Membrane Filtration Basics 101 Paul J. Delphos, Black & Veatch 757-456-5380, ext 12 VA AWWA Plant Operations Committee Operators Conference Virginia Beach, VA May 19-21, 2014 Presentation Overview Market Assessment Membrane


slide-1
SLIDE 1

Membrane Filtration Basics 101

Paul J. Delphos, Black & Veatch 757-456-5380, ext 12 VA AWWA Plant Operations Committee Operators Conference Virginia Beach, VA May 19-21, 2014

slide-2
SLIDE 2

Presentation Overview

 Market Assessment  Membrane Theory  Example Applications

slide-3
SLIDE 3

What’s The Big Deal??

 1st Significant MF/UF System in North America in

1993 (Saratoga, CA – 3.6 mgd)

 Over 250 plants now on-line  Historically, small facilities (i.e. < 1 mgd) for small

clients

 Trend is to fewer, but larger facilities

 Minneapolis – 70 and 90 mgd  Singapore – 72 mgd  Lancaster – 24 mgd, expandable to 36 mgd

slide-4
SLIDE 4

Desalination Is Growing As Well

SWRO BWRO EDR BWRO SWRO EDR BWNF

250

20 15

71 110 92

44

110

BWNF

Numb Number er of

  • f Inst

Installa allation tions Ca Capacity ity (mg (mgd)

slide-5
SLIDE 5

Other Perspectives

 Membrane System Sales To Reach $9 Billion by

2008 (Mcllvaine Company, 2006)

 $6.8 Billion in 2005 (33% Top End Growth)  Includes Desalination and Low-Pressure Membranes

 Microfiltration from $1.9 to $2.5 Billion  Only 2.5% of US Drinking Water is Treated with

MF/UF Membranes

 Expected to Reach $10 Billion by 2010

Nearly All New Revenues Are From New Projects

slide-6
SLIDE 6

What Are Membranes? Cartridge/Pressure Submerged/Vacuum

slide-7
SLIDE 7

Membrane Theory Overview

Colloids Bacteria Pollens Yeasts Organic macromolecules Organic compounds Viruses Dissolved salts Reverse osmosis Nanofiltration Microfiltration Sand filter 1 0.1 0.01 0.001 0.0001 10 100 um hair visible to naked eye Giardia Smallest microorganisms Polio virus Ultrafiltration

slide-8
SLIDE 8

How Do Membranes Work? Membranes can remove anything that is larger than its pores.

slide-9
SLIDE 9

Giardia Cryptosporidium

slide-10
SLIDE 10
  • Membranes fail incrementally – one fiber at a time.
  • Statistically, individual fiber breaks are insignificant

to the overall microbial water quality.

Membrane Failure Mode

slide-11
SLIDE 11

Bubble point Air pressure Sonic wave Bio-challenge Turbidity Particle monitoring

Direct Measures Indirect Measures

The accepted standard is moving towards continuous (safety interlock) turbidimeters. Detection limit  0.001 NTU.

On-Line Integrity Testing

slide-12
SLIDE 12

Some Key (and New) Terms

NEW

 Flux  Flux Decline  Specific Flux/Permeability  Reverse Filtration  Membrane Integrity  Log Removal  Recovery  Transmembrane Pressure

OLD

 Overflow Rate  Declining Rate  ????  Backwash  Filter Breakthrough  Filtered Turbidity  Backwash Volume  Filter Head Loss

slide-13
SLIDE 13

Piloting Overview

 Number of Systems?  Regulatory Acceptance  Verified Membrane

Applicability

 Basis of Design  Operator Experience

slide-14
SLIDE 14

Data Evaluation

City of Lancaster MF Pilot

10 20 30 40 50 60 Nov Jan Mar Apr Jun gfd psi 2 4 6 8 10 12 ZW 500-C, Sp Permeability @ 20°C ZW 500-C, Instantaneous Flux ZW 500-C, Average TMP

 Flux  Recovery/Waste Disposal  Cold Water TMP Issues  Daily Cleans vs. Monthly

Cleans

 Turbidity  TOC/UV254  Particle Counts – log removal  MIT’s

slide-15
SLIDE 15

Membrane Fouling

Causes

 Biological  Organic/Colloidal/

Particle

 Chemical Scaling  Membrane Compression  Synthetic Polymers

Mitigation Measures

 Chlorination  Cross-Flow  Backwash  Chemical Cleaning  Additives/Coagulants  Pretreatment

slide-16
SLIDE 16

Membrane Fouling Directly Impacts Costs

 Fouling is the limiting factor in most membrane system

designs

 By removing organics, or natural organic matter (NOM),

membranes become much more effective

 Coagulation removes NOM by:

 Charge Neutralization  Adsorption To Precipitates

 With membranes, coagulation is geared to TOC removal  The “cake layer” on pressure systems improves TOC

removal

slide-17
SLIDE 17

Membrane Fouling

2 4 6 8 10 12 14 16 50 100 150 200 250 300

Time

Pressure - psi

Membrane Fouling Backwash Irreversable Fouling Backwash & Chemical Cleaning

slide-18
SLIDE 18

Membrane Fouling Example

Before and After Backwashing

2 4 6 8 10 12 14 16 18 20 22 22- Jul 24- Jul 26- Jul 28- Jul 30- Jul 1- Aug 3- Aug 5- Aug 7- Aug 9- Aug 11- Aug 13- Aug 15- Aug 17- Aug 19- Aug 21- Aug

Date TMP (psi)

Before BP Vacuum After BP Vacuum

(1) Vacuum increase due to flux increase corresponding to re-adjusted permeate flow. (2) Rain event - organics/color raw water spike, alum dosage not increased to compensate. (3) High vacuum alarm --> tank dumped, re-started with higher alum dosage. (4) Caustic dosing interrupted. (5) High vacuum alarm --> clean (6) Clean - vacuum recovers to 4"Hg. (7) Ferric dosing interrupted? (Floc tank pH = 6.8). (8) High vaccum alarm --> system off for 6.5 hours and then re-started.

(1) (2) (3) (5) (4) (6) (7) (8)

slide-19
SLIDE 19

SEM Images of Fouling Layer

(UF Membrane, CA, 100k MWCO)

 Clean Membrane  Growth of NOM Fouling Layer Over Time  Effect of Backwashing on Fouling Layer  HIOP Cake Layer with Sorbed NOM  Effect of Backwashing on Cake Layer

slide-20
SLIDE 20

Clean Membrane, CA 100k MWCO

slide-21
SLIDE 21

Dead-End Filtration – 30 Minutes

slide-22
SLIDE 22

Dead-End Filtration – 1 Hour

slide-23
SLIDE 23

NOM Layer Before Backwash

slide-24
SLIDE 24

NOM Layer After Backwash

slide-25
SLIDE 25

Coagulant Aid (HIOPS) + NOM Before BW

slide-26
SLIDE 26

Coagulant Aid + NOM After BW

slide-27
SLIDE 27

 Turbidity/pathogen/TOC removal on raw water  Replace conventional filters following

flocculation/sedimentation

 Treatment of conventional filter backwash water  Pretreatment ahead of RO or NF membrane system  Fe/Mn removal following oxidation  Arsenic Removal  Pathogen removal following conventional treatment

Potential Applications For Low Pressure Membranes

slide-28
SLIDE 28

Typical Pressure MF/UF System

Air System B/W Water Cl2 Raw Water Source Supply Pump Particle Strainer CIP System Membrane Modules Backwash Waste/ Concentrate To Disposal Finished Water Storage Finished Water Pumping Permeate

slide-29
SLIDE 29

Submerged - Enhanced Coagulation

Air Permeate Pump Feed Water Bleed/Concentrate Flocculation Chamber Coagulant Flash Mixer High solids concentration in tank

slide-30
SLIDE 30

Filtered Water

5 to 50 psi

Filtered Water Filtered Water Solids and Liquids Under Pressure

Pressure vs. Submerged

slide-31
SLIDE 31

Pressure vs. Submerged

Pressure

 Advantages

Skid-mounted

Easy to install

Great for small systems

Easy competition

High Fluxes

 Disadvantages

Larger systems

Fouling/energy

Low Dosages of Coagulant

Backwashing

Submerged

 Advantages

Use of existing tanks

Larger systems

Low energy

Great for poor raw water

Low fouling

Backwash recovery

 Disadvantages

Modifications can be expensive

Low flux rates

Concentrate with fiber breakage

slide-32
SLIDE 32

Filtered Water

5 to 50 psi

Filtered Water Filtered Water Solids and Liquids Under Pressure

Outside-In vs. Inside-Out

slide-33
SLIDE 33

Outside-In vs. Inside-Out

Outside-In

 Advantages

 Submerged option  Larger active area  Higher solids  Lower Pressure  Dead-end flow

 Disadvantages

 Lower comparative flux  Irreversible fouling?

Inside-Out

 Advantages

 Great with clean water  Cross-flow operation minimizes

irreversible fouling

 Disadvantages

 Recirculation required  Higher flux requirements  High fouling potential  Increased energy

slide-34
SLIDE 34

MF/UF Modes of Operation

Conventional

(Dead-End)

Feed

membrane filter

Cross-flow Feed

membrane filter

slide-35
SLIDE 35

Principal Suppliers of Low Pressure Drinking Water Membrane Systems

Membrane System Suppliers

 Pall Corporation (MF/UF)  GE - Zenon Environmental, Inc.

(MF/UF)

 Evoqua Water Technologies

(Siemens - US Filter/Memcor (MF) )

 Wigen, Inc. (UF)  H2O Installations  WesTech  Kruger

Membrane Module Suppliers

 GE (UF  Evoqua (MF)  Dow (UF)  Toray (UF)  Hydronautics, Inc. (UF)  Asahi (MF)

slide-36
SLIDE 36

Primary Elements of Low-Pressure Membrane System

 Feed water/vacuum pumps  Ancillary pumps  Automatic screens  Skids with PLC-based controls  Clean-in-place (CIP)  SCADA system/PLC network  Air delivery system  Waste holding tank/pumps  Neutralization tank/pumps

slide-37
SLIDE 37

Roanoke, VA – Crystal Spring

 Spring has been used for drinking water since 1880s  In summer of 2000, VDH determine spring was GWUI as

coliform counts increased

 Virginia Membrane Plants -

Memcor - 14 Koch - 1

 VDH “Approved” Other Membrane Manufacturers  Competitive Bid Between Memcor and Pall

slide-38
SLIDE 38

Crystal Spring WTP - Design Conditions

 5 mgd firm (one rack out of service)  99.5% recovery (backwash recovery)  No pretreatment (chlorine was recommended by Pall)  30 day cleaning cycle  60 minute backwash frequency  10-year membrane warranty  Performance testing for successful bidder

slide-39
SLIDE 39

Crystal Spring WTP - Bid Summary

Cost Component US Filter - Memcor Pall Capital $1,600,317 $1,960,000 O&M (20-yr PW) $436,625 $303,176 Membrane Repl. (20-yr PW) $357,822 $429,130 Total 20-yr PW $2,394,764 $2,692,306

slide-40
SLIDE 40

Performance Testing Operating Results

 Flux: 34.8 gfd @ 15oC  TMP: 1 psi increase per 15 to 18 days  Average TMP: 10.5 psi  Backwashing: 150 sec/90 minutes  97% Recovery  CIP Interval of Over 90 days

slide-41
SLIDE 41

Crystal Spring WTP – Performance Testing Criteria

 Flux:

34.6 gfd

 Recovery:

95% w/o backwash recovery 99.5% w/ backwash recovery

 Backwash:

150 sec/60 min

 CIP Interval:

30 days

 Chemical Consumption Limits  Power Consumption Limits  100 – day Duration

slide-42
SLIDE 42

Performance Testing Water Quality Results

 Turbidity

 Raw: 0.06 NTU to 0.14 NTU  Permeate: 0.02 NTU (lower limit of turbidimeter)

 Particle Counts

 Raw: 25 to 75 >2 um/mL  Permeate:

2 to 8 >2 um/mL

 1 to 1.5 log removal

slide-43
SLIDE 43

Pilot Turbidity Spike Data

9.8 9.9 10 10.1 10.2 10.3 10.4 10.5 10.6 14:15 14:40 15:11 15:39 15:44 16:12 16:23 16:40 16:46 Time TMP (psi) 5 10 15 20 25 30 35 Feed Turbidity (NTU) TMP Turbidity ``

Permeate <0.023 NTU

slide-44
SLIDE 44

Crystal Spring WTP

slide-45
SLIDE 45

Spring, Pumps and Screens

slide-46
SLIDE 46

Installed Membrane System

slide-47
SLIDE 47

Installed Membrane System

slide-48
SLIDE 48

CIP System

slide-49
SLIDE 49

Membrane System Piping

slide-50
SLIDE 50

Operating Data - Flow

0.00 1.00 2.00 3.00 4.00 5.00 6.00 December January Febuary March April May June July August Month Flow (mgd)

slide-51
SLIDE 51

Operating Data - Flux

20 22 24 26 28 30 32 34 December January Febuary March April May June July August

Month Flux (gfd)

slide-52
SLIDE 52

Operating Data - Recovery

90% 91% 92% 93% 94% 95% 96% 97% 98% 99% 100% December January Febuary March April May June July August Month Recovery (%)

slide-53
SLIDE 53

Operating Data - Turbidity

0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2 December January Febuary March April May June July August Month Turbidity

slide-54
SLIDE 54

Operating Data - TMP

5 10 15 20 25 30 Febuary March April May June July August Month TMP (psi) Filter 1 Filter 2 Filter 3 Filter 4 Filter 5

slide-55
SLIDE 55

Other 1st Year Results

 CIP Interval: 1 per 6 months  Zero Fiber Breaks (over 10 million fibers)  Manpower Reqt’s: < 2 h/d, 5 d/wk  “The Plant Runs Itself” – Greg Belcher, City of Roanoke

slide-56
SLIDE 56

Chesapeake, Virginia

 7.5 MGD Submerged Membrane Plant  Dedicated in April 2006  Raw Water TOC – 4 to 6 mg/L  Raw Water Turbidity 25 to 50 NTU  Coagulant Feed – 20 to 25 mg/L  Coagulant pH – 5.5 to 6.0

slide-57
SLIDE 57

Chesapeake TOC Data Sample May 8 May 22 May 30 Jun 7 Raw 4.10 4.22 4.50 4.29 Permeate 1.36 1.77 1.88 1.82 % Reduction 67% 60% 58% 58% Alum Dose (mg/L) 25 20 20 20 pH 5.46 5.87 5.90 5.85

slide-58
SLIDE 58

Raw Water Strainers

slide-59
SLIDE 59

Pretreatment Tanks

slide-60
SLIDE 60

Membrane Tanks

slide-61
SLIDE 61

Multiple Membrane Trains with Crane

slide-62
SLIDE 62

Lancaster Pennsylvania

 24 and 12 MGD WTPs  Regulatory Drivers

LT2 ESTWR (Crypto Removal)

Stage 2 D/DBP Rule

Future Rules

 Conventional Facilities  Zenon 500 Upgrade  Direct vs. Clarified Feed

slide-63
SLIDE 63

Lancaster, PA

 24 and 12 mgd Membrane Facilities  Two of the Largest on the East Coast  Includes State-of-the-Art Thickening Process  Include Two-Stage Membrane Treatment with UV

Disinfection

 Over $70 million  Great client reference

slide-64
SLIDE 64

Lancaster, PA - Pilot Operation

Raw

 Pre-screened River

Water

 Alum Feed

 Acid

 15 minute floc  99.7% recovery  PACl later

Clarified

 Post-clarification  Daily Cleans vs.

Monthly Cleans

 95% Recovery  EC Jar Tests

slide-65
SLIDE 65

Data Evaluation - Permeate

Parameter Raw MF/UF Clarified MF/UF EC Alum Dose 50 mg/L 30 mg/L 70 mg/L Turbidity <0.03 NTU <0.03 NTU <0.3 NTU Particle Cts (#/mL) <10 <10 NA TOC Removal 35-50% 15-25% 35-50% DBP’s 1 3 2

slide-66
SLIDE 66

Lancaster – Other Findings

 Raw will work on flashy river water

 Need to pay attention closely during flashy events

 Daily cleans – Helped when working  Heated daily cleans/backwashes helped short-

term

 High fluxes can be unstable

slide-67
SLIDE 67

Lancaster – Other Findings (cont.)

 Clarification process is not necessarily an

additional barrier or a reduction of risk

 Constructability and retrofit costs can be very

difficult to quantify

 Cold water (<3oC) was difficult  PACl worked best in cold water  Raw water membrane costs (capital and

  • perating) – 30 to 40% above clarified
slide-68
SLIDE 68

Swansea Water District, MA

 First Desalination Project on East Coast for HDR  1.5 mgd Desalination plus 1 mgd Fe/Mn

Groundwater Membrane Plant

 Upon completion, will be the 2nd surface water

desalination facility north of Florida

 Pall/Toray

slide-69
SLIDE 69

Summary

 Membranes are here and will become a more

technology in the future.

 Membranes are a great particle removal

mechanism

 Significant fractions of organics are not normally

removed with MF/UF, but when coupled with a coagulant, removals are equal to or better than conventional facilities

 Membranes will work on all waters, cost is just the

major factor – so, pick the correct system!!!!!!

slide-70
SLIDE 70

For more information, contact: Paul J. Delphos DelphosP@bv.com 757-456-5380, ext 12

Membrane Filtration Basics 101
