A GMR-based Magnetic Flow Cytometer Using Matched Filtering Chih-Cheng Huang, Xiahan Zhou, Da Ying, and Drew A. Hall University of California, San Diego Optical Flow Cytometer Quantitative cellular analysis in hematology Identifying

slide-1
SLIDE 1

A GMR-based Magnetic Flow Cytometer Using Matched Filtering

Chih-Cheng Huang, Xiahan Zhou, Da Ying, and Drew A. Hall University of California, San Diego

slide-2
SLIDE 2

2

Optical Flow Cytometer

  • Quantitative cellular analysis in hematology
  • Identifying prognostic indicators:
  • Cancer, HIV, and other time-dependent biomarkers
  • Gold standard for multi-parametric analysis
  • Sophisticated instrumentation

Challenge: Hard to translate to a PoC setting!

slide-3
SLIDE 3

3

Magnetic Flow Cytometer

Signal [mΩ] Blood Sample MNPs

MNP-coated cells evoke change of sensor resistance

Hz

slide-4
SLIDE 4

Optical FCM

  • Complex optics, lasers, and

photodetectors

  • Extensive sample preparation
  • Long turnaround times and
  • ut of reach for routine

monitoring

Magnetic FCM

  • Biological samples have no

magnetic background

  • Sample preparation can

largely be eliminated

  • Can be miniaturized, which

also improves their sensitivity

Optical- vs. Magnetic-FCM

4

slide-5
SLIDE 5

Multi-stripe Layout

5

Single-strip

Unique signature improves matched filtering

slide-6
SLIDE 6
  • Commonly used inside hard disk drives
  • Key enabler for higher areal density (larger HDD)
  • Nobel prize in 2007 awarded to Fert and Grünberg

Magnetoresistive Sensors

6

R.S. Gaster, D.A. Hall, S.X. Wang nanoLetters 2011 (cover art)

slide-7
SLIDE 7

Parallel State

GMR Spin-Valves (GMR SV)

7

Bias Point (90˚) 𝑁𝑆 = 𝑆𝐵𝑄 − 𝑆𝑄 𝑆𝑄 Parallel (0˚) Antiparallel (180˚)

D.A. Hall, R.S. Gaster, et al. - Biosensors and Bioelectronics 2010

Hext

Antiparallel State

slide-8
SLIDE 8

System Architecture

8

Inlet Outlet

120µm

slide-9
SLIDE 9

Micromagnetic Simulations

9

5,000× Adembeads

Simulations closely match with our measurement results!

Random distribution of MNPs on a cell

slide-10
SLIDE 10

Hydrodynamic Analysis

10

10

  • 8

10

  • 7

10

  • 6

10

  • 5

10

  • 22

10

  • 20

10

  • 18

10

  • 16

10

  • 14

10

  • 12

10

  • 10

10

  • 8

10

  • 8

10

  • 7

10

  • 6

10

  • 5

Magnetic force DLVO force Gravity Hydrodynamic force Langevin force Magnetic force

Particle diameter (m) Forces (N)

10

  • 22

10

  • 20

10

  • 18

10

  • 16

10

  • 14

10

  • 12

10

  • 10

10

  • 8

M450 M280 MyOne Adem Nanomag SHS30 MACS

slide-11
SLIDE 11

Micromagnetic Simulation of MNPs

11

Y: signal ratio (R/Redge-peak) (Height/Diameter)

slide-12
SLIDE 12

ToF Measurement Results

12

Detection of individual magnetic bead (M-450)

slide-13
SLIDE 13

Matched Filtering

13

Improve detection of signal events and reject false alarms Minimum detectable SNR:14 dB  4.5 dB

slide-14
SLIDE 14

Flow Rate Optimization

14

10 20 30 40 50 10 20 30 40

Detected Events Pumping rate (L/min)

10 20 30 40 50 20 40 60 80 100 120

Maximum Signal (m) Pumping rate (L/min)

Tradeoff between signal and flow rate for a given Hz

slide-15
SLIDE 15

Complex Detection

15 MNPs MNPs Biotin-coated Polymer Beads

slide-16
SLIDE 16

Measurement of Real Cells

16

Detection of pancreatic cancer cells

20μm

slide-17
SLIDE 17
  • Multi-stripe layout: enables distinct magnetic

signature used for matched filtering

  • Matched filter: reduces minimum detectable SNR

from 14 dB to 4.5 dB, and improves detection efficiency

  • ToF measurements: offers multi-parametric

analysis of flowing analytes

  • GMR-based FCMs: increases portability and rapid

“sample-to-answer” measurement capability

Conclusion

17

slide-18
SLIDE 18

Thanks!

18
