Baty International Ltd 3D Vision Systems 3D Vision and Touch Systems precision measuring instruments www.baty.co.uk Venture 3 Axis Manual or CNC 250mm x 125mm and 300mm x 300mm models Manual with motorised autofocus or full


slide-1
SLIDE 1

precision measuring instruments www.baty.co.uk

Baty International Ltd

 3D Vision Systems  3D Vision and Touch Systems

slide-2
SLIDE 2

precision measuring instruments www.baty.co.uk

  • 250mm x 125mm and 300mm x

300mm models

  • Manual with motorised autofocus
  • r full CNC options
  • Heavy duty mechanics (ideal for

shop floor)

  • 6.5:1 zoom optics
  • Programmable segmented LED

lighting

  • Low cost
  • 165mm Z axis on adjustable

dovetail slide for taller parts

Venture 3 Axis Manual or CNC

slide-3
SLIDE 3

precision measuring instruments www.baty.co.uk

3D Large Format CNC Multi-Sensor

  • 600 x 600 and 600 x 900 models, all with 250mm Z axis
  • 3D Fusion software with advanced edge detection
  • Multi-sensor capability
  • Proven air bearing design
  • Programmable segmented LED Lighting
  • Supplied with stand
slide-4
SLIDE 4

precision measuring instruments www.baty.co.uk

  • A common measuring platform across all models
  • Multi-sensor capability
  • Fully dimensioned part view
  • Teach and Repeat programming
  • Profile scanning and best fit to CAD
  • Retrofit possibilities for existing equipment
  • Industry leading graphical user interface

Baty's Fusion Metrology Software

slide-5
SLIDE 5

precision measuring instruments www.baty.co.uk

  • Speed of measurement
  • More data per feature
  • High accuracy
  • Ease of use
  • No operator influence
  • Greater understanding of form
  • Highly repeatable measurements
  • Views the edge from directly above

unlike field of view systems

  • Superb edge detection tools find

the edge where many systems fail

  • Touch probe options and tool

change on CNC systems

Why Choose a Baty Vision System?

slide-6
SLIDE 6

precision measuring instruments www.baty.co.uk

ITS FAST!! - VED Means Hundreds of Data Points per Click

slide-7
SLIDE 7

precision measuring instruments www.baty.co.uk

Higher Accuracy and Repeatability

slide-8
SLIDE 8

precision measuring instruments www.baty.co.uk

Results are not Influenced by the Operator / Probing Force

  • Advanced Edge Detection
slide-9
SLIDE 9

precision measuring instruments www.baty.co.uk

Measure 2D Surface and Profile Edges

  • Edge detection can be used on surface images
slide-10
SLIDE 10

precision measuring instruments www.baty.co.uk

Combine with Touch Probe for ‘Best of Both Worlds'

slide-11
SLIDE 11

precision measuring instruments www.baty.co.uk

Non-Contact Measurement: Will Not Influence the Part

  • No need to clamp the workpiece
  • Soft materials (plastics and rubbers) will not be

distorted or damaged during measurement

  • High magnification allows tiny features to be

viewed as well as measured

  • No probing force issues
  • Edge detection means the system makes the

decisions

slide-12
SLIDE 12

precision measuring instruments www.baty.co.uk

Why Choose Baty?

  • More functions as standard than any other

Vision System

  • Powerful yet easy to use Fusion software
  • Designed and manufactured by Baty in

Burgess Hill

  • Web and telephone applications support
  • Manufacturer trained Field Service

Engineers

  • Low cost of ownership and software

upgrades are free of charge

slide-13
SLIDE 13

precision measuring instruments www.baty.co.uk

USPs Included as Standard

  • Zoom optics
  • Multi-sensor compatible
  • Dovetail slide for taller parts
  • Heavy duty cross-roller rail-guide

staging

  • Unique segmented LED lighting

including TTL

  • Unique USB2 camera developed

for Baty Venture

  • Advanced error mapping
slide-14
SLIDE 14

precision measuring instruments www.baty.co.uk

Advanced Vision Measurement Tools

  • Developed by Baty specifically

for our Venture range

  • Multi-sensor capability
  • Powerful edge detection editing
  • Easy programming
  • SPC, profile scanning / best

fitting, CAD i/face all standard

  • Graphics report produces

dimensioned drawing - 1 click

  • utput to Excel
slide-15
SLIDE 15

precision measuring instruments www.baty.co.uk

Programmable, Segmented LED Lighting

  • High intensity white LEDs for colour


  • Lighting conditions reproduced

automatically

  • Segment control to a single pair
  • Collimated profile light
  • TTL (Through The Lens) lighting as

standard

slide-16
SLIDE 16

precision measuring instruments www.baty.co.uk

Our Camera

  • 3.2 megapixel
  • Dynamic latch to motion control for

faster, more accurate autofocus

  • Optimised to Venture's optics
  • Drivers written specifically for Fusion
  • Digital zooming
  • Auto mode to optimise image for

metrology

slide-17
SLIDE 17

precision measuring instruments www.baty.co.uk

The Complete Package

  • All features are STANDARD
  • Ongoing development with

FREE software upgrades

  • Complete product portfolio

to cover a range of applications and budgets

slide-18
SLIDE 18

precision measuring instruments www.baty.co.uk

Designed and Made by Baty

  • Optical measurement specialists since 1932
  • Spares and support readily available
  • Fast reaction to market feedback
  • Hardware and software development under one roof
  • ISO 9001:2000 Quality Assured
slide-19
SLIDE 19

precision measuring instruments www.baty.co.uk

Existing Markets

  • Motor Sport
  • Aerospace
  • Electronics
  • Automotive
  • Pharmaceutical
slide-20
SLIDE 20

precision measuring instruments www.baty.co.uk

Reference Customers

  • McLaren F1
  • Ferrari
  • Renault F1
  • TWR
  • Jordan F1
  • Jaguar F1
  • Delphi
  • Bespak
  • Whirlpool
  • Visteon
  • Rolls Royce
  • Gillette
  • Robert Bosch
  • Bentley Cars
  • Eaton
  • DePuy
  • Johnson & Johnson
  • Logitech
slide-21
SLIDE 21

precision measuring instruments www.baty.co.uk

Reference Customers - Europe

  • Bosch Braking Systems
  • Lear Corporation
  • Renault Espana
  • Sandvik Espanola
  • Schnider Electric
  • Tyco Electronics Amp
  • Valeo
  • Avon Cosmetics
  • MAHLE
  • Philips Lighting
  • Volkswagen
  • Eaton
slide-22
SLIDE 22

precision measuring instruments www.baty.co.uk

Applications

slide-23
SLIDE 23

precision measuring instruments www.baty.co.uk

Applications

slide-24
SLIDE 24

precision measuring instruments www.baty.co.uk

Applications

slide-25
SLIDE 25

precision measuring instruments www.baty.co.uk

Applications

slide-26
SLIDE 26

precision measuring instruments www.baty.co.uk

Applications
