Data Processing at the Speed of 100 Gbps using Apache Crail Patrick Stuedi IBM Research Apache Crail (crail.apache.org) Apache Crail (crail.apache.org) Ephemeral Data HDFS, Input data S3 Map-reduce job Broadcast Map Shuffle Reduce

slide-1
SLIDE 1

Patrick Stuedi IBM Research

Data Processing at the Speed of 100 Gbps using Apache Crail

slide-2
SLIDE 2

Apache Crail (crail.apache.org)

slide-3
SLIDE 3

Apache Crail (crail.apache.org)

slide-4
SLIDE 4

Ephemeral Data

Broadcast Shuffle Map Reduce Input data Output data Map-reduce job

HDFS, S3 HDFS, S3

slide-5
SLIDE 5

Ephemeral Data

Broadcast Shuffle Map Reduce Input data Output data Map-reduce job

HDFS, S3 HDFS, S3

slide-6
SLIDE 6

Ephemeral Data

Broadcast Shuffle Map Reduce Input data Output data Apache Crail

HDFS, S3 HDFS, S3

slide-7
SLIDE 7

Ephemeral Data

Broadcast Shuffle Map Reduce Input data Intermediate data Apache Crail

HDFS, S3 HDFS, S3 HDFS, S3

slide-8
SLIDE 8

Ephemeral Data

Input data Apache Crail

HDFS, S3 HDFS, S3 HDFS, S3

ML pre-processing (map-reduce job) ML training (Tensorflow job) normalized images

slide-9
SLIDE 9

Ephemeral Data

Input data Apache Crail

HDFS, S3 HDFS, S3 HDFS, S3

ML pre-processing (map-reduce job) ML training (Tensorflow job) normalized images

HDFS, S3

slide-10
SLIDE 10

Ephemeral Data

Input data Apache Crail

HDFS, S3 HDFS, S3

ML pre-processing (map-reduce job) ML training (Tensorflow job) normalized images

slide-11
SLIDE 11

Why/when to use Crail

slide-12
SLIDE 12

Why/when to use Crail

No Crail needed

100MB/s 10ms 10Gb/s 20us

slide-13
SLIDE 13

Why/when to use Crail

100x Crail land

10GB/s 10us 200Gb/s 1us

No Crail needed

100MB/s 10ms 10Gb/s 20us

slide-14
SLIDE 14

Why/when to use Crail

100x Crail land No Crail needed

20 40 60 80 100 100 200 300 400 500 Throughput (Gbit/s) Elapsed time (seconds) Spark/Crail Spark/Vanilla hardware limit 88.3s 527.6s

100MB/s 10ms 10Gb/s 20us 10GB/s 10us 200Gb/s 1us

Terasort 12.8 TB data 128 nodes

slide-15
SLIDE 15

Performance Challenge

Sorting Application JVM Netty Sorter Serializer sockets Data Processing Framework TCP/IP Ethernet NIC filesystem block layer iSCSI SSD

slide-16
SLIDE 16

Performance Challenge

Sorting Application JVM Netty Sorter Serializer sockets Data Processing Framework TCP/IP Ethernet NIC filesystem block layer iSCSI SSD

HotNets’16 Fetch chunk Over the network Process chunk In reduce task

slide-17
SLIDE 17

Performance Challenge

Sorting Application JVM Netty Sorter Serializer sockets Data Processing Framework TCP/IP Ethernet NIC filesystem block layer iSCSI SSD

HotNets’16

slide-18
SLIDE 18

Performance Challenge

Sorting Application JVM Netty Sorter Serializer sockets Data Processing Framework TCP/IP Ethernet NIC filesystem block layer iSCSI SSD

software overhead are spread

  • ver the entire

stack

HotNets’16

slide-19
SLIDE 19

Crail Overview

Multiple interfaces Multiple storage backends (pluggable,

  • pen interface)
slide-20
SLIDE 20

Crail Overview

Multiple interfaces Multiple storage backends (pluggable,

  • pen interface)

primary high-performance storage backends

slide-21
SLIDE 21

Crail Architecture & API

MultiFile

slide-22
SLIDE 22

Crail Architecture & API

  • ptimized

for shuffle data key-value semantics append-only file

MultiFile

slide-23
SLIDE 23

Crail Architecture & API

Java: C++:

MultiFile

slide-24
SLIDE 24

Crail Architecture & API

Java: C++:

Node type

MultiFile

slide-25
SLIDE 25

Crail Architecture & API

Java: C++:

non-blocking & asynchronous

MultiFile

slide-26
SLIDE 26

Where does the performance come from?

slide-27
SLIDE 27

User-Level I/O: Metadata

2 1 1 2

Crail client library

slide-28
SLIDE 28

User-Level I/O: Metadata

2 1 1 2

Crail client library

No threads No context switches

slide-29
SLIDE 29

User-Level I/O: Data

1 2 2 1

slide-30
SLIDE 30

User-Level I/O: Data

1 2 2 1 zero-copy, transfer only data that is requested Application

slide-31
SLIDE 31

Crail Deployment Modes

compute/storage co-located storage disaggregation flash storage disaggregation

slide-32
SLIDE 32

YCSB KeyValue Workload

Crail offers Get latencies of ~12us and 30us for DRAM and NVM for 100 byte KV pairs Crail offers Get latencies of ~30us and 40us for DRAM and NVM for 1000 byte KV pairs

latency [us] latency [us] GET Value size: 1KB GET Value size: 100KB

slide-33
SLIDE 33

Spark GroupBy (80M keys, 4K)

Spark/ Vanilla 5x 2.5x 2x

20 40 60 80 100 10 20 30 40 50 60 70 80 90 100 110 120 Throughput (Gbit/s) Elapsed time (seconds) 1 core 4 cores 8 cores 20 40 60 80 100 10 20 30 40 50 60 70 80 90 100 110 120 Throughput (Gbit/s) Elapsed time (seconds) 1 core 4 cores 8 cores

Spark/ Crail

Spark shuffling via Crail on a single core is 2x faster than vanilla Spark on 8 cores per executor (8 executors)

slide-34
SLIDE 34

DRAM & Flash Disaggregation

Crail enables disaggregation of temporary data at no cost

slide-35
SLIDE 35

DRAM/Flash Tiering

Using flash only increases the sorting time by around 48%

20 40 60 80 100 120 100/0 100/0 80/20 60/40 40/60 20/80 0/100 Vanilla Spark (100% Memory) Runtime (seconds) Memory to Flash Ratio Map Reduce

slide-36
SLIDE 36

put your #assignedhashtag here by setting the footer in view-header/footer

  • Apache Crail: Fast distributed “tmp”

–

User-level I/O

–

Storage disaggregation

–

Memory/flash convergence

  • Applications

–

Intra-job scratch space (shuffle, broadcast, etc.)

–

Multi-job pipelines

  • Coming soon

–

Native Crail (C++)

–

Tensorflow-Crail

Conclusions
