hour)

  • Traffic is relatively constant

Current Experience:

  • Spot concerns of increased delays

Future Growth:

  • Policy based growth encouraging

modal shift

  • Improved public realm
  • Managing traffic

36

slide-37
SLIDE 37

Bicycle Data: Heat Map

  • New bicycle data currently under

review tracking raw numbers of bicycle trips

  • All streets are cycling streets, some

are more intense that others

  • Shift in transportation mode choice

as people choose to walk or cycle for example with improved infrastructure

  • Shift in mode choice results in

stabilised vehicle traffic despite increased population density

37

slide-38
SLIDE 38

38

Complete Streets

Streets that have been designed to fully accommodate all street users – including pedestrians of all ages and abilities, cyclists, transit users, car drivers, emergency and utility vehicles, and goods delivery – as well as space to support social and economic activities.

slide-39
SLIDE 39

Small Table Discussions

slide-40
SLIDE 40

Small Table Discussions

40

A C B D

Exercise #1: Character Zones and Study Area Boundary

Area to consider for expansion of Study Area Boundary Study Area indicated on Council Motion

slide-41
SLIDE 41
  • Exercise #2: Our Goals

Six themes have been identified based on the community feedback to date:

  • Our Buildings
  • Our Streetscape
  • Area Character
  • Our Community Services
  • Our Parks and Open Spaces
  • How We Move Around

Pick 3 themes and identify your top 3 goals (what you would like to see accomplished or improved) for those themes:

Small Table Discussions

41

slide-42
SLIDE 42
  • Exercise #3: Our Vision

Thinking about the study area as a whole, identify 3 key words that you would use to describe the area in the future.

Small Table Discussions

42

slide-43
SLIDE 43

THANK YOU Questions ?
