B e r g m a n s M e c h a t r o n i c s L L C Laser Alignment System for Tunable Diode Laser Sensors www.bergmans.com Jan 2010 1616 Bedford Lane, Unit A Phone: 714-474-8956 Newport Beach, CA 92660 Fax: 949-646-1429 Bergmans Mechatronics

B e r g m a n s M e c h a t r o n i c s L L C Laser Alignment System for Tunable Diode Laser Sensors www.bergmans.com Jan 2010 1616 Bedford Lane, Unit A Phone: 714-474-8956 Newport Beach, CA 92660 Fax: 949-646-1429
Bergmans Mechatronics LLC Laser Alignment System - Schematic Launch Optics LasIR Enclosure Detector Enclosure Stepper Motors and Lens Process Gas Detector Signal IR Laser Light LasIR Control Signals to Stepper Motors LAS Processing Unit Legend Fiber Optic Cable Coax Cable Control Cable Beam Path
Bergmans Mechatronics LLC LAS Basic Mechanical Components Linear potentiometers Collimating lens Mirror Mount Window Stepper motors Collimating Lens Fiber Optic Cable Stepper Motors Mirror mount Mirror mount (base) Stepper Motor Controller (pivoting platform) Left side view Launch optics mechanism within Unisearch NEMA-4 enclosure at power plant
Bergmans Mechatronics LLC LAS Processing Unit Integrated with LasIR Ammonia Monitor Ethernet Router Laptop LasIR NH3 Monitor Laser Alignment System Processing Unit
Bergmans Mechatronics LLC Laser Alignment System - Launch Optics Envelop Top view Unisearch mirror mount (Note 1) Linear Stepper motors potentiometers Right side view Front view Through holes for mounting to Unisearch flange Modified version of stock optics mount Notes: 1) Mirror mount is stock ThorLabs model KM100B 2) Dimensions in inches
Bergmans Mechatronics LLC Laser Alignment System – NEMA-4 Enclosure Launch optics mechanism mounted within Unisearch NEMA-4 enclosure at power plant
Bergmans Mechatronics LLC Effect of Detector Movement on Beam Power Based on results of full-scale testing in coal-fired power plant duct: • For manually aligned system with 1.2” of detector movement, spot size must be 3.4” diam (9.1 in 2 area) • Auto-aligned system, spot size can be 1” diam (0.8 in 2 area) • Resulting power density of manually aligned system is 8.6% of auto-aligned system Detector 1.2” Launch 1” Ø 3.4” Ø 28 feet
Bergmans Mechatronics LLC Interfacing Non-Fiber Coupled TDL Sensor to Laser Alignment System (Proposed) Stepper Motor Controlled Mirror Mount and Mirror Receiver LAS Launch Optics Enclosure Process Gas Detector Signal Transmitter Control Signals to Legend Stepper Motors Detector Signal Cable LAS Control Cable Laser Beam Path LAS Processing Unit
