An Initial Characterization

• f the Emu Chick

Eric Hein, Tom Conte, (ECE) Jeff Young, (CS) Srinivas Eswar, Jiajia Li, Patrick Lavin, Richard Vuduc, Jason Riedy (CSE)

5/21/2018

. . . .

2

5/21/2018

Migratory Memory-side Processing

• Main innovation: Thread contexts migrate to the data
• Threads always read from local memory
• Migration is hardware-controlled, triggered on a remote

read

• CRNCH Rogue’s Gallery
• Early access to Emu Chick hardware prototype

. . . .

3

5/21/2018

Outline

• Emu Architecture Description
• Data Allocation and Thread Spawning
• Benchmark Results
• STREAM
• Sparse Matrix Vector Multiply (SpMV)
• Pointer Chasing
• Simulator Validation
• Conclusion

. . . .

4

5/21/2018

Emu Architecture

. . . .

5

5/21/2018

Fine-grained Memory Accesses

• Narrow-channel DRAM (NCDRAM)
• 8-bit bus allows access at 8-byte granularity without waste
• Many narrow channels instead of few wide channels
• Remote Writes
• Write to remote nodelet without migrating
• Proceed directly to the memory front-end, bypassing the GC
• Remote Atomics
• Performed in Memory Front-End (MFE), near memory

. . . .

6

5/21/2018

Emu Cilk

• cilk_spawn: create a child thread to execute a function in parallel
• Creates an actual thread, not just a continuation stack frame
• No work-stealing across nodelets
• cilk_sync: wait for all child threads to complete
• Threads die instead of waiting, last thread to arrive continues
• “Remote Spawn”: Create thread on a remote nodelet
• Determines location of cactus stack frame

7

Emu Nodelet Emu Node Card (8 nodelets) Emu Chick (8 nodes) Emu1 Rack (256 nodes) Current Future Current Future Current Future # of cores 1 core 4 cores 8 cores 32 cores 64 cores 256 cores 8192 cores # of threads 64 256 512 2048 4096 16384 > 2 million Memory capacity 2 GiB 8 GiB 16 GiB 64 GiB 128 GiB 512 GiB 16 TiB # of 8-bit DDR4 channels 1 channel 1 channel 8 channels 8 channels 64 channels 64 channels 2048 Memory bandwidth 120 MB/s 2.5 GB/s 1.2 GB/s 20 GB/s 8 GB/s 160 GB/s 5.12 TB/s

Images and data from www.emutechnology.com

. . . .

8

5/21/2018

STREAM: Thread spawning

https://www.cilkplus.org/tutorial-cilk-plus-keywords#cilk_for

Recursive Spawn Serial Spawn

. . . .

9

5/21/2018

Emu Memory Layouts

10

Nodelet 2 Nodelet 1 Nodelet 0 Nodelet 3

Serial Spawn Recursive Remote Spawn Serial Remote Spawn

. . . .

11

5/21/2018

STREAM: Emu hardware results (single-node)

~140 MB/s per nodelet ~1.2 GB/s per node (8 nodelets)

• Surprisingly, serial spawn performance matches recursive spawn
• Remote spawn is necessary to saturate global bandwidth

. . . .

12

5/21/2018

STREAM: Emu hardware results (multi-node)

. . . .

13

5/21/2018

Proxy applications

• Pointer chasing -> streaming graphs
• Designed to mimic the traversal of an edge list in a streaming

graph data structure

• Using results to tune streaming graph engine for Emu
• SpMV -> sparse tensor analysis
• Exploring data layout options with a sparse matrix
• Will transfer knowledge to design of sparse tensor library

. . . .

14

5/21/2018

Sparse matrix-vector multiply (SpMV)

Data layout is very important on Emu. We experimented with three layouts for the sparse matrix. In each case, the vector X was replicated onto all nodelets.

. . . .

15

5/21/2018

SpMV results: Emu simulator vs Haswell Xeon

• “2D” layout outperforms “1D” layout
• Spurious thread migrations are limiting performance on Emu

. . . .

16

5/21/2018

Pointer Chasing Microbenchmark

• Designed to mimic access pattern of dynamically allocated data structures

(i.e. streaming graphs)

• Data-dependent loads: Memory-level parallelism is severely limited since

each thread must wait for one pointer dereference to complete before accessing the next pointer

• Fine-grained accesses: Spatial locality is restricted since all accesses are at

a 16B granularity. This is smaller than a 64B cache line on x86 platforms, and much smaller than a typical DRAM page size (around 8KB).

• Random access pattern: Since each block of memory is read exactly once

in random order, caching and prefetching are mostly ineffective.

. . . .

17

5/21/2018

Pointer chasing: Initialization

• 1. Create a linked list of elements

“Ordered” Access pattern is sequential and predictable Plenty of spatial locality available

. . . .

18

5/21/2018

Pointer chasing: Intra-block shuffle

• 2. Randomize traversal order of elements within each block

“Intra-block shuffle” Creates small contiguous blocks of memory that are accessed in random

• rder.

Overall access pattern is still sequential.

. . . .

19

5/21/2018

Pointer chasing: Block shuffle

• 3. Randomize traversal order of each block

“Block shuffle” Overall access pattern is now random. Small chunks of sequential locality still available.

. . . .

20

5/21/2018

Pointer Chasing: Sandy Bridge Xeon Results

. . . .

21

5/21/2018

Pointer Chasing: Emu Hardware Results (single-node)

. . . .

22

5/21/2018

Pointer Chasing: Bandwidth Utilization

. . . .

23

5/21/2018

Simulator Validation: STREAM

When configured to match the current hardware specifications, the simulator results match closely for local stream and global stream.

. . . .

24

5/21/2018

Simulator Validation: Migrations

• Pointer chasing performs 2x better in the simulator
• Simulator is over-estimating migration throughput
• Updated simulator matches more closely

. . . .

25

5/21/2018

Conclusions

• First independent evaluation of Emu Chick prototype
• STREAM bandwidth is low, but scales well
• Memory layout and thread management decisions are critical to achieving

scalability in SpMV

• Pointer Chasing maintains 80% memory bandwidth utilization in a worst-

case pointer chasing scenario

• Future work: Applying these lessons to streaming graphs analytics and

sparse tensor processing
