A virtualized approach to Mass Storage System Dorin Lobontu, Jos van Wezel and Martin Beitzinger STEINBUCH CENTRE FOR COMPUTING KIT University of the State of Baden-Wuerttemberg and www.kit.edu National Research Center of the Helmholtz

SLIDE 1

KIT – University of the State of Baden-Wuerttemberg and National Research Center of the Helmholtz Association

STEINBUCH CENTRE FOR COMPUTING

www.kit.edu

A virtualized approach to Mass Storage System

Dorin Lobontu, Jos van Wezel and Martin Beitzinger

SLIDE 2

Steinbuch Centre for Computing 2 Dorin Lobontu

Presentation Overview

01.06.2011

GridKa Storage Overview
TSM as Management System for MSS
Tape Library Virtualization with ERMM
Tape Reports

SLIDE 3

Steinbuch Centre for Computing 3 Dorin Lobontu

GridKa Storage Overview

01.06.2011

ptimized tape access

keep file copies for performance improvement write on tape by TSM

NameSpace Operations Access Controls Storage Management Pool Management LHC-Centers

temporary storage
analysis
monte-carlo-simulation

GridFTP

an extension of the standard

FTP for Grid applications

authentification over GSI

(Grid Security Infrastructure)

encryption by SSL
partial file transfer
automatic TCP optimization
parallel and striped transfers

GridFTP GridKa Storage System dCache

dCache is a storage management system:

manages a large amount of data
stores data on distributed media (disk, tape)
hierarchical storage management
has automatic load balancing

GridKa Storage System

75 fileservers in 3 dCache

installations

3 tape libraries - 10 PB tape

capacity

8 PB disk capacity

MSS

350 MegaByte per second

Read-Pools Write-Pools Stage-pools

1 GB/s 1 GB/s

SLIDE 4

Steinbuch Centre for Computing 4 Dorin Lobontu

MSS Requirements

01.06.2011

Components

Mass Storage System

Library manager dCache TSS+STA+DM dCache TSS+STA+DM dCache TSS+STA+DM xrootd TSS+STA+DM xrootd TSS+STA+DM LSDF Clients dCache Arch. Manager Xrootd Arch. Manager LSDF Arch. Manager

MSS has to have a scalable architecture
MSS has to uncouple tape resources and

applications

MSS has to share the same resources for different

applications

MSS has to provide security mechanisms to

prevent/grant applications access to its resources

SLIDE 5

Steinbuch Centre for Computing 5 Dorin Lobontu

Presentation Overview

01.06.2011

GridKa Storage Overview
TSM as Management System for MSS
Tape Library Virtualization with ERMM
Tape Reports

SLIDE 6

Steinbuch Centre for Computing 6 Dorin Lobontu

TSM as Library Manager

01.06.2011

TSM Server & Library Manager

IBM TS3500 Grau ITL-XL STK SL-8500

dCachePool dCachePool dCachePool dCachePool tss tss tss tss StorageAgent StorageAgent StorageAgent StorageAgent

on the TSM server one path for every agent and every tape drive must be defined

(65 agents x 26 drives = 1690 paths)

these paths must be manually maintained

SLIDE 7

Steinbuch Centre for Computing 7 Dorin Lobontu

Distributing Data over all Libraries

01.06.2011

TSS TSM

Grau ITL-XL IBM TS3500 STK SL-8500

MGMTC1 STGPOOL1 MGMTC2 STGPOOL2 MGMTCN STGPOOLN StorageClass1 <-> TSM MGMTC1 StorageClass2 <-> TSM MGMTC2 StorageClassN <-> TSM MGMTCN StorageClass1 StorageClass2 StorageClassN StorageClassX

dCache

data is statically distributed by TSS (Tape Staging Server) over the

libraries

drives load-balancing is not possible
a library crash interrupts the processes assigned to this library

DevC-Grau DevC-IBM DevC-STK

SLIDE 8

Steinbuch Centre for Computing 8 Dorin Lobontu

Presentation Overview

01.06.2011

GridKa Storage Overview TSM as Management System for MSS

Tape Libraries Virtualization with ERMM

Tape Reports

SLIDE 9

Steinbuch Centre for Computing 9 Dorin Lobontu

ERMM as Library Manager

01.06.2011

IBM TS3500 Grau ITL-XL STK SL-8500

ERMM TSM

ERMM-Client dCache-Pool tss StorageAgent ERMM-Client ERMM-Client ERMM-Client dCache-Pool dCache-Pool dCache-Pool tss tss tss StorageAgent StorageAgent StorageAgent

ERMM :
takes over the entire management of the libraries
coordinates the access to drives and tapes
logs all activities in an own DB2 database
provides a single point of control of tape resources

SLIDE 10

Steinbuch Centre for Computing 10 Dorin Lobontu

Distributing Data over all Libraries

01.06.2011

dCache TSS TSM ERMM

StorageClass1 StorageClass2 StorageClassX StorageClassN StorageClass1 <-> TSM MGMTC1 StorageClass2 <-> TSM MGMTC2 StorageClassN <-> TSM MGMTCN MGMTC1 STGPOOL1 MGMTC2 STGPOOL2 MGMTCN STGPOOLN

DevC-LTO STK GRAU IBM drives group tapes group

TSM has only one external library
TSM defines only one path for every storage agent to the external

library

ERMM maintains dynamically all path from the storage agents to all

drives

ERMM spreads the data over all phisycal libraries
ERMM makes dynamic drives load balancing

SLIDE 11

Steinbuch Centre for Computing 11 Dorin Lobontu

Presentation Overview

01.06.2011

GridKa Storage Overview TSM as Management System for MSS Tape Libraries Virtualization with ERMM

Tape Reports

SLIDE 12

Steinbuch Centre for Computing 12 Dorin Lobontu

Collecting Statistics Data

01.06.2011

Sense data request ERMM event Sense data

ERMM

pipe collector

TSM dCache

archive DB
one external library
no drive
no scrtach
library manager
all drives
all cartridges
temporary DCA

Mass Storage System MySql DB

drive information
library information
cartridge information
drive cartridge access record for every
peration

SLIDE 13

Steinbuch Centre for Computing 13 Dorin Lobontu

Generate Tape Reports

01.06.2011

Statistics generator (perl program) Statistics:

throuput reports per drive, cartridge, library

and time unit

number of mounts per drive, cartridge,

library and time unit

number of concurrent drives in use per

library and time unit

error reports per drive, cartridge, library and

time unit

plot generator graphics Complete history af Drive Cartridge Access

amount of data written/read per mount
mout and unmount time
number of soft/hard error per mount

MySql DB Web

SLIDE 14

Steinbuch Centre for Computing 14

Activity Reports

Dorin Lobontu 01.06.2011

DriveActivity LibraryActivity VolumeInfo Home

SLIDE 15

Steinbuch Centre for Computing 15

Activity Reports

Dorin Lobontu 01.06.2011

DriveActivity LibraryActivity VolumeInfo Home

SLIDE 16

Steinbuch Centre for Computing 16

Activity Reports

Dorin Lobontu 01.06.2011

DriveActivity LibraryActivity VolumeInfo Home

SLIDE 17

Steinbuch Centre for Computing 17

Error Reports - per Library per month

Dorin Lobontu 01.06.2011

iwr_grau1_lto3(16 drives) iwr_grau1_lto4(8 drives)

SLIDE 18

Steinbuch Centre for Computing 18

Tape Errors

Since November 2009 about 100 cartrigdes removed due to increasing correctable errors (~25 LTO3 from a total of ~5000 ~75LTO4 from a total of ~5000) 4 drives(from ~64) replaced due to bad performance and increasing error rate Lost 4 cartrigdes with internal label destroyed TSM: ANR8355E Error reading label for volume …

Dorin Lobontu 01.06.2011

SLIDE 19

Steinbuch Centre for Computing 19 Dorin Lobontu 01.06.2011
