All your GPS Trackers belong to Us 1 Who we are Pierre Barre, Lead Security Researcher, Mobile and Telecom Lab Chaouki Kasmi, Lab Director, Mobile and Telecom Lab Eiman Al Shehhi, Security Researcher, Mobile and Telecom Lab The

slide-1
SLIDE 1

1

All your GPS Trackers belong to Us

slide-2
SLIDE 2

2

Who we are

  • Pierre Barre, Lead Security Researcher, Mobile and Telecom Lab
  • Chaouki Kasmi, Lab Director, Mobile and Telecom Lab
  • Eiman Al Shehhi, Security Researcher, Mobile and Telecom Lab
  • The opinions and results presented in this article are the sole responsibility of the authors.
  • Tests and Validation Labs, xen1thLabs, DarkMatter Group
slide-3
SLIDE 3

3

GPS Tracker Technology

  • Cheap
  • Using remote management without advertising it
  • Available everywhere
  • Compatible with IOS/Android
slide-4
SLIDE 4

4

Presentation

  • Infrastructure
  • Devices
  • Blackbox analysis
  • Information gathering (FCC ID)
  • Network analysis (Wireless and wired)
  • Reverse Engineering (hard, firmware, clients)
  • OWASP - webapp
slide-5
SLIDE 5

5

General Architecture

  • Points of interaction:
  • Radio interface

(GPS/mobile network)

  • Remote servers
  • Web application
  • Mobile application
  • Management protocols

Internet Internet

GPS Satellites Mobile Network Tracked devices/items Tracking reports Management Servers Data Base Web Servers

slide-6
SLIDE 6

6

Existing researches

  • Web analysis – Trackmageddon (Multiple vulnerabilities in the online services of (GPS)

location tracking devices)

  • Kang Wang, Shuhua Chen, Aimin Pan, Time and Position Spoofing with Open Source Projects
  • Fidus, Exploiting 10,000+ devices used by Britain’s most vulnerable
slide-7
SLIDE 7

7

Defining attack surfaces

  • Security of GPS trackers is well-known
  • Objectives: finding new vulnerabilities/weaknesses, having fun, hacking the planet 
  • Exploitation: detecting trackers (2G, 2.5G, 3G and IP Network), tracking people,

remotely shutdown car engines, GPS informations, BTS and eNodeB information

  • Attack Surfaces:
  • Radio – passive (2G, GPRS)
  • Radio – active (2G, GPRS and GPS)
  • Network (Layer 3!) – remote management server and custom protocols
  • Hardware attack - tracker
  • Software attack - tracker
  • Software attack - iOS/Android clients
  • Web interface (management)
slide-8
SLIDE 8

8

Analyzed trackers

  • Multiple GPS trackers bought online (Aliexpress)
  • Presentation of the devices
  • 3 types of GPS / infrastructures
  • GPS infrastructures share the same technologies!
  • Chinese domination on existing solutions
  • 2 solutions
  • GSM (A5/1) interception
  • Setup of a custom BTS
  • 1 paper in MISC (focused on methodology)
  • 1 scientific paper (focused on privacy)
slide-9
SLIDE 9

9

Passive Radio Attack

  • YateBTS with sgsntun interface
  • SIM cards (not USIM)
  • Live demo!
  • Registration (using IMEI or S/N and 123456)
  • Creation of account in advance
  • Configuration using SMS
  • First Fail: content of all SMS sent to China (we will come back to this later)
  • Proprietary protocols over text messages
slide-10
SLIDE 10

10

Passive Radio Attack

  • Setup is very cheap (BladeRF, SIM cards, Internet)
  • Very good results in a limited time
  • All trackers send coordinates to IPs in China
  • The traffic is not encrypted and is easily identifiable
  • Passwords sent in clear-text, S/N used as a token
  • SMS configuration is generic and very dangerous
  • “Firewall” using a master phone number – bypassed by spoofing Caller-ID
  • Phone number of the tracker is supposed to be “secret” (security/privacy)
slide-11
SLIDE 11

11

Passive Radio Attack – configuration using SMS

  • 1. SMS (Status) is sent to tracker from 440025239
  • ver 2G
  • 1. Sniffing of GPRS data from the tracker:
  • 1. IP packet to 203.130.62.29:8841
  • 2. 690217122612463 = S/N of GPS tracker
  • 3. +440025239 is the sender
  • 4. Status is the content of SMS

Only specific commands sent from SMS?

  • 1. SMS (jjjj[…]) is sent to tracker using 2G
  • 2. Tracker send the content of SMS to a remote

Server (203.130.62.29)

slide-12
SLIDE 12

12

Passive Network Attack – RE of custom protocols

  • No authentication

\x79\x79\x00 I \xf2 [S/N-ASCII][BLOB-ASCII] \x01\x7e [BLOB-ASCII]

  • Traffic sent to 203.130.62.29:8841/tcp (geo-located in China)
  • Basic client allowing us to send forged coordinates
  • Where is Waldo ?

Pinging 203.130.62.29 with 32 bytes of data: Reply from 203.130.62.29: bytes=32 time=9ms TTL=58 Reply from 203.130.62.29: bytes=32 time=10ms TTL=58

  • 10ms and 6 hops ? To China ? Impossible
  • 203.130.62.29/24 is announced by Etisalat, the largest UAE provider, and hosted in Dubai
  • Everything (configuration, tracking, information, phone numbers) is sent to UAE
  • Big trust given to the manufacturer. GDPR anyone ?
  • Reconfiguration of the management server using SMS = allows expats to setup a SMS forward service

for no cost 

slide-13
SLIDE 13

13

Passive Network Attack – RE of custom protocols

  • U-Blox module – connection to a TCP service on the 56447/tcp port:

cmd=full;user=XXXXXX@gmail.com;pwd=XXXXXX;lat=22.680193;lon=114.146846;alt=0.0;pacc=100.00 u-blox a-gps server (c) 1997-2009 u-blox AG Content-Length: 2856 Content-Type: application/ubx .b..0......

  • The client then regularly sends information to a second server (8011 / tcp) indicating its

position:

*HQ,17000XXXXX,V1,115112,A,2240.8116,N,11408.8108,E,000.0,000.00,100119,FFFFFFFF# *HQ,17000XXXXX,NBR,094111,310,26,02,1,1000,10,23,100119,FFFFFFFF# *HQ,17000XXXXX,LINK,115112,22,0,6,0,0,100119,FFFFFFFF# *HQ,17000XXXXX,NBR,115117,310,26,02,1,1000,10,22,100119,FFFFFFFF#

  • Different commands can be detected according to the serial number (17000XXXXX).

2240.8116 corresponds to the latitude 22.408116 and the longitude 11.4088108.

slide-14
SLIDE 14

14

Active Network Attack – RE of custom protocols

  • There is no authentication in the protocol
  • We wrote a client in Perl resulting in locations in North Korea:
  • An attacker able to guess a serial number can

send false information to the GPS management infrastructure.

  • Hint: this is do-able
slide-15
SLIDE 15

15

Active Radio Attack

  • GPS Spoofing – public for years
  • Detection of GPS trackers using SMS (custom keywords without “authentication”)
  • Custom spoofed SMS (“reg my_ip”)
  • Not always mandatory to spoof
  • New management server defined
  • Using `balance` to intercept and change the traffic over the Internet 
  • balance -b ::ffff:my_ip 8841 203.130.62.29:8841
  • Data traffic modification on-the-fly (mitmproxy, bettercap, …)
  • Use a faraday cage
  • Don’t do this at home
slide-16
SLIDE 16

16

Active Radio Attack

  • Voice
  • Using the device to listen (2G)
  • Call-back support (by SMS)
  • Microphone
  • Movement/noise detectors
  • Cameras
  • Additional wireless interfaces
  • Wireless client
  • Scanner
  • RF - attack surface
slide-17
SLIDE 17

17

Network – attack surface

  • Multiple trackers – multiple remote management servers
  • 3 GPS trackers, 3 different back-ends
  • Infrastructures based on a few OEM solutions
  • Chinese IPs but:
  • Located in China,
  • Located in Germany,
  • Located in UAE (open ports, banking websites, …),
  • Reverse Engineering of protocols: Done
  • Specific traffic: on the ISP side, easy to detect, extract coordinates and modify on-the-fly
  • APIs
  • Live demo
slide-18
SLIDE 18

18

Hardware Attack

  • GPS chips:
  • U-blox G7020
  • SIMCom SIM800
  • Support of GPS, GLONASS, QZSS, Galilleo
  • Flash memory (4MB)
  • MediaTek SOC (ARM - MT6261DA)
  • No protection against physical attacks
  • UART port
  • Firmware dumping
  • Debug interface available
  • Analysis (ARM)
  • Hidden commands found
slide-19
SLIDE 19

19

Software Attack

  • ARM dump
  • Loaded within IDA Pro
  • Nucleus RTOS
  • Data Line S8 Locator – hidden commands
  • Backdoors SMS codes
  • Different trackers, different OEMS, different commands

different network protocols

  • Not all of these SMS commands seem to be functional.
  • SMS parsing, Quick’n’Dirty
  • HTTP client and custom client
  • Parsing prone to errors
  • No firmware update features
slide-20
SLIDE 20

20

Android/IOS Clients

  • Dynamic Analysis (android emulator)
  • Static Analysis (jadx)
  • Results
  • Authentication (login/password)
  • APIs access
  • (Lack of?) Authentication for APIs
  • Need an unrelated valid session
  • Communication over HTTP (no encryption)
  • http://m.999gps.net/OpenAPIV2.asmx with debug!
  • http://m.999gps.net/OpenAPIV2.asmx?WSDL (full description!)
  • Insecure Direct Object References
  • IDOR Already found by Trackmaggedon team in January 2018!
slide-21
SLIDE 21

21

Web Interface – attack surface

  • Web site
  • Live information (GPS, speed)
  • Replay
  • Geofence definition
  • OEM version (.NET) provided to a lot of providers of GPS

products

slide-22
SLIDE 22

22

Web Interface – attack surface – Geofence

  • Authentication based on last 7 integers of the S/N
  • Default pwd: 123456
  • Geofence:
  • Stop/start command with a remote control (!)
  • Auto-shutdown of the car (!)
  • Alerts (SMS, push on app)
  • Vulnerable to IDOR
  • Anyone can geofence your tracker
  • Blindly trust the (forged) GPS information

sent to the server

  • Good idea, very bad implementation
slide-23
SLIDE 23

23

Web Interface – attack surface

  • Web interface full of vulnerabilities
  • IDOR everywhere (tracker ID: 82383)
  • Full history of GPS tracker data
  • APIs
  • Let’s dig
  • Full of vulnerabilities
  • Same as Android/IOS
  • Kudos to Trackmaggedon team (pwn of 100s APIs)
  • Live demo
  • GDPR?
slide-24
SLIDE 24

24

Conclusion

  • Thanks!
  • Black box devices – implementations from big OEM vendor
  • Used everywhere (in industrial machines too)
  • Cell-IDs – can be used to map the critical mobile telecom infrastructure of a given country
  • Huge subject (including RE, network analysis, SDR, web) – a real CTF 
  • Hope you had fun!
  • Still some work to do!
  • At xen1thLabs we are committed to uncovering new vulnerabilities that combat tomorrow’s

threats today.

slide-25
SLIDE 25

25

References

  • V. Stykas, M. Gruhn, Multiple vulnerabilities in the online services of (GPS) location tracking devices, [online]

https://0x0.li/trackmageddon/ Kang Wang, Shuhua Chen, Aimin Pan, Time and Position Spoofing with Open Source Projects, BlackHat Europe 2015, Amsterdam, NL, [online] https://www.blackhat.com/docs/eu-15/materials/eu-15-Kang-Is-Your-Timespace-Safe-Time-And-Position-Spoofing- Opensourcely-wp.pdf https://github.com/osqzss/gps-sdr-sim 302 GPS TRACKER, [online] https://fccid.io/2AA64-302/User-Manual/User-Manual-3470390 YateBTS GSM basestation - Open Source Software, [online] https://yatebts.com/open_source/#svn https://github.com/skylot/jadx GPS tracking vulnerabilities leave millions of products at risk By Steve Ragan, Senior Staff Writer, CSO | JANUARY 02, 2018 https://www.csoonline.com/article/3245312/gps-tracking-vulnerabilities-leave-millions-of-products-at-risk.html security issue in kids/ elderly tracking watches https://fil.forbrukerradet.no/wp-content/uploads/2017/10/watchout-rapport-october-2017.pdf https://www.pentestpartners.com/security-blog/tracking-and-snooping-on-a-million-kids/
