BIOTOILET M E C H W AT T E C H N O L O G I E S P V T. LT D . W W W. M E C H W AT. C O M WHAT IS A BIOTOILET ? BioT oilet is an assemble unit of toilet super structure with bio- digester process unit for complete decomposition of human
M E C H W AT T E C H N O L O G I E S P V T. LT D . W W W. M E C H W AT. C O M
WHAT IS A BIOTOILET ?
toilet super structure with bio- digester process unit for complete decomposition of human sewage waste into gases and digested nutrient rich liquid fertilizer residual. BioT
mechanism is followed by anaerobic and aerobic
Hydrolysis
1
Acid forming Stage
2
Methanogenesis Stage
3
VA R I O U S B I OTO I L E T M O D E L S T R U C T U R E
BIOTOILET MODEL 151
Sr. No Detail Specification 1 Size-[ L x B x H] ft. [ 4 x 4 x 7] ft. 2 MOC 24 mm PVC Solid Sheet 3 Structure MS Angle & Square Pipe 4 Ventilation 250 mm Crompton make exhaust fan 5 Door 24 mm pvc solid sheet with door 6 WC Western/ Indian ; both available 7 Piping work Schedule 40 UPVC for water line; Schedule 80 PVC for Drain Line 8 Sanitary Item Health Faucet; Two way bib cock, wash basin and flush tank included 9 Bio-digester Capacity 500 Liter
Detail Specification 1 Size-[ L x B x H] ft. [ 4 x 4 x 7] ft. 2 MOC 12 mm PVC Solid Sheet 3 Structure MS Angle & Square Pipe 4 Ventilation 250 mm Crompton make exhaust fan 5 Door 12 mm pvc solid sheet with door 6 WC Western/ Indian ; both available 7 Piping work Schedule 40 UPVC for water line; Schedule 80 PVC for Drain Line 8 Sanitary Item Health Faucet; Two way bib cock, wash basin and flush tank included 9 Bio-Digester Capacity 500 Liter
BIOTOILET MODEL 153
Detail Specification 1 Size-[ L x B x H] ft. [ 4 x 4 x 7] ft. 2 MOC 40 mm Puf Coated 1mm GI Sheet Panel/ Puf Panel / HDPE Panel /PVC Panel/FRP Panel Sheet 3 Structure MS Square Pipe & Aluminum Section 4 Ventilation 250 mm Crompton make exhaust fan 5 Door 40 mm puf coated 1 mm GI Sheet Panel 6 WC Western/ Indian ; both available 7 Piping work Schedule 40 UPVC for water line; Schedule 80 PVC for Drain Line 8 Sanitary Item Health Faucet; Two way bib cock, wash basin and flush tank included 9 Bio-Digester Capacity 500 Liter
W E M A N U F A C T U R E T H E C U S T O M D E S I G N O F B I O T O I L E T A S P E R C L I E N T R E Q U I R E M E N T & S P E C I F I C AT I O N .
B I OTO I L E T P R O J E C T WO R K D E TA I L [ 2 0 1 6 - 2 0 1 7 ]
P R O J E C T W O R K C O M P L E T E D I N V A R I O U S S C H O O L O F G U J A R A T R E G I O N .
M A H I B R I D G E P R O J E C T
BGR ENERGY SYSTEM LTD PROJECT
completed under the BGR Energy System Ltd i.e., Dr. NarlaTata Rao Power Plant, Ennore Power Plant , Ghatampur Power Plant,etc.
A S P A R T O F C S R P R O J E C T, B I O T O I L E T I N S T A L L E D F O R P U B L I C U S E I N D A D R A N A G A R H A V E L I .
M O R E T H A N 2 8 S I T E S P R O J E C T E X E C U T I O N D O N E B Y M E C H W A T I N L A S T 1 2 M O N T H F O R V A R I O U S R E G I O N O F I N D I A
ADITYA BIRLA GROUP PROJECT
manufacturing & Services for various coal mining sites of Aditya Birla Group in India
M A N U FA C T U R I N G , E X P O RT A N D S E RV I C E O F B I OTO I L E T & S A N I TAT I O N P R O J E C T
G R OW I N G A M O N G TO P L E A D E R S I N E N G I N E E R I N G S E C TO R
