René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann

Bridging the Gap between Smart Home Platforms and Machine Learning using Relational Reference Attribute Grammars Models@run.time 2019

September 17, 2019

Context and Goal

https://www.youtube.com/watch?v=HSFO1aD_w8o

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 2 / 16

Context and Goal

https://www.youtube.com/watch?v=HSFO1aD_w8o

Recognize arrival Control lights

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 2 / 16

Two Important Trends

More “Smart” Devices

— “20 billion internet-connected things by 2020” [Gartner, Inc., 2017] — Middleware platforms manage large number of devices, abstract hardware details, and provide static rules

Commercial Machine Learning

— “Machine learning has progressed dramatically over the past two decades, from laboratory curiosity to a practical technology in widespread commercial use” [Jordan and Mitchell, 2015]

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 3 / 16

Two Important Trends

More “Smart” Devices

— “20 billion internet-connected things by 2020” [Gartner, Inc., 2017] — Middleware platforms manage large number of devices, abstract hardware details, and provide static rules

Commercial Machine Learning

— “Machine learning has progressed dramatically over the past two decades, from laboratory curiosity to a practical technology in widespread commercial use” [Jordan and Mitchell, 2015]

Combination of Smart Home Platforms and Machine Learning

— Middleware only use static rules, machine learning alone can not be used easily at runtime — Very few approaches integrating both, and none uses Open Source Middleware Platforms

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 3 / 16

State-of-the-art: Middleware Platforms

• penHAB

Written in Java, based on Eclipse Smarthome. Concepts: Thing, item, type

Home Assistant

Written in Python. Concepts: state object, event, zone, scene

ioBroker

Written in JavaScript. Concepts: Adapter, instance, (UI) object

FHEM

Written in Perl. Concepts: Devices, events

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 4 / 16

Research Questions

RQ1 How to integrate multiple smart home middleware platforms with multiple machine learning components? RQ2 Which model elements and relations between them are necessary for such an integration? RQ3 How to ease the selection of relevant inputs for different instances of machine learning approaches?

Devices Middleware 3 Middleware 2 Smart Home Middleware 1 Component 3 Component 2 Machine Learning Component 1 newData ◮

◭ classify

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 5 / 16

Research Questions

RQ1 How to integrate multiple smart home middleware platforms with multiple machine learning components? RQ2 Which model elements and relations between them are necessary for such an integration? RQ3 How to ease the selection of relevant inputs for different instances of machine learning approaches?

Devices Middleware 3 Middleware 2 Smart Home Middleware 1 Component 3 Component 2 Machine Learning Component 1 Runtime Model

◭ sync ◮

newData ◮

◭ classify

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 5 / 16

Research Questions

RQ1 How to integrate multiple smart home middleware platforms with multiple machine learning components? RQ2 Which model elements and relations between them are necessary for such an integration? RQ3 How to ease the selection of relevant inputs for different instances of machine learning approaches?

Devices Middleware 3 Middleware 2 Smart Home Middleware 1 Component 3 Component 2 Machine Learning Component 1 Runtime Model

◭ sync ◮

newData ◮

◭ classify

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 5 / 16

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

OpenHAB

Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

OpenHAB

MQTT Broker Knowledge Base Create a Structured Knowledge Base integrating all investigated middleware platforms Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

Home I/O Simulator

Brightness Sensor

OpenHAB OpenHAB

MQTT Broker Knowledge Base Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

Home I/O Simulator

Brightness Sensor

OpenHAB OpenHAB

MQTT Broker

M A P E

Knowledge Base Extend the Resulting Knowledge Base with new information needed for self-adaptive behaviour Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

Home I/O Simulator

Brightness Sensor

OpenHAB OpenHAB

MQTT Broker

M A P E

Knowledge Base

Activity Learning Component Preference Learning Component

Enable Machine Learning Algorithms to learn user’s preferences Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

Home I/O Simulator

Brightness Sensor

OpenHAB OpenHAB

MQTT Broker

M A P E

Knowledge Base

Activity Learning Component Preference Learning Component

Represent the Relations between machine learning models and elements in the structured knowledge base Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

Home I/O Simulator

Brightness Sensor

OpenHAB OpenHAB

MQTT Broker

M A P E

Knowledge Base

Activity Learning Component Preference Learning Component

Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

Home I/O Simulator

Brightness Sensor Home Assistant

OpenHAB

MQTT Broker

M A P E

Knowledge Base

Activity Learning Component Preference Learning Component

Component Data Flow MAPE Control Flow

Solution: A Structured Model

Smart- phone Smart- watch Smart Light

Home I/O Simulator

Brightness Sensor Home Assistant

OpenHAB

MQTT Broker

M A P E

Knowledge Base

Activity Learning Component Preference Learning Component with Decision Trees

Component Data Flow MAPE Control Flow

The Five Aspects (to be) Modelled with RAGs

located in Smart Home Entity Model Preferences Activity Location User nearby located in valid for has performs happens in valid for affects

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 7 / 16

The Five Aspects (to be) Modelled with RAGs: Smart Home Entities

ItemMetaData Smart Home Entity Model Group Item Channel Category Channel ChannelType Thing ThingType * * * * linkedItems * 1 1 * * * * * *

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 8 / 16

The Five Aspects (to be) Modelled with RAGs: Smart Home Entities

1 SmartHomeEntityModel ::= Thing* Group* ThingType* ChannelType* ChannelCategory*

ItemCategory* /ActivityItem:Item/ ;

2 ThingType : DescribableModelElement ::= Parameter* ; 3 rel ThingType.ChannelType* -> ChannelType ; 4 abstract Item : LabelledModelElement ::= <_fetched_data:boolean>

MetaData:ItemMetaData* [ItemObserver] ;

5 rel Item.Category? -> ItemCategory ; 6 rel Item.Controlling* <-> Item.ControlledBy* ; 7 8 abstract ItemWithBooleanState : Item ::= <_state:boolean> ; 9 abstract ItemWithStringState : Item ::= <_state:String> ; 10 abstract ItemWithDoubleState : Item ::= <_state:double> ; 11 ColorItem : Item ::= <_state:TupleHSB> ; 12 DateTimeItem : Item ::= <_state:Instant> ; 13 ContactItem : ItemWithBooleanState ;

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 8 / 16

Architecture Details (1/2)

Modelled using Relational RAGs

— Declarative specification of structure, and its relations — Analyses on this structure — Definition of relations rel MachineLearningModel.RelevantItem* <-> Item.RelevantInMachineLearningModel* ; rel MachineLearningModel.TargetItem* <-> Item.TargetInMachineLearningModel* ;

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 9 / 16

Architecture Details (1/2)

Modelled using Relational RAGs

— Declarative specification of structure, and its relations — Analyses on this structure — Definition of relations rel MachineLearningModel.RelevantItem* <-> Item.RelevantInMachineLearningModel* ; rel MachineLearningModel.TargetItem* <-> Item.TargetInMachineLearningModel* ;

Adapter to Middleware Platforms

— Claim: Model is general enough to map concepts of every middleware — Currently implemented for openHAB

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 9 / 16

Architecture Details (2/2)

MAPE-K and Integration with Machine Learning

— Underlying adaptation mechanism is MAPE — Activity recognition used in Analyse Phase to check current activity — Preference learning used in Plan to get preferences to be applied

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 10 / 16

Architecture Details (2/2)

MAPE-K and Integration with Machine Learning

— Underlying adaptation mechanism is MAPE — Activity recognition used in Analyse Phase to check current activity — Preference learning used in Plan to get preferences to be applied

Adapter to Machine Learning

— Claim: Model is general enough to map concepts to machine learning — Currently implemented for Neural Networks and Decision Trees

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 10 / 16

Evaluation (1/2)

Setup

— Activity recognition based on rotation and acceleration data from phone and watch — Resulting activity plus brightness is input for preference learning Input Activity Sleeping Working . . . Preference

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 11 / 16

Evaluation (1/2)

Setup

— Activity recognition based on rotation and acceleration data from phone and watch — Resulting activity plus brightness is input for preference learning Input Activity Sleeping Working . . . Preference

Adapters

Connecting Knowledge Base and Machine Learning Models Encoder to transform entity states to input variables Decoder to interpret classification result

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 11 / 16

Evaluation (2/2) Knowledge Base Machine Learning Component

… … …

Smartphone Smartwatch x1

1

x1

2

x12

1

y1

1

y6

1

x10

2

y1

2

y2

2

Encoder Encoder

Contributions

— Definition of structured model to describe smart home entities and related aspects — Integration of model in Smart Home Middleware: Prototype using openHAB — Integration of model with Machine Learning Algorithms: Prototype using Neural Networks — DSL to load and serialize runtime model

Devices Middleware 3 Middleware 2 Smart Home Middleware 1 Component 3 Component 2 Machine Learning Component 1 Runtime Model

◭ sync ◮

newData ◮

◭ classify

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 13 / 16

Future Work

Further decouple tasks of encoder and decoder

Two tasks: Feature selection and mapping between models

Handle Interference of preferences of multiple users

Define order for application of preferences

Challenges in user experience

Design UI explaining system behaviour, capture intend of user changes

Specifications and proof of invariant

Use knowledge base to ensure consistent, predictable behaviour

Smart Home Platforms + Machine Learning with RAGs René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann September 17, 2019 14 / 16

René Schöne, Johannes Mey, Boqi Ren and Uwe Aßmann

Bridging the Gap between Smart Home Platforms and Machine Learning using Relational Reference Attribute Grammars Models@run.time 2019

September 17, 2019

Devices Middleware 3 Middleware 2 Smart Home Middleware 1 Component 3 Component 2 Machine Learning Component 1 Runtime Model

◭ sync ◮

newData ◮

◭ classify

https://git-st.inf.tu-dresden.de/OpenLicht/eraser

References

Gartner, Inc. (2017). Leading the IoT: Gartner Insights on How to Lead in a Connected World. Technical report. Jordan, M. I. and Mitchell, T. M. (2015). Machine learning: Trends, perspectives, and prospects. Science, 349(6245):255–260.
