Albert-Ludwigs-Universität Freiburg Fakultät für Angewandte Wissenschaften Dec 5, 2006

Alert classification to reduce false positives in intrusion detection

Tadeusz Pietraszek / 'tʌ·deuʃ

pɪe·'trʌ·ʃek/

tadek@pietraszek.org

P h D D e f e n s e P r e s e n t a t i o n

PhD Defense 2 13.08.07

Thesis Statement

Thesis at the intersection of machine learning and computer security. 1. Using machine learning it is possible to train classifiers in the form of human readable classification rules by observing the human analyst. 2. Abstaining Classifiers can significantly reduce the number of misclassified alerts with acceptable abstention rate and are useful in intrusion detection. 3. Combining supervised and unsupervised learning in a two-stage alert-processing system forms a robust framework for alert processing.

PhD Defense 3 13.08.07

Outline

• Background and problem statement.
• 1. Adaptive learning for alert classification.
• 2. Abstaining classifiers.
• 3. Combining supervised and

unsupervised learning.

• Summary and conclusions.

PhD Defense 4 13.08.07

Intrusion Detection Background

• Intrusion Detection Systems (IDSs) [And80,Den87] detect

intrusions i.e. sets of actions that attempt to compromise the integrity, confidentiality, or availability of computer resource [HLMS90].

• IDS have to be effective (detect as many intrusions as possible)

and keep false positives to the acceptable level, however, in real environments 95-99% alerts are false positives [Axe99, Jul01, Jul03].

• Eliminating false positives is a difficult problem:

– intrusion may only slightly differ from normal actions (IDSs have limited context processing capabilities), – writing a good signature is a difficult task (specific vs. general), – actions considered intrusive in one systems, may be normal in others, – viewed as a statistical problem – base rate fallacy.

PhD Defense 5 13.08.07

Global picture – IDS monitoring

Manual knowledge acquisition is not used for classifying alerts – Fact 1: Large database of historical alerts. – Fact 2: Analyst typically analyzes alerts in real time.

PhD Defense 6 13.08.07

Problem statement

• Given

– A sequence of alerts (A1, A2, …, Ai, …) in an alert log L – A set of classes C = {C1, C2, …, Cn} – An intrusion detection analyst O sequentially and in real-time assigning classes to alerts – A utility function U describing the value of a classifier to the analyst O

• Find

– A system classifying alerts, maximizing the utility function U

• Misclassified alerts
• Analyst’s workload
• Abstentions

PhD Defense 7 13.08.07

Outline

• Background and problem statement.
• 1. Adaptive learning for alert classification.
• 2. Abstaining classifiers.
• 3. Combining supervised and

unsupervised learning.

• Summary and conclusions.

PhD Defense 8 13.08.07

ALAC (Adaptive Learner for Alert Classification)

Automatically learn an alert classifier based on analyst’s feedback using machine learning techniques.

Background Knowledge

Rules Params

Alert Classifier

Classified Alerts Alerts Update Rules ID Analyst IDS

Machine Learning

Training Examples Feedback Model Update

Recommender mode

• Misclassifications

PhD Defense 9 13.08.07

ALAC (Adaptive Learner for Alert Classification)

Background Knowledge

Rules Params

Alert Classifier

No Alerts Update Rules ID Analyst IDS

Machine Learning

Training Examples Feedback Model Update

Confident? Process

Yes

Agent mode

• Misclassifications
• Analyst’s workload

PhD Defense 10 13.08.07

Why does learning work and why can it be difficult?

• The approach hinges on the two assumptions

– Analysts are able to classify most of alerts correctly – It is possible to learn a classifier based on historical alerts

• Difficult learning problem

1. Use analyst’s feedback (learning from training examples). 2. Generate the rules in a human readable form (correctness can be verified). 3. Be efficient for large data files. 4. Use background knowledge. 5. Asses the confidence of classification. 6. Work with skewed class distributions / misclassification costs. 7. Adapt to environment changes.

PhD Defense 11 13.08.07

Requirements - revisited

• 1. Core algorithm - RIPPER.
• 2. Rules in readable form.
• 3. Efficient to work on large datasets.
• 4. Background knowledge represented in attribute-value form.
• 5. Confidence – rule performance on testing data with Laplace

correction.

• 6. Cost Sensitivity – weighted examples.
• 7. Incremental Learning – “batch incremental approach” –

batch size depends on the current classification accuracy.

PhD Defense 12 13.08.07

Results - Thesis Statement (1)

Adaptive Learner for Alert Classification (ALAC)

• Human feedback, background knowledge, ML

techniques.

– Recommender Mode (focusing on the misclassifications in the utility function U).

• Good performance: fn=0.025, fp=0.038 (DARPA),

fn = 0.003, fp = 0.12 (Data Set B).

– Agent Mode (focusing on the misclassifications and the workload in the utility function U).

• Similar number of misclassifications and more than 66%
• f false positives are automatically discarded.

– Many rules are interpretable.

PhD Defense 13 13.08.07

Outline

• Background and problem statement.
• 1. Adaptive learning for alert classification.
• 2. Abstaining classifiers.
• 3. Combining supervised and

unsupervised learning.

• Summary and conclusions.

PhD Defense 14 13.08.07

Metaclassifier Aα,β

Abstaining binary classifier A is a classifier that in certain case can refrain from classification. We construct it as follows:

where Cα, Cβ is such that: (Conditions used by Flach&Wu [FW05] in their work on repairing concavities of the ROC curves, met in particular if Cα, Cβ are constructed from a single scoring classifier R). Can we optimally select Cα, Cβ?

Cα Cβ

Result + + +

• +

? +

• Impossible
• (

) (

)

⎪ ⎩ ⎪ ⎨ ⎧ − = − + = ∧ − = + = + = ) ( ) ( ) ( ? ) ( ) (

,

x x x x x

β β α α β α

C C C C A

) ) ( ) ( ( ) ) ( ) ( ( : − = ⇒ − = ∧ + = ⇒ + = ∀ x x x x x

α β β α

C C C C

PhD Defense 15 13.08.07

“Optimal” Metaclassifier Aα,β

How do we compare binary classifiers and abstaining classifiers? How to select an optimal classifier? No clear answer

– Use cost based model (Cost-Based Model) (extension of [Tor04] – Use boundary conditions:

• Maximum number of instances classified as “?” (Bounded-

Abstention Model)

• Maximum misclassification cost (Bounded-Improvement Model)

PhD Defense 16 13.08.07

Cost-based model – a simulated example

0.0 0.2 0.4 0.6 0.8 1.0 0.0 0.2 0.4 0.6 0.8 1.0

ROC curve with two optimal classifiers

FP TP Classifier A Classifier B F P ( a ) 0.0 0.2 0.4 0.6 0.8 1.0 FP(b) 0.0 0.2 0.4 0.6 0.8 1.0 Cost 0.2 0.3 0.4 0.5

Misclassification cost for different combinations of A and B

F P ( a ) 0.0 0.2 0.4 0.6 0.8 1.0 FP(b) 0.0 0.2 0.4 0.6 0.8 1.0 Cost 0.2 0.3 0.4 0.5

Misclassification cost for different combinations of A and B

P N c c c fp f P N c c c fp f

ROC ROC 13 23 21 13 12 23

) ( ) ( − = ′ − = ′

α β

PhD Defense 17 13.08.07

Bounded models

Problem: 2x3 cost matrix is not always given and would have to be estimated. However, classifier is very sensitive to c13, c23. Finding other optimization criteria for an abstaining classifier using a standard cost matrix. – Calculate misclassification costs per classified instance. Follow the same reasoning to find the optimal classifier.

PhD Defense 18 13.08.07

Bounded models equation

Obtained the following equation, determining the relationship between k and rc for as a function of classifiers Cα, Cβ. – Constrain k, minimize rc → bounded-abstention – Constrain rc, minimize k → bounded-improvement No algebraic solution, however, for a convex ROCCH we can show an efficient algorithm.

( )( )(

) ( ) ( ) ( )

β α α β β α

FN FN FP FP P N k c FN c FP P N k rc − + − + = + + − = 1 1 1

12 21

PhD Defense 19 13.08.07

Bounded-abstention model

Among classifiers abstaining for no more than a fraction

• f kMAX instances find the one that minimizes rc.

Useful application in real-time processing instances where the non-classified instances will be processed by another classifier with a limited processing speed. Algorithm: Three-step derivation – Step 1: Show an (impractical) solution for a smooth ROCCH and equality k = kMAX. – Step 2: Extend for a inequality k ≤ kMAX – Step 3: Derive an algorithm for ROCCH.

PhD Defense 20 13.08.07

Bounded-abstention model – Step 1 and 2

Using Lagrange method (constrained optimization under equality conditions) ∇rc ×∇k=0 we obtain Starting for known optimal classifier for a given k can construct an

• ptimal classifier path for k + δk.

– Known points can be either the optimal binary classifier or an all- abstaining classifier. – Such a solution is impractical. Can show that except for a very special boundary case this classifier is also optimal for k ≤ kMAX.

( )

( )

12 21 2 12 21

1 c c P N c c P N fp f fp f

ROC ROC

⎟ ⎠ ⎞ ⎜ ⎝ ⎛ = ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ − + ′ ′

α β

PhD Defense 21 13.08.07

Bounded-abstention model – Step 3

ROCCH consists of line segments connecting points Pi, Pi+1 with coefficients Ai and Bi such that tp = Ai fp + Bi Using similar reasoning as in Step 1 we obtain that: – Either Cα or Cβ is located on the vertex Pi or Pj. – The optimal classifier depends

• n the sign of X.

O(n) algorithm for finding the

• ptimal classifier.

Pi Pj Pi+1 Case 1 X > 0 Pi Pj Pj−1 Case 2 X < 0

12 21 2 12 21

1 c c P N c c P N A A X

i j

⎟ ⎠ ⎞ ⎜ ⎝ ⎛ − ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ − + =

PhD Defense 22 13.08.07

Bounded-abstention model – a simulated example

FP(a) 0.0 0.2 0.4 0.6 0.8 1.0 FP(b) 0.0 0.2 0.4 0.6 0.8 1.0 C

• s

t 0.1 0.2 0.3 0.4 0.5

Optimal classifier path − bounded−abstention

FP(a) 0.0 0.2 0.4 0.6 0.8 1.0 F P ( b ) 0.0 0.2 0.4 0.6 0.8 1.0 C

• s

t 0.2 0.3 0.4 0.5

Optimal classifier path − bounded−abstention

PhD Defense 23 13.08.07

How can we use it in ALAC? ALAC+

ALAC architecture fits a tri-state classifier.

Tri-State Alert Classifier

No (?) Alerts ID Analyst IDS

Learn Tri-State Classifier

Training Examples Feedback

Class Assigned? Process

Yes (+/-)

PhD Defense 24 13.08.07

Results - Thesis Statement (2)

• Applied abstaining classifiers for alert classification

(ALAC+) – Recommender mode

• DARPA: comparable fn, significantly lower fp (up to 97%),

cost reduction by 15-20%.

• Data Set B: lowered fn (76%) and fp (97%), cost reduction

by 87%.

– Agent mode

• DARPA: comparable fn, much lower fp, comparable cost
• Data Set B: lowered fn (60%) and fp (96%), cost reduction

by 72%.

– ALAC+ reduced the overall number of misclassifications (in particular fp) and, in most cases, misclassification costs. – Higher precision is better for human analysts [Axe99].

PhD Defense 25 13.08.07

Outline

• Background and problem statement.
• 1. Adaptive learning for alert classification.
• 2. Abstaining classifiers.
• 3. Combining supervised and

unsupervised learning.

• Summary, conclusions and

contributions.

PhD Defense 26 13.08.07

Clustering (CLARAty)

• Julisch[Jul03] observed that a great number of alerts can

be attributed to a small number of root causes, which are persistent over time. – Julisch used a modified AOI[Jul03] to generate human readable cluster descriptions – Root causes can be identified and root causes can be removed.

• Inputs:

– Alerts – Generalization Hierarchies (mostly IP addresses)

• Outputs:

– Clusters (in the form of generalized alerts)

PhD Defense 27 13.08.07

Two-stage alert classification system

Alert Classifier Machine Learning

Training Examples Background Knowledge Rules Params

Alerts Update Rules ID Analyst IDS

Agent Confident?

Process

Yes No

Environment:

• investigating network and

configuration problems Alert Clustering

Clusters

Analyst

• Interpretation
• Finding root causes

IDS:

• filtering rules

Alert Filter IDS:

• modif.

signatures Environment:

• investigating intrusions

Feedback

Alert Clustering Adaptive Alert Classification

• CLARAty used for filtering and labeling alerts

– Filtering mode (FI) – Feature Construction mode (FC)

• Alerts subsequently passed onto ALAC

PhD Defense 28 13.08.07

Results - Thesis Statement (3)

• Proposed a two-stage alert classification system, based on

CLARAty[Jul03]

• using clusters for retrospective alert analysis,
• automated cluster processing system,
• two-stage alert processing system.
• Feature Construction (FC) does not yield big improvements.
• Filtering (FI) performs better (in terms of FN ) and

comparably (in terms of FP ). Most likely because the “easy” alerts have been removed.

• Thanks to the first stage, the number of alerts to be

processed in the second stage (analyst’s workload) have been reduced by 63%.

PhD Defense 29 13.08.07

Outline

• Background and problem statement.
• 1. Adaptive learning for alert classification.
• 2. Abstaining classifiers.
• 3. Combining supervised and

unsupervised learning.

• Summary and conclusions.

PhD Defense 30 13.08.07

Conclusions

• Evolution of IDSs

– Level 1: Improving IDSs themselves – Level 2: Leveraging the Environment – Level 3: Alert Postprocessing – Level 4: Analyst’s Involvement

• Using ML techniques for IDS alert classification.
• Verified the three-part thesis statement.
• System works but inherently there is a risk that some

attacks might be missed.

• Step towards a more efficient and reliable alert-

management system.

Thank you!

PhD Defense 32 13.08.07

Future Work

Combining with existing multi-stage alert correlation systems. Other learning algorithms: SVM, Bayesian, predictive clustering rules? Multi-class classification. Link mining. Dynamic ROC evaluation in incremental settings. HCI issues.

PhD Defense 33 13.08.07

Can Machine Learning be secure? [NKS06], [BNSJ+06] ML does not deal with active attackers [CB06]

– “Mutagenesis dataset never tried to evade your classifier”

All automated classification systems bear certain risk (it’s a matter of trade-offs!)

– attacker may try to hide their activities among background alerts hoping to evade detection – BUT they do it anyway because such attacks already have a lower chance of being caught!

• By removing irrelevant alerts the system can highlight the

important ones, but there’s no guarantee.

• But it is also possible that this effect is amplified by ALAC.

PhD Defense 34 13.08.07

Can Machine Learning be secure? [NKS06], [BNSJ+06] Good news

– ALAC does not provide immediate feedback. – The interaction with background knowledge is complex. – There is only that many attacks the attacker might try. – Might be treated as noise.

Bad news

– There is no guarantee. – Once such systems are common, they may turn into “arms race” (cf. spam). But for this to happen IDSs would have to be much better than they are now. Let’s see how spam filters and automated signature generation deals with it first ;-)

PhD Defense 35 13.08.07

Publication List

• Tadeusz Pietraszek. On the use of ROC analysis for the optimization of abstaining
• classifiers. Machine Learning Journal, (accepted with minor revisions to appear), 2007.
• Tadeusz Pietraszek. Classification of intrusion detection alerts using abstaining
• classifiers. Intelligent Data Analysis Journal, 11(3):(to appear), 2007.
• Tadeusz Pietraszek, Axel Tanner. Data Mining and Machine Learning---Towards

Reducing False Positives in Intrusion Detection. Information Security Technical Report Journal, Volume 10(3), pages 169--183, 2005.

• Tadeusz Pietraszek, Chris Vanden Berghe. Defending against Injection Attacks through

Context-Sensitive String Evaluation. In Recent Advances in Intrusion Detection (RAID 2005), volume 3858 of Lecture Notes in Computer Science, pages 124--145, Seattle, WA, 2005.

• Tadeusz Pietraszek. Optimizing Abstaining Classifiers using ROC Analysis. In

Proceedings of 22nd International Conference in Machine Learning (ICML 2005), pages 665-672, Bonn, Germany, 2005.

• Tadeusz Pietraszek. Using Adaptive Alert Classification to Reduce False Positives in

Intrusion Detection. In Recent Advances in Intrusion Detection (RAID2004), volume 3324 of Lecture Notes in Computer Science, pages 102-124, Sophia Antipolis, France, 2004.

PhD Defense 36 13.08.07

References (1)

• [And80] James P. Anderson. Computer security threat monitoring and

surveillance.Technical report, James P. Anderson Co., 1980.

• [Axe05] Stefan Axelsson.Understanding Intrusion Detection Through Visualization.

PhD thesis, Chalmers University of Technology, 2005.

• [Axe99] Stefan Axelsson.The base-rate fallacy and its implications for the intrusion
• detection. In Proceedings of the 6th ACM Conference on Computer and

Communications Security, pages 1-7, Kent Ridge Digital Labs, Singapore, 1999.

• [BNSJ+06] Marco Barreno, Blaine Nelson, Russell Sears, Anthony D.
• Joseph, J. D. Tygar. Can Machine Learning Be Secure?. Conference on Computer and

Communications Security. Proceedings of the 2006 ACM Symposium on Information, computer and communications security. Pages 16-25. Taipei, Taiwan 2006.

• [Bugtraq03] SecurityFocus. BugTraq. Web page at http://www.securityfocus.com/bid,

1998-2004.

• [CAMB02] Frederic Cuppens, Fabien Autrel, Alexandre Miege, and Salem Benferhat.

Correlation in an intrusion detection process. In Proceedings SEcurit\e des Communications sur Internet(SECI02), pages 153-171, 2002.

• [CB06] Alvaro A. Cárdenas and John S. Baras. Evaluation of Classifiers and Learning

Rules: Considerations for Security Applications. Proceedings of the AAAI 06 Workshop on Evaluation Methods for Machine Learning. Boston, Massachusetts, July 17, 2006.

• [DC01] Olivier Dain and Robert K. Cunningham. Fusing a heterogeneous alert stream

into scenarios. In Proceedings of the 2001 ACM Workshop on Data Mining for Security Application, pages 1-13, Philadelphia, PA, 2001.

• [Den87] Dorothy E. Denning. An intrusion detection model. IEEE Transactions on

Software Engineering, SE-13(2):222-232, 1987.

PhD Defense 37 13.08.07

References (2)

• [Der03] Renaud Deraison.The Nessus Project. Web page at http://www.nessus.org,

2000-2003.

• [DW01] Herve Debar and Andreas Wespi. Aggregation and correlation of intrusion-

detection alerts. In Recent Advances in Intrusion Detection (RAID2001), volume 2212 of Lecture Notes in Computer Science, pages 85-103. Springer-Verlag, 2001.

• [FW05] P. A. Flach and S. Wu.Repairing concavities in ROC curves. In Proceedings

2003 UK Workshop on Computational Intelligence, pages 38-44, Bristol, UK, 2003.

• [HLMS90] Richard Heady, George Luger, Arthur Maccabe, and Mark Servilla. The

architecture of a network level intrusion detection system. Technical report, University

• f New Mexico, 1990.
• [How97] John D. Howard.An Analysis of Security Incidents on the Internet 1989-1995.

PhD thesis, Carnegie Mellon University, 1997.

• [IBM03] IBM. IBM Tivoli Risk Manager. Tivoli Risk Manager User's Guide. Version 4.1,

2002.

• [Jul01] Klaus Julisch. Mining Alarm Clusters to Improve Alarm Handling Efficiency. In

Proceedings 17th Annual Computer Security Applications Conference, pages 12-21, New Orleans, LA, Dec. 2001.

• [Jul03a] Klaus Julisch. Clustering intrusion detection alarms to support root cause
• analysis. ACM Transactions on Information and System Security (TISSEC), 6(4):443-

471, 2003.

• [Jul03b] Klaus Julisch. Using Root Cause Analysis to Handle Intrusion Detection
• Alarms. PhD thesis, University of Dortmund, Germany, 2003.
• [Krs98] Ivan Victor Krsul. Software Vulnerability Analysis. PhD thesis, Purdue

University, 1998.

PhD Defense 38 13.08.07

References (3)

• [LBMC94] Carl E. Landwehr, Alan R. Bull, John P. McDermott, and William S. Choi. A

taxonomy of computer program security flaws. ACM Computing Surveys (CSUR), 26(3):211-254, 1994.

• [LWS02] Richard Lippmann, Seth Webster, and Douglas Stetson. The effect of

identifying vulnerabilities and patching software on the utility of network intrusion

• detection. In Recent Advances in Intrusion Detection (RAID2002), volume 2516 of

Lecture Notes in Computer Science, pages 307-326. Springer-Verlag, 2002.

• [MC03] Matthew V. Mahoney and Philip K. Chan. An analysis of the 1999

DARPA/Lincoln Laboratory evaluation data for network anomaly detection. In Recent Advances in Intrusion Detection (RAID2003), volume 2820 of Lecture Notes in Computer Science, pages 220-237. Springer-Verlag, 2003.

• [McH00] John McHugh. The 1998 Lincoln Laboratory IDS evaluation. A critique. In

Recent Advances in Intrusion Detection (RAID2000), volume 1907 of Lecture Notes in Computer Science, pages 145-161. Springer-Verlag, 2000.

• [MIT03] MITRE. Common Vulnerabilites and Exposures. Web page at

http://cve.mitre.org, 1999-2004.

• [MHL94] Biswanath Mukherjee, Todd L. Heberlein, and Karl N. Levitt. Network intrusion
• detection. IEEE Network, 8(3):26-41, 1994.
• [NKS06] James Newsome, Brad Karp, Dawn Song. Paragraph: Thwarting Signature

Learning By Training Maliciously. In Recent Advances in Intrusion Detection (RAID2006), Hamburg, Germany 2006.

• [PF98] Mark Paradies and David Busch. Root cause analysis at Savannah river plant. In

Proceedings of the IEEE Converence on Human Factors and Power Plants, 1988.

PhD Defense 39 13.08.07

References (4)

• [PV05] Tadeusz Pietraszek and Chris Vanden Berghe. Defending against injection

attacks through context-sensitive string evaluation. In Recent Advances in Intrusion Detection (RAID2005), volume 3858 of Lecture Notes in Computer Science, pages 124- 145, Seattle, WA, 2005. Springer-Verlag.

• [RZD05] James Riordan, Diego Zamboni, and Yann Duponchel.Billy Goat, an accurate

worm-detection system (revised version) (RZ 3609). Technical report, IBM Zurich Research Laboratory, 2005.

• [SP01] Umesh Shankar and Vern Paxson. Active mapping: Resisting NIDS evasion

without altering traffic.In Proceedings of the 2003 IEEE Symposium on Security and Privacy, pages 44-62, Oakland, CA, 2001.

• [SP03] Robin Sommer and Vern Paxson. Enhancing byte-level network intrusion

detection signatures with context. In Proceedings of the 10th ACM Conference on Computer and Communication Security, pages 262-271, Washington, DC, 2003.

• [VS01] Alfonso Valdes and Keith Skinner. Probabilistic alert correlation. In Recent

Advances in Intrusion Detection (RAID2001), volume 2212 of Lecture Notes in Computer Science, pages 54-68. Springer-Verlag, 2001.

• [VVCK04] F. Valeur, G. Vigna, C.Kruegel, and R. Kemmerer. A comprehensive approach

to intrusion detection alert correlation. IEEE Transactions on Dependable and Secure Computing, 1(3):146-169, 2004.

• [WF00] Ian H. Witten and Eibe Frank. Data Mining: Practical machine learning tools with

Java implementations. Morgan Kaufmann Publishers, San Francisco, CA, 2000.

Security – supporting slides

PhD Defense 41 13.08.07

Computer Security

Confidentiality – prevention of (un)intentional unauthorized disclosure of data Integrity – prevention of (un)intentional unauthorized modification of data. Availability - prevention of unauthorized withholding of computing resources. Intrusion – any set of actions that attempt to compromise the confidentiality, integrity or availability of a computing resource.

PhD Defense 42 13.08.07

Intrusion detection

Traditional approach to security: build a “protective shield” around systems [MHL94].

– Tradeoff security vs. usability – Open systems are more productive – “Secure systems” are vulnerable to attacks exploiting internal errors (e.g., buffer overflows, injection attacks, race conditions), – Systems are vulnerable to insider attacks (intentional

• r unintentional)

Intrusion detection [Den87]: retrofit systems with security by detecting attacks and alerting a SSO.

PhD Defense 43 13.08.07

Intrusion Detection Systems (IDS)

• Intrusion Detection System - an automated system detecting

and alarming of any situation where an intrusion has taken

• r is about to take place [Axe05].

SSO/ID Analyst

Monitored System Audit collection Audit storage Processing Component Alert Active/Processing Data Reference Data Configuration Data Automated Response Automated Response Manual Response

PhD Defense 44 13.08.07

Intrusion Detection Systems: anomaly vs. misuse

Anomaly-based model Misuse-base model, detects only known attacks. Why not just prevent them if they are known?

– Window of vulnerability – Detecting failed attacks – Detecting policy violations – Additional layer of protection – Generalized and intent-guessing signatures.

PhD Defense 45 13.08.07

Snort – an open source IDS

PhD Defense 46 13.08.07

Snort – signature examples

PhD Defense 47 13.08.07

Striving to reduce false positives

• Level 1: Improving IDSs themselves

– More sophisticated protocol analyzers, state keeping [Roe05,Pax99] – Highly specialized IDSs: Billygoat [RZD05], CSSE[PV05]

• Level 2: Leveraging the environment

– Active mapping [SP01], Context Signatures [SP03] – Vulnerability correlation [LWS02, VVCK04]

• Level 3: Alert Postprocessing

– Data mining [Jul03b] – Alert correlation systems [CAMB02, DW01, VS01, VVCK04]

• Level 4: Analyst’s Involvement

– Idea pursued in this thesis and mostly orthogonal to the other approaches.

Alerts ID Analyst IDS

Level 1 Level 4 Level 3 Level 2

PhD Defense 48 13.08.07

Binary vs. multi-class classification

• Analysts analyze

– The root cause of alerts [PB88] – The impact on the environment – The actions that need to be taken

• Taxonomizing root causes is a difficult task [How97, Jul03b, Krs98, LBMC94].
• Ad-hoc classifications exist, for example:

– Intentional/malicious (e.g. scanning, unauthorized access, privilege escalation, policy violation, DoS attack), – Inadvetent/non-malicious (e.g. network misconfiguraion, normal acitivities).

• The main distinction for the analyst “Is the alert actionable or not?”

– Determined by the combination of the root cause and the impact on the environment. – For our purposes we will assume that the this is equivalent to our two classes: true positives and false positives.

ALAC – supporting slides

PhD Defense 50 13.08.07

Evaluation problem – two datasets [Pie04, PT05]

• DARPA1999 Data Set

– Used network traces, run through Snort IDS – Used attack truth tables to label the alerts

• Data Set B

– Real network traces collected in a mid-sized corporate network – Used Snort IDS to generate alerts – Manually labeled (bias!)

PhD Defense 51 13.08.07

Evaluation Problem – new dataset

• MSSD Datasets

– Real datasets from MSSD, different commercial NIDSs, some companies more than 1. – Looked at some 20 companies for time period

• f 6 months

– Some alerts belong to incidents, labeled by security analysts

PhD Defense 52 13.08.07

Evaluation problem

• Lack of publicly available data sources for the evaluation of IDSs

– No common reference for evaluation – Everybody can install an IDS in their own network

• Yes, but this data often cannot be shared (sensitive information)
• Has no labels

– Honeypots Data [PDP05]

• All data is by definition suspicious
• More useful for detecting automated attacks then real attackers.
• DARPA1998 and DARPA1999 efforts

– MIT Lincoln Labs simulated environment – Many flaws have been identified [McH01, MC03] – Still used in many papers (e.g., UCI Dataset and KDD CUP 1999)

• Recent effort presented at ETRICS06 (Qian et at.)
• Proprietary

– Data Set B: undisclosed customer, collected with Snort, classified by the author – MSSD Data Sets: data from IBM’s SOC, implicitly classified by real security analysts.

PhD Defense 53 13.08.07

Evaluation Problem – Summary

• These datasets are quite different!

– DARPA1999 DataSet & Data Set B

• On average 1472 alerts per company per day out of which 359 are

true positives (24%)

– MSSD Dataset

• On average 3250 alerts per company per day out of which 11 are

true positives (0.34%).

• Most alerts are clustered in incidents, on average 1 incident every 9

days

– Moreover, we are not sure if all the labels are correct

• Some incidents could have been missed
• Some incidents may have turned out to be false positives
• We should probably handle them differently

PhD Defense 54 13.08.07

Background Knowledge

Network topology

– Classification of IP addresses – Create rules using generalized concepts

Installed software Alert semantics

– How do we understand the attack? CVE[MIT03], Bugtraq[03] – Was the attack successful? IDD[IBM03], Nessus[Des03]

Alert context i.e. alerts related to the current one (correlation in intrusion detection, e.g. [DW01, DC01, VS01]).

– Set or sequence of alerts related to the current one – Additional features (aggregates, alert summaries, alert categories), expressing domain knowledge in intrusion detection

PhD Defense 55 13.08.07

Background Knowledge

Alerts with classification have been written to relational database Use scripts to generate background knowledge in A-V form: – IP address classification – OS classification – Aggregates (all in three different time windows – 1min, 5min, 30min)

• Number of alerts coming from the same IP addresses (src,

dst, srcdst, srcdst)

• Number of alerts of the same type
• Number of alerts with similar classification

PhD Defense 56 13.08.07

Misclassification, Statistics (DARPA1999)

0.005 0.01 0.015 0.02 0.025 0.03 0.035 0.04 20000 30000 40000 50000 60000 False Negative rate (fn) Alerts Processed by System 0.01 0.02 0.03 0.04 0.05 20000 30000 40000 50000 60000 False Positive rate (fp) Alerts Processed by the System Agent - sampling 0.1 Agent - sampling 0.25 Agent - sampling 0.5 Recommender Batch Classification

PhD Defense 57 13.08.07

Misclassification, Statistics (Data Set B)

0.005 0.01 0.015 0.02 10000 15000 20000 25000 30000 35000 40000 45000 50000 False Negative rate (fn) Alerts Processed by System Agent - sampling 0.1 Agent - sampling 0.25 Agent - sampling 0.5 Recommender Batch Learning 0.05 0.1 0.15 0.2 10000 20000 30000 40000 50000 False Positive rate (FP) Alerts Processed by the System Agent - sampling 0.1 Agent - sampling 0.25 Agent - sampling 0.5 Recommender Batch Classification

PhD Defense 58 13.08.07

Automatic Processing

DARPA1999 Data Set B

0.25 0.5 0.75 1 20000 30000 40000 50000 60000 Discarded False Positive rate Alerts Processed by the System Agent - sampling 0.1 Agent - sampling 0.25 Agent - sampling 0.5 0.25 0.5 0.75 10000 20000 30000 40000 50000 Discarded False Positive rate Alerts Processed by the System Agent - sampling 0.1 Agent - sampling 0.25 Agent - sampling 0.5

PhD Defense 59 13.08.07

Understanding the Rules

Rules are quite understandable. They use attributes generated by the background knowledge.

(cnt_intr_w1 <= 0) and (cnt_sign_w3 >= 1) and (cnt_sign_w1 >= 1) and (cnt_dstIP_w1 >= 1) => class=FALSE (cnt_srcIP_w3 <= 6) and (cnt_int_w2 <= 0) and (cnt_ip_w2 >= 2) and (sign = ICMP PING NMAP) => class=FALSE

“If there’s been similar alerts recently and they are all false alarms (no intrusions) then the current alert is a false alert.” “If the number of NMAP pings is small and there are no intrusions, the alert is a false alert.”

PhD Defense 60 13.08.07

Experiments - Setting ALAC Parameters

• Using ROC curve, one can choose the optimal classifier.

– Need to know target class distributions and misclassification costs

• Didn’t have such data -> selected value ad-hoc CR=50

(more on this later!)

• Classification accuracy

– When to retrain the model

• Selected a value based on performance in ROC
• Automatic processing – confidence

– Right now ad-hoc, looking for something better (more on this later!)

ML – supporting slides

PhD Defense 62 13.08.07

Evaluating classifiers – confusion and cost matrices

A/C +

• +

c12

• c21

A = Actual, C = Classified as

TN FP TN tn TN FP FP fp FN TP FN fn FN TP TP tp + = + = + = + = Cost Matrix Confusion Matrix

12 21

c c CR =

A/C +

• +

TP FN P

• FP

TN N

PhD Defense 63 13.08.07

ROC Background

ROC (Received Operating Characteristic) used for model evaluation and model selection for binary classifiers – multiple class extensions are not practically used Allows to evaluate model performance under all class and cost distributions – 2D plot fp × tp (X – false positive rate, Y - true positive rate) – one point corresponds to one classifier

PhD Defense 64 13.08.07

ROC Background

A Classifier C produces a single point on the ROC curve (fp, tp). Classifier Cτ (or a machine learning method Lτ) has a parameter τ varying which produces multiple points. Therefore we consider a ROC curve a function f : τ a (fpτ, tpτ). Can find an inverse function f-1 : (fpτ, tpτ) a τ and approximate it with f ˆ-1

PhD Defense 65 13.08.07

ROC Background

ROC Convex Hull – A piecewise-linear convex down curve fR, having the following properties:

• fR(0) = 0, fR(1) = 1
• Slope of fR is monotonically non-increasing.

– Assume that for any value m, there [PF98] exists fR(x) = m.

• Vertices have ``slopes’’ assuming values between the slopes of adjacent

edges

• Assume sentinel edges: 0th edge with a slope ∞ and (n+1)th edge with a

slope 0.

– We will use ROCCH instead of ROC.

Abstaining Classifiers – supporting slides

PhD Defense 67 13.08.07

Selecting the Optimal Classifier

Criteria – minimize the misclassification cost

( ) ( )

1 1 1 ) 1 ( 1 ) ( 1

12 21 12 21 12 21 12 21

= ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ ⎟ ⎠ ⎞ ⎜ ⎝ ⎛ ′ ⋅ ⋅ − + = ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ ⋅ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ ⎟ ⎠ ⎞ ⎜ ⎝ ⎛ − + ⋅ + = ⎟ ⎠ ⎞ ⎜ ⎝ ⎛ ⋅ = ⋅ − + ⋅ + = = ⋅ + ⋅ + = N FP f c N P c P N FP d rc d c N FP f P c FP P N rc N FP f P TP c TP P c FP P N rc fp f tp c FN c FP P N rc

ROC ROC ROC ROC

PhD Defense 68 13.08.07

Cost Minimizing Criteria for One Classifier

( )

P N CR fp fROC = ′

• Known iso-performance lines [PF98]

PhD Defense 69 13.08.07

Cost-based model - selecting the optimal classifier

Similar criteria – minimize the cost

( ) ( )

P N c c c fp f P N c c c fp f FP rc FP rc c FN FN c FP FP c FP c FN P N rc

ROC ROC misclass disagree misclass disagree fp fp fn fn 13 23 21 13 12 23 . 13 . 23 , 21 , 12

) ( ) ( 1 − = ′ − = ′ ⇒ = ∂ ∂ ∧ = ∂ ∂ ⎟ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎜ ⎝ ⎛ − + − + + + =

− − α β α β α β α β α β β α α α β β

4 4 3 4 4 2 1 4 4 3 4 4 2 1 3 2 1 3 2 1

Depends only on the slopes of ROC (similar to a single-classifier case)

PhD Defense 70 13.08.07

Cost-based model - understanding cost matrices

2x2 cost matrix is well known. 2x3 cost matrices has some interesting properties: e.g. under which conditions the optimal classifier is an abstaining classifier Our derivation is valid for we can prove that if this condition is not met the classifier is a trivial binary classifier

( ) ( ) ( )

12 23 13 21 12 21 13 12 23 21

c c c c c c c c c c + ≥ ∧ > ∧ ≥

PhD Defense 71 13.08.07

Cost-based model - understanding cost matrices

• Theorem. If (*) is not met, the classifier is a trivial

binary classifier. Proof (sketch) – show that for an optimal classifier fR’(fp*

α) ≥ fR’(fp*) ≥ fR’(fp* β), where fp* corresponds

to an optimal binary classifier. – show that if (*) is not met, is positive for fp*

α < fp*

and that is positive for fp*

β > fp*

– therefore fp*

α = fp* = fp* β

( ) ( ) ( )

(*)

12 23 13 21 12 21 13 12 23 21

c c c c c c c c c c + ≥ ∧ > ∧ ≥

α

fp rc ∂ ∂

β

fp rc ∂ ∂

PhD Defense 72 13.08.07

Cost-based model - interesting cases

How to set c13, c23 so that the classifier is a non- trivial abstaining classifier? Two interesting cases – Symmetric case (c13=c23) – Proportional case (c13/c12 = c23/c21)

12 21 21 12 23 13

c c c c c c + ≤ =

2 2

21 23 12 13

c c c c ≤ ⇔ ≤

PhD Defense 73 13.08.07

Bounded-abstention model – Algorithm

PhD Defense 74 13.08.07

Experiments

Tested with 15 UCI KDD datasets, using averaged cross-validation. In each model used one independent parameter c13=c23, k or f. Classifier – Bayesian classifier from Weka [WF00]. In many cases obtained a large cost reduction even with a small abstention k=0.1. Now applying it to alert classification.

PhD Defense 75 13.08.07

Results with abstaining classifiers

CLARAty – supporting slides

PhD Defense 77 13.08.07

CLARAty algorithm[Jul03b]

PhD Defense 78 13.08.07

CLARAty & cluster labeling

• Running CLARAty with no labels and trying to label clusters

– Containing only false positives – Containing only true positives – Mixed

• Two main purposes

– Retroactive alert analysis

• By looking at cluster descriptions again, the analysts may spot previously

missed incidents or large groups of alerts indicating problems

• Can write rules recognizing some incidents

– Predictive value

Historical Incident Data

Alerts

Alert Clustering

Create Trigger Rule (TP) Alert Filter

Historical Alert Data

Incident Correlation

Create Filtering Rule (FP) Split Clusters or Investigate missed TP

PhD Defense 79 13.08.07

Clustering Conclusions

• Clusters are persistent

– Average clustering coverage 90% – Average filtering coverage 63%

• Most of the clusters are FP only clusters (avg. 95%)

– These clusters tend to be persistent

• There are only very few TP clusters (avg. 0.2%)

– These clusters are ephemeral

• Mixed clusters (avg. 5%)

– These clusters need to be investigated more carefully.

• Filtering works well, although if clusters are not reviewed some attacks

can be missed – Investigated, mostly due to incorrect labeling.

PhD Defense 80 13.08.07

Automated Clustering & Analysis Framework

• Only FP clusters are filtered out.

– Evaluation verifies that no FP are missed – Applied to DARPA1999 Data Set and Data Set B – Applied 26 times to each company on MSSD data (weekly clustering)

PhD Defense 81 13.08.07

Cluster filtering (DARPA1999 and Data Set B)

5000 10000 15000 20000

DARPA1999 Data

date (clustering period 1 week) #alerts Feb 28 Mar 10 Mar 20 Mar 30 #alerts #positives clusters 0.0 0.2 0.4 0.6 0.8 1.0

DARPA1999 Data

date (clustering period 1 week) fraction of alerts (1 week) Feb 28 Mar 10 Mar 20 Mar 30 5000 10000 15000 20000

Data Set B

date (clustering period 1 week) #alerts Nov 14 Nov 19 Nov 24 Nov 29 Dec 04 Dec 09 #alerts #positives clusters 0.0 0.2 0.4 0.6 0.8 1.0

Data Set B

date (clustering period 1 week) fraction of alerts (1 week) Nov 14 Nov 19 Nov 24 Nov 29 Dec 04 Dec 09

PhD Defense 82 13.08.07

Cluster persistency (DARPA1999 and Data Set B)

5000 10000 15000 20000

Filtering using Clustering (DARPA 1999 Data)

date (clustering period 1 week) #alerts Feb 28 Mar 10 Mar 20 Mar 30 #alerts #covered (clustering) #covered (FP clusters) #filtered #positives #positives missed 0.0 0.2 0.4 0.6 0.8 1.0

Filtering using Clustering (DARPA 1999 Data))

date (clustering period 1 week) fraction 1/(N+P) Feb 28 Mar 10 Mar 20 Mar 30 covered (clustering) covered (FP clusters) filtered positives missed (FN/P) 5000 10000 15000 20000

Filtering using Clustering (Data Set B)

date (clustering period 1 week) #alerts Nov 14 Nov 19 Nov 24 Nov 29 Dec 04 Dec 09 #alerts #covered (clustering) #covered (FP clusters) #filtered #positives #positives missed 0.0 0.2 0.4 0.6 0.8 1.0

Filtering using Clustering (DARPA 1999 Data))

date (clustering period 1 week) fraction 1/(N+P) Feb 28 Mar 10 Mar 20 Mar 30 covered (clustering) covered (FP clusters) filtered positives missed (FN/P)

PhD Defense 83 13.08.07

Cluster Accuracy & Coverage (DARPA1999)

PhD Defense 84 13.08.07

Cluster Accuracy & Coverage (Data Set B)

PhD Defense 85 13.08.07

Two-stage alert classification – ROC analysis

• Feature construction performs only marginally better
• Filtering performs much better for DARPA and comparably

for Data Set B.

0.0 0.1 0.2 0.3 0.4 0.90 0.92 0.94 0.96 0.98 1.00

Two−Staged System − DARPA

fp tp 1 4 8 12 39 53.5 54.06 80.12 128 2 4 8 16 84 127.5 1 3 4.5 7 18 54 1 3 4.5 7 18 54.34 81 Original Feature construction (2FC) Filtering (2FI) Filtering (2FI) (rescaled) 0.0 0.1 0.2 0.3 0.4 0.90 0.92 0.94 0.96 0.98 1.00

Two−Staged System − Data Set B

fp tp 0.25 1 2.5 6 163245 48 112.39 0.25 1 1 2 4.25 4.69 7 11 19.11 34.88 54.49 132.45 512 0.5 1 2.75 4.25 6 12 24 0.5 1 2.75 4.25 6 12 24 25.4 61.72 69. Original Feature construction (2FC) Filtering (2FI) Filtering (2FI) (rescaled)

PhD Defense 86 13.08.07

Misclassifications (two-stage) (DARPA)

0.005 0.01 0.015 0.02 0.025 0.03 0.035 0.04 10000 20000 30000 40000 50000 60000 False Negative rate (fn) Alerts Processed by System Recommender Recommender (2FC) Recommender (2FI) Agent Agent (2FC) Agent (2FI) 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 10000 20000 30000 40000 50000 60000 False Positive rate (fp) Alerts Processed by System

PhD Defense 87 13.08.07

Misclassifications (two-stage) (Data Set B)

0.002 0.004 0.006 0.008 0.01 10000 20000 30000 40000 50000 False Negative rate (fn) Alerts Processed by System Recommender Recommender (2FC) Recommender (2FI) Agent Agent (2FC) Agent (2FI) 0.05 0.1 0.15 0.2 10000 20000 30000 40000 50000 False Positive rate (fp) Alerts Processed by System

PhD Defense 88 13.08.07

Automatic Processing (two-stage)

0.25 0.5 0.75 10000 20000 30000 40000 50000 60000 Discarded False Positive rate Alerts Processed by the System Agent Agent (2FC) Agent (2FI) 0.25 0.5 0.75 1 10000 20000 30000 40000 50000 Discarded False Positive rate Alerts Processed by the System Agent Agent (2FC) Agent (2FI)

DARPA1999 Data Set B

END!
