Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax: 82-2-948-2342 Homepage: http://www.waco.co.kr 1. HW-UP 100 Series (for undersink type) HW-UP 100 :Sediment filter + Pre Carbon filter + RO

slide-1
SLIDE 1

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-2
SLIDE 2
  • 1. HW-UP 100 Series (for undersink type)

▶HW-UP 100 :Sediment filter + Pre Carbon filter + RO membrane filter + Post Carbon filter ▶HW-UP 100 M :Sediment filter + Pre Carbon filter + RO membrane filter + Post Carbon filter + RO pump

  • 2. HW-UP 200 Series (for undersink or counter top type)

▶HW-UP(OP)200 A : Sediment Filter + Pre Carbon Filter + Alkali Filter + Post Carbon Filter ▶HW-UP(OP)200 N : Sediment Filter + Pre Carbon Filter + Nano pH Filter + Post Carbon Filter ▶HW-UP(OP)200 U : Sediment Filter + Pre Carbon Filter + UF membrane Filter + Post Carbon Filter

  • 3. HW-UP 300 Series (for undersink or counter top type, tankless RO system)

▶HW-UP(OP) 300 M : Sediment Filter + Pre Carbon Filter + RO membrane Filter + Post Carbon Filter+ RO pump Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-3
SLIDE 3

1) Features of HW-UP 100 Series

◎Undersink type ◎Use of RO membrane Filter

  • Average Flow Rate(GPD):50, 75,100,150 GPD
  • Improving the TDS(Total Dissolved Solids) rejection
  • Meets all different water quality needs.

◎With booster pump (HW-UP100M)

  • Using the high quality booster pump that can provide 100-120psi water

pressure to pass through the membrane even with areas under low water pressure.

◎Specification

  • Dimension : 325*180*430mm(W*D*H)
  • Weight : 7.5kgs (HW-UP 100) , 9.5kgs (HW-UP100M)

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-4
SLIDE 4

2) Installation Diagram of HW-UP 100 Series & Components

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-5
SLIDE 5

3) Inside form of HW-UP 100 series

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-6
SLIDE 6

1) Features of HW-UP(OP) 200 Series

◎Undersink type & Onsink type(Counter top) ◎Saving space ◎Optional Filter System(UF membrane/ Alkali/ Nano pH)

*UF membrane Filter - Removal for harmful chemicals, bacteria, virus, Etc. But, containing the minerals beneficial for health *Alkali Filter - Removal Active Oxygen *Nano pH Filter - Strong of oxidation-reduction potential reducing rate Removal Active Oxygen

◎Specification

  • Dimension : 325*180*430mm(W*D*H)
  • Weight : 7.5kgs

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-7
SLIDE 7

2) Installation Diagram of HW-UP(OP) 200 Series

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-8
SLIDE 8

3) Components & Inside form of HW-UP(OP) 200 series

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-9
SLIDE 9

1) Features of HW-UP 300 Series

◎Tankless Reverse Osmosis System ◎Undersink type & Onsink type(Counter top) ◎Use of RO 300 GPD Filter

  • Average Flow Rate(GPD):300 GPD
  • Improving the TDS(Total Dissolved Solids) rejection (Rejection Rate:97 %)
  • Meets all different water quality needs.

◎With booster pump(Motor)

  • Using the high quality booster pump that can provide 100-120psi water pressure

to pass through the membrane even with areas under low water pressure.

◎Specification

  • Dimension : 325*180*430mm(W*D*H)
  • Weight : 10.5kgs

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-10
SLIDE 10

2) Installation Diagram of HW-UP(OP) 300 Series & Components

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-11
SLIDE 11

3) Inside form of HW-UP(OP) 300 series

Address: A-301, Hagye Technotown, 10, Nowon-ro 15-gil, Nowon-gu, Seoul, Korea Tel: 82-2-948-0657 Fax:82-2-948-2342 Homepage: http://www.waco.co.kr

slide-12
SLIDE 12
