CHEMISTRY THAT DRIVES COMMERCE

WELCOME TO TRAINING

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

JOE LONG

jlong@oldworldind.com

203-648-2849 www.peakhd.com

2

Inhibitors + (4 -6%) Glycol -(50%) Glycol Provides Boil-Over And Freeze Point Protection Water - (50%) Water Transfers Heat

Inhibitors Protect Metals From Rust And Corrosion

WHAT IS ANTIFREEZE/COOLANT?

CHEMISTRY THAT DRIVES COMMERCE

TESTING COOLANT

• 1) Color
• 2) Clarity
• 3) Odor
• 4) Freeze Point
• 5) Chemical Protection

CHEMISTRY THAT DRIVES COMMERCE

TESTING COOLANT

• 1) Color – indicates technology or mixing – whatever the

color of the coolant is (red, pink, yellow, green, gold), it should have a fluorescent color. It should not be brown..

• 2) Clarity – indicates oil, fuel, corrosion
• 3) Odor – indicates high pH – ammonia state above 11.0

destroys soft metals – below 7 indicates acidic

• 4) Freeze Point –indicates dilution -12 to -65 Fahrenheit

acceptable 60/40 – 40/60 mix of glycol /water

• 5) Chemical Protection – indicates adequate protection –

dilution – use test strip – OAT use pass / fail. If it fails add converter/extender as per chart – ½ gallon to 15 gallon

• system. If Fully Formulated – uses NITRITE test strip & add

SCA

CHEMISTRY THAT DRIVES COMMERCE

Antifreeze / Glycol Testing (Freeze point)

6 Test Strips DO NOT USE !

• Not accurate

with Red Coolants

• Small scale
• Expire

Hydrometers

• Not very

accurate

• Must be cleaned

after every use Refractometer (Analog)

• Very Accurate
• Will Test EG / PG / Specific gravity
• Readings will be off on some newer

coolants

CHEMISTRY THAT DRIVES COMMERCE

WHEN SHOULD I I TEST THE COOLANT?

Every 20 – 25,000 miles Or Every 3 – 4 months Or Every 600 – 800 hours

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

GLOBAL EVOLUTION OF HEAVY-DUTY COOLANT

Conventional Technology Fully Formulated Technology Nitrite-Free Extended Life Technology

OEM Date Technology Change Europeans 1990’s Extended Life Technology Japanese 1990’s Extended Life Technology G.M. & Caterpillar 1995 Extended Life Technology

1900’s 1980’s 1990’s

OEM Date Technology Change Paccar 2001 Extended Life Technology All HD OEM’s offer 2002 Extended Life Technology All HD OEM’s FF 2010 Extended Life Technology

Nitrited Extended Life Technology

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE Fully Formulated Technology

HEAVY DUTY COOLANT TECHNOLOGIES

▪ Organic Inhibitors (OAT):

• No Silicates, Phosphates or Borates

▪ Requires NO addition of SCAs

Extended Life Technology (ELC)

• Long Lived
• No Drop-out

Concerns ▪ Inorganic Inhibitors:

• Low-Silicate, Borate, Nitrate, Nitrite
• No Phosphates

▪ Supplemental Coolant Additive (SCA) Precharged for Heavy-Duty applications

• Short Lived
• Fewer Drop-out

Concerns ▪ Inorganic Inhibitors:

• Low-Silicate, Phosphate, Borate, Nitrate, Nitrite

▪ Requires the addition of SCAs to prevent wet sleeve liner cavitation (ie Penray, NalCool)

Conventional Technology

• Short Lived
• Inhibitor Drop-out

Concerns

Hybrid Technology

▪ Inorganic & Organic Inhibitors (HOAT): ▪ Organic acids combined with one or more conventional inhibitors (Silicate, Borate, Nitrate, and/or Nitrite) ▪ Typically No Phosphates ▪ Supplemental Coolant Additive (SCA)Precharged for Heavy-Duty applications

• Longer Lived
• Potential Drop-out

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

FULLY FORMULATED COOLANT/ANTIFREEZE

• Works in ALL heavy-duty diesel, gasoline and natural gas

engine cooling systems.

• Designed to last the life of the engine when maintained with a

high quality SCA filter system.

• Fully-formulated, requires no initial dose of SCAs
• Optimum protection against freezing and boil over.
• Incorporates nitrite to provide wet sleeve liner protection

against cavitation.

• Provides corrosion protection of all cooling system metals and

component

• Low silicate, phosphate free formula reduces the risk of scale

Benefits

FULLY FORMULATED ANTIFREEZE & COOLANT

Technology Application

• Conventional
• On Road/ Off Road

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

Maintenance

FULLY FORMULATED COOLANT/ANTIFREEZE

SCA

• SCAs must be checked and maintained
• Check Nitrite Level Every 25,000 Miles Or 500

Hours/3 Months

• Maintain SCA Level Based On OEM

Recommendations

• Typically 1200 ppm
• Can last the life of the engine when properly

maintained with high quality SCAs and filters.

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

HYBRID BLUE COOLANT/ANTIFREEZE

Benefits

HYBRID BLUE ANTIFREEZE & COOLANT

• Heavy duty, commercial/stationary engines operating on diesel,

gasoline, natural gas, propane, LPG, biofuels or methane waste gas where the OEM specifies a HOAT fluid formulation based

• n nitrite, low silicate, phosphate-borate and OAT technology
• Hybrid ESI coolant/antifreeze with service intervals at 150,000

miles / 4,000 hours

• Fully-formulated, requires no initial dose of SCAs. Easily

maintained with DCA4 liquid or chemical filter SCA system.

• Delivers excellent liner pitting, corrosion, & erosion protection
• Proprietary inhibitor eliminates scale deposits that can

significantly reduce heat transfer

• Compatible with any antifreeze/coolant

Technology

Application

• Hybrid Organic Acid Technology, 2-EHA Free

On Road/ Off Road

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

Maintenance

SCA

SCAs must be checked and maintained Can last the life of the engine when properly maintained with high quality SCAs and filters.

HYBRID BLUE COOLANT/ANTIFREEZE

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

Extended Life Coolants ELC NOAT OAT –NF OAT – NON 2EH WHY ELC?

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

IMPROVED COMPONENT LIFE – HEAT EXCHANGERS

No Silicates to plate out on surfaces No Phosphates to drop out and form scale No Borates which can be aggressive to Aluminum

SILICATES, PHOSPHATES OR BORATES CAN CAUSE ISSUES

Improved Component Life

CONVENTIONAL HD COOLANT EXTENDED LIFE COOLANT

CHEMISTRY THAT DRIVES COMMERCE

Flux Problems:

Some aluminum radiators are contaminated on the inside with brazing flux. The flux residue can bind to the silicate in conventional coolant causing it to drop out and plug the system. Since the silicate was the primary protection for aluminum, the aluminum radiator is left unprotected against corrosion, which is accelerated by the flux. A flush and fill removes the flux and the system ready to last a life

• time. Factory fill with ELC eliminates the silicate issues since most ELC

isn’t formulated with any. Unfortunately the flux is still present and may reduce the effectiveness or longevity of the coolant. . Nitrite has been shown to attack and corrode the aluminum in these high flow cooling systems. This is why some engine manufacturers are requiring the use of Nitrite free coolant.

CHEMISTRY THAT DRIVES COMMERCE

Why Nitrite Free:

Some aluminum radiators are formed with “dimpled” tubes to improve heat dissipation and allow the use of smaller

• radiators. Nitrite has been shown to

attack and corrode the aluminum in these high flow cooling

• systems. This is why some engine manufacturers are requiring the

use of Nitrite free coolant. Unfortunately, Nitrite has been one of the best ways to protect wet sleeve liners against cavitation erosion. This is why some engine manufacturers are still recommending Nitrite containing ELC - (NOAT ) formulations.

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

IMPROVED HEAT TRANSFER

No Silicates or Phosphates to form a scale and create another heat barrier

Improved Heat Transfer

Conventional Extended Life

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

• Works in ALL heavy-duty diesel, gasoline and natural gas

engine cooling systems

• Protection for 750,000 MILES of on-road use (8 years or

15,000hours of off-road use)

• Eliminates the need for SCAs and chemically charged filters
• Excellent heat transfer for high temperature applications such

as engines with EGR and SCR systems

• Outstanding protection against corrosion and cavitation
• Non-abrasive formula can improve water pump seal life
• Eliminates drop-out, gel and reduces scale
• Can be mixed with other coolants

Benefits

NITRITED EXTENDED LIFE COOLANT

Technology Application

• Nitrited Organic Acid Technology, 2-EHA
• On Road/ Off Road

NOAT COOLANT

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

• 2-Ethylhexanoic (2-EH) degrades silicon

elastomeric materials

• Silicon Elastomers Are Still Used In Cummins

High Horsepower Engines Commonly Used In Mining Applications

2–EH AND SILICON ELASTOMERIC MATERIALS

Silicon sample after aging in commercially available 2-EH based OAT Silicon sample aged in an a non 2-EH based coolant

• Fleetguard ELC Is Nitrite-Free
• John Deere is Nitrite-Free
• Freightliner is Nitrite-Free
• All Japanese Coolants Are Nitrite-Free
• Europeans Are Only Evaluating Nitrite -

Free Coolants Industry Positions:

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

EXTENDED LIFE COOLANT/ANTIFREEZE

Benefits

NITRITE FREE EXTENDED LIFE COOLANT

• Works in ALL heavy-duty diesel, gasoline and natural gas

engine cooling systems

• Guaranteed protection for ONE MILLION MILES of on-road

use (8 years or 20,000 hours of off-road use)

• Eliminates the need for SCAs and chemically charged filters
• Excellent heat transfer for high temperature applications such

as engines with EGR and SCR systems

• Outstanding protection against corrosion and cavitation
• Non-abrasive formula can improve water pump seal life
• Eliminates drop-out, gel and reduces scale
• Can be mixed with other coolants (to maintain corrosion

protection contamination levels should be kept below 25%)

• Provides exceptional long term elastomer compatibility

Technology

Application

• Nitrite Free Organic Acid Technology, 2-EH Free
• On Road/ Off Road
• Fleets with Cummins Equipment

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

ELC NF COOLANT/ANTIFREEZE

• On-highway heavy duty vehicles and commercial/stationary engines operated on

diesel, gasoline, natural gas, propane, LPG, biofuels, or methane waste gas, where the OEM recommends a nitrite, silicate and phosphate-free coolant

• Extended service life of up to 600,000 miles/12,000 hours or 6 years in heavy duty

applications under normal operating conditions, up to150,000 miles or 5 years of service in light and medium duty applications

• Eliminates the need for SCAs and chemically charged filters
• Excellent heat transfer due to OAT technology compared to conventional silicate

containing coolants

• Improved water pump seal life due to silicate-free environment, as well as protection

against cavitation erosion, and corrosion wear

• Compatibility with other conventional and extended life antifreeze/coolants

Benefits

NITRITE FREE EXTENDED LIFE COOLANT

Technology Application

• Organic Corrosion Inhibitors
• On Road

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

LIGHT DUTY VS HEAVY DUTY

ASTM and TMC* have separate standards and practices for Automotive versus Heavy Duty coolants

− ASTM D3306: Standard Specification for Glycol Base Engine Coolant for Automobile and Light- Duty Service − ASTM D6210: Standard Specification for Fully- Formulated Glycol Base Engine Coolant for Heavy- Duty Engines − TMC RP 302: Fleet Purchasing Specification for Low-Silicate Ethylene Glycol Base Engine Coolant Requiring SCAs (min. specs for coolant) − TMC RP 329: Fleet Purchasing Specification for Nitrite-Containing Ethylene Glycol Base Coolant (for heavy duty vehicles)

* American Society for Testing & Materials; Technology Maintenance Council of the American Trucking Association

CHEMISTRY THAT DRIVES COMMERCE CHEMISTRY THAT DRIVES COMMERCE

OEM POSITIONS FACTORY FILL: INTERNATIONAL, FREIGHTLINER, FORD, GM, VOLVO/MACK, ASIA & EUROPE ALL FACTORY FILLED WITH NITRITE FREE EXTENDED LIFE COOLANT ONLY PACCAR FILLS WITH NITRITED COOLANT

CHEMISTRY THAT DRIVES COMMERCE

CHEMISTRY THAT DRIVES COMMERCE

THANK YOU !
