Apache Beam

Modèle de programmation unifié pour Big Data

Who am I?

Jean-Baptiste Onofre <jbonofre@apache.org> <jbonofre@talend.com> @jbonofre | http://blog.nanthrax.net Member of the Apache Software Foundation Fellow/Software Architect at Talend PMC on ~20 Apache Projects from system integration & container (Karaf, Camel, ActiveMQ, Archiva, Aries, ServiceMix, …) to big data (Beam, CarbonData, Falcon, Gearpump, Lens, …)

Apache Beam origin

MapReduce

BigTable Dremel Colossus Flume Megastore Spanner PubSub Millwheel

Apache Beam

Google Cloud Dataflow

Beam model: asking the right questions

What results are calculated? Where in event time are results calculated? When in processing time are results materialized? How do refinements of results relate?

Customizing What Where When How 3 Streaming 4 Streaming + Accumulation 1 Classic Batch 2 Windowed Batch

What is Apache Beam?

1. Unified model (Batch + strEAM) What / Where / When / How

• 2. SDKs (Java, Python, ...) & DSLs (Scala, …)
• 3. Runners for Existing Distributed Processing

Backends (Google Dataflow, Spark, Flink, …)

• 4. IOs: Data store Sources / Sinks

Apache Beam vision

Beam Model: Fn Runners Apache Flink Apache Spark Beam Model: Pipeline Construction Other Languages Beam Java Beam Python Execution Execution Cloud Dataflow Execution

• 1. End users: who want to write

pipelines in a language that’s familiar.

• 2. SDK/DSL writers: who want to make

Beam concepts available in new languages.

• 3. Runner writers: who have a

distributed processing environment and want to support Beam pipelines

Apache Beam - SDKs & DSLs

SDKs

API based on the Beam Model 1. Current:

• a. Java
• b. Python

2.

Future (possible) SDKs:

Go, Ruby, etc.

DSLs Domain-Specific Languages based on the Beam Model:

1.

Current:

• Scio (Scala API),

2.

Future (ideas):

• Streaming SQL (Calcite)
• Machine Learning
• Complex Event Processing

Apache Beam SDK concepts

1. Pipeline - data processing job as a directed graph of transformations

• 2. PCollection - the data inside a pipeline
• 3. PTransform - a transformation step in the pipeline
• a. IO transforms - Read from a Source or Write to a Sink.
• b. Core transforms - common transformation provided (ParDo, GroupByKey, …)
• c. Composite transforms - combine multiple transforms

Apache Beam - Pipeline

Data processing pipeline (executed via a Beam runner)

PTransform PTransform Read PTransform (source) Write PTransform (sink)

Apache Beam - PCollection

1. PCollection is immutable, does not support random access to element, belongs to a Pipeline

• 2. Each element in PCollection has a Timestamp (commonly set by IO Source)
• 3. Coder to support different data serialization
• 4. Bounded (batch) or Unbounded (streaming) (depending of the IO Source)

Apache Beam - PTransform

1. PTransform are operations that transform data

• 2. Receive one or multiple PCollections and produce one or multiple

PCollections

• 3. They must be Serializable
• 4. Should be thread-compatible (If you create your threads you must sync them).
• 5. Idempotency is not required but recommended.

Apache Beam - IO Transforms

1. IO read/write data as PCollections (Source/Sink)

• 2. Support Bounded and/or Unbounded PCollections
• 3. Extensible API to create custom sources & sinks
• 4. Deal with timestamp, watermarks, deduplication, read/write parallelism

• 1. Evolution of the Big Data programming models
• 2. The Beam approach
• 3. Apache Beam

Agenda

Apache Beam - Current IOs

Ready

File Avro Google Cloud Storage BigQuery BigTable DataStore HDFS Elasticsearch HBase MQTT JDBC Mongo / GridFS JMS Kafka Kinesis

WIP

Hive Cassandra Reddis RabbitMQ ...

Apache Beam - Pipeline with IO Example

public static void main(String[] args) { // Create a pipeline parameterized by command line flags eg. --runner Pipeline p = Pipeline.create(PipelineOptionsFactory.fromArgs(arg)); p.apply(KafkaIO.read().withBootstrapServers(servers) .withTopics(topics)) // Read input .apply(new YourFancyFn()) // Do some processing .apply(ElasticsearchIO.write().withAddress(esServer) .withIndex(index).withType(type)); // Write output // Run the pipeline. p.run(); }

What are you computing?

What Where When How

Element-Wise Aggregating Composite

Apache Beam - Programming model in the SDK

Grouping

GroupByKey Combine -> Reduce Sum Count Min Max Mean ...

Element-wise

ParDo MapElements FlatMapElements Filter WithKeys Keys Values

Windowing/Triggers

FixedWindows GlobalWindows SlidingWindows Sessions AfterWatermark AfterProcessingTime AfterPane ...

Apache Beam - Example - GDELT Events by location

Pipeline pipeline = Pipeline.create(options); // Read events from a text file and parse them. pipeline .apply("GDELTFile", TextIO.Read.from(options.getInput())) // Extract location from the fields .apply("ExtractLocation", ParDo.of(...) // Count events per location .apply("CountPerLocation", Count.<String>perElement()) // Reformat KV as a String .apply("StringFormat", MapElements.via(...)) // write to result files .apply("Results",TextIO.Write.to(options.getOutput())); // Run the batch pipeline. pipeline.run();

Apache Bean - Runners / Execution Engines

Runners “translate” the code to a target runtime (the runner itself doesn’t provide the runtime) Many runners are tied to other top-level Apache projects, such as Apache Flink and Apache Spark Due to this, runners can be run on-premise (on your local Flink cluster) or in a public cloud (using Google Cloud Dataproc or Amazon EMR) for example Apache Beam is focused on treating runners as a top-level use case (with APIs, support, etc.) so runners can be developed with minimal friction for maximum pipeline portability

Runners

Google Cloud Dataflow Managed (NoOps) Apache Flink Apache Spark Apache Apex Apache MapReduce Apache Gearpump Apache Beam Direct Runner Local Apache Karaf Same code, different runners & runtimes WIP

Apache Beam - Use cases

Apache Beam is a great choice for both batch and stream processing and can handle bounded and unbounded datasets Batch can focus on ETL/ELT, catch-up processing, daily aggregations, and so on Stream can focus on handling real-time processing on a record-by-record basis Real use cases Data processing, both batch and stream processing Real-time event processing from IoT devices Fraud detection, ...

Why Apache Beam?

• 1. Portable - You can use the same code with different runners (agnostic) and

backends on premise, in the cloud, or locally

• 2. Unified - Same unified model for batch and stream processing
• 3. Advanced features - Event windowing, triggering, watermarking, lateness, etc.
• 4. Extensible model and SDK - Extensible API; can define custom sources to

read and write in parallel

Collaborate - Beam is becoming a community- driven effort with participation from many

• rganizations and contributors

Grow - We want to grow the Beam ecosystem and community with active, open involvement so Beam is a part of the larger OSS ecosystem

Growing the Beam Community

Learn More!

Apache Beam http://beam.apache.org Join the Beam mailing lists! user-subscribe@beam.apache.org dev-subscribe@beam.apache.org Follow @ApacheBeam on Twitter

Thank You !
