Bright Cluster Manager

Advanced HPC cluster management made easy

Martijn de Vries

CTO Bright Computing

2

About Bright Computing

Bright Computing

• 1. Develops and supports Bright Cluster Manager for

HPC systems and server farms

• 2. Incorporated in USA (HQ in San Jose, California)
• 3. Development office in Amsterdam, NL
• 4. Backed by ING Bank as shareholder and investor
• 5. Sells through a rapidly growing network of resellers

and OEMs world-wide

• 6. Customers and resellers in US, Canada, Brazil, Europe,

Middle-East, India, Singapore, Japan

• 7. Installations in Academia, Government, Industry,

ranging from 4 node to TOP500 systems

3

Customers

I ndustry Governm ent Academ ia

4

The Commonly Used “Toolkit” Approach

• Most HPC cluster management solutions use the “toolkit”

approach (Linux distro + tools)

• Examples: Rocks, PCM, OSCAR, UniCluster, CMU, bullx, etc.
• Tools typically used: Ganglia, Cacti, Nagios, Cfengine, System Imager,

Puppet, Cobbler, Hobbit, Big Brother, Zabbix, Groundwork, etc.

• Issues with the “toolkit” approach:
• Tools rarely designed to work together
• Tools rarely designed for HPC
• Tools rarely designed to scale
• Each tool has its own command line interface and GUI
• Each tool has its own daemon and database
• Roadmap dependent on developers of the tools
• Making a collection of unrelated tools work together
• Requires a lot of expertise and scripting
• Rarely leads to a really easy-to-use and scalable solution

5

About Bright Cluster Manager

• Bright Cluster Manager takes a much more fundamental

& integrated approach

• Designed and written from the ground up
• Single cluster management daemon provides all functionality
• Single, central database for configuration and monitoring data
• Single CLI and GUI for ALL cluster management functionality
• Which makes Bright Cluster Manager …
• Extremely easy to use
• Extremely scalable
• Secure & reliable
• Complete
• Flexible

6

CMDaemon

Architecture

7

Bright Cluster Manager — Elements

Cluster Management Shell Cluster Management GUI SSL / SOAP / X509 / IPtables Cluster Management Daemon Disk Ethernet Interconnect IPMI / iLO PDU CPU GPU Memory PBS Pro Torque Maui/MOAB Grid Engine SLURM LSF* Monitoring Automation Health Checks Management Compilers Libraries Debuggers Profilers Provisioning SLES / RHEL / CentOS / SL / Oracle EL SLES / RHEL / CentOS / SL / Oracle EL ScaleMP vSMP

8

HPC User Environment

• Let users focus on performing computations
• Rich collection of HPC software
• Compilers (GNU, Intel*, Portland*, Open64, etc.)
• Parallel middleware (MPI libraries, threading libraries, OpenMP,

Global Arrays, etc.)

• Mathematical libraries (ACML, MKL*, LAPACK, BLAS, etc.)
• Development tools (debuggers, profilers, etc.)
• Environment modules
• Intel Cluster Ready Compliant

Compliant applications run out of the box

9

Management Interface

Graphical User Interface (GUI)

• Offers administrator full cluster control
• Standalone desktop application
• Manages multiple clusters simultaneously
• Runs on Linux, Windows, MacOS X*
• Built on top of Mozilla XUL engine

Cluster Management Shell (CMSH)

• All GUI functionality also available through

Cluster Management Shell

• Interactive and scriptable in batch mode

12

Cluster Management Shell (CMSH)

Features:

• Modular interface
• Command completion using tab key
• Command line history
• Output redirection to file or shell command
• Scriptable in batch mode
• Support for looping over objects

Example

[demo]% device [demo->device]% status demo ................ [ UP ] node001 ............. [ UP ] node002 ............. [ UP ]

17

Node Provisioning

Image based

• Slave node image is a directory on the head node
• Unlimited number of images can be created
• Software changes for the slave nodes are made inside the

image(s) on the head node

• Provisioning system ensures that changes are propagated to the

slave nodes

Nodes always boot over the network

• Slave nodes PXE boot into Node Installer, which
• Identifies node (switch port or MAC based)
• Configures BMC
• Partition disks (if any) and creates file systems
• Installs or updates software image
• Pivot the root from NFS to the local file system

20

Architecture — Monitoring

CMDaemon

BMC BMC BMC

25

Bright Cluster Manager for GPGPU

26

GPU Development Environment

• CUDA & OpenCL redistribution rights
• Current and previous versions of CUDA & OpenCL
• Easy switching between CUDA & OpenCL versions
• CUDA driver automatically compiled at boot time
• Support for new Fermi architecture
• Native 64-bit GPU support
• Multiple copy engine support
• ECC reporting
• Concurrent kernel execution
• Fermi HW debugging support in cuda-gdb

27

GPU Monitoring

31

Cluster Health Checking

• Goal: provide problem free environment for running jobs
• Hardware & software health
• Three types of health check
• Health checks before jobs are run

– Halt workload manager few (milli)seconds before job is executed – Check health of each reserved node – If unhealthy, take off line, inform system administrator – Hand job back to workload manager

• Frequently scheduled health checks

– Run health check when node is not used – Run health check through queuing system

• Hardware burn-in environment

– Most thorough health check – Requires reboot

• All types are extensible

36

Scalability

Cluster Management software should not be limiting factor for cluster size. Philosophy used for Bright Cluster Manager:

• All tasks performed by master node should be off-

loadable to dedicated nodes.

• If master node can not handle a task as a result of

cluster size, task can be placed on 1 or more dedicated nodes.

• For example: multiple dedicated load-balanced

provisioning nodes may be assigned in a cluster.

37

Image Based Provisioning

• Software image (or “image”) is directory on head node
• Image contains full Linux file-tree (/bin, /usr, …)
• Software is not installed on nodes directly, but rather

to image

• After image has been changed, changes can be

propagated to the compute nodes

• Propagating image changes to nodes can be done in

two ways:

1. Rebooting nodes 2. Using device imageupdate in CMSH, or “Update Node” in GUI

• Latter allows nodes to be updated without reboot
• Some changes do require reboot (e.g. kernel update)

38

Provisioning Process

• Node Installer submits provisioning request to head

node

• Head node will queue request until a provisioning slot

becomes available on one of the provisioning nodes (possibly just head node itself)

• Provisioning node will connect to compute node to

provision software image to local file system

• Two install modes:
• FULL: Re-partition hard drives, transfer image from scratch
• SYNC: Only transfer differences between image and local disk
• Default install mode is SYNC
• Disk setup mismatch triggers FULL install mode

40

Changing Software Images

• Installing/updating RPMs

rpm --root=/cm/images/default-image –i myapp.rpm yum --installroot=/cm/images/default-image install myapp yum --installroot=/cm/images/default-image update

• Installing software from source

make DESTDIR=/cm/images/default-image install Note that not all Makefiles support $DESTDIR Usage example from Makefile: install -m644 file-example $(DESTDIR)/etc/file

• Making changes manually
• chroot /cm/images/default-image

cd /usr/src/myapp; make install

• emacs /cm/images/default-image/etc/file

41

Cloud Bursting (in development)

• Allow clusters to be extended with cloud resources
• Cluster can grow or shrink based on workload and

policies

• Integrated interface to public cloud providers
• Unsolved problem: how to deal with local storage?

42
