ANYWAVE COMMUNICATION TECHNOLOGIES PRODUCT PRESENTATION Air Cooled UHF TV Transmitter 1 – 10kW

GRANITE SERIES

The foundation of your transmission facilities

“.a very hard, crystalline, igneous rock consisting mainly of quartz, mica, and feldspar and often used as a building stone … “ VERSION 2018.01

1.2kW ATSC / ATSC3.0 per amplifier Up to 9.6kW in single rack BLF888E Broadband LDMOS Doherty Modulation Air Cooled

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Broadband asymmetrical high efficiency Doherty amplifier. Single design covers entire bandwidth, no tuning or hardware modification needed for changing channels. Transistor efficiency >55%, module efficiency>50%, system efficiency >45% in ATSC and 42% in OFDM.

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Field replaceable pallets with easy access to all

• components. No

proprietary parts

Highest power level per PA and power density available. Only 3.5 RU PA module which has 8x888E. Produces > 1.1 kw OFDM (shoulder level 36dB) and 1.4kw ATSC (shoulder level 40 dB).

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

One-piece aluminum heat sink The entire heat sink is processed off a single aluminum piece. Compared to most others, it has much better effective heat transfer

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Anywave Design. Typical Design.

User can set target temperature value according to application and room temperature. Each fan is individually speed controlled by target temperature and detected temperature.

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Intelligent fan monitoring: should any fan fail, or the dust filter is blocked, an alarm will be triggered and power will be reduced.

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Easy maintenance: replacing the fans only requires a single screw driver and can be completed in 10 minutes.

Two high capacity power supplies which are easily replaceable, hot swappable from the front panel without shutting down the PA unit.

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

No tools are needed to replace the power supplies. AC voltage and current, DC voltage and current, temperature, fan status can be monitored from the web interface.

Even heat distribution and heat removal, no critical hot spots … designed to last !

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Graphene Enhanced Thermal Management technology

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Without Graphene With Graphene

Graphene’s heat conductivity is 4 times better than copper and 8 times better than aluminum

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Self-running, all automatic, adaptive phase and gain matching of all PA modules and or racks. Multiple PA modules (up to 10 per rack, and up to 6 racks)

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Automatically balances entire system in gain and phase within 10 minutes for maximum output power and highest efficiency. Typical system efficiency improvement up to 4%

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

No manual intervention needed, no turning off power, no reducing power. Typical method is to use manual adjustment for gain and phase, which is complex and typically ineffective.

1.1kW Rear View

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

Easy access to all sides with removable panels No dangerous voltages Modular: Self contained, self protected Easy installation Small footprint

2.2kW Side View

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

8 Amplifiers provides 10kW 25 various sensors in each PA unit, 216 sensors and over 10 micro controllers in an 8 PA rack

RF, ASI

• r IP

INPUT DIGITAL EXCITER DIGITAL EXCITER (optional) CONTROLLER AND PRE-AMP MULTI-WAY SPLITTER MULTI-WAY COMBINER 1 to 10 PA’s LOW PASS FILTER BAND PASS FILTER RF POWER AMPLIFIER

DUAL INTEGRATED HOT PLUGGABLE AC/DC POWER SUPPLY

φ dB

See Individual Transistor Currents Touch “Amplifier” See Fan Speeds

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

CONTROLLER

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

• Innovative DDRF™ (Direct Digital RF) broadband automatic balancing

technology achieves near perfect RF performance

• Superior linear and non-linear pre-correction
• Up to 15 dB shoulder improvements
• Up to 10 dB MER (SNR) improvements
• In band flatness: <±0.5 dB
• Powerful graphic Test & Measurement GUI
• Modifies incoming PSIP information

EXCITER

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

ANY1020/22 option Real time signal quality monitoring including spectrum, constellation, MER, frequency response, impulse response, group delay, CCDF , etc.

ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES

• Web Browser Remote control
• SNMP MIBS
• E-mail alerts *
• Parallel I/O

* Email alerts (optional) for

• Forward Power Low
• VSWR High
• Room Temperature High

ABOUT ANYWAVE ➢1990’s Key involvement in the development of ATSC ➢2006 Assisted in the development of CMMB ➢2007 Anywave Founded ➢2010 Unique algorithms for amplifier linearization ➢2013 Patents in On-Channel Digital Repeaters ➢2015 Doherty modulation Amplifiers for LPTV and MPTV ➢2017 Broadband Low and Medium Hi-Efficiency Amplifiers ➢2018 10kW Air Cooled transmitter in one rack ➢2018 80kW High Power Liquid Cooled Transmitter

GRANITE SERIES ANYWAVE

COMMUNICATION TECHNOLOGIES

GRANITE SERIES ANYWAVE

COMMUNICATION TECHNOLOGIES

1200 sq. ft. Warehouse – near Cincinnati, OH Airport

Technical Support - Customer Call Center Equipment repair and retuning Transmitter test facility

Warehouse / Storage Meeting Room Loading Area

GRANITE SERIES ANYWAVE

COMMUNICATION TECHNOLOGIES

Over 100 Transmitters in stock Full Test and Repair capabilities

EMAIL Sales_us@Anywavecom.com ADDRESS 300 Knightsbridge Parkway, Suite 150 Lincolnshire, IL 60069-3655 TELEPHONE / FAX +1 (847) 415 2258 / +1 847 415 2112 WEBSITE www.anywavecom.net

Contact Us….
