Advantages of direct drives in positioning systems 1 Agenda 1. About us 2. Linear motor: Basics 3. Why choose a linear motor? 4. Applications 2 Mity napdy bezporednie TECNOTION About us Specialized in linear motors

slide-1
SLIDE 1

Advantages of direct drives in positioning systems

1

slide-2
SLIDE 2

Agenda

1. About us 2. Linear motor: Basics 3. Why choose a linear motor? 4. Applications

2

slide-3
SLIDE 3

TECNOTION

Mity – napędy bezpośrednie

slide-4
SLIDE 4

About us

  • Specialized in linear motors
  • Former part of Philips
  • More than 25 years of experience
  • Worldwide 210 employees
  • Turnover approx. 45,000,000 Euro
  • Headquarters in Almelo/The Netherlands
  • Branches in Germany, Poland, USA & Korea
  • Production facilities in The Netherlands & China

4

slide-5
SLIDE 5

Linear motor: Basics

5

slide-6
SLIDE 6

Linear motor: Basics

Quelle: Wikipedia

6

slide-7
SLIDE 7

Linear motor

slide-8
SLIDE 8

Permanent magnets (secondary part)

8

Linear motor: Basics

slide-9
SLIDE 9

Permanent magnets (secondary part) Forcer (primary part)

9

Linear motor: Basics

slide-10
SLIDE 10

Coils Permanent magnets (secondary part) Forcer (primary part)

10

Linear motor: Basics

slide-11
SLIDE 11

Magnetic flux (B) Force (F) Current (I)

 F = I x B x L

11

Linear motor: Basics

slide-12
SLIDE 12

Products

Torque Motors Vacuum linear motors

12

Iron core linear motors Ironless linear motors

slide-13
SLIDE 13

Motor Technologies

Iron core linear motors Ironless linear motor

 High Forces / Masses  Velocity up to 12 m/s  Costs  Dynamics  Velocity up to 18 m/s  No cogging

13

slide-14
SLIDE 14

Portfolio

TECNOTION Vacuum

Iron less Iron core

slide-15
SLIDE 15

Portfolio

TECNOTION Torque motor

slide-16
SLIDE 16

Torque motors

What is a torque motor?

slide-17
SLIDE 17

Serwo Gear box Coupling Torque motor Mechanics

Torque motors

Encoder Mechanics Encoder Labour time Labour time Foot print Foot print

Price

slide-18
SLIDE 18

Portfolio

TECNOTION Torque motor

slide-19
SLIDE 19

TECNOTION Designation

Portfolio

Motor height Outer Diameter

133 160

Series

Outer Diameter Motor height

105 17 N QTR

Magnet Type Winding type

34 60 25 92 A S

X

slide-20
SLIDE 20

Portfolio

TECNOTION Vacuum

Iron less Iron core

slide-21
SLIDE 21

Portfolio

TECNOTION Specials

UXA

Level 1 Level 2 Level 3 Level 4 Degrees of customization:

  • 1. Connector addition
  • 2. Cable length / special winding
  • 3. Custom tooling (different geometry / cable, cable exit)
  • 4. Complete custom

Customization guidelines

slide-22
SLIDE 22

Why choose a linear motor?

24

slide-23
SLIDE 23

Belt Screw Linear motor

Drive systems

Rack & Pinion

100 m/s2 < 1µm 40 m/s2 ~40µm 10 m/s2 5µm 50 m/s2 ~50µm

Acc. Precision

25

slide-24
SLIDE 24

Why choose a linear motor

 Acceleration up to 100 m/s2

26

  • High dynamics (acceleration)/ Высокая динамика/ускорение
  • High velocity / высокая скорость
  • Position accuracy / точность позиционирования
  • Flexibility / modular system / гибкость
  • Compact design / компактность
  • Simple procurement / простота заказа
  • Maintenance free / не требует обслуживания ( смазка, обслуживание)
  • Low-noise / низкий шум
  • Suitable for vacuum / решения для вакуума
  • Cleanroom / стерильное помещение на производстве
slide-25
SLIDE 25

Why choose a linear motor

 Velocity up to 18 m/s

27

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-26
SLIDE 26

Why choose a linear motor

 Possible accuracy < 1 μm

28

Quelle: Wikipedia

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-27
SLIDE 27

29

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-28
SLIDE 28

30

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-29
SLIDE 29

 No Gearboxes needed  No bearings (screw & belt)  No couplings

31

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-30
SLIDE 30

 Small number of parts

32

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-31
SLIDE 31

 No wear and tear  No lubrication

33

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-32
SLIDE 32

34

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-33
SLIDE 33

 Rated outgassing values up to 10-8 mBar

35

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-34
SLIDE 34

 Up to ISO cleanroom class 1

36

Why choose a linear motor

  • High dynamics (acceleration)
  • High velocity
  • Position accuracy
  • Flexibility / modular system
  • Compact design
  • Simple procurement
  • Maintenance free
  • Low-noise
  • Suitable for vacuum
  • Cleanroom
slide-35
SLIDE 35

37

Carriage Cable chain Stator Guideway Encoder Forcer

Ironcore motor Ironless Motor

Osie liniowe - zabudowa

slide-36
SLIDE 36

Semiconductor Electronics F.P.D. Solar Digital Printing Machine Tooling Biomedical Vacuum Inspection

38

Markets

slide-37
SLIDE 37

39

QUALITY AND SERVICE DELIVERED WORLDWIDE
