ATLAS2K – The Framework for Precise and Extensible Signal Descriptions in Modern ATS

Sqn Ldr Dick Delaney MSc RAF Chris Gorringe

slide-2
SLIDE 2

Current ATLAS

Strengths of ATLAS: – Test technology related Keywords – Formal syntax and semantics – Non proprietary – Portability of Test Specifications - UUT Orientated Weaknesses of ATLAS: – Lags behind advances in technology – Limited extend mechanisms – Perceived to be expensive to use

slide-3
SLIDE 3

Aims of ATLAS 2K

Builds upon the strengths of ATLAS: – Focuses on signal and event definitions – Align with modern programming practices –Object Orientation –Component Object Model technology – Usable within any COM enabled development environment – Test program portability at the ATS level

slide-4
SLIDE 4

ATLAS 2K Layer Model

Test Procedure Layer Native Code Language Neutral Description (LND) Test Technology Framework (TTF) ATLAS2K Basic Components Signal Methods Modeling Language (SMML) Environment Layer

slide-5
SLIDE 5

Signal Methods and Modeling Layer

  • Signals described in mathematical terms
  • Only a small number required
  • Allows pictorial representation
  • Underpin the Basic Components
slide-6
SLIDE 6

Basic Components

  • Lowest level available to user
  • Re-usable, formally described fundamental

signal classes

  • Used to define all higher level signals
  • Centered towards real world entities giving

bias towards engineering

  • Introduce real world elements such as

connections

  • Generic name for fundamental signal class is

SignalFunction

slide-7
SLIDE 7

SignalFunction Diagram

SignalFunction Name In (Signal) Out Signal Attributes Value Sync (Event)

Types: Sources, Measurement Functions, EventConditioners, CNX

slide-8
SLIDE 8

Test Technology Frameworks

  • The extensibility mechanism
  • Library of pre-configured signals
  • built up from ATLAS 2K Basic Components
  • Signals in a TTF are complex and comprise:

– Two or more ATLAS 2K Basic Components – Some other combination of ATLAS 2K Basic Components and other TTF signals

  • Domain Specific signal definitions
  • Will permit existing users to migrate to ATLAS

2K in the future

slide-9
SLIDE 9

ATLAS 2K TTF – Triangular Wave Signal

Triangular_ Wave_Signal Trigger_burst Enable Delay Period Duration Repetition lo_ampl hi_ampl period dc_ampl noise_ ampl density freq seed

SUM Constant

DC_Offset

Triangular

Triangular_ Signal

Noise

noise_signal

Event Sequence

Burst TRIANGULAR_ WAVE_SIGNAL

slide-10
SLIDE 10

Language Neutral Description

  • Written using an IDL
  • Type library that provides a method for

specifying all of the ATLAS 2K Basic and TTF components

  • Information includes:

– Name, property name, allowed name – Allowed values, enumerate value types

  • Removes any possibility of different behaviour

due to language dependent features

  • Ensures consistent signal definitions across all

implementations

slide-11
SLIDE 11

Native Code layer

  • Could use this layer to write test programs
  • Can be the native programming language for a

given ATS

  • Allows a complete specification of test

requirements at this level.

  • Benefits:

– Test programmers can combine ATLAS 2K signals with features in preferred language – Assists test program portability – Can use COTS compilers, debuggers etc

slide-12
SLIDE 12

Test Procedure Layer

  • Defines Stylised English syntax and semantics

to define an ‘all-textual’ test requirement

  • Equivalent to previous published ATLAS

standards

  • Contains traditional ATLAS verbs such as

SETUP, CONNECT, ARM, FETCH

  • The Standard will map the Test Procedure

Layer onto the Native Code Layer and TTF models

  • This layer provides portability at the test

specification level

slide-13
SLIDE 13

Environment Layer

  • User’s Choice of graphical interface, carrier

language and development tools

  • Components will be COTS items such as

Microsoft Developers Studio

  • Different end-user applications can be

developed using different development environments but the same ATLAS 2K signal components

slide-14
SLIDE 14

ATLAS 2K Conclusions

  • Culmination of a radical review of ATLAS
  • Applicable to a wider user community
  • Designers may use signal definitions
  • Overall reduction in life cycle costs
  • User choose own operating environment,

carrier language and tools

  • Signal definitions can be deployed in other ATS

architecture standards such as IVI

slide-15
SLIDE 15

ATLAS 2K Conclusions

  • Legacy link and portability of test specifications

has been preserved through Test Procedure Layer

  • Native Code and Language Neutral Description

Layers achieve portability at the test program level

  • TTFs and ATLAS 2K Basic Components ensure

consistency of signal definitions and provide extensibility

slide-16
SLIDE 16

QUESTIONS

slide-17
SLIDE 17

ATLAS 2K TTF – Triangular Wave Signal

Description A periodic wave whose instantaneous value varies alternately and linearly between two specified values (initial and alternate). The interval required to transition from the initial value to the alternate value shall be equal to the interval to transition from the alternate value to the initial value. Interface Properties

Description Name Type Default Range Triangular Wave Signal low amplitude lo_amp Voltage | Current | Power Triangular Wave Signal high amplitude hi_amp Voltage | Current | Power Triangular Wave Signal Period period Time DC Offset dc_ampl Voltage | Current | Power 0(Note 1) Noise Signal amplitude noise_ampl Voltage | Power (Note 2) Noise Density density Voltage/Frequency| Power/Frequency (Note 3) Pseudo Random Noise Frequency freq Frequency Pseudo Random Noise Seed seed Real Number 0 > n < 1 Burst Enable Voltage | Current | Power (Note 4) Burst timing reference Delay Time Burst Initiate Period Time 1 sec Burst Cease Duration Time 1 sec Burst Repeat Repetition Integer 1

slide-18
SLIDE 18

ATLAS 2K TTF – Triangular Wave Signal

Notes:

  • 1. DC Offset is included in the model to allow this property to be mapped from pervious standards of ATLAS.
  • 2. The default for Random Noise is White Noise (characterised by a flat frequency spectrum in the frequency range of interest),

White Noise needs only one parameter to be specified: either Noise Signal Amplitude or Noise Amplitude/Power Density.

  • 3. For Pseudo Random Noise, all parameters other than Noise Amplitude/Power Density need to be specified.
  • 4. The default for burst provides 1 un-synchronised burst of infinite length, i.e. the signal is not subject to bursts.
slide-19
SLIDE 19

ATLAS 2K TTF – Triangular Wave Signal

Model Description

Name Type Terminal Inputs Output Formula Triangular signal triangular<type> signal[out] triangular signal amp1 lo_amp amp2 hi_amp event_time period ET=period 2 dc_offset constant<type> signal[out] dc_ offset amp dc_ampl noise_signal noise<type> signal[out] noise_signal ampl noise_ampl density density freq frequency seed seed burst Event_sequence timing sequence[out] burst signal [in] Triangular_signal sync trigger_burst Enable Enable Delay Delay Period Period Duration Duration Repetition Repetition TRIANGULAR_WAVE_ SIGNAL sum signal[out] TRIANGULAR_W AVE_ SIGNAL signal [in] triangular_signal signal [in] dc_offset signal [in] noise_signal event [in] burst

slide-20
SLIDE 20

Revolution in Thinking

Without taking you Pen off the paper join the dots with no more that 4 straight lines

slide-21
SLIDE 21

Build your Own Extensible Signals

slide-22
SLIDE 22

Use of Atlas

slide-23
SLIDE 23

Puzzle

The Traditional Answer
