Simplifying ML Workflows with Apache Beam & TensorFlow Extended Tyler Akidau @takidau Software Engineer at Google Apache Beam PMC + Apache Beam Portable data-processing pipelines + Example pipelines Python Java + Cross-language
SLIDE 2
SLIDE 3
Example pipelines
+ Java Python
SLIDE 4
Cross-language Portability Framework
+
Language B SDK Language A SDK Language C SDK Runner 1 Runner 3 Runner 2 The Beam Model Language A Language C Language B The Beam Model
SLIDE 5
Python compatible runners
+
Direct runner (local machine): Google Cloud Dataflow: Apache Flink: Apache Spark: Now Now Q2-Q3 Q3-Q4
SLIDE 6
TensorFlow Extended
End-to-end machine learning in production +
SLIDE 7
“Doing ML in production is hard.”
- Everyone who has ever tried
SLIDE 8
Because, in addition to the actual ML...
ML Code
+
SLIDE 9
...you have to worry about so much more.
Configuration Data Collection Data Verification Feature Extraction Process Management Tools Analysis Tools Machine Resource Management Serving Infrastructure Monitoring
Source: Sculley et al.: Hidden Technical Debt in Machine Learning Systems ML Code
+
SLIDE 10
In this talk, I will...
+
SLIDE 11
In this talk, I will...
Show you how to apply transformations...
TensorFlow Transform
Show you how to apply transformations...
+
SLIDE 12
In this talk, we will...
Show you how to apply transformations... ... consistently between Training and Serving
TensorFlow Transform TensorFlow Estimators TensorFlow Serving
+
SLIDE 13
In this talk, we will...
Introduce something new...
TensorFlow Transform TensorFlow Estimators TensorFlow Serving TensorFlow Model Analysis
+
SLIDE 14
TensorFlow Transform
Consistent In-Graph Transformations in Training and Serving +
SLIDE 15
Typical ML Pipeline
batch processing During training “live” processing During serving data request
+
SLIDE 16
Typical ML Pipeline
batch processing During training “live” processing During serving data request
+
SLIDE 17
TensorFlow Transform
tf.Transform batch processing During training transform as tf.Graph During serving data request
+
SLIDE 18
Defining a preprocessing function in TF Transform
def preprocessing_fn(inputs): x = inputs['X'] ... return { "A": tft.bucketize( tft.normalize(x) * y), "B": tensorflow_fn(y, z), "C": tft.ngrams(z) } Many operations available for dealing with text and numeric features, user can define their own. X Y Z
+
SLIDE 19
Defining a preprocessing function in TF Transform
def preprocessing_fn(inputs): x = inputs['X'] ... return { "A": tft.bucketize( tft.normalize(x) * y), "B": tensorflow_fn(y, z), "C": tft.ngrams(z) } Many operations available for dealing with text and numeric features, user can define their own. X Y Z
mean stddev normalize
+
SLIDE 20
Defining a preprocessing function in TF Transform
def preprocessing_fn(inputs): x = inputs['X'] ... return { "A": tft.bucketize( tft.normalize(x) * y), "B": tensorflow_fn(y, z), "C": tft.ngrams(z) } Many operations available for dealing with text and numeric features, user can define their own. X Y Z
mean stddev normalize multiply
+
SLIDE 21
X Y Z
mean stddev normalize multiply
Defining a preprocessing function in TF Transform
def preprocessing_fn(inputs): x = inputs['X'] ... return { "A": tft.bucketize( tft.normalize(x) * y), "B": tensorflow_fn(y, z), "C": tft.ngrams(z) } Many operations available for dealing with text and numeric features, user can define their own.
quantiles bucketize
A
+
SLIDE 22
X Y Z
mean stddev normalize multiply quantiles bucketize
A
Defining a preprocessing function in TF Transform
def preprocessing_fn(inputs): x = inputs['X'] ... return { "A": tft.bucketize( tft.normalize(x) * y), "B": tensorflow_fn(y, z), "C": tft.ngrams(z) } Many operations available for dealing with text and numeric features, user can define their own. B
+
SLIDE 23
X Y Z
mean stddev normalize multiply quantiles bucketize
A B
Defining a preprocessing function in TF Transform
def preprocessing_fn(inputs): x = inputs['X'] ... return { "A": tft.bucketize( tft.normalize(x) * y), "B": tensorflow_fn(y, z), "C": tft.ngrams(z) } Many operations available for dealing with text and numeric features, user can define their own. C
+
SLIDE 24
mean stddev normalize multiply quantiles bucketize
Analyzers
Reduce (full pass) Implemented as a distributed data pipeline
Transforms
Instance-to-instance (don’t change batch dimension) Pure TensorFlow
+
SLIDE 25
Analyze
normalize multiply bucketize
constant tensors
data
mean stddev normalize multiply quantiles bucketize
SLIDE 26
What can be done with TF Transform?
Pretty much anything. tf.Transform batch processing
+
SLIDE 27
What can be done with TF Transform?
Anything that can be expressed as a TensorFlow Graph Pretty much anything. tf.Transform batch processing Serving Graph
+
SLIDE 28
Scale to ... Bag of Words / N-Grams Bucketization Feature Crosses
Some common use-cases...
SLIDE 29
Apply another TensorFlow Model
Some common use-cases...
Scale to ... Bag of Words / N-Grams Bucketization Feature Crosses
SLIDE 30
github.com/tensorflow/transform
SLIDE 31
TensorFlow Model Analysis
Scaleable, sliced, and full-pass metrics
Introducing…
+
SLIDE 32
Let’s Talk about Metrics...
- How accurate?
- Converged model?
- What about my TB sized eval set?
- Slices / subsets?
- Across model versions?
+
SLIDE 33
ML Fairness: analyzing model mistakes by subgroup
Specificity (False Positive Rate) Sensitivity (True Positive Rate) ROC Curve
All groups
Learn more at ml-fairness.com
SLIDE 34
ML Fairness: analyzing model mistakes by subgroup
Specificity (False Positive Rate) Sensitivity (True Positive Rate) ROC Curve
All groups Group A Group B
Learn more at ml-fairness.com
SLIDE 35
ML Fairness: understand the failure modes of your models
SLIDE 36
ML Fairness: Learn More ml-fairness.com
SLIDE 37
How does it work?
... estimator = DNNLinearCombinedClassifier(...) estimator.train(...) estimator.export_savedmodel( serving_input_receiver_fn=serving_input_fn) tfma.export.export_eval_savedmodel ( estimator=estimator, eval_input_receiver_fn=eval_input_fn) ... Inference Graph (SavedModel)
SignatureDef
+
SLIDE 38
... estimator = DNNLinearCombinedClassifier(...) estimator.train(...) estimator.export_savedmodel( serving_input_receiver_fn=serving_input_fn) tfma.export.export_eval_savedmodel ( estimator=estimator, eval_input_receiver_fn=eval_input_fn) ...
How does it work?
Eval Graph (SavedModel)
SignatureDef Eval Metadata
Inference Graph (SavedModel)
SignatureDef
+
SLIDE 39
github.com/tensorflow/model-analysis
SLIDE 40
Summary
Apache Beam: Data-processing framework the runs locally and scales to massive data, in the Cloud (now) and soon
- n-premise via Flink (Q2-Q3) and Spark (Q3-Q4). Powers
