slide-1
SLIDE 1

Webinar 3 of 3, September 10, 2020

A New Way Forward

slide-2
SLIDE 2

Your questions please?

(if you don’t see the control panel, click on the orange arrow icon to expand it) Please enter your questions in the text box of the webinar control panel (remember to press send)

Remember: The completion of a Nautel webinar qualifies for ½ SBE re-certification credit, identified under Category I of the Re-certification Schedule for SBE Certifications.

slide-3
SLIDE 3

Host Jeff Welton Sales Manager, Central USA Nautel Panelist Philipp Schmid Chief Technology Officer Nautel Panelist Rick Greenhut Independent Media Consultant Panelist Marty Sacks Executive VP Sales, Support, & Marketing Telos Alliance Panelist Alex Hartman Customer Service Technologist Nautel

Webinar production by Ed Sylvester

slide-4
SLIDE 4

Today’s topics

  • Nautel and Telos Alliance Collaboration
  • Virtualization and the cloud
  • The HD Radio opportunity
  • Review HD RadioTM Drift Elimination Solution
  • Solution ingredients:
  • Telos Alliance Omnia Enterprise 9s
  • Software HD Radio Server
  • Made for Radio: E2X and MPX
  • Demo 1: FM+HD Time Locked in the cloud
  • Cloud Hosted Air-Chain: flexible, easy deployment
  • Architecture options and resiliency considerations
  • Demo 2: Cloud Hosted Air-Chain
  • Panel Discussion/Questions
slide-5
SLIDE 5

So why this current collaboration and why now?

  • Nautel and Telos Alliance: Passion & innovation
  • Change:
  • Industry & technology
  • Challenges:
  • Listeners, locations, competition, complexity
  • Fresh approaches
  • Apply new technologies, reduce complexity, drive out costs

Digital Signal Processing AoIP

slide-6
SLIDE 6

Dig igit ital Radio matters more now

  • 65 Million HD Radio cars
  • Opportunities:
  • Podcasts/Streams On-Air
  • Ethnic broadcasting
  • Leased channels
  • Sports coverage
  • Over 2300 HD Radio stations
  • but 13,000 Analog only
  • Challenging for many:
  • Too complex? Too expensive? ROI?

Cheaper, Easier, More Flexible Air-Chain Solutions

slide-7
SLIDE 7

About 23% (almost one in four) of all cars on the road in America have an HD Radio receiver.

The Di Digital Di Differenc nce

slide-8
SLIDE 8

Consumers have gotten used to all their in-cabin entertainment sources offering images and metadata . . .

The Di Digital Di Differenc nce

slide-9
SLIDE 9

. . . except for analog radio.

The Di Digital Di Differenc nce

slide-10
SLIDE 10

This is your station in analog . . .

The Di Digital Di Differenc nce

slide-11
SLIDE 11

This is your station in digital . . .

The Di Digital Di Differenc nce

slide-12
SLIDE 12

. . . and this is your station in digital . . .

The Di Digital Di Differenc nce

slide-13
SLIDE 13

. . . and this is your station in digital . . .

The Di Digital Di Differenc nce

slide-14
SLIDE 14

. . . these are your digital presets . . .

The Di Digital Di Differenc nce

slide-15
SLIDE 15

. . . and this is your satellite competition.

The Di Digital Di Differenc nce

slide-16
SLIDE 16

Radio now shares the dash with a myriad of competitors

The Di Digital Di Differenc nce

slide-17
SLIDE 17

Radio now shares the dash with a myriad of competitors

The Di Digital Di Differenc nce

slide-18
SLIDE 18

Radio now shares the dash with a myriad of competitors

The Di Digital Di Differenc nce

slide-19
SLIDE 19

The moral of this story?

With all the media choices now available to the consumer, radio digital metadata & images can help level the playing field.

The Di Digital Di Differenc nce

slide-20
SLIDE 20

The moral of this story?

The message is very simple . . .

The Di Digital Di Differenc nce

slide-21
SLIDE 21

Don’t be the “Blank Screen”!

The Di Digital Di Differenc nce

slide-22
SLIDE 22

Stereo broadcasting quickly became the “table stakes” that all FM music broadcasters needed to remain fully competitive by the end of the century. Digital broadcasting has become the 21st century equivalent of FM stereo. There was the expectation that higher quality audio would keep existing listeners for longer periods of time. That increased TSL came to pass. In equivalent dollars, HD Radio technology now costs less to implement today than converting an FM station from mono to stereo did back in 1965.

HD RADIO DIGITAL BROADCASTING UPGRADE COSTS IN PERSPECTIVE

The Di Digital Di Differenc nce

slide-23
SLIDE 23

Why virtualization?

slide-24
SLIDE 24

Why clo loud? V Vir irtualization vs Physical Equipment

  • Alignment with the IT industry (IP Based)
  • The source of many of our standards (incl security)
  • The source of much of our hardware
  • Customizable and Flexible
  • Workflows vary widely and can change (hybrid options)
  • Spin up and down instances as needed
  • Example: Telos Alliance Omnia Enterprise 9s
  • More future friendly as standards and operating systems change
  • Reliability/Availability/Maintainability
  • Reduce traditional dedicated broadcast hardware
  • (ie one box per purpose) for greater redundancy
  • Less wiring / fewer site visits / remote management
slide-25
SLIDE 25

Omnia Enterprise 9s

Omnia Enterprise 9s FM / HD Processor

  • Built from the Omnia 9
  • Highest quality audio
  • Common feature “DNA”
  • Undo
  • Advanced Signal analytics
  • Flexible Monitoring
  • Embedded pilot & RDS
slide-26
SLIDE 26

Why clo loud? V Vir irtualization vs Physical Equipment

  • Alignment with the IT industry (IP Based)
  • The source of many of our standards (incl security)
  • The source of much of our hardware
  • Customizable and Flexible
  • Workflows vary widely and can change (hybrid options)
  • Spin up and down instances as needed
  • Example: Telos Alliance Omnia Enterprise 9s
  • More future friendly as standards and operating systems change
  • Reliability/Availability/Maintainability
  • Reduce traditional dedicated broadcast hardware
  • (ie one box per purpose) for greater redundancy
  • Less wiring / fewer site visits / remote management
slide-27
SLIDE 27

HD Radio Diversity Delay Solved with Soft ftware HD Serv rver

Review from Last Webinar

slide-28
SLIDE 28

GV

content creation content contribution content creation content contribution content creation content contribution FM processor exgine HD modulator FM STL receiver RDS encoder FM STL transmitter playout automation emergency alert content creation content contribution synchronizer HD1 exporter HD2-4 importer FM exciter ratings watermark FM delay HD STL transmitter HD STL receiver HD1 processor

GPS GPS

HD

PSD

HD2-4 processor

FM and HD audio must be within 3 audio samples

FM

HD Radio FM/HD Div iversity Dela lay Challenges

Initially Importer and Exporter at studio to minimize HD STL bandwidth

slide-29
SLIDE 29

Best blend within 68μs

  • r 3 audio samples

(NRSC-5 specification) 12 to 50 samples (272μs to 1.1ms) notches significant audio content (comb filter effect) Better blend with selective notches 300 samples / 6.8 ms

Audio Fil iltering Effects during Ble lending

slide-30
SLIDE 30

Typical Div iversity Dela lay Dri rift Measurements*

Without 10 MHz GPS Synchronization 200 samples / 4.5 ms swing With 10 MHz Exciter Synchronization 15 samples / 340 μs swing

±3 samples

*NRSC-G203 NRSC IBOC Time and Level Alignment Guideline

±3 samples

slide-31
SLIDE 31

GV

content creation content contribution content creation content contribution content creation content contribution FM+HD processor exgine HD modulator multi channel STL RDS encoder multi channel STL playout automation emergency alert content creation content contribution synchronizer HD1 exporter HD2-4 importer FM exciter ratings watermark FM delay HD2-4 processor

GPS

Approaches for Optimizing FM/HD Ble lend Experience

All HD equipment AND audio processor is suggested to be at the transmitter site* STL must now carry all HD1-HD4 audio streams, high bandwidth Single FM+HD audio processor for best alignment and blend

*NRSC-G203 NRSC IBOC Time and Level Alignment Guideline

slide-32
SLIDE 32

Synchronous System fr from SPLIT IT to JOIN

main audio feed

TCP/IP exgine FM modulator

buffer

+

44.1 kHz HD1 L/R E2X MPX 176.4 kHz MPX

E2X MPX E2X MPX

time keeper

Software HD Radio Server Nautel Exciter SPLIT JOIN

slide-33
SLIDE 33

Last Webinar Demonstration

Livewire Livewire Livewire icecast Proc Core

VS 300 n n VSHD VS 300 n

VS300 + VSHD

firewall Sofia RX Justin 808 Proc Core Proc Core Proc Core HD1 HD2 HD3 HD4 FM MPX Station Logo Gen4 Importer Software HD Radio Server RDS Saint Cloud, Minnesota Alex Hartman’s Garage Nautel HQ Public Internet TCP/IP: E2X + Linear MPX Nautel VS300

Long distance IP delivery over public Internet Stable delay without GPS synchronization 1470 miles (39 ms ping)

80 W

slide-34
SLIDE 34

Our Demonstration Today

  • St. Cloud Mn
  • St. Cloud Mn

RadioJar web stream Proc Core

VS 300 n n VSHD VS 300 n

VS300 + VSHD

firewall Sofia RX Justin 808 Proc Core Proc Core Proc Core HD1 HD2 HD3 HD4 FM MPX Station Logo Gen4 Importer

Cloudporter

FLAC FLAC icecast 128 kbps MP3 RDS Amazon Web Services Ohio East Zone 2A Nautel HQ TCP/IP: E2X + MPX Nautel VS300 80 W

slide-35
SLIDE 35

Demonstration: What you’ll see

Omnia Enterprise 9s Remote UI GEN4 Importer Web UI Nautel Web UI Inovonics Sofia Streaming Receiver Inovonics Justin 808

slide-36
SLIDE 36

Demonstration: What you’ll see

slide-37
SLIDE 37

Our Demonstration Today

  • St. Cloud Mn
  • St. Cloud Mn

RadioJar web stream Proc Core

VS 300 n n VSHD VS 300 n

VS300 + VSHD

firewall Sofia RX Justin 808 Proc Core Proc Core Proc Core HD1 HD2 HD3 HD4 FM MPX Station Logo Gen4 Importer

Cloudporter

FLAC FLAC icecast 128 kbps MP3 RDS Amazon Web Services Ohio East Zone 2A Nautel HQ TCP/IP: E2X + MPX Nautel VS300 80 W

slide-38
SLIDE 38

Cloud Hosted Air-Chain

slide-39
SLIDE 39

Vir irtualization in in the Clo loud

  • Global presence
  • Replicate Virtual Machine globally in seconds, online in a few minutes
  • Built-in redundancy within Availability Zones
  • Transparent failover
  • Modern IT Infrastructure
  • High Availability and Load Balancers
  • Evaluated on Amazon Web Services
  • Founded in 2006
  • 35% market share
  • Largest datacenter deployment

worldwide

slide-40
SLIDE 40

Clo loud Scala lability: : We clo loned 4 Clo loudporters

n VSHD VS 300 n

VS300 + VSHD

80 W firewall Nautel HQ AWS Load Balancer Cloudporter 1 Cloudporter 2 Cloudporter 3 Cloudporter 4

AWS South America São Paulo, Brazil AWS US West Oregon AWS US East Ohio 2A AWS US East Ohio 2B

slide-41
SLIDE 41

AWS Load Bala lancers: : Redundancy in in the Clo loud

n VSHD VS 300 n

VS300 + VSHD

80 W firewall Nautel HQ AWS Load Balancer Cloudporter 1 Cloudporter 2 Cloudporter 3 Cloudporter 4

AWS South America São Paulo, Brazil AWS US West Oregon AWS US East Ohio 2A AWS US East Ohio 2B

39 ms ping

slide-42
SLIDE 42 n VSHD VS 300 n

VS300 + VSHD

80 W firewall Nautel HQ AWS Load Balancer Cloudporter 1 Cloudporter 2 Cloudporter 3 Cloudporter 4

AWS South America São Paulo, Brazil AWS US West Oregon AWS US East Ohio 2A AWS US East Ohio 2B

X

AWS Load Bala lancers: : Health Check

39 ms ping

slide-43
SLIDE 43

Nation Wid ide Fall llback

n VSHD VS 300 n

VS300 + VSHD

80 W firewall Nautel HQ AWS Load Balancer Cloudporter 1 Cloudporter 2 Cloudporter 3 Cloudporter 4

AWS South America São Paulo, Brazil AWS US West Oregon AWS US East Ohio 2A AWS US East Ohio 2B

X X X

103 ms ping

slide-44
SLIDE 44

Stress Test: : 132 ms ms pin ing to Brazil

n VSHD VS 300 n

VS300 + VSHD

80 W firewall Nautel HQ AWS Load Balancer Cloudporter 1 Cloudporter 2 Cloudporter 3 Cloudporter 4

AWS South America São Paulo, Brazil AWS US West Oregon AWS US East Ohio 2A AWS US East Ohio 2B

X X X X

132 ms ping

slide-45
SLIDE 45

HD HD Mult ltiCast+ as Physical Backup

n VSHD VS 300 n

VS300 + VSHD

80 W firewall Nautel HQ AWS Load Balancer HD MultiCast+ Cloudporter 1 Cloudporter 2 Cloudporter 3 Cloudporter 4

AWS South America São Paulo, Brazil AWS US West Oregon AWS US East Ohio 2A AWS US East Ohio 2B

X X X X X

Last Mile

slide-46
SLIDE 46

Demonstration: What you’ll see

Nautel Web UI Inovonics Sofia Streaming Receiver Inovonics Justin 808 AWS Control Panel

slide-47
SLIDE 47
slide-48
SLIDE 48

But what about …

  • Transmitter fleet scalability?

demonstrated today

  • Cloud availability / redundancy?

demonstrated today

  • TX IP link reliability?

Dual homed routers and ISPs TX site fallback on HD MultiCast+ On-going development

  • IT security?

Cloud VPNs Looking at private/public key authentication and/or SSL/TSL

  • Workflow flexibility?

Demonstrated cloud playout with webstreams and RadioJar

More to come from Nautel and Telos Alliance…

slide-49
SLIDE 49

Im Implementation topologies

  • Traditional site located Importer, Exporter.
  • Existing 4th generation equipment with reactive receiver, GPS required
  • Location agnostic importer/exporter anywhere (studio, …)
  • Software implemented Importer Exporter Audio Processing
  • Resilient backup with HD MultiCast+
  • 1: Cloud connectivity as main with HD MultiCast+ backup
  • 2: HD MultiCast+ as main with cloud support
  • Importer/exporter/processing in virtual environments
  • 1: Hosted in on-premise data center
  • 2: Hosted with cloud service provider

New New New

Today

slide-50
SLIDE 50

GV

content creation content creation content contribution content creation content contribution FM+HD1 processor IP STL IP STL playout automation emergency alert content creation content contribution

combined imp/exporter

FM+HD exciter ratings watermark

Can we Centralize the Entire Radio Air ir-Chain? Yes

Our demo showed many air chains across the globe to a single transmitter In reality: many (centralized) air chains to many transmitters

Centralized Studio (cloud and/or on-premise)

Backup HDMC FM+HD

dual homed router

slide-51
SLIDE 51

Summary ry

  • Cloud opportunity:
  • Availability / Resiliency
  • Flexibility
  • Manageability
  • Easier deployments
  • Flexible workflows
  • FM+HD Time locked
  • Potential for location flexibility
  • Studio, transmitter, local or cloud datacenter
  • Concept demo stage showing technology direction
  • Future: betas, product, availability, standards initiatives
slide-52
SLIDE 52

Panel Discussion/Questions

slide-53
SLIDE 53

Summary ry

  • Cloud opportunity:
  • Availability / Resiliency
  • Flexibility
  • Manageability
  • Easier deployments
  • Flexible workflows
  • FM+HD Time locked
  • Potential for location flexibility
  • Studio, transmitter, local or cloud datacenter
  • Concept demo stage showing technology direction
  • Future: betas, product, availability, standards initiatives
slide-54
SLIDE 54

Thank you

slide-55
SLIDE 55

Im Implementation topologies

  • Today:

Traditional site located Importer, Exporter.

Existing 4th generation equipment with reactive receiver, GPS required

  • New:

Location agnostic importer/exporter anywhere (studio, …)

Software implemented Importer Exporter Audio Processing

  • New:

Resilient backup with HD MultiCast+ 1: Cloud connectivity as main with HD MultiCast+ backup 2: HD MultiCast+ as main with cloud support

  • New:

Importer/exporter in virtual environment

1: Hosted in on-premise data center 2: Hosted with cloud service provider

slide-56
SLIDE 56
