SLIDE 1
B-Quenched
SKETCH MODEL REVIEW ORANGE B
What do we do when disaster strikes? How can we get clean drinking water without power?
Source: https://goo.gl/iE3dpg Source: https://goo.gl/NX8sse
B-Quenched SKETCH MODEL REVIEW ORANGE B What do we do when - - PowerPoint PPT Presentation
B-Quenched SKETCH MODEL REVIEW ORANGE B What do we do when - - PowerPoint PPT Presentation
B-Quenched SKETCH MODEL REVIEW ORANGE B What do we do when disaster strikes? How can we get clean drinking water without power? Source: https://goo.gl/NX8sse Source: https://goo.gl/iE3dpg B-Quenched filters and disinfects water and is
SLIDE 2
SLIDE 3
B-Quenched filters and disinfects water and is powered by simply shaking the bottle.
SLIDE 4
Particle Filter Coil UVC Source Magnet
SLIDE 5
Cost
$100 $8* $50
Weight
17oz 3oz 3.5oz
Time
60s 30min ~60s
Issues
Expensive Slow Small Nozzle
*Per 25L
SLIDE 6
Cost
$100 $8* $50
Weight
17oz 3oz 3.5oz
Time
60s 30min ~60s
Issues
Expensive Slow Small Nozzle
*Per 25L
Benchmark
SLIDE 7
Can we use UV-C LEDs as a low power sterilization method? Can we power a traditional UVC bulb using linear induction?
SLIDE 8
Coil + Magnet UVC Source Diode Rectifier Water Bottle
SLIDE 9
UVC LEDs are still extremely expensive à Between $275 and $1,200 each à Not scalable in our market segment Traditional UVC bulbs are complex to work with à High voltages à Current limiter via electric ballasts à Consistent and steady power input
SLIDE 10
à Create strong, steady voltage à Develop particle filter à Find required exposure
SLIDE 11
3.5 million Hurricane Maria victims left without power this year
Source: https://goo.gl/qAa7vu Source: https://goo.gl/xpbjC8 Source: https://goo.gl/16jSBK
SLIDE 12
