A Holistic Approach to Site Assessment of Former Landfill and Sustainable Remediation

Jane Oakeshott Montreal SusRem 2016

1

The world’s leading sustainability consultancy

Contents

2

• Proposed Development
• Sustainability Context
• Site History, SI & GQRA
• Development Options
• DQRA
• Sustainable Remediation Assessment : MCA
• Environment, Social & Economic
• Carbon Footprint
• Conclusions
• Acknowledgements: Don Reid & Alan Thomas

The world’s leading sustainability consultancy

Introduction (1)

3

• Proposed Development
• Intermodal rail freight

exchange

• Large distribution centre

next to key rail and road radials / national arterial routes

• Few suitable sites -

requires sufficient land- take, high level connection & access arrangements, and proximity to the intended market

• Ground conditions

secondary consideration

• Main constraint: fixed

development level

The world’s leading sustainability consultancy

Introduction (2)

4

• Background / Setting for the Assessment of Sustainable

Remediation for this site

• Project &

Sustainability Objectives

• Constraints
• Stakeholders
• Boundaries
• Scope & assessment

criteria

The world’s leading sustainability consultancy

Sustainable Remediation Framework

ability to influence sustainability

PLANNING (brownfield) REMEDIATION CONSTRUCTION PROJECT DEFINITION REMEDIAL OPTIONS APPRAISAL SITE INVESTIGATION REMEDIATION OPTIMISATION CLIENT OBJECTIVE CLIENT GOAL Community & stakeholder engagement Sustainable Procurement

Setting the remediation specification and strategy Setting the remediation technical approach

RISK ASSESSMENT

• Based on SuRF-UK Framework for Sustainable Remediation 2010
• Risk Based Land Management principles are at the heart of Sustainable

Remediation.

• Helps address two fundamental questions:

i) Is Remediation Really Necessary? ii) How Much Remediation Is Necessary?

5

The world’s leading sustainability consultancy

Sustainable Management Practices: Site Investigation

6

• Former Landfills &

Regulatory Context

• Site Investigation &

GQRA

• Initial Engagement

Regulators

• Findings:
• Extent & nature landfill

deposits

• Generic QRA:
• Human Health
• Controlled Waters
• Gas

The world’s leading sustainability consultancy

Development Option (1)

7

• Initial Proposal
• Cut-and-Fill under voluntary scheme, CL:AIRE Waste

Code of Practice (CoP) adopted in England & Wales

• Details CoP

(Certainty, Quantity, Suitability, Protection Human Health & Environment)

• Liaison regulators
• Initial stance
• CoP not appropriate,
• Permitting regime inflexible - removal landfill
• First Option: excavate & replace all waste material…..
• Further liaison – CoP might be applicable if supported by

DQRA

The world’s leading sustainability consultancy

SMP: Detailed Quantitative Risk Assessment

8

• Brief Details:
• Conceptual Model:

S-P-R

• Definition source

term

• Finding / agreeing

compliance point / receptor with regulator…

• Results
• Critical to eventual

agreement with regulator….

The world’s leading sustainability consultancy

Development Options (2 & 3)

9

• RA: Sign off contaminated land/brownfield officers,

resistance still from permitting officers regarding CoP

• Second Option:

Cut material not suitable for re-use without treatment /containment - not practicable - replace

• But then…… Update of Permitting Regime
• New Recovery Permit

(benefit, suitable, minimum quantity, substitute non-waste, appropriate standards: RA & engineering)

• Application to both onsite material redistribution and

import

• Third Option:

Cut-and-Fill & Import Selected Former Waste Material

The world’s leading sustainability consultancy

Development Options: Summary

10 1st Option: Excavation & replace all landfill material, latter to include import to make up site levels 2nd Option: Replace all cut landfill material & replace, latter to include import to make up site levels 3rd Option: Cut-and-fill with screening for re-use, import of recovered waste to make up site levels

The world’s leading sustainability consultancy

Sustainable Remediation Assessment: MCA

11

• ERM developed multi-criteria/

attribute analysis based on CL:AIRE SuRF-UK indicators for 3 categories:

• Environment
• Social
• Economic
• First step: relative weighting of

the above categories and their sub-categories

• Second step: assessment of the

remediation development

• ptions to determine relative

ranking

The world’s leading sustainability consultancy

MCA: Environment

12

• Carbon footprinting undertaken to support assessment of impact on air

emissions

Environment Sustainability Criteria Relative Weighting Relative Assessment Option 1 Option 2 Option3 Impact on water 3 2 1 1 Impact on soil 2 1 Impact on air emissions - climate change 3

• 1

Impact on air emissions - local 4

• 4
• 3
• 1

Impact on ecology 1 Natural resource use and waste generation 5

• 5
• 3

2 Net Environmental Benefit

• 36
• 15

9

The world’s leading sustainability consultancy

Carbon Footprint System Boundaries

13

Import Fill Material Landfill Excavation & Placement of Material

• n-site

Transport Transport Off-site Landfill Fuels Excavated waste Imported material Materials & energy used

The world’s leading sustainability consultancy

Carbon Footprint

14

0 ¡ 10,000 ¡ 20,000 ¡ 30,000 ¡ 40,000 ¡ 50,000 ¡ 60,000 ¡ Op,on ¡1 ¡ Op,on ¡2 ¡ Op,on ¡3 ¡ t ¡CO2-­‑eq ¡ Excava,on ¡works ¡ Imported ¡Material ¡Transport ¡ Material ¡to ¡Landfill ¡Transport ¡

The world’s leading sustainability consultancy

MCA: Social

15

• Stakeholders – local community important but regulator most influential

Social Sustainability Criteria Relative Weighting Relative Assessment Option 1 Option 2 Option3 Human health - chronic & acute risks 3

• 2
• 1

Ethics and equality 1 Neighbourhood & locality 4

• 5
• 2
• 1

Communities and community involvement 2 1 1 1 Uncertainty & evidence 4

• 4
• 2

2 Net Social Benefit

• 40
• 17

6

The world’s leading sustainability consultancy

MCA: Economic

16

Economic Sustainability Criteria Relative Weighting Relative Assessment Option 1 Option 2 Option3 Direct economic costs & benefits 5

• 5
• 2

2 Indirect economic costs & benefits 3

• 3
• 1

1 Employment opportunities & human capital 2 1 1 1 Induced economic costs and benefits 1 1 1 1 Project lifespan & flexibility 3 3 2 1 Net Economic Benefit

• 22
• 4

19

The world’s leading sustainability consultancy

MCA: Summary

17

• Environment, Social & Economic Net Benefit
• Sustainability Net Benefit
• ­‑50 ¡
• ­‑40 ¡
• ­‑30 ¡
• ­‑20 ¡
• ­‑10 ¡

0 ¡ 10 ¡ 20 ¡ 30 ¡ Op,on ¡1 ¡ Op,on ¡2 ¡ ¡ Op,on ¡3 ¡

Net ¡environmental ¡benefit ¡ Net ¡social ¡benefit ¡ Net ¡economic ¡benefit ¡

• ­‑120 ¡
• ­‑100 ¡
• ­‑80 ¡
• ­‑60 ¡
• ­‑40 ¡
• ­‑20 ¡

0 ¡ 20 ¡ 40 ¡ 60 ¡ Op,on ¡1 ¡ Op,on ¡2 ¡ ¡ Op,on ¡3 ¡

Overall ¡net-­‑benefit ¡(Sustainability) ¡

The world’s leading sustainability consultancy

MCA: sensitivity

18

• Option 3 - economic criteria >50% of overall evaluation,
• Removal of economic criteria (not prime concern of regulator):

significant reduction of ‘score’ and differential with option 2

• Relative net-benefit

(minus economic criteria)

• Relative net-benefit

Economic ¡ ¡ criteria ¡ ¡22% ¡ Economic ¡ ¡ criteria ¡ ¡11% ¡ Economic ¡ ¡ criteria ¡ ¡56% ¡

• ­‑120 ¡
• ­‑100 ¡
• ­‑80 ¡
• ­‑60 ¡
• ­‑40 ¡
• ­‑20 ¡

0 ¡ 20 ¡ 40 ¡ 60 ¡ Op,on ¡1 ¡ Op,on ¡2 ¡ ¡ Op,on ¡3 ¡

Overall ¡social ¡& ¡environmental-­‑benefit ¡(Sustainability) ¡

• ­‑120 ¡
• ­‑100 ¡
• ­‑80 ¡
• ­‑60 ¡
• ­‑40 ¡
• ­‑20 ¡

0 ¡ 20 ¡ 40 ¡ 60 ¡ Op,on ¡1 ¡ Op,on ¡2 ¡ ¡ Op,on ¡3 ¡

Overall ¡net-­‑benefit ¡(Sustainability) ¡

The world’s leading sustainability consultancy

Conclusions

19

• Regulatory context & continued engagement with regulators

critical

• Risk Assessment underpinned eventual option and

regulatory acceptance

• Sustainability case strengthened by metrics – sustainability

assessment multi-criteria analysis & carbon footprinting
