BRIGHT COLORS IN PURE AIR

The "TWEKO" painting equipment plant is a family-

• wned company that was founded in 1992. From the

moment of creation till now, the specialists of the enterprise have developed and implemented into production dozens of models of equipment for cleaning and preparation surfaces of products, as well as equipment for painting and drying various coatings - soils, varnishes, paints, thermal insulation coatings, etc.. For all its time, the main goal of the company was to create safe and comfortable working conditions for the most effective preparation / painting works in various industries, ranging from the provision of painting services to individuals and the introduction of high- performance painting plots at large industrial factory's.

ABOUT COMPANY

WWW.TWEKO.COM.UA

YEARS OF EXPERIENCE

During the work, the “Plant of equipment for painting “TWEKO“ has designed, made and assembled more than 200 different spraying and drying complexes for leading domestic and foreign enterprises in various industries of industrial production.

> 200

COMPLETED PROJECTS

BRIGHT COLORS IN PURE AIR

WWW.TWEKO.COM.UA

OUR CUSTOMERS

Central depot of the railway station in Tbilisi, «IRON TRADE» Ltd, VO «Voshod», DP «Ukrspetsvagon», “AZ MDF” LLC, SAS ADIDOR VOITURES, Myanmar Government, Yacht building shipyard «Fifth Ocean Yachts», LLC «Aerotechnica-MLT», JSC «Elektrozavod», JSC «Plant «Transformer», JSC «Dnipropetrovs'k aggregate plant», LLC “Paritet-K”, LLC «Polymer», JSC «Khersonoblenergo», Yagotinsky mechanical factory and others.

BRIGHT COLORS IN PURE AIR

WWW.TWEKO.COM.UA

DESIGN FOR INDIVIDUAL ORDER

Realization of projects on an individual request gave the team of the plant TWEKO an invaluable experience, thanks to which the R&D department and production department of the plant successfully implement industrial painting and drying chambers of any complexity.

BRIGHT COLORS IN PURE AIR

PAINTING CHMBERS

MAIN COMPANY PRODUCTS

WWW.TWEKO.COM.UA Painting and drying chamber (KFS) is a complex of equipment, which significantly increases the quality of painting and drying of protective or decorative paint and varnish coating. The KFS provides a constant and uniform flow of clean air heated to a given temperature, and thanks to the air preparation system, dust and other contaminating particles that can enter the chamber from the atmosphere, are effectively captured and delayed and full air purification is achieved during coating. Overpressure resulting from a right- calculated system of inlet and exhaust ventilation prevents dust from entering the clean room from the outside. In this case, the chamber provides the implementation of a full cycle

• f work on the quality of applying paint and varnish materials

to the surface and their subsequent drying, with the

• bservance of temperature and time regimes, set by the
• perator. In the chamber, any soils, paints, including water-

based, enamels, varnishes and other spraying materials can be used.

ABRASIVE BLASTING CHAMBER

MAIN COMPANY PRODUCTS

WWW.TWEKO.COM.UA The abrasive blasting chamber (KASO) is a complex of equipment designed to create safe working conditions for efficient and quick cleaning of surfaces of various products from rust, scale, paint or other contaminants. The dimensions

• f KASO and its processes meet all the most demanding

requirements for the protection of workers during blasting. In KASO, any type of abrasive materials can be used, depending on the type of surface to be treated, it may be steel pounded fraction / cast fraction, glass balls, electrocorundum, boron carbide or silicon, and others. In this case, KASO provides a full cycle of work on the supply, collection and regeneration of abrasive material. The abrasive blasting chamber is equipped with a fully automatic system for collecting and regenerating abrasive material, as well as a ventilation and dust removal system, which makes the product cleaning process as efficient as possible.

AUTOMATIC SHOT BLASTING MACHINE

MAIN COMPANY PRODUCTS

WWW.TWEKO.COM.UA Automatic pass-through shot blasting machine UDO is intended for clearing of rust, scale, and other contaminations

• f steel sheets, beams, corner profiles and pipes. Shot

blasting machine installation allows you to clean metal surfaces with an appropriate level of roughness and create an

• ptimum surface for further application of paint and varnish
• coating. Due to shot blasting cleansing, it improves

significantly adhesion to paint and lengthens the life of metal products. UDO cleans products according to the ISO Sa2.5 standard, whereby the surface should look like sealed from visible oil, grease and dirt, and from most of the scale, rust, paint and

• ther foreign substances. The equipment consists of a roller

conveyor, a chamber, a shot blasting turbine, an air separator fraction of dust (separator), shot cleaning system, dust removal system, longitudinal roller table conveyor, automatic control system and other devices.

WWW.TWEKO.COM.UA

LIFTING-MOBILE PLATFORMS FOR PAINTERS

ADDITIONAL EQUIPMENT FOR EFFECTIVE WORK

Lifting-mobile platforms are installed on each side of the cab

• f the painting and drying chamber and provide a quick and

safe movement of painters along the products. The platform movement is provided by pneumatic actuators, designed for long-term use. Platform management can be done directly from the work basket, while at the same time at any height. The control panel inside the basket allows you to maneuver along walls right-to-left, up-down, and protrude the basket from the wall to the product.

PARAMETER UNITS VALUE

Maximum load kg 150 Speed, under pressure 6 – 8 bar. m/min 4

RAIL TRANSPORT TROLLEY

ADDITIONAL EQUIPMENT FOR EFFECTIVE WORK

WWW.TWEKO.COM.UA The rail transport trolley (RTV) is intended for the transportation of various products and goods between production sites, located in one or different production rooms. RTV is a powerful welded platform with lower-mounted running wheels. The longitudinal and transverse stiffness is provided by powerful metal profiles that form the basis of the

• platform. The upper surface of the cart is flat, entirely covered

with a corrugated or cut sheet in the thickness of 3-4 mm. From the deflection of the sheet protect the longitudinal edges

• f the rigidity made of the channel. In the frame mounted

monorail running wheels. The cart can be made with any width

• f the rail track.

PARAMETER UNITS VALUE

Overall size, L х W m 2 х 6 Max load capacity t 20

WWW.TWEKO.COM.UA

ABRASIVE-BLASTING MACHINE WITH INDIVIDUAL PROTECTION PRODUCTS

ADDITIONAL EQUIPMENT FOR EFFECTIVE WORK

The abrasive-blasting machine is intended for cleaning surfaces from various contaminations such as rust, paint, scale and others. The machine performs the dispersal of abrasive particles using the energy of compressed air and directs them through a nozzle to a cleaned surface. Abrasive particles creep into the surface and remove from it a not strong layer, it can be paint and varnish coating, rust or other contamination.

PARAMETER UNITS VALUE

Cleaning class SA 2 Diameter of the tank mm 609 Height of the tank mm 1480 Max working pressure Bar 12 Capacity of the tank l 200 Air consumption, at a pressure of 8 bar m3 / min. 9 – 16,1 Surface treatment speed m2/h 21 – 37 Average consumption of abrasive kg/m2 28 – 32

The purification efficiency is theoretical, calculated for cleaning the equal surface of the primary metal by a qualified operator.

MOBILE SPRAY BOOTH

REALIZED PROJECTS

LLC «VERTIKAL», Kharkiv, Ukraine

MOBILE SPRAY BOOTH

REALIZED PROJECTS

LLC «VERTIKAL», Kharkiv, Ukraine

PAINTING-DRYING COMPLEX

REALIZED PROJECTS

“Kryukov Railway Car Building Works” PJSC, Kremenchug, Ukraine

PAINTING-DRYING CHAMBER IKFS SERIES

REALIZED PROJECTS

Yuzhnoye State Design.

AUTOMOBILE PAINTING-DRYING CHAMBER AKFS SERIES

REALIZED PROJECTS

MPM Motors, Paris, France

PAINTING POST FOR FURNITURE PRODUCTS

REALIZED PROJECTS

JSC «Association «Progress», Slavuta, Khmelnitskiy, Ukraine

PAINTING POST FOR MILITARY EQUIPMENT

REALIZED PROJECTS

«SpecOboronMash».

FURNITURE PAINTING-DRYING COMPLEX

REALIZED PROJECTS

PKF “Polimer”, Zaporizhia, Ukraine

SHOT BLASTING CHAMBER

REALIZED PROJECTS

Myanmar

AUTOMATIC SHOT BLASTING MACHINE

REALIZED PROJECTS

Myanmar

WWW.TWEKO.COM.UA

PAINTING OF A BIG TRUCK TRAILER

PROCESS OF WORKING IN THE PAINTING CHAMBER

WWW.TWEKO.COM.UA

PAINTING OF RAILWAY WAGON

PROCESS OF WORKING IN THE PAINTING CHAMBER

PAINTING OF ARMORED CAR ON RAIL TRANSPORT TROLLEY

PROCESS OF WORKING IN THE PAINTING CHAMBER

WWW.TWEKO.COM.UA

LIGHTING THE CHAMBER. TOP COUPLING ENERGY EFFICIENT LED LIGHTS

ELEMENTS OF EQUIPMENT PAINTING-DRYING CHAMBER

Painting-drying chamber AKFS series AUTOMOTIVE SERVICE STATION AUTOMAXIMUM, Kharkiv, Ukraine WWW.TWEKO.COM.UA

THREE-WHEEL GATES

ELEMENTS OF EQUIPMENT PAINTING-DRYING CHAMBER

Painting-drying chamber AKFS series AUTOMOTIVE SERVICE STATION AUTOMAXIMUM, Kharkiv, Ukraine WWW.TWEKO.COM.UA

OUTDOOR CONSTRUCTION OF AIRCRAFT

ELEMENTS OF EQUIPMENT PAINTING-DRYING CHAMBER

WWW.TWEKO.COM.UA

WWW.TWEKO.COM.UA

PAINTING CHAMBER CONTROL PANEL

ELEMENTS OF EQUIPMENT PAINTING-DRYING CHAMBER

FILTER VENTILATION AND SHOT SEPARATOR

ELEMENTS OF EQUIPMENT BLASTING CHAMBER

Shot-blasting chamber ТМ «BADOR» Ternopil, Ukraine WWW.TWEKO.COM.UA WWW.TWEKO.COM.UA

WWW.TWEKO.COM.UA

SYSTEM OF AUTOMATIC SHOT COLLECTING – SCRAPER FLOUR

ELEMENTS OF EQUIPMENT BLASTING CHAMBER

Shot-blasting chamber ТМ «BADOR» Ternopil, Ukraine

WWW.TWEKO.COM.UA

PROTECTIVE GUM COVERING WALLS

INTERNAL VIEW OF BLASTING CHAMBER

Shot blasting chamber Myanmar

THANK YOU FOR YOUR ATTENTION!

The team of TWEKO plant wish you improving working conditions, improving your products quality and accelerating your business. CONTACTS: +38 044 566 98 07 +38 044 566 98 08 E-MAIL: TWEKO1@GMAIL.COM
